Hyundai Creta (2016 year). Instruction

Maintenance

4.Remove the socket from the

Rear fog lamp (if equipped)

High mounted stop light

assembly by turning the socket

counterclockwise until the tabs on

the socket align with the slots on

the assembly.

5.Remove the bulb from the socket

by pressing it in and rotating it

counterclockwise until the tabs on

the bulb align with the slots in the

socket. Pull the bulb out of the

socket.

6.Insert a new bulb into the socket.

7.Install the socket into the assembly

OGC074031

by aligning the tabs on the socket

1.Remove the socket from the

If the light does not operate, we rec-

with the slots on the assembly and

assembly by turning the socket

ommend that the vehicle be checked

turning the socket clockwise.

counterclockwise until the tabs on

by an authorized HYUNDAI dealer.

the socket align with the slots on

the assembly.

2.Remove the bulb from the socket

by pressing it in and rotating it

counterclockwise until the tabs on

the bulb align with the slots in the

socket. Pull the bulb out of the

socket.

3.Insert a new bulb in the socket.

4.Reinstall the light assembly to the

body of the vehicle.

7-86

Maintenance

Interior light bulb replacement

1. Using a flat-blade screwdriver,

gently pry the lens from the interi-

■ Map lamp (if equipped)

■ Luggage room lamp

or lamp housing.

2. Remove the bulb by pulling it

straight out.

WARNING

Prior to working on the Interior

lamps, ensure that the “OFF” but-

ton is depressed to avoid burning

your fingers or receiving an elec-

tric shock.

■ Room lamp

OGS075047/OGS075049/OGS075048

3. Install a new bulb in the socket.

4. Align the lens tabs with the interior

lamp housing notches and snap

the lens into place.

NOTICE

Use care not to dirty or damage lens,

lens tab, and plastic housings.

7-88

APPEARANCE CARE

Exterior care

Finish maintenance

NOTICE

Exterior general caution

Washing

•

Do not use strong soap, chemical

To help protect your vehicle’s finish

It is very important to follow the label

detergents or hot water, and do not

directions when using any chemical

from rust and deterioration, wash it

wash the vehicle in direct sunlight

thoroughly and frequently at least

cleaner or polish. Read all warning

or when the body of the vehicle is

and caution statements that appear

once a month with lukewarm or cold

warm.

water.

on the label.

•

Be careful when washing the side

If you use your vehicle for off-road

windows of your vehicle.

driving, you should wash it after each

Especially, with high-pressure

off-road trip. Pay special attention to

water, water may leak through the

the removal of any accumulation of

windows and wet the interior.

salt, dirt, mud, and other foreign

materials. Make sure the drain holes

•

To prevent damage to the plastic

parts and lamps, do not clean with

in the lower edges of the doors and

rocker panels are kept clear and

chemical solvents or strong deter-

gents.

clean.

Insects, tar, tree sap, bird droppings,

WARNING

industrial pollution and similar

deposits can damage your vehicle’s

Wet brakes

finish if not removed immediately.

Even prompt washing with plain

After washing the vehicle, test the

water may not completely remove all

brakes while driving slowly to see if

these deposits. A mild soap, safe for

they have been affected by water. If

use on painted surfaces, may be

braking performance is impaired,

used.

dry the brakes by applying them

After washing, rinse the vehicle thor-

lightly while maintaining a slow for-

ward speed.

oughly with lukewarm or cold water.

Do not allow soap to dry on the finish.

7-89

Maintenance

Waxing

Finish damage repair

Wax the vehicle when water will no

Deep scratches or stone chips in the

longer bead on the paint.

painted surface must be repaired

promptly. Exposed metal will quickly

Always wash and dry the vehicle

before waxing. Use a good quality

rust and may develop into a major

repair expense.

liquid or paste wax, and follow the

manufacturer’s instructions. Wax all

metal trim to protect it and to main-

Information

tain its luster.

If your vehicle is damaged and

Removing oil, tar, and similar materi-

requires any metal repair or replace-

als with a spot remover will usually

OLMB073082

ment, be sure the body shop applies

strip the wax from the finish. Be sure to

anti-corrosion materials to the parts

NOTICE

re-wax these areas even if the rest of

repaired or replaced.

the vehicle does not yet need waxing.

• Water washing in the engine com-

partment including high pressure

NOTICE

water washing may cause the fail-

ure of electrical circuits located in

• Wiping dust or dirt off the body with

the engine compartment.

a dry cloth will scratch the finish.

• Never allow water or other liquids to

• Do not use steel wool, abrasive

come in contact with electrical/elec-

cleaners, or strong detergents con-

tronic components inside the vehi-

taining highly alkaline or caustic

cle as this may damage them.

agents on chrome-plated or

anodized aluminum parts. This may

result in damage to the protective

coating and cause discoloration or

paint deterioration.

7-90

Bright-metal maintenance

Underbody maintenance

WARNING

•

To remove road tar and insects,

Corrosive materials used for ice and

use a tar remover, not a scraper or

snow removal and dust control may

After washing the vehicle, test the

other sharp object.

collect on the underbody. If these

brakes while driving slowly to see

•

To protect the surfaces of bright-

materials are not removed, acceler-

if they have been affected by

ated rusting can occur on the under-

metal parts from corrosion, apply a

water. If braking performance is

coating of wax or chrome preser-

body parts such as the fuel lines,

impaired, dry the brakes by apply-

frame, floor pan and exhaust system,

vative and rub to a high luster.

ing them lightly while maintaining

even though they have been treated

•

During winter weather or in coastal

a slow forward speed.

with rust protection.

areas, cover the bright metal parts

Thoroughly flush the vehicle under-

with a heavier coating of wax or

body and wheel openings with luke-

preservative. If necessary, coat the

warm or cold water once a month,

parts with non-corrosive gasoli-

after off-road driving and at the end

neeum jelly or other protective

of each winter. Pay special attention

compound.

to these areas because it is difficult

to see all the mud and dirt. It will do

more harm than good to wet down

the road grime without removing it.

The lower edges of the doors, rocker

panels, and frame members have

drain holes that should not clog with

dirt; trapped water in these areas can

cause rusting.

7-91

Maintenance

Aluminum wheel maintenance

Corrosion protection

High-corrosion areas

The aluminum wheels are coated

Protecting your vehicle from corro-

If you live in an area where your vehi-

with a clear protective finish.

sion

cle is regularly exposed to corrosive

materials, corrosion protection is

•

Do not use any abrasive cleaner,

By using the most advanced design

particularly important. Some of the

polishing compound, solvent, or

and construction practices to combat

common causes of accelerated cor-

wire brushes on aluminum wheels.

corrosion, we produce vehicles of

rosion are road salts, dust control

They may scratch or damage the

the highest quality. However, this is

chemicals, ocean air

and industrial

finish.

only part of the job. To achieve the

pollution.

long-term corrosion resistance your

•

Clean the wheel when it has

vehicle can deliver, the owner's

cooled.

cooperation and assistance is also

•

Use only a mild soap or neutral

required.

detergent, and rinse thoroughly

with water. Also, be sure to clean

the wheels after driving on salted

Common causes of corrosion

roads. This helps prevent corro-

The most common causes of corro-

sion.

sion on your vehicle are:

•

Avoid washing the wheels with

• Road salt, dirt and moisture that is

high-speed car wash brushes.

allowed to accumulate underneath

•

Do not use any alkaline or acid

the vehicle.

detergent. It may damage and cor-

• Removal of paint or protective

rode the aluminum wheels coated

coatings by stones, gravel, abra-

with a clear protective finish.

sion or minor scrapes and dents

which leave unprotected metal

exposed to corrosion.

7-92

Moisture breeds corrosion

To help prevent corrosion

• When cleaning underneath the

vehicle, give particular attention to

Moisture creates the conditions in

You can help prevent corrosion from

the components under the fenders

which corrosion is most likely to

getting started by observing the fol-

and other areas that are hidden

occur. For example, corrosion is

lowing:

from view. Do a thorough job; just

accelerated by high humidity, partic-

dampening the accumulated mud

ularly when temperatures are just

Keep your vehicle clean

rather than washing it away will

above freezing. In such conditions,

The best way to prevent corrosion is

accelerate corrosion rather than

the corrosive material is kept in con-

to keep your vehicle clean and free

prevent it. Water under high pres-

tact with the vehicle’s surface by

of corrosive materials. Attention to

sure and steam are particularly

moisture that slowly evaporates.

the underside of the vehicle is partic-

effective in removing accumulated

Mud is particularly corrosive

ularly important.

mud and corrosive materials.

because it dries slowly and holds

• When cleaning lower door panels,

moisture in contact with the vehicle.

rocker panels and frame members,

Although the mud appears to be dry,

• If you live in a high-corrosion area

be sure that drain holes are kept

it can still retain moisture and pro-

— where road salts are used, near

open so that moisture can escape

mote corrosion.

the ocean, areas with industrial

and not be trapped inside to accel-

High temperatures can also acceler-

pollution, acid rain, etc.—, you

erate corrosion.

ate corrosion of parts that are not

should take extra care to prevent

properly ventilated so the moisture

corrosion. In winter, hose off the

can be dispersed. For all these rea-

underside of your vehicle at least

sons, it is particularly important to

once a month and be sure to clean

keep your vehicle clean and free of

the underside thoroughly when

mud or accumulations of other mate-

winter is over.

rials. This applies not only to the vis-

ible surfaces but particularly to the

underside of the vehicle.

7-93

Maintenance

Keep your garage dry

Don't neglect the interior

Interior care

Don't park your vehicle in a damp,

Moisture can collect under the floor

Interior general precautions

poorly ventilated garage. This cre-

mats and carpeting and cause corro-

Prevent chemicals such as perfume,

ates a favorable environment for cor-

sion. Check under the mats periodi-

cosmetic oil, sun cream, hand clean-

rosion. This is particularly true if you

cally to be sure the carpeting is dry.

er, and air freshener from contacting

wash your vehicle in the garage or

Use particular care if you carry fertil-

the interior parts because they may

drive it into the garage when it is still

izers, cleaning materials or chemi-

cause damage or discoloration. If

wet or covered with snow, ice or

cals in the vehicle.

they do contact the interior parts,

mud. Even a heated garage can con-

These should be carried only in

wipe them off immediately. See the

tribute to corrosion unless it is well

proper containers and any spills or

instructions that follow for the proper

ventilated so moisture is dispersed.

leaks should be cleaned up, flushed

way to clean vinyl.

with clean

water

and

thoroughly

dried.

Keep paint and trim in good condi-

NOTICE

tion

Never allow water or other liquids to

Scratches or chips in the finish

come in contact with electrical/ elec-

should be covered with "touch-up"

tronic components inside the vehicle

paint as soon as possible to reduce

as this may damage them.

the possibility of corrosion. If bare

metal is showing through, the atten-

NOTICE

tion of a qualified body and paint

shop is recommended.

When cleaning leather products

Bird droppings : Bird droppings are

(steering wheel, seats etc.), use neu-

highly corrosive and may damage

tral detergents or low alcohol content

painted surfaces in just a few hours.

solutions. If you use high alcohol

Always remove bird droppings as

content solutions or acid/alkaline

soon as possible.

detergents, the color of the leather

may fade or the surface may get

stripped off.

7-94

Cleaning the upholstery and interi-

Cleaning the lap/shoulder belt

or trim

webbing

Vinyl

Clean the belt webbing with any mild

Remove dust and loose dirt from

soap solution recommended for

cleaning upholstery or carpet. Follow

vinyl with a whisk broom or vacuum

cleaner. Clean vinyl surfaces with a

the instructions provided with the

soap. Do not bleach or re-dye the

vinyl cleaner.

webbing because this may weaken it.

Fabric

Cleaning the interior window glass

Remove dust and loose dirt from fab-

ric with a whisk broom or vacuum

If the interior glass surfaces of the

cleaner. Clean with a mild soap solu-

vehicle become fogged (that is, cov-

tion recommended for upholstery or

ered with an oily, greasy or waxy

carpets. Remove fresh spots imme-

film), they should be cleaned with

diately with a fabric spot cleaner. If

glass cleaner. Follow the directions

fresh spots do not receive immediate

on the glass cleaner container.

attention, the fabric can be stained

NOTICE

and its color can be affected. Also, its

fire-resistant properties can be

Do not scrape or scratch the inside

reduced if the material is not proper-

of the rear window. This may result

ly maintained.

in damage to the rear window

defroster grid.

NOTICE

Using anything but recommended

cleaners and procedures may affect

the fabric’s appearance and fire-

resistant properties.

7-95

Maintenance

EMISSION CONTROl SYSTEM

The emission control system of your

1. Crankcase emission control

2. Evaporative emission control

vehicle is covered by a written limited

system

warranty. Please see the warranty

The positive crankcase ventilation

The Evaporative Emission Control

information contained in the Service

system is employed to prevent air

System is designed to prevent fuel

Passport in your vehicle.

pollution caused by blow-by gases

vapors from escaping into the atmos-

Your vehicle is equipped with an

being emitted from the crankcase.

phere.

emission control system to meet all

This system supplies fresh filtered air

emission regulations.

to the crankcase through the air

Canister

There are three emission control

intake hose. Inside the crankcase,

Fuel vapors generated inside the fuel

systems which are as follows.

the fresh air mixes with blow-by

tank are absorbed and stored in the

gases, which then pass through the

onboard canister. When the engine is

PCV valve into the induction system.

(1) Crankcase emission control sys-

running, the fuel vapors absorbed in

tem

the canister are drawn into the surge

(2) Evaporative emission control sys-

tank through the purge control sole-

tem

noid valve.

(3) Exhaust emission control system

Purge Control Solenoid Valve

(PCSV)

In order to assure the proper function

The purge control solenoid valve is

of the emission control systems, it is

controlled by the Engine Control

recommended that you have your

Module

(ECM); when the engine

car inspected and maintained by an

coolant temperature is low during

authorized HYUNDAI dealer in

idling, the PCSV closes so that evap-

accordance with the maintenance

orated fuel is not taken into the

schedule in this manual.

engine. After the engine warms up

during ordinary driving, the PCSV

opens to introduce evaporated fuel to

the engine.

7-96

3. Exhaust emission control

Engine exhaust gas precautions

•

Do not operate the engine in con-

system

(carbon monoxide)

fined or closed areas

(such as

garages) any more than what is

The Exhaust Emission Control

• Carbon monoxide can be present

necessary to move the vehicle in or

System is a highly effective system

with other exhaust fumes.

out of the area.

which controls exhaust emissions

Therefore, if you smell exhaust

while maintaining good vehicle per-

fumes of any kind inside your vehi-

•

When the vehicle is stopped in an

formance.

cle, have it inspected and repaired

open area for more than a short

immediately. If you ever suspect

time with the engine running,

exhaust fumes are coming into

adjust the ventilation system

(as

Vehicle modifications

your vehicle, drive it only with all

needed) to draw outside air into the

•

This vehicle should not be modi-

the windows fully open. Have your

vehicle.

fied. Modification of your vehicle

vehicle checked and repaired

•

Never sit in a parked or stopped

could affect its performance, safety

immediately.

vehicle for any extended time with

or durability and may even violate

the engine running.

governmental safety and emis-

WARNING

•

When the engine stalls or fails to

sions regulations.

start, excessive attempts to restart

In addition, damage or perform-

Exhaust

the engine may cause damage to

ance problems resulting from any

the emission control system.

modification may not be covered

Engine exhaust gases contain

under warranty.

carbon monoxide (CO). Though

colorless and odorless, it is dan-

•

If you use unauthorized electronic

gerous and could be lethal if

devices, it may cause the vehicle to

inhaled. Follow the instructions on

operate abnormally, wire damage,

this page to avoid CO poisoning.

battery discharge and fire. For your

safety, do not use unauthorized

electronic devices.

7-97

Maintenance

Operating precautions for catalytic

Your vehicle is equipped with a cat-

• Avoid driving with a extremely low

converters (if equipped)

alytic converter emission control

fuel level. Running out of fuel could

device.

cause the engine to misfire, dam-

aging the catalytic converter.

WARNING

Therefore, the following precautions

must be observed:

Failure to observe these precautions

Fire

•

Use only UNLEADED FUEL for

could result in damage to the catalyt-

ic converter and to your vehicle.

Gasoline engine.

•

A hot exhaust system can ignite

Additionally, such actions could void

flammable items under your

•

Do not operate the vehicle when

your warranties.

vehicle. Do not park, idle, or

there are signs of engine malfunc-

drive the vehicle over or near

tion, such as misfire or a noticeable

flammable objects, such as

loss of performance.

grass,

vegetation,

paper,

•

Do not misuse or abuse the

leaves, etc.

engine. Examples of misuse are

•

The exhaust system and catalyt-

coasting with the ignition off and

ic system are very hot while the

descending steep grades in gear

engine is running or immediate-

with the ignition off.

ly after the engine is turned off.

•

Do not operate the engine at high

Keep away from the exhaust

idle speed for extended periods (5

system and catalytic, you may

minutes or more).

get burned. Also, do not remove

•

Do not modify or tamper with any

the heat sink around the

part of the engine or emission con-

exhaust system, do not seal the

trol system. All inspections and

bottom of the vehicle or do not

adjustments must be made by an

coat the vehicle for corrosion

authorized HYUNDAI dealer.

control. It may present a fire risk

under certain conditions.

7-98

Specifications & Consumer information

DImENSIoNS

Item

mm (in)

Overall length

4,270 (168.11)

Overall width

1,780 (70.08)

Overall height

1,630 (64.17) / 1,665 (65.55) *1

205/65R16

1,556.5

(61.28)

Front tread

215/60R17

1,544.6

(60.81)

205/65R16

1,570 (61.81)

Rear tread

215/60R17

1,558 (61.34)

Wheelbase

2,590 (101.97)

*1 : with roof rack

ENGINE

Item

U2 1.4 TCI

U2 1.6 TCI

Gamma 1.6 MPI

Displacement

1,396 (85.2)

1,582 (97.09)

1,591 (97.09)

cc (cu. in)

Bore x Stroke

75 x 79 (3.0 x 3.1)

77.2 x 84.5 (3.04 x 3.33)

77 x 85.44 (3.03 x 3.36)

mm (in.)

Firing order

1-3-4-2

No. of cylinders

4. In-line

8-2

bulb wattaGE

Light Bulb

Wattage (W)

Type A

60/55

Headlight

Type B

Turn signal light

Type A

Position light

Type B

LED

Front

Static bending light (SBL)*

Fog light*

Type A

Side Repeater light (Outside mirror)

Type B

LED

Daytime running light*

21/5

Stop/Tail

21/5

Tail

21/5

Rear combination light

Turn signal

Rear

Back up

High mounted stop light

License plate light

Fog light*

Map lamp

Room lamp

Interior

Sunvisor lamp

Luggage room lamp

* : If equipped

8-3

Specifications & Consumer information

tIrES aND whEElS

Inflation pressure bar (psi)

Wheel lug nut

Item

Tire size

Wheel size

Normal load *1

Maximum load

torque

kgf•m (lbf•ft, N•m)

Front

Rear

Front

Rear

205/65R16

6.0J X 16

9~11

Full size tire

230 (33)

250 (36)

215/60R17

6.5J X 17

(65~79, 88~107)

*1 : Normal load : Up to 3 persons

NOTICE

• It is permissible to add 3 psi to the standard tire pressure specification if colder temperatures are expected soon.

Tires typically loose 1 psi (7 kPa) for every 7°C temperature drop. If extreme temperature variations are expected,

recheck your tire pressure as necessary to keep them properly inflated.

• An air pressure generally decreases, as you drive up to a high-altitude area above sea level. Thus, if you plan to

drive a high-altitude area, check the tire pressures in advance. If necessary, inflate them to a proper level. (Air infla-

tion per altitude : +10 kPa/1 km)

CAUTION

When replacing tires, use the same size originally supplied with the vehicle.

Using tires of a different size can damage the related parts or make it work irregularly.

8-4

Hyundai Creta (2016 year). Instruction - part 28
