POWER DOOR LOCKS

BE -137

ASSIST DOOR LOCK SWITCH

1.

Disconnect the negative (-) battery terminal.

2.

Remove the front door trim and power window switch
module. (Refer to the Body group - front door)

3.

Disconnect the connector from the switch.

1

2

3

4

10

9

8

7

6

5

SCMBE6249L

4.

Check for continuity between the terminals in each
switch position according to the table.

Lock

3

4

7

Unlock

Terminal

Position

SCMBE6251L

BE -138

BODY ELECTRICAL SYSTEM

POWER DOOR MIRRORS

COMPONENT LOCATION

E5B25FCD

1

1. Power door mirror

2. Power door mirror switch

2*

AUT

O

The parts with asterisk(*) :
This illustration shows the LHD type.
RHD type is symmetrical.

SCMBE6260L

POWER DOOR MIRRORS

BE -139

POWER DOOR MIRROR SWITCH

COMPONENTS

E98FAE26

1

2

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

Power outside mirror switch

Power outside mirror switch connector (12 Pin)

SCMBE6261L

BE -140

BODY ELECTRICAL SYSTEM

INSPECTION

E4439FF6

1.

Disconnect the negative (-) battery terminal.

2.

Remove the front door trim and power window switch
module. (Refer to the Body group-front door)

[LHD]

AU

TO

SCMBE6246L

[RHD]

AU

TO

SCMBE6246R

3.

Check for the continuity between terminals of power
door lock switch according to the table.

5

4

3

2

14

12

11

10

8

9

1

7

6

13

SCMBE6247L

Lock

4(4)

11(11)

10(10)

Unlock

Terminal

Position

(    ) : RHD

SCMBE6248L

4.

Check for continuity between the terminals in each
switch position according to the table.

5

4

6

7

8

9

10

UP

DOWN

OFF

LEFT

RIGHT

UP

DOWN

OFF

LEFT

RIGHT

Terminal

Direction

Item

Left

Right

SCMBE6256L
