POWER DOOR LOCKS

BE -129

5.

Both sides do not lock either.

Door lock fuse(25A) short check

OK

NG

Check for an open in the wire

Replace the fuse

Replace the relay

Door lock switch input signal inspection

(BCM connector terminal 3)

OK

OK

NG

Check for an open in the wire

NG

Door unlock switch input signal inspection

(BCM-B connector terminal 7)

OK

Replace the BCM

Door lock/unlock relay inspection

NG

SCMBE6254L

BE -130

BODY ELECTRICAL SYSTEM

POWER DOOR LOCK
ACTUATORS

INSPECTION

EEF47A4B

FRONT DOOR LOCK ACTUATOR

1.

Remove the front door trim. (Refer to the Body group
- Front door)

2.

Remove the front door module. (Refer to the Body
group - Front door).

3.

Disconnect the connectors from the actuator.

1

2
3

4
5

6

7

1

2

3
4

5

6

[CENTRAL LOCK]

[DEAD LOCK]

SCMBE6130L

4.

Check actuator operation by connecting power and
ground according to the table. To prevent damage to
the actuator, apply battery voltage only momentarily.

Terminal

Position

Front left

Unlock

Lock

Unlock

Lock

Front right

4

3

[CENTRAL LOCK]

SCMBE6131L

Terminal

Position

Front

left

Central

Lock

Dead

Lock

Unlock

Lock

Unlock

Lock

Unlock

Lock

Unlock

Lock

Front

right

Front

left

Front

right

5

6

7

[DEAD LOCK]

SCMBE6144L

POWER DOOR LOCKS

BE -131

REAR DOOR LOCK ACTUATOR

1.

Remove the rear door trim panel. (Refer to the Body
group - Rear door)

2.

Remove the rear door module. (Refer to the Body
group - Rear door)

3.

Disconnect the connectors from the actuator.

1

2
3

4
5

6

7

1

2

3
4

5

6

[CENTRAL LOCK]

[DEAD LOCK]

SCMBE6132L

4.

Check actuator operation by connecting power and
ground according to the table. To prevent damage to
the actuator, apply battery voltage only momentarily.

Terminal

[CENTRAL LOCK]

Position

Rear left

Unlock

Lock

Unlock

Lock

Rear right

4

3

SCMBE6133L

Terminal

Position

Rear

left

Central

Lock

Dead

Lock

Unlock

Lock

Unlock

Lock

Unlock

Lock

Unlock

Lock

Rear

right

Rear

left

Rear

right

5

6

7

[DEAD LOCK]

SCMBE6145L

BE -132

BODY ELECTRICAL SYSTEM

TAILGATE LOCK ACTUATOR

1.

Remove the tailgate trim. (Refer to the Body group -
Tailgate)

2.

Disconnect the 4P connector from the actuator.

1

2

3 4

SCMBE6134D

3.

Check actuator operation by connecting power and
ground according to the table. To prevent damage to
the actuator, apply battery voltage only momentarily.

Lock

Unlock

2

3

Terminal

Position

SCMBE6135L

FRONT DOOR LOCK SWITCH

1.

Remove the front door trim. (Refer to the Body group
- Front door)

2.

Remove the front door module. (Refer to the Body
group - Front door).

3.

Disconnect the connectors from the actuator.

1

2
3

4
5

6

7

1

2

3
4

5

6

[CENTRAL LOCK]

[DEAD LOCK]

SCMBE6130L
