FUSES AND RELAYS

BE -109

INSPECTION

EE70B5AD

POWER RELAY (TYPE A)

Check for continuity between the terminals.

1.

There should be continuity between the No.30 and
No.87 terminals when power and ground are con-
nected to the No.85 and No.86 terminals.

2.

There should be no continuity between the No.30 and
No.87 terminals when power is disconnected.

30

85

86

87

87

85

30

86

A/T control relay

Cooling pan relay

Front fog lamp relay

A/C relay

Head lamp relay(High)

Tail lamp relay

Windshield relay

Horn relay

Fuel pump relay

Condenser pan 1 relay

Head lamp relay (Low-right side)

Head lamp relay (Low-left side)

Fuel filter heater relay

SCMBE6194L

30

87

85

+

86

Disconnected

Connected

Terminal

Power

SCMBE6195L

POWER RELAY (TYPE B)

Check for continuity between the terminals.

1.

There should be continuity between the No.30 and
No.87 terminals when power and ground are con-
nected to the No.85 and No.86 terminals.

2.

There should be continuity between the No.30 and
No.87 terminals when power is disconnected.

30

87

85

87

86

85

87

87

86

30

Wiper relay

Rain sensor relay

Condenser pan 2 relay

SCMBE6196L

85

86

30

87

87

+

Disconnected

Connected

Terminal

Power

SCMBE6197L

BE -110

BODY ELECTRICAL SYSTEM

POWER RELAY (TYPE C)

Check for continuity between the terminals.

1.

There should be continuity between the No.30 and
No.87 terminals when power and ground are con-
nected to the No.85 and No.86 terminals.

2.

There should be no continuity between the No.30 and
No.87 terminals when power is disconnected.

87

87

86

30

85

86

85

30

PTC heater relay #2

Glow relay

PTC heater relay #1

PTC heater relay #3

Start relay

Rear defogger relay

SCMBE6198L

86

85

87

+

30

Disconnected

Connected

Terminal

Power

SCMBE6199L

POWER RELAY (TYPE D)

Check for continuity between the terminals.

1.

There should be continuity between the No.30 and
No.87 terminals when power and ground are con-
nected to the No.85 and No.86 terminals.

2.

There should be continuity between the No.30 and
No.87 terminals when power is disconnected.

87

87a

86

85

30

86

87a

87

85

30

Start relay

SCMBE6200L

86

85

87

87a

30

+

Disconnected

Connected

Terminal

Power

SCMBE6201L

FUSE

1.

Be sure there is no play in the fuse holders, and that
the fuses are held securely.

2.

Are the fuse capacities for each circuit correct?

3.

Are there any blown fuses?
If a fuse is to be replaced, be sure to use a new fuse
of the same capacity. Always determine why the fuse
blew first and completely eliminate the problem before
installing a new fuse.

FUSES AND RELAYS

BE -111

RELAY BOX (PASSENGER
COMPARTMENT)

COMPONENT LOCATION

EBFFF18D

<REAR>

< FRONT>

 USE THE DESIGNATED FUSE ONLY

C/LIGHTER

15A

POWER

CONNECTOR

P/OUTLET

25A

S/WARMER

25A

A/CON

10A

ROOM LP

10A

A/BAG #1

15A

P/OUTLET

CTR 15A

P/AMP

30A

P/SEAT

30A

S/ROOF

20A

P/WDW RH

30A

P/WDW LH

30A

START

10A

RR WIPER

15A

T/SIG

10A

ATM LOCK

10A

A/BAG IND

10A

HAZARD

15A

DR/LOCK

20A

BCM #2

10A

CLOCK

15A

BCM #3

10A

STOP LP

15A

ATM

10A

AUDIO #1

15A

BLOWER

30A

AUDIO #2

10A

IMS

10A

B/ALARM

HORN 10A

FUEL LID

15A

BCM #1

10A

CLUSTER

10A

RR FOG/

BWS 10A

RR A/CON

15A

A/CON SW

10A

MIRR HTD

10A

I/P-E

(FRONT)

I/P-M

(MAIN)

I/P-N

(MAIN)

I/P-G

(MAIN)

I/P-H

(MAIN)

I/P-J

(MAIN)

I/P-K

(MAIN)

I/P-L

(A/BAG)

I/P-F

(FLOOR)

I/P-A

(FRONT)

I/P-C

(FRONT)

I/P-B

(ROOF)

I/P-D

(FLOOR)

2

1

2

34

5

13

14

10

11

*

***

**

13

5

6

7

4

*

91

0
1

1

34

11

12

12

13

14

8

9

10

7

8

9

15

17

18

*

**

**

*

*

**

*

2

13

4

5

6

7

8

10

*

*

*

*

2

1

5

11

12

13

14

4

15

6

7

8

*

*

*

**

*

12

91

0

1

1

1

3

1

4

15

4

123

5

6

7

11

89

1

0

16

4

12

7

8

**

*

13

10

11

12

14

15

16

17

9

18

1

**

67

45

13

14

91

0

1

1

1

2

*

13

*

*

89

46

*

*

14

15

12

34

8

567

9

1

0

12

3

4

67

8

1

0

1

1

5

12

10

11

12

13

SCMBE6210L

BE -112

BODY ELECTRICAL SYSTEM

CIRCUIT

FUSE

(A)

Circuit Protected

C/LIGHTER

RR A/CON

CIGARETTE LIGHTER

FRONT POWER OUTLET, REAR POWER OUTLET

CENTER POWER OUTLET

POWER OUTSIDE MIRROR SWITCH, AUDIO, DIGITAL CLOCK,

ATM KEY LOCK CONTROL MODULE

MULTIFUNCTION SWITCH, REAR WIPER CONTROL MODULE, REAR WIPER MOTOR

RAIN SENSOR

RHEOSTAT, BCM, INSTRUMENT CLUSTER

A/C CONTROL MODULE, INCAR & HUMIDITY SENSOR, HIGH BLOWER RELAY,

REAR A/CON SWITCH, ICM RELAY BOX, AQS SENSOR, FUSIBLE LINK BOX (DSL),

SUNROOF MOTOR, BLOWER RELAY, ELECTRO CHROMIC MIRROR

BLOWER RELAY, BLOWER MOTOR, A/C CONTROL MODULE

A/C CONTROL MODULE

SRS CONTROL MODULE

PAB CUT OFF SWITCH, INSTRUMENT CLUSTER

HAZARD SWITCH

MULTIFUNCTION SWITCH, STEERING ANGLE SENSOR, ESP SWITCH,

ATM KEY LOCK CONTROL MODULE, SEAT WARMER MODULE

OIL LEVEL SENSOR MODULE, BCM

INSTRUMENT CLUSTER, PRE-EXCITATION RESISTOR, BCM,

SEMI ACTIVE ENGINE MOUNTING CONTROL MODULE (GSL), GENERATOR

BURGLAR ALARM RELAY

DELPHI AMP, MOBIS AMP

SEAT WARMER CONTROL MODULE

POWER SEAT SWITCH

ICM RELAY BOX

ICM RELAY BOX

SUNROOF MOTOR

BURGLAR ALARM HORN RELAY

REAR DEFOGGER SWITCH, POWER OUTSIDE MIRROR MOTOR

DOOR LOCK (UN) RELAY, ICM RELAY BOX

STOP LAMP SWITCH

FUEL LID SWITCH

KEY SOLENOID, SEMI ACTIVE SOLENOID (GSL), SPORTS MODE SWITCH

INSTRUMENT CLUSTER, LUGGAGE LAMP, MAP LAMP, REAR PERSONAL LAMP,

ROOM LAMP, FRONT DOOR LAMP, CARGO LAMP, VANITY LAMP SWITCH

IGNITION KEY ILL. & DOOR WARNING SWITCH, BCM, SECURITY INDICATOR

A/C CONTROL MODULE, DATA LINK CONNECTOR, DIGITAL CLOCK

DELPHI AUDIO, MOBIS AUDIO

HAZARD SWITCH, HAZARD RELAY

POWER WINDOW MAIN SWITCH, REAR POWER WINDOW SWITCH LH

POWER WINDOW MAIN SWITCH, REAR POWER WINDOW SWITCH RH

P/OUTLET

P/OUTLET CTR

AUDIO #2

RR WIPER

IMS

BCM #2

A/CON

BLOWER

 A/CON SW

A/BAG #1

A/BAG IND

T/SIG

ATM LOCK

BCM #1

CLUSTER

START

P/AMP

S/WARMER

P/SEAT

15A

15A

RR FOG/BWS

10A

S/ROOF

20A

B/ALARM HORN

10A

MIRR HTD

10A

DR/LOCK

20A

STOP LP

15A

FUEL LID

15A

ATM

10A

ROOM LP

10A

BCM #3

10A

CLOCK

15A

AUDIO #1

15A

HAZARD

15A

P/WDW LH

30A

P/WDW RH

30A

25A

15A

10A

15A

10A

10A

10A

30A

10A

15A

10A

10A

10A

10A

10A

10A

30A

25A

30A

 USE THE DESIGNATED FUSE ONLY

SCMBE6211L
