CP-10
CORROSION PROTECTION
SIDE BODY
CAVITY WAX INJECTION
In order to provide greater corrosion resistance, cavity wax injection has been performed for the lower areas of the vehicle,
such as the side member, the side sill and the inside of other panels which have a hollow construction.
When replacing these parts, be sure to apply cavity wax to the appropriate areas of the new parts.
BFDCP6213
BFDCP6212
A - A
40mm
Wax injection hole
Side sill inner panel
Side outer panel
Side sill inner front extension
Side sill outer
reinforcement
25
16
A
A
