CP-6

CORROSION PROTECTION

BFDCP6210

BFDCP6211

BFDCP6209

BFDCP6208

Front seat mounting member

Spare tire mounting bracket

Rear floor rear panel

Rear floor side member

Rear floor front panel

Rear floor front panel

F - F

G - G

H - H

I - I

22mm

33mm

CORROSION PROTECTION

CP-7

UNDER  BODY & SIDE BODY COAT

In order to provide corrosion, stone chipping and vibration resistance, under body coat is applied to the under sides of the
floor  and wheel house.
Therefore, when such  panel is replaced or repaired, apply under body coat to that part.

BFDCP6002

C

C

B

B

E

E

A

A

D

D

F

F

X

Y

Under body coating  (Thickness             : 1.0 mm ,             :1.5 mm ,             : 2.0mm)

CP-8

CORROSION PROTECTION

BFDCP6105

BFDCP6103

BFDCP6107

BFDCP6106

BFDCP6104

B - B

D - D

A - A

C - C

G

G

[ Wagon ]

Fender apron upper inner panel

Shock absorber

housing lower

panel

Front side

inner member

Side outer rear extension

Side frame
mounting rear support

Side frame mounting
rear reinforcement

Fender apron
upper outer
panel

Shock absorber
housing cover

Front side outer member

Tie down front reinforcement

Center floor

side member

Side sill inner panel

Side outer

panel

Side frame

mounting rear

 bracket

CORROSION PROTECTION

CP-9

BFDCP6111

BFDCP6110

BFDCP6112

BFDCP6109

BFDCP6108

E - E

Y

F - F

X

G - G

Rear floor rear panel

Rear floor

center cross

member

[ 5Door ]

20mm

50mm

50mm

Rear suspension
mounting bracket

Wheel house

inner panel

Outer inner uper panel

Side outer panel

Rear floor rear panel

Rear floor center

cross member

Back panel

[ Wagon ]

20mm

50mm

50mm
