1. Remove all traces of the original adhesive patch. 2. Clean the threads of the bolt with brake parts cleaner or the equivalent and allow to dry. 3. Apply Threadlocker GM P/N 12345382 (Canadian P/N 10953489) to the threads of the bolt. 3. Install the differential carrier assembly right side axle mount bolt and nut. Tighten: Tighten the bolts to 100 N.m (75 lb ft). 4. Install the differential carrier assembly left side axle mount bolt and nut. Tighten: Tighten the bolts to 100 N.m (75 lb ft). 5. Remove the transmission jack. 6. Install the lower control arm crossmember. Refer to Crossmember Replacement (Lower Control Arm) in Frame and Underbody. NOTE: Refer to Fastener Notice in Cautions and Notices.
2004 Hummer H2 2004 DRIVELINE/AXLE Front Drive Axle - Hummer H2
|
