1. Remove the inner axle shaft and housing assembly from the differential carrier case assembly. Refer to Inner Shaft and/or Housing Replacement - Front Drive Axle . 2. Install the inner axle shaft housing into a vise. Clamp only on the mounting flange of the inner axle shaft housing. 3. Install the J 29369-2 behind the inner axle shaft seal. See Special Tools and Equipment . 4. Install the J 2619-01 (2) to the J 29369-2 (1). See Special Tools and Equipment . 5. Remove the inner axle shaft seal using the J 2619-01 . Fig. 45: Installing J 29369-02 Behind Inner Axle Shaft Seal
2004 Hummer H2 2004 DRIVELINE/AXLE Front Drive Axle - Hummer H2
|
