Hummer H2. Manual - part 756
Longitudinal Terminal Identification Accelerometer
2
WH
883
Right Rear Wheel Speed Sensor Low Reference
3
-
-
Not Used
4
D-GN
872
Right Front Wheel Speed Sensor Signal
5
TN
833
Right Front Wheel Speed Sensor Low Reference
6
L-BU
1320
CHMSL Supply Voltage/Stop Lamp Supply Voltage
7
-
-
Not Used
8
PK
1339
Ignition 1 Voltage
9
PU
333
Brake Fluid Level Sensor Signal
10
D-BU
716
LNG Rate Signal
11
L-BU
2206
Traction Control Preference Switch Signal
12
BK
2150
Ground
13
RD
442
Battery Positive Voltage
14
OG
2340
Battery Positive Voltage
15
BK
2851
Ground
16
OG
2554
Traction Control Preference Switch Indicator
17
-
-
Not Used
18
L-BU
2088
LNG Rate Low Reference
19
-
-
Not Used
20
L-BU
830
Left Front Wheel Speed Sensor Signal
21
YE
873
Left Front Wheel Speed Sensor Low Reference
22
BK
884
Left Rear Wheel Speed Sensor Signal
23
RD
885
Left Rear Wheel Speed Sensor Low Reference
24
-
-
Not Used
25
L-BU
1122
ABS/TCS Class 2 Serial Data
26-27
-
-
Not Used
28
D-GN
2087
LNG Rate Sensor 5 Volt Reference
2004 Hummer H2
2004 BRAKES Anti-Lock Brake System - Hummer H2
