Fig. 36: Aligning Windshield
Courtesy of GENERAL MOTORS CORP.

22. Align the masking tape (1) lines on the window (2) and the body.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 37: Pressing Window Into Place
Courtesy of GENERAL MOTORS CORP.

23. Press the window firmly into place.

24. Tape the window to the body in order to minimize movement until the urethane adhesive cures.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 38: Cleaning Excess Urethane Adhesive
Courtesy of GENERAL MOTORS CORP.

25. Clean any excess urethane adhesive from the body.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 39: Water Hose Test
Courtesy of GENERAL MOTORS CORP.

26. Use a soft spray of warm water in order to immediately water test the window.

27. Inspect the window for leaks.

28. If any leaks are found, use a plastic paddle in order to apply extra urethane adhesive at the leak point.

29. Retest the window for leaks.

IMPORTANT: Do not direct a hard stream of high pressure water to the freshly applied

urethane adhesive.

CAUTION: Insufficient curing of urethane adhesive may allow unrestrained

occupants to be ejected from the vehicle resulting in personal injury.

z

For the moisture-curing type of urethane adhesive, allow a
minimum of 6 hours at 21°C (70°F) or greater and with at least
30 percent relative humidity. Allow at least 24 hours for the
complete curing of the urethane adhesive.

z

For the chemical-curing type of urethane adhesive, allow a
minimum of 1 hour.
