Hummer H2. Manual - part 705

Fig. 28: Aligning Windshield
Courtesy of GENERAL MOTORS CORP.

11. Using masking tape in order to mark the locations (1) of the window (2) in the opening.

12. Cut the masking in the center and remove the window from the opening.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 29: Applying Glass Prep (Clear #1)
Courtesy of GENERAL MOTORS CORP.

13. Use a new dauber in order to apply glass prep clear #1 to the area approximately 10-16 mm (3/8-5/8 in)

around the entire perimeter of the window inner surface.

Immediately wipe the glass primed area using a clean, lint-free cloth.

IMPORTANT: Use care when applying glass prep clear #1 on the window. This primer

dries almost instantly, and may stain the viewing area of the window if not
applied evenly.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 30: Applying Glass Prep (Clear #1)
Courtesy of GENERAL MOTORS CORP.

14. Apply a second coat of the glass prep clear #1 to the same area of the glass.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 31: Applying Glass Primer (Black #2)
Courtesy of GENERAL MOTORS CORP.

15. Shake the glass primer black #2 for at least 1 minute.

16. Use a new dauber in order to apply the glass primer black #2 to the same areas (2) that glass prep clear #1

was applied.

17. Allow the glass primer to dry for approximately 10 minutes.

IMPORTANT: The glass primer black #2 is effective up to 8 hours after applying it to the

glass. The primed surface of the glass must be kept clean.
