Hummer H2. Manual - part 304

Off-Road Lamps Terminal Identification - Roof Inner (w/USB/USC)

Off-Road Lamps Terminal Identification - Roof Outer (w/USB/USC)

1

PU

34

Front Off-Road Lamps Supply Voltage (UNR)

PU

2234

Roof Off-Road Lamps Supply Voltage 2 (USB/USC)

2

YE

317

Off-Road Lamp Relay Control

3

-

-

Not Used

4

BU

316

Battery Positive Voltage

5

BK

1050

Ground

Connector Part Information

z

12052641

z

2-Way F Metri-Pack 150 Series (BK)

Pin

Wire Color

Circuit No.

Function

A

RD

122

Roof Off-Road Lamps Supply Voltage 1

B

BK

1050

Ground



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Lighting Systems - Hummer H2



PRNDL Terminal Identification Lamp (2)

Park/Turn Signal Lamp Terminal Identification - LF

Connector Part Information

z

12052641

z

2-Way F Metri-Pack 150 Series (BK)

Pin

Wire Color

Circuit No.

Function

A

PU

34

Roof Off-Road Lamps Supply Voltage 2

B

BK

1050

Ground

Connector Part Information

z

12162711

z

2-Way W-2 Axial (BK)

Pin

Wire Color

Circuit No.

Function

A

BN/WH

230

Instrument Panel Lamps Dimming Control

B

BK

1050

Ground



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Lighting Systems - Hummer H2



Park/Turn Signal Lamp Terminal Identification - RF

Connector Part Information

z

15409405

z

3-Way F 3W SLD (BK)

Pin

Wire Color

Circuit No.

Function

1

BK

150

Ground

2

BN

2309

Front Park Lamps Supply Voltage

3

L-BU

2114

Left Turn Signal Lamps Supply Voltage

Connector Part Information

z

15409405

z

3-Way F 3W SLD (BK)

Pin

Wire Color

Circuit No.

Function

1

BK

150

Ground

2

BN

2309

Front Park Lamps Supply Voltage



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Lighting Systems - Hummer H2



Roof Lamps Terminal Identification - Center Front (3)

Roof Lamps Terminal Identification - Center Rear (3)

3

D-BU

2115

Right Turn Signal Lamps Supply Voltage

Connector Part Information

z

15300027

z

2-Way F Metri-Pack 280 Series Sealed (BK)

Pin

Wire Color

Circuit No.

Function

A

BN

2409

Interior Park Lamps Supply Voltage

B

BK

1050

Ground

Connector Part Information

z

15300027

z

2-Way F Metri-Pack 280 Series Sealed (BK)

Pin

Wire Color

Circuit No.

Function



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Lighting Systems - Hummer H2
