Fig. 20: Separating Urethane Adhesive From Window
Courtesy of GENERAL MOTORS CORP.

8. This will allow the urethane adhesive to be separated from the window.

z

Leave a base of urethane on the pinchweld flange.

z

The only suitable lubrication is clear water.

z

Use J 24402-A , J 39032 or equivalent in order to remove the window. See Special Tools and
Equipment .

IMPORTANT: Keep the cutting edge of the tool against the window.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 21: Removing Bottom Of Window
Courtesy of GENERAL MOTORS CORP.

9. Remove the bottom of the window from the urethane adhesive using a long utility knife or similar tool.

Keep the cutting edge of the utility knife against the glass.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 22: Identifying Windshield
Courtesy of GENERAL MOTORS CORP.

10. With the aid of an assistant remove the window from the vehicle.

Installation Procedure

1. Install the windshield into the opening. Refer to Urethane Adhesive Installation of Stationary

Windows .

2. Install the cowl air inlet grille panel. Refer to Air Inlet Grille Panel Replacement - Non Functional in

Exterior Trim.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 23: Identifying Windshield
Courtesy of GENERAL MOTORS CORP.

3. Install the window side reveal moldings to the vehicle. Refer to Windshield Side Reveal Molding

Replacement .

4. Install the window wiper arms. Refer to Wiper Arm Replacement in Wipers/Washer Systems.

5. Install the rear view mirror. Refer to Rearview Mirror Replacement .

6. Close the hood.

7. Remove the double layer of masking tape around the perimeter of the painted surfaces and the interior

trim.

QUARTER WINDOW REPLACEMENT (SUV BODY SIDE QUARTER WINDOW)

Tools Required
