adhesive.

5. Clean the inside windshield glass and the mounting surface of the mirror mounting base thoroughly with

a clean cloth saturated with naphtha or a 50/50 mixture (by volume) of clean water and isopropyl alcohol.

Fig. 17: Preparing Mirror Mounting Base
Courtesy of GENERAL MOTORS CORP.

6. Use Inside Mirror Adhesive Kit GM P/N 1052369 or equivalent to apply a small amount of activator to

the mounting surface of the mirror mounting base.

7. Apply a small amount of activator to the windshield where the mounting base is to be installed.

8. Allow the activator to dry 5 minutes.

IMPORTANT: Do not touch the mounting surface of the mirror mounting base or the

glass.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



9. Apply 1 drop of adhesive to the center of the mirror mounting base.

Fig. 18: Installing Mirror Base
Courtesy of GENERAL MOTORS CORP.

10. Immediately apply the mounting base to the windshield, ensuring that the mounting base aligns correctly

to the marks made on the outside of the windshield.

11. Hold the mounting base firmly in place for 1 minute.

12. Allow the adhesive to set for 15 minutes.

13. Install the mirror to the mirror mounting base and fasten, if necessary.

14. Connect the electrical connector and install the wire cover, if equipped.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



WINDSHIELD REPLACEMENT

Tools Required

z

J 24402-A Cold Knife Glass Sealant Remover. See Special Tools and Equipment .

z

J 39032 Stationary Window Removal Tool. See Special Tools and Equipment .

z

Urethane Adhesive Kit GM P/N 12346392 or Equivalent

z

Isopropyl Alcohol or Equivalent

z

Cartridge-type Caulking Gun

z

Commercial-type Utility Knife

z

Razor Blade Scraper

z

Suction Cups

z

Plastic Paddle

Removal Procedure

1. Open the hood.

2. Remove the window wiper arms. Refer to Wiper Arm Replacement in Wipers/Washer Systems.

3. Remove the window side reveal moldings from the vehicle. Refer to Windshield Side Reveal Molding

Replacement .

4. Remove the cowl air inlet grille panel. Refer to Air Inlet Grille Panel Replacement - Non Functional in

Exterior Trim.

5. Cover to protect the following parts from broken glass:

z

The upper dash pad

z

The defroster outlets and A/C outlets

z

The seats and carpeting

6. Remove the rear view mirror. Refer to Rearview Mirror Replacement .

IMPORTANT: Before cutting out a stationary window, apply a double layer of masking

tape around the perimeter of the painted surfaces and the interior trim.

CAUTION: If broken glass falls into the defroster outlets, it can be blown into the

passenger compartment and cause personal injury.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 19: Window Lower Supports
Courtesy of GENERAL MOTORS CORP.

7. If necessary, remove the window lower supports (1) by using a flat bladed tool, lightly prying upward in

the middle until it releases.

IMPORTANT: The window lower supports (1) have molded in locks with an urethane

adhesive strip (2) on the back side. Once the window lower stop have
been removed they must be replaced.
