Continued

645

Braking

Brake System

Driving

Keeps the brake applied after releasing the brake pedal until the accelerator pedal is
pressed. You can use this system while the vehicle is temporarily stopped, like at
traffic lights and in heavy traffic.

■

Turning on the system

Fasten your seat belt properly, then start the
engine. Press the automatic brake hold
button.

The automatic brake hold system
indicator comes on. The system is turned
on.

The system is in the previously selected on or
off setting each time you fasten the driver’s
seat belt and start the engine.

■

Activating the system

Depress the brake pedal to come to a
complete stop. The transmission must not be
in

(

The automatic brake hold indicator
comes on. Braking is kept for up to 10
minutes.

Release the brake pedal after the
automatic brake hold indicator comes
on.

■

Automatic Brake Hold

Automatic Brake Hold

WARNING

Activating the automatic brake hold system
on steep hills or slippery roads may still
allow the vehicle to move if you remove
your foot from the brake pedal.

If a vehicle unexpectedly moves, it may
cause a crash resulting in serious injury or
death.

Never activate the automatic brake hold
system or rely on it to keep a vehicle from
moving when stopped on a steep hill or
slippery roads.

WARNING

Using the automatic brake hold system to
park the vehicle may result in the vehicle
unexpectedly moving.

If a vehicle moves unexpectedly, it may
cause a crash, resulting in serious injury or
death.

Never leave the vehicle when braking is
temporarily kept by automatic brake hold
and always park the vehicle by putting the
transmission in

(

and applying the parking

brake.

Comes
On

Automatic Brake
Hold Button

Brake Pedal

Comes
On

U.S.

Canada

Braking

Brake System

646

Driving

■

Canceling the system

Depress the accelerator pedal while the
transmission is in a position other than

(

. The system is canceled and the vehicle

starts to move.

The automatic brake hold indicator goes
off. The system continues to be on.

■

The system automatically cancels when:

•

You engage the parking brake.

•

You depress the brake pedal and put the transmission into

(

■

The system automatically cancels and the parking brake is applied when:

•

Braking is kept for more than 10 minutes.

•

The driver’s seat belt is unfastened.

•

The engine is turned off.

•

There is a problem with automatic brake hold system.

Automatic Brake Hold

While the system is activated, you can turn off the
engine or park the vehicle through the same
procedure as you normally do.

When Stopped

P. 650

You may hear an operating noise if the vehicle moves
while the automatic brake hold system is in
operation.

WARNING

When using the automatic brake hold,
keep your foot on the brake pedal until the
automatic brake hold indicator comes on.

If the vehicle unexpectedly moves, it may
cause a crash resulting in serious injury or
death.
Release your foot from the brake pedal
after the automatic brake hold indicator
comes on.

Accelerator Pedal

Goes
Off

647

Braking

Brake System

Driving

■

Turning off the automatic brake hold system

Only the automatic brake hold system
indicator comes on:

•

Press the automatic brake hold button.

The automatic brake hold system
indicator goes off.

When the automatic brake hold indicator
comes on at the same time:

•

Press the automatic brake hold button with
the brake pedal depressed.

The automatic brake hold system
indicator and the automatic brake hold
indicator go off.

Turning off the automatic brake hold system

Make sure to turn off the automatic brake hold
system before using an automated car wash.

If you turn off the engine or unfasten the driver’s seat
belt while the automatic brake hold system is on, the
automatic brake hold system will automatically turn
off. In this case, when the driver’s seat belt is
fastened and the engine is restarted, the automatic
brake hold system will turn on without needing to
press the automatic brake hold button.

Automatic Brake
Hold Button

Goes
Off

648

Braking

Anti-lock Brake System (ABS)

Driving

Anti-lock Brake System (ABS)

Helps prevent the wheels from locking up, and helps you retain steering control by
pumping the brakes rapidly, much faster than you can.

The electronic brake distribution (EBD) system, which is part of the ABS, also
balances the front-to-rear braking distribution according to vehicle loading.

You should never pump the brake pedal. Let the ABS work for you by always
keeping firm, steady pressure on the brake pedal. This is sometimes referred to as
“stomp and steer.”

■

ABS operation

The brake pedal may pulsate slightly when the ABS is working. Depress the brake
pedal and keep holding the pedal firmly down. On dry pavement, you will need to
press on the brake pedal very hard before the ABS activates. However, you may feel
the ABS activate immediately if you are trying to stop on snow or ice.

ABS may activate when you depress the brake pedal when driving on:

•

Wet or snow covered roads.

•

Roads paved with stone.

•

Roads with uneven surfaces, such as potholes, cracks, manholes, etc.

When the vehicle speed goes under 6 mph (10 km/h), the ABS stops.

■

ABS

Anti-lock Brake System (ABS)

NOTICE

The ABS may not function correctly if you use a tire of
the incorrect size or type.

If the

ABS

indicator comes on while driving, there

may be a problem with the system.
While normal braking will not be affected, there is a
possibility that the ABS will not be operating. Have
your vehicle checked by a dealer immediately.

The ABS is not designed for the purpose of reducing
the time or distance it takes for a vehicle to stop: It is
designed to limit brake lockup which can lead to
skidding and loss of steering control.

In the following cases, your vehicle may need more
distance to stop than a vehicle without the ABS:

•

You are driving on rough or uneven road surfaces,
such as gravel or snow.

•

The tires are equipped with snow chains.

The following may be observed with the ABS system:

•

Motor sounds coming from the engine

compartment when the brakes are applied, or when
system checks are being performed after the engine
has been started and while the vehicle accelerates.

•

Brake pedal and/or the vehicle body vibration when
ABS activates.

These vibrations and sounds are normal to ABS
systems and are no cause for concern.

649

Braking

Brake Assist System

Driving

Brake Assist System

Designed to assist the driver by generating greater braking force when you depress
the brake pedal hard during emergency braking.

■

Brake assist system operation

Press the brake pedal firmly for more powerful braking.

When brake assist operates, the pedal may wiggle slightly and an operating noise
may be heard. This is normal. Keep holding the brake pedal firmly down.

650

Driving

Parking Your Vehicle

When Stopped

Depress the brake pedal firmly and come to a complete stop.

With the brake pedal depressed, pull up the electric parking brake switch slowly,
but fully.

Change the shift position to

(

Do not release the brake pedal until you have confirmed that

(

is shown on

the shift position indicator.

Turn off the engine.

The parking brake and brake system indicator goes off in about 15 seconds.

Always set the parking brake, especially if you are parked on an incline.

When Stopped

Do not park your vehicle near flammable objects,
such as dry grass, oil, or timber.
Heat from the exhaust can cause a fire.

NOTICE

The following can damage the transmission:

•

Depressing the accelerator and brake pedals
simultaneously.

•

Holding the vehicle in place when facing uphill by
depressing the accelerator pedal.

•

Changing into

(

before the vehicle stops

completely.

WARNING

The vehicle can roll away if left unattended
without confirming that Park is engaged.

A vehicle that rolls away could cause a crash
resulting in serious injury or death.

Always keep your foot on the brake pedal
until you have confirmed that

(

is shown

on the gear position Indicator.

652

Parking Your Vehicle

Parking Sensor System

Driving

Parking Sensor System

The corner and center sensors monitor obstacles around your vehicle, and the
beeper, driver information interface and audio/information screen let you know the
approximate distance between your vehicle and the obstacle.

■

The sensor location and range

Parking Sensor System

Even when the system is on, always confirm if there is
no obstacle near your vehicle before parking.

The system may not work properly when:

•

The sensors are covered with snow, ice, mud, or
dirt.

•

The vehicle has been out in hot or cold weather.

•

There is something nearby that emits ultrasonic
waves or high frequency sounds.

•

Driving in bad weather (rain, fog, snow, etc.).

The system may not detect these obstacles:

•

Thin or low objects.

•

Sonic-absorptive materials, such as snow, cotton,
or sponge.

•

Objects directly under the bumper.

The system may falsely detect obstacles in the
following situations:

•

The vehicle is on uneven surface, such as grass,
bumps, or a hill.

•

When close to other vehicles with sonar sensors or
other objects that emit ultrasonic waves.

•

There is splashing water near the sensors due to
heavy rains, etc.

Do not put any accessories on or around the sensors.

If you put any accessories (such as a towing hitch

or bicycle rack) on or around the rear sensors, the
system may activate if it detects these accessories as
an obstacle. In this case, turn off the rear sensor.

Customized Features

P. 426

Front Corner Sensors

Rear Corner Sensors

Rear Center Sensors

Front Center Sensors

Within about 24 in (60 cm) or less

Within about 43 in (110 cm) or less

* Not available on all models

Continued

653

Parking Your Vehicle

Parking Sensor System

Driving

■

Parking sensor system on and off

You can turn the system on and off using the driver information interface.

Switching the Display

P. 125, 154

Safety Support

P. 136, 164

The front corner, rear corner and rear center sensors start to detect an obstacle
when the transmission is in

(

, and the vehicle speed is less than 5 mph (8 km/h).

The front corner and front center sensors start to detect an obstacle when the
transmission is in any position other than

(

, and the vehicle speed is less

than 5 mph (8 km/h).

Parking sensor system on and off

When you set the power mode to ON, the system will
be in the previously selected condition.

You can turn the rear parking sensor system on and
off using the audio/information screen.

Customized Features

P. 426

When the Drive Mode is in

TOW

mode, the rear

parking sensor system will turn off.

Drive Mode System

P. 536

654

Parking Your Vehicle

Parking Sensor System

Driving

■

Screen Operation

You can switch between split view off and split view on by touching the split screen
tab.

Split Screen
Tab

Split View Off

Split View On

Models with multi-view rear camera system

Split Screen
Tab

Split View Off

Split View On

Models with surround view camera system

655

Parking Your Vehicle

Parking Sensor System

Continued

Driving

■

When the distance between your vehicle and obstacles becomes shorter

*1:On the driver information interface
*2:On the audio/information screen
*3:At this stage, only the center sensors detect obstacles.

Interval

between

beeps

Distance between the Bumper and Obstacle

Indicator

Driver information

interface

Audio/Information Screen

Corner Sensors

Center Sensors

Moderate

—

Front: About 43-29 in

(110-75 cm)

Rear: About 43-25 in

(110-65 cm)

Comes on

Blinks

in Yellow

Short

About 24-18 in

(60-45 cm)

Front: About 29-23 in

(75-60 cm)

Rear: About 25-19 in

(65-50 cm)

Comes on

Blinks

in Amber

Very short

About 18-14 in

(45-35 cm)

Front: About 23-19 in

(60-50 cm)

Rear: About 19-15 in

(50-40 cm)

Continuous

About 14 in

(35 cm) or less

Front: About 19 in

(50 cm) or less

Rear: About 15 in

(40 cm) or less

Comes on

Blinks

in Red

Indicators light up
where the sensor
detects an obstacle.

Indicators light up where the
sensor detects an obstacle.

656

Parking Your Vehicle

Parking Sensor System

Driving

To temporarily turn off the beeper, press the left

/right

selector wheel while it is sounding. Temporary OFF will be canceled when the

shift position is switched or the vehicle speed reaches 9 mph (14 km/h) or higher.
*1: Models with A-type meter
*2: Models with B-type meter

657

Parking Your Vehicle

Cross Traffic Monitor

Continued

Driving

Cross Traffic Monitor

Monitors the rear corner areas using the radar sensors when reversing, and alerts
you if a vehicle approaching from a rear corner is detected.

The system is convenient when you are backing out of a parking space.

Cross Traffic Monitor

CAUTION

Cross Traffic Monitor cannot detect all
approaching vehicles and may not detect
an approaching vehicle at all.

Failure to visually confirm that it is safe to
back up the vehicle before doing so may
result in a collision.

Do not solely rely on the system when
reversing; always also use your mirrors, and
look behind and to the sides of your vehicle
before reversing.

* Not available on all models

Parking Your Vehicle

Cross Traffic Monitor

658

Driving

The system activates when:

•

The power mode is in ON.

•

The Cross Traffic Monitor is turned on.

Cross Traffic Monitor On and Off

P. 660

•

The transmission is in

(

•

Your vehicle is moving at 3 mph (5 km/h) or
lower.

When a vehicle is detected approaching from a rear corner, Cross Traffic Monitor
alerts you with a buzzer and a displayed warning.

The system will not detect a vehicle that approaches from directly behind your
vehicle, nor will it provide alerts about a detected vehicle when it moves directly
behind your vehicle.

The system does not provide alerts for a vehicle that is moving away from your
vehicle, and it may alert for pedestrians, bicycles, or stationary objects.

■

How the System Works

Cross Traffic Monitor

Cross Traffic Monitor may not detect or may delay
alerting an approaching vehicle, or may alert without
an approaching vehicle under the following
conditions:

•

An obstacle, such as another vehicle or a wall near
your vehicle's rear bumper, is blocking the radar
sensor's scope.

•

Your vehicle is moving at a speed of about 3 mph
(5 km/h) or higher.

•

A vehicle is approaching at a speed other than
between about 6 and 16 mph (10 and 25 km/h).

•

The system picks up external interference such as
other radar sensors from another vehicle or strong
radio wave transmitted from a facility nearby.

•

Either corner of the rear bumper is covered with
snow, ice, mud or dirt.

•

When there is bad weather.

•

Your vehicle is on an incline.

•

Your vehicle is tilted due to a heavy load in the rear.

•

Your vehicle is reversing toward a wall, a pole, a
vehicle, and so on.

•

When driving for long distances on a road in a
trafficless area such as a desert.

If the rear bumper or the sensors have been
improperly repaired or the rear bumper has been
deformed. Have a vehicle checked by a dealer.

For proper operation, always keep the rear bumper
corner area clean.
Do not cover the rear bumper corner area with labels
or stickers of any kind.

Radar sensors:
Underneath the rear bumper
corners

* Not available on all models

Continued

659

Parking Your Vehicle

Cross Traffic Monitor

Driving

An arrow icon appears on the side a vehicle is approaching on the audio/information
screen.

■

When the System Detects a Vehicle

When the System Detects a Vehicle

If the

changes to

in amber when the

transmission is in

(

, mud, snow or ice, etc. may

have accumulated in the vicinity of the sensor. The
system is temporarily canceled. Check the bumper
corners for any obstructions, and thoroughly clean
the area if necessary.

If the

comes on when the transmission is in

(

there may be a problem with the Cross Traffic
Monitor system. Do not use the system and have your
vehicle checked by a dealer.

If the display remains the same with the transmission
in

(

, there may be a problem with the rear camera

system and the Cross Traffic Monitor system.
Do not use the system and have your vehicle checked
by a dealer.

Wide View

Normal View

Arrow Icon

Models with multi-view rear camera system

Top Down View

Rear Wide View/
Ground View

Rear Normal View/
Ground View

Arrow Icon

Models with surround view camera system

Parking Your Vehicle

Cross Traffic Monitor

660

Driving

The system can be turned on and off on the
audio/information screen by selecting the
Cross Traffic Monitor icon.

■

Cross Traffic Monitor On and Off

Cross Traffic Monitor On and Off

You can also switch the system on and off using the
audio/information screen.

Customized Features

P. 421, 426

Cross Traffic Monitor icon

Models with multi-view rear camera
system

Cross Traffic Monitor icon

Models with surround view camera
system

661

Continued

Driving

Multi-View Rear Camera

About Your Multi-View Rear Camera

The audio/information screen can display your vehicle’s rear view.
The display automatically changes to the rear view when the transmission is put into

(

■

Multi-View Rear Camera Display Area

About Your Multi-View Rear Camera

The rear camera view is restricted. You cannot see
the corner ends of the bumper or what is underneath
the bumper. Its unique lens also makes objects
appear closer or farther than they actually are.

Visually confirm that it is safe to drive before backing
up. Certain conditions (such as weather, lighting, and
high temperatures) may also restrict the rear view. Do
not rely on the rearview display which does not give
you all information about conditions at the back of
your vehicle.

The rear camera view is displayed prior to the audio/
information screen.

If the camera lens is covered with dirt or moisture,
activate the rearview camera washer or use a soft,
moist cloth to keep the lens clean and free of debris.

Rear Wiper/Washer

P. 231

You can change the

Fixed Guideline

and

Dynamic

Guideline

settings.

Customized Features

P. 421, 426

Fixed Guideline
ON:

Guidelines appear when you put the

transmission into

(

OFF:

Guidelines do not appear.

Dynamic Guideline
ON:

Guidelines move according to the steering

wheel direction.

OFF:

Guidelines do not move.

Approx. 39 inches (1 m)

Camera

Tailgate open range

* Not available on all models

Multi-View Rear Camera

About Your Multi-View Rear Camera

662

Driving

You can view three different camera modes on the audio/information screen.
Touch the appropriate icon to switch the mode.

•

If you were last using Wide view mode or Normal view mode, the same view
mode will be activated the next time you put the transmission into

(

•

If you were using Top down view mode before you turned off the engine, Wide
view mode will be activated the next time you set the power mode to ON and put
the transmission into

(

•

If you were using Top down view mode and 10 seconds elapsed after you took
the transmission out of

(

, Wide view mode will be activated the next time you

put the transmission into

(

•

If you were using Top down view mode and put the transmission back into

(

within 10 seconds after you took it out of

(

, Top down view mode will be

activated.

Bumper

Wide view mode

Normal view mode

Top down view mode

About Your Multi-View Rear Camera

If the vehicle’s rear view is not displayed on the audio/
information screen while the shift position is in

(

there may be a problem with the system. Have your
vehicle checked by a dealer immediately.

663

Driving

Surround View Camera System

Is a four camera system that views areas commonly known as “blind spots” from
different angles, then displays the images on the audio/information screen. This
system can be used to:

•

Check for obstacles when you are moving in

(

Checking for obstacles at the back of your vehicle

P. 672

•

Check the right and left sides of the vehicle while crossing at intersections with
poor visibility (obstructed view, etc.).

Checking from the front wide view at intersections

P. 670

•

Check for obstacles in front of the vehicle when parking or maneuvering in
confined areas.

Checking the front and sides of your vehicle

P. 669

Checking the sides of your vehicle

P. 671

Surround View Camera System

WARNING

Failure to visually assess the area around
the vehicle (directly or by use of the
mirrors) may result in a crash causing
serious injury or death.

The areas shown in the surround view
camera system display are limited. The
display may not show all pedestrians or
other objects around your vehicle.

Do not solely rely only on the surround
view camera system display to assess
whether it is safe to move your vehicle.

WARNING

Failure to pay proper attention to your
surroundings while driving may result in a
crash causing serious injury or death.

To help mitigate the chances of a collision,
only look at the surround view camera
system display when it is safe to do so.

* Not available on all models

664

Surround View Camera System

Displaying an Image From the Surround View Cameras

Driving

Displaying an Image From the Surround View
Cameras

■

For frontal views:

Press the

CAMERA

button when the vehicle is

stationary or moving at 12 mph (20 km/h) or
slower.

■

For rear reviews:

Change the shift position to

(

when the

vehicle is stationary. Press the

CAMERA

button to switch to rear view mode.

You can customize the display setting.

Customized Features

P. 426

Surround View Camera System

The surround view camera system does not eliminate
all blind spots. The system is for your convenience only.
Always keep the camera lenses clean and free from
debris.

If the front or rear camera lens is covered with dirt or
moisture, activate the frontview or rearview camera
washer or use a soft, moist cloth to keep the lens clean
and free of debris.

Windshield Wipers/Washers

P. 229

Rear Wiper/Washer

P. 231

When the parking sensor system detects any
obstacles, the indicator will display.

Parking Sensor System

P. 652

When a vehicle is detected approaching from a rear
corner, Cross Traffic Monitor alerts you.

Cross Traffic Monitor

P. 657

CAMERA

Button

* Not available on all models

Continued

665

Surround View Camera System

Displaying an Image From the Surround View Cameras

Driving

Displaying an Image From the Surround View Cameras

The navigation system is disabled when the shift
position is in

(

Operating the navigation system or audio system
while the surround view camera system screen is
displayed cancels the surround view camera system
screen and starts up the navigation system screen.

If you press the

CAMERA

button while the vehicle

speed is more than 16 mph (25 km/h), the standby
screen appears.
When the vehicle speed is reduced below 12 mph (20
km/h), the screen switches to a surround view camera
system image.

When the drive mode is in

TRAIL

mode, images from

the Surround View Camera System are displayed
while your vehicle speed is about 12 mph (20 km/h)
or lower. When the vehicle’s speed reaches about 16
mph (25 km/h) or higher, the display will return to the
previous screen.

TRAIL Mode

P. 539

Surround View Camera Guideline accuracy degrades
off road.

TrailWatch

* Not available on all models

666

Surround View Camera System

Displaying an Image From the Surround View Cameras

Driving

■

Camera Locations and Images

Sideview Camera
(Passenger side)

Sideview Camera
(Driver side)

The unique surround view camera lenses make distances appear
differently than they actually are - objects seen on the audio/
information screen may appear closer or further away, and may be
distorted. This becomes more apparent the further away an object is
from your vehicle.

Front-view Camera

Rearview Camera

667

Surround View Camera System

Displaying an Image From the Surround View Cameras

Continued

Driving

Front Wide View

Front View + Ground View

Side View

Side View + Ground View

Rear Wide View + Ground View

Rear Wide View

Rear View + Ground View

Rear View

or
or

Surround View Camera System

Displaying an Image From the Surround View Cameras

668

Driving

The following can be displayed when the system is on.

Fixed Guideline

: Helps you to get a sense of a distance between your vehicle and

the rear surroundings. The distance may appear differently than the actual distance.

Dynamic Guideline

: Indicates vehicle direction while the steering wheel is in the

current position.

■

Reference Lines and Guides

Reference Lines and Guides

The positions/distances indicated by the guidelines
and camera views on the display may differ from the
actual positions/distances due to the changes in the
vehicle height, road conditions, and other factors.
The guidelines should be used as a reference only.

The guidelines can be turned on and off using the
audio/information screen.

Customized Features

P. 426

If you turn the guidelines off, they remain off until
you turn them back on.

Continued

669

Surround View Camera System

Displaying an Image From the Surround View Cameras

Driving

■

Checking the front and sides of your vehicle

You can display the front ground view screen using all the four cameras for the
system. Pressing the

CAMERA

button when the vehicle speed is at below 12 mph

(20 km/h) changes the image as follows.

■

Using the Surround View Camera System

Checking the front and sides of your vehicle

When the vehicle speed exceeds 16 mph (25 km/h),
the front or side view on the screen automatically
switches to the audio/information screen. The front
or side view screen resumes when the vehicle speed
is reduced below 12 mph (20 km/h).

0 mph (0 km/h)

Down

Camera

Screen

Camera

Screen

Audio/Information

Screen

Audio/Information

Screen

16 mph (25 km/h)

12 mph (20 km/h)

0 mph (0 km/h)

Approximate distance the
reference line indicates.

approx. 3 feet
(1 m)

Front Wide View

Front View + Ground View

When the
steering wheel
is turned more
than 90
degrees.

The dynamic guideline
appears approx. 14 inches
(35 cm) outside the vehicle
body.

Side View

Side View + Ground View

When the
steering wheel
is turned more
than 90
degrees.

The dynamic guideline
appears approx. 14 inches
(35 cm) outside the vehicle
body.

Surround View Camera System

Displaying an Image From the Surround View Cameras

670

Driving

■

Checking from the front wide view at intersections

The front wide view screen is useful when you need to check for vehicles crossing
from either direction at an intersection with poor visibility.

Checking from the front wide view at intersections

The front wide view image is a wide-angled view. The
displayed image will be largely distorted, and objects
may appear closer or more distant than they actually
are.

The angle provided by the
front wide view screen is
approx. 180 degrees.

Front Wide View Screen

When the vehicle speed is below 12 mph (20 km/h), press
the

CAMERA

button and touch the ground view icon.

Ground View Icon

Continued

671

Surround View Camera System

Displaying an Image From the Surround View Cameras

Driving

■

Checking the sides of your vehicle

The side view screens are convenient when you pull over at a curb or tollbooth, or
slowly pass by oncoming vehicles on a narrow road.

Checking the sides of your vehicle

When the door mirrors are folded, the side views
cannot be displayed.

approx.
16 inches
(40 cm)

Approximate distance the
projection lines indicate is
16 inches (40 cm) from
the vehicle.

Side Views
The images from the side cameras.

approx.
16 inches
(40 cm)

Side View

Side View + Ground View

Surround View Camera System

Displaying an Image From the Surround View Cameras

672

Driving

■

Checking for obstacles at the back of your vehicle

The display automatically changes to the rear view when the shift position is
changed to

(

Checking for obstacles at the back of your vehicle

The ground view can be displayed even with the door
mirrors folded. However, the viewable angle and
blind spot change.
Do not refer to the surround view camera system
when the door mirrors are folded.

Folded

Not folded

Rear Wide View

Rear Wide View + Ground View

When the
steering wheel
is turned more
than 90
degrees.

The dynamic guideline
appears approx. 16 inches
(40 cm) outside the vehicle
body.

Rear View

Rear View + Ground View

When the
steering wheel
is turned more
than 90
degrees.

The dynamic guideline
appears approx. 16 inches
(40 cm) outside the vehicle
body.

Continued

673

Surround View Camera System

Displaying an Image From the Surround View Cameras

Driving

Checking for obstacles at the back of your vehicle

When changing the gear position from/to

(

, you

may experience a delay in switching between the
audio/information screen and a rear view image.

Approximate
distances the guide
lines indicate

Approximate
distances the
projection lines
indicate

approx.
39 inches
(1 m)

approx.
28 inches
(72 cm)

674

Surround View Camera System

Displaying an Image From the Surround View Cameras

Driving

The system may not work properly under the following conditions.

■

Surround View Camera System Limitations

Conditions

Solutions

The images may not
appear clearly when:

●

You activate the system in bad weather (heavy rain,
snow, fog, etc.) or in the dark.

●

Camera temperatures are high.

●

A sudden change between light and dark such as an
entrance or exit of a tunnel.

●

You drive into the sunlight (e.g., at dawn or dusk.)

Do not use the surround view camera system but rely
only on visual confirmation until the conditions allow
the system to work properly.

●

A camera lens is covered with dirt, moisture, or
debris.

●

A camera lens is scratched.

Clean camera lenses with the frontview or rearview
camera washer or a soft cloth moisturized with water,
mild detergent or glass cleaner.

Windshield Wipers/Washers

P. 229

Rear Wiper/Washer

P. 231

The audio/information screen is dirty.

Wipe off the screen using a soft dry cloth.

A camera angle is
altered.

A camera or the area around the camera has been
severely impacted.

Do not use the surround view camera system and
contact a dealer.

An error message is displayed while the surround view camera system is in use.

675

Driving

Refueling

Fuel Information

■

Fuel recommendation

Use of a lower octane gasoline can cause a persistent, heavy metallic knocking noise
that can lead to engine damage.

■

Top tier detergent gasoline

Because the level of detergency and additives in gasoline vary in the market, Honda
endorses the use of “TOP TIER Detergent Gasoline” where available to help
maintain the performance and reliability of your vehicle. TOP TIER Detergent
Gasoline meets a new gasoline standard jointly established by leading automotive
manufacturers to meet the needs of today’s advanced engines.

Qualifying gasoline retailers will, in most cases, identify their gasoline as having met
“TOP TIER Detergent Gasoline” standards at the retail location. This fuel is
guaranteed to contain the proper level of detergent additives and be free of metallic
additives. The proper level of detergent additives, and absence of harmful metallic
additives in gasoline, help avoid buildup of deposits in your engine and emission
control system.

For further important fuel-related information for your vehicle, or on information on
gasoline that does not contain MMT, visit www.hondacars.com. In Canada, visit
www.honda.ca for additional information on gasoline. For more information on top
tier gasoline, visit

www.toptiergas.com

■

Fuel tank capacity: 18.5 US gal (70 L)

Unleaded gasoline, pump octane number 87 or higher

Fuel Information

NOTICE

We recommend quality gasoline containing
detergent additives that help prevent fuel system and
engine deposits. In addition, in order to maintain
good performance, fuel economy, and emissions
control, we strongly recommend the use of gasoline
that does NOT contain harmful manganese-based
fuel additives such as MMT, if such gasoline is
available.

Use of gasoline with these additives may adversely
affect performance, and cause the malfunction
indicator lamp on your instrument panel to come on.
If this happens, contact a dealer for service. Some
gasoline today is blended with oxygenates such as
ethanol. Your vehicle is designed to operate on
oxygenated gasoline containing up to 15% ethanol
by volume. Do not use gasoline containing methanol.
If you notice any undesirable operating symptoms, try
another service station or switch to another brand of
gasoline.

676

Refueling

How to Refuel

Driving

How to Refuel

Your fuel tank is not equipped with a fuel filler cap. You can insert the filler nozzle
directly into the filler neck. The tank seals itself again when you pull out the filler
nozzle.

Stop your vehicle with the service station
pump on the left side of the vehicle in the
rear.

Turn off the engine.

Unlock the driver’s door.

The fuel fill door on the outer side of the
vehicle will unlock.

Press and release the area indicated by the
arrow to release the fuel fill door. You will
hear a click and the lid will open slightly.

Manually pull the fuel fill door to a fully
open position.

How to Refuel

The fuel filler opening is designed to accept only
service station filler nozzles for refueling. Use of
smaller diameter tubes (e.g., those used to siphon
fuel for other uses) or other non-service station
devices can damage the area in and around the filler
opening.

Use the master door lock switch to unlock the fuel fill door.
The vehicle doors and fuel fill door automatically
relock if the keyless remote unlock function is used.
This can be deactivated by briefly opening then
closing the driver’s door.

Using the Walk away auto lock

feature will also lock

the fuel fill door. Always make sure both the driver’s
door and fuel fill door are unlocked before
attempting to open the fuel fill door.

Locking the doors and tailgate (Walk away
auto lock

)

P. 184

WARNING

Gasoline is highly flammable and explosive.
You can be burned or seriously injured
when handling fuel.

•

Stop the engine, and keep heat, sparks,
and flames away.

•

Handle fuel only outdoors.

•

Wipe up spills immediately.

Press

Honda Pilot (2024 year). Manual in english - page 20
