Checking and Maintaining Wiper Blades

Checking Wiper Blades

If the wiper blade rubber has deteriorated, it will leave streaks and become noisy,
and the hard surfaces of the blade may scratch the window glass.

Lifting the Front Wiper Arms

Set the power mode to VEHICLE OFF.

While holding the wiper switch in the

MIST

position, set the power mode to ON,

then to VEHICLE OFF.

Both wiper arms are set to the
maintenance position as shown in the
image.

Lift both wiper arms.

Lifting the Front Wiper Arms

NOTICE

When lifting the wiper arms, always follow the
instructions to move them into the maintenance
position.

The wiper arms may be damaged if they are moved
manually.

612

Checking and Maintaining Wiper Blades

Changing the Front Wiper Blade Rubber

Main

tenan

Changing the Front Wiper Blade Rubber

Lift both wiper arms.

Lifting the Front Wiper Arms

P. 611

Press up on and hold the tab, then slide the
holder off the wiper arm.

Pull the end of the wiper blade in the
direction of the arrow in the image until it is
out of the holder’s end cap.

Pull the wiper blade in the opposite
direction to slide it out of the holder.

Changing the Front Wiper Blade Rubber

NOTICE

Avoid dropping the wiper arm onto the windshield,
as it may damage the wiper arm and/or the
windshield.

Tab

Wiper
Blade

End Cap at
the bottom

Holder

Continued

613

Checking and Maintaining Wiper Blades

Changing the Rear Wiper Blade Rubber

Main

tenan

Insert the flat side of the new wiper blade
onto the bottom part of the holder. Insert
the blade all the way.

Install the end of the wiper blade into the
cap.

Slide the holder onto the wiper arm until it
locks.

Lower both wiper arms.

Set the power mode to ON and hold the
wiper switch in the

MIST

position until both

wiper arms return to the standard position.

Changing the Rear Wiper Blade Rubber

Raise the wiper arm off.

Pivot the bottom end of the wiper blade up
until it comes off from the wiper arm.

Cap

Wiper
Blade

Holder

Changing the Rear Wiper Blade Rubber

NOTICE

Do not try to forcefully lift up the wiper arm.
The wiper arm may be damaged if it is lifted too high.

NOTICE

Avoid dropping the wiper arm, as it may damage the
rear window.

Wiper
Blade

Wiper
Arm

614

Checking and Maintaining Wiper Blades

Changing the Rear Wiper Blade Rubber

Main

tenan

Slide the blade out of the holder.

Remove the retainers from wiper blade and
mount it to a new rubber blade.

Slide the new wiper blade onto the holder.

Make sure it is engaged correctly, then
install the wiper blade assembly onto the
wiper arm.

Blade

Retainer

Rubber

615

Main

tenan

Checking and Maintaining Tires

Checking Tires

To safely operate your vehicle, your tires must be of the proper type and size, in
good condition with adequate tread, and properly inflated.

■

Inflation guidelines

Properly inflated tires provide the best combination of handling, tread life, and
comfort. Refer to the driver’s doorjamb label or specifications page for the specified
pressure.

Underinflated tires wear unevenly, adversely affect handling and fuel economy, and
are more likely to fail from overheating.

Overinflated tires make your vehicle ride harshly, are more prone to road hazards,
and wear unevenly.

Every day before you drive, look at each of the tires. If one looks lower than the
others, check the pressure with a tire gauge.

At least once a month or before long trips, use a gauge to measure the pressure in
all tires, including the spare. Even tires in good condition can lose 1-2 psi (10-20 kPa,
0.1-0.2 kgf/cm

) per month.

■

Inspection guidelines

Every time you check inflation, also examine the tires and valve stems. Look for:

•

Bumps or bulges on the side or in the tread. Replace the tire if you find any cuts,
splits, or cracks in the side of the tire. Replace it if you see fabric or cord.

•

Remove any foreign objects and inspect for air leaks.

•

Uneven tread wear. Have a dealer check the wheel alignment.

•

Excessive tread wear.

Wear Indicators

P. 620

•

Cracks or other damage around valve stem.

Checking Tires

Measure the air pressure when tires are cold. This
means the vehicle has been parked for at least three
hours, or driven less than 1 mile (1.6 km). If
necessary, add or release air until the specified
pressure is reached.

If checked when hot, tire pressure can be as much as
4–6 psi (30–40 kPa, 0.3–0.4 kgf/cm

) higher than if

checked when cold.

Have a dealer check the tires if you feel a consistent
vibration while driving. New tires and any that have
been removed and reinstalled should be properly
balanced.

WARNING

Using tires that are excessively worn or
improperly inflated can cause a crash in
which you can be seriously hurt or killed.

Follow all instructions in this owner’s
manual regarding tire inflation and
maintenance.

616

Checking and Maintaining Tires

Tire and Loading Information Label

Main

tenan

Tire and Loading Information Label

The label attached to the driver’s doorjamb provides necessary tire and loading
information.

Tire Labeling

The tires that came on your vehicle have a
number of markings. Those you should be
aware of are described as shown.

Whenever tires are replaced, they should be replaced with tires of the same size.

Tire and Loading Information Label

The tire and loading information label attached to the
driver’s doorjamb contains:

The number of people your vehicle can carry.

The total weight your vehicle can carry. Do not
exceed this weight.

The original tire sizes for front, rear, and spare.

The proper cold tire pressure for front, rear, and
spare.

Label
Example

Example

Tire Size

Tire
Identification
Number (TIN)

Maximum
Tire Load

Maximum
Tire Pressure

Tire Size

■

Tire Sizes

Tire Sizes

Following is an example of tire size with an
explanation of what each component means.

P235/60 R18 102T

P: Vehicle type (P indicates passenger vehicle).
235: Tire width in millimeters.
60: Aspect ratio (the tire’s section height as a
percentage of its width).
R: Tire construction code (R indicates radial).
18: Rim diameter in inches.
102: Load index (a numerical code associated with
the maximum load the tire can carry).
T: Speed symbol (an alphabetical code indicating the
maximum speed rating).

617

Checking and Maintaining Tires

Tire Labeling

Main

tenan

The tire identification number (TIN) is a group of numbers and letters that look like
the examples in the side column. TIN is located on the sidewall of the tire.

Cold Tire Pressure

– The tire air pressure when the vehicle has been parked for at

least three hours or driven less than 1 mile (1.6 km).

Load Rating

– Means the maximum load that a tire is rated to carry for a given

inflation pressure.

Maximum Inflation Pressure

– The maximum tire air pressure that the tire can

hold.

Maximum Load Rating

– Means the load rating for a tire at the maximum

permissible inflation pressure for that tire.

Recommended Inflation Pressure

– The cold tire inflation pressure

recommended by the manufacturer.

Treadwear Indicators (TWI)

– Means the projections within the principal grooves

designed to give a visual indication of the degrees of wear of the tread.

■

Tire Identification Number (TIN)

■

Glossary of Tire Terminology

Tire Identification Number (TIN)

There are two different formats that TIN may be listed
in.

Format A

DOT B97R FW6X 2209

DOT: This indicates that the tire meets all
requirements of the U.S. Department of
Transportation.
B97R: Manufacturer’s identification mark.
FW6X: Tire type code.
22 09: Date of manufacture.

Year
Week

Format B

DOT 1A3 OFBEKP 1522

DOT: This indicates that the tire meets all
requirements of the U.S. Department of
Transportation.
1A3: PLANT CODE
OFBEKP: MANUFACTURE CODE
15 22: DATE CODE

Year
Week

618

Checking and Maintaining Tires

DOT Tire Quality Grading (U.S. Vehicles)

Main

tenan

DOT Tire Quality Grading (U.S. Vehicles)

The tires on your vehicle meet all U.S. Federal Safety
Requirements. All tires are also graded for treadwear, traction,
and temperature performance according to Department of
Transportation (DOT) standards. The following explains these
gradings.

Quality grades can be found where applicable on the tire sidewall
between tread shoulder and maximum section width.

The treadwear grade is a comparative rating based on the wear
rate of the tire when tested under controlled conditions on a
specified government test course. For example, a tire graded 150
would wear one and one-half (1 1/2) times as well on the
government course as a tire graded 100. The relative performance
of tires depends upon the actual conditions of their use, however,
and may depart significantly from the norm due to variations in
driving habits, service practices and differences in road
characteristics and climate.

■

Uniform Tire Quality Grading

■

Treadwear

Uniform Tire Quality Grading

For example:

Treadwear 200
Traction AA
Temperature A

All passenger car tires must conform
to Federal Safety Requirements in
addition to these grades.

619

Checking and Maintaining Tires

DOT Tire Quality Grading (U.S. Vehicles)

Main

tenan

The traction grades, from highest to lowest, are AA, A, B, and C.
Those grades represent the tire’s ability to stop on wet pavement
as measured under controlled conditions on specified
government test surfaces of asphalt and concrete. A tire marked
C may have poor traction performance.

The temperature grades are A (the highest), B, and C,
representing the tire’s resistance to the generation of heat and its
ability to dissipate heat when tested under controlled conditions
on a specified indoor laboratory test wheel. Sustained high
temperature can cause the material of the tire to degenerate and
reduce tire life, and excessive temperature can lead to sudden tire
failure. The grade C corresponds to a level of performance which
all passenger car tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A represent higher levels
of performance on the laboratory test wheel than the minimum
required by law.

■

Traction

■

Temperature

Traction

Warning: The traction grade
assigned to this tire is based on
straight-ahead braking traction tests,
and does not include acceleration,
cornering, hydroplaning, or peak
traction characteristics.

Temperature

Warning: The temperature grade for
this tire is established for a tire that is
properly inflated and not
overloaded. Excessive speed,
underinflation, or excessive loading,
either separately or in combination,
can cause heat buildup and possible
tire failure.

620

Checking and Maintaining Tires

Wear Indicators

Main

tenan

Wear Indicators

The groove where the wear indicator is
located is about 1/16 inch (about 1.6 mm)
shallower than elsewhere on the tire. If the
tread has worn so that the indicator is
exposed, replace the tire.

Worn out tires have poor traction on wet
roads.

Tire Service Life

The life of your tires is dependent on many factors, including driving habits, road
conditions, vehicle loading, inflation pressure, maintenance history, speed, and
environmental conditions (even when the tires are not in use).

In addition to regular inspections and inflation pressure maintenance, it is
recommended that you have annual inspections performed once the tires reach five
years old. All tires, including the spare, should be removed from service after 10
years from the date of manufacture, regardless of their condition or state of wear.

Example of a Wear
Indicator mark

621

Checking and Maintaining Tires

Tire and Wheel Replacement

Main

tenan

Tire and Wheel Replacement

Replace your tires with radials of the same size, load range, speed rating, and
maximum cold tire pressure rating (as shown on the tire’s sidewall). Using tires of a
different size or construction can cause certain vehicle systems such as the ABS and
Vehicle Stability Assist

(VSA

) system to work incorrectly.

It is best to replace all four tires at the same time. If that isn’t possible, replace the
front or rear tires in pairs.

Whenever you have a tire replaced or reset, make sure that the rubber valve stem is
replaced and that the TPMS sensor is transferred from the old valve stem to the new
one.

If you replace a wheel, make sure that the wheel’s specifications match those of the
original wheels.

Tire and Wheel Replacement

WARNING

Installing improper tires on your vehicle can
affect handling and stability. This can cause
a crash in which you can be seriously hurt or
killed.

Always use the size and type of tires
recommended in this owner’s manual.

622

Checking and Maintaining Tires

Tire Rotation

Main

tenan

Tire Rotation

Rotating tires according to the maintenance messages on the driver information
interface helps to distribute wear more evenly and increase tire life.

■

Tires without rotation marks

Rotate the tires as shown here.

■

Tires with rotation marks

Rotate the tires as shown here.

Tire Rotation

Tires with directional tread patterns should only be
rotated front to back (not from one side to the other).
Directional tires should be mounted with the rotation
indication mark facing forward, as shown below.

Front

Rotation Mark

Front

623

Checking and Maintaining Tires

Winter Tires

Main

tenan

Winter Tires

If driving on snowy or frozen roads, mount all season marked

M+S

tires, snow tires,

or tire chains; reduce speed; and maintain sufficient distance between vehicles when
driving.

Be particularly careful when operating the steering wheel or brakes to prevent
skidding.

Use tire chains, snow tires, or all season tires when necessary or according to the
law.

When mounting, refer to the following points.

For winter tires:

•

Select the size and load ranges that are the same as the original tires.

•

Mount the tires to all four wheels.

For tire chains:

•

Install them on the front tires only.

•

Because your vehicle has limited tire clearance, we strongly recommend using the
chains listed below:

•

Follow the chain manufacturer’s instruction when installing. Mount them as
tightly as you can.

•

Check that the chains do not touch the brake lines or suspension.

•

Drive slowly.

Peerless Auto-Trac 231905

Peerless Auto-Trac 232405

Winter Tires

NOTICE

Traction devices that are the wrong size or improperly
installed can damage your vehicle’s brake lines,
suspension, body, and wheels. Stop driving if they are
hitting any part of the vehicle.

When tire chains are mounted, follow the chain
manufacturer’s instructions regarding vehicle
operational limits.

If your vehicle is equipped with summer tires, be
aware that these tires are not designed for winter
driving conditions. For more information, contact a
dealer.

WARNING

Using the wrong chains, or not properly
installing chains, can damage the brake
lines and cause a crash in which you can be
seriously injured or killed.

Follow all instructions in this owner’s
manual regarding the selection and use of
tire chains.

Models with 235/60R18 tires

Models with 235/55R19 tires

624

Main

tenan

Battery

Checking the Battery

The condition of the battery is monitored by a
sensor located on the negative terminal of the
battery. If there is a problem with this sensor,
the driver information interface will display a
warning message. If this happens, have your
vehicle inspected by a dealer.

Check the battery terminals for corrosion
monthly.

To access the battery terminals:

Remove the engine compartment cover.

Engine Compartment Cover

P. 593

Remove the clips using a Phillips-head
screwdriver, then remove the air intake
duct.

If your vehicle’s battery is disconnected or goes dead:

•

The audio system is disabled.

Reactivating the audio system

P. 261

•

The clock resets.

Clock

P. 144

•

The immobilizer system needs to be reset.

Immobilizer System Indicator

P. 98

Battery

WARNING:

Battery post, terminals,

and related accessories contain lead
and lead compounds.

Wash your hands after handling.

When you find corrosion, clean the battery terminals
by applying a baking powder and water solution.
Clean the terminals with a damp towel. Cloth/towel
dry the battery. Coat the terminals with grease to
help prevent future corrosion.

When replacing the battery, the replacement must be
of the same specifications.
Consult a dealer for more information.

WARNING

The battery gives off explosive hydrogen
gas during normal operation.

A spark or flame can cause the battery to
explode with enough force to kill or
seriously hurt you.

When conducting any battery
maintenance, wear protective clothing and
a face shield, or have a skilled technician do
it.

Clip

Air Intake Duct

Canadian models only

625

Battery

Charging the AGM Battery

Main

tenan

Charging the AGM Battery

AGM labeled batteries like those installed in your vehicle require a compatible
charger to be properly charged. Damage to the battery can result if the battery is
charged improperly or with the wrong equipment. For more information on how to
charge your vehicle’s AGM battery, consult a dealer.

Battery

The battery installed in this vehicle is specifically
designed for a model with Auto Idle Stop.
Using a battery other than this specified type may
shorten the battery life, and prevent Auto Idle Stop
from activating. If you need to replace the battery,
make sure to select the specified type and size. Ask a
dealer for more details.

626

Main

tenan

Remote Transmitter Care

Replacing the Remote Battery

If the indicator does not come on when the button is pressed, replace the battery.

Remove the built-in key.

Remove the upper half of the cover by
carefully prying on the edge with a coin.

Wrap a coin with a cloth to prevent
scratching the remote.

Remove carefully to avoid losing the
buttons.

Make sure to replace the battery with the
correct polarity.

Replacing the Remote Battery

NOTICE

An improperly disposed of battery can damage the
environment. Always confirm local regulations for
battery disposal.

Replacement batteries are commercially available or
at a dealer.

WARNING

CHEMICAL BURN HAZARD

The battery that powers the remote
transmitter can cause severe internal burns
and can even lead to death if swallowed.
Keep new and used batteries away from
children.

If you suspect that a child has swallowed
the battery, seek medical attention
immediately.

Battery type: CR2032

Battery

627

Continued

Main

tenan

Remote Control and Wireless Headphone Care

Replacing the Battery

If it takes several pushes on the remote control buttons to operate the Blu-ray/DVD
rear entertainment system, replace the batteries.

Remove the cover.

Make sure to replace the batteries with the
correct polarity.

■

Remote Control

Models with Blu-ray/DVD rear entertainment system

Replacing the Battery

NOTICE

An improperly disposed of battery can damage the
environment. Always confirm local regulations for
battery disposal.

Replacement batteries are commercially available or
at a dealer.

Make sure to replace the two batteries at once.

Battery type: AAA

* Not available on all models

628

Remote Control and Wireless Headphone Care

Replacing the Battery

Main

tenan

If there is no sound coming from the wireless headphones, replace the batteries.

Remove the screw.

Open the cover.

Make sure to replace the batteries with the
correct polarity.

■

Wireless Headphones

Battery type: AAA

Cover

Batteries

629

Main

tenan

Climate Control System Maintenance

Air Conditioning

To ensure proper and safe operation, the Society of Automotive Engineers (SAE
J2845) recommends that the refrigerant system only be serviced by trained and
certified technicians.

Never repair or replace the air conditioning evaporator (cooling coil) with one
removed from a used or salvaged vehicle.

New replacement mobile air conditioning evaporators must be certified (and
labeled) as meeting SAE Standard J2842.

Dust and Pollen Filter

The climate control system is equipped with a dust and pollen filter that collects
pollen, dust, and other debris in the air. The Maintenance Minder

messages will let

you know when to replace the filter.

We recommend that you replace the dust and pollen filter sooner when using your
vehicle in areas with high concentrations of dust.

Air Conditioning

NOTICE

Vented refrigerant is harmful to the environment.
To avoid refrigerant from venting, never replace the
evaporator with one removed from a used or
salvaged vehicle.

Refrigerant in your vehicle’s air conditioning system is
flammable and can be ignited during servicing if
proper procedures are not followed.

The air conditioner label is found under the hood:

Safety Labels

P. 86

Specifications

P. 678

Canadian models

Caution

Flammable Refrigerant

Requires Registered
Technician to Service

Air Conditioning
System

Dust and Pollen Filter

If the airflow from the climate control system
deteriorates noticeably, and the windows fog up
easily, the filter may need to be replaced. Please
contact a dealer for replacement.

630

Main

tenan

Cleaning

Interior Care

Use a damp cloth with a mixture of mild detergent and warm water to remove dirt.
Use a clean cloth to remove detergent residue.

Use a soft brush with a mixture of mild soap and warm water to clean the seat belts.
Let the belts air dry. Wipe the loops of the seat belt anchors using a clean cloth.

Wipe using a glass cleaner.

■

Cleaning Seat Belts

Interior Care

Do not spill liquids inside the vehicle. Electrical
devices and systems may malfunction if liquids are
splashed on them.

Do not use silicone-based sprays on electrical devices
such as audio devices and switches. Doing so may
cause the items to malfunction or cause a fire inside
the vehicle.
If a silicone-based spray is inadvertently used on
electrical devices, consult a dealer.

Depending on their composition, chemicals and
liquid aromatics may cause discoloration, wrinkles,
and cracking to resin-based parts and textiles.
Do not use alkali solvents or organic solvents such as
benzene or gasoline.

After using chemicals, make sure to gently wipe them
off using a dry cloth.
Do not place used cloths on top of resin-based parts
or textiles for long periods of time without washing.

Loop

■

Cleaning the Window

Cleaning the Window

Wires are mounted to the inside of the rear window.
Wipe along the same direction as the wires with a
soft cloth so as not to damage them.

Be careful not to spill fluids, such as water or glass
cleaner, on or around the cover of the electrical
components around the rearview mirror.

631

Cleaning

Interior Care

Main

tenan

The driver’s floor mat hooks over floor
anchors, which keep the mat from sliding
forward.

Do not put any additional floor mats on
top of the anchored mat.

To properly clean leather:

Use a vacuum or soft dry cloth first to remove any dirt or dust.

Clean the leather with a soft cloth dampened with a solution comprised of 90%
water and 10% neutral soap.

Wipe away any soap residue with a clean damp cloth.

Wipe away residual water and allow leather to air dry in the shade.

■

Floor Mats

Floor Mats

If you use any floor mats that were not originally
provided with your vehicle, make sure they are
designed for your specific vehicle, fit correctly, and
are securely anchored by the floor anchors.
Position any second row seat floor mat properly. If
not properly positioned, the floor mat can interfere
with the front seat functions.

Unlock

Lock

Example

■

Maintaining Genuine Leather

Maintaining Genuine Leather

It is important to clean or wipe away dirt or dust as
soon as possible. Spills can soak into leather, resulting
in stains. Dirt or dust can cause abrasions in the
leather. In addition, please note that some dark
colored clothing can rub onto the leather seats,
resulting in discoloration or stains.

* Not available on all models

632

Cleaning

Exterior Care

Main

tenan

Exterior Care

Dust off the vehicle body after you drive. Regularly inspect your vehicle for scratches
on painted surfaces. A scratch on a painted surface can result in body rust. If you
find a scratch, promptly repair it.

Wash the vehicle regularly. Wash more frequently when driving in the following
conditions:

•

If driving on roads with road salt.

•

If driving in coastal areas.

•

If tar, soot, bird droppings, insects, or tree sap is stuck to painted surfaces.

■

Washing the Vehicle

Washing the Vehicle

Do not spray water into the air intake vents. It can
cause a malfunction.

Lock the doors when washing the vehicle. Do not
spray water onto the capless unit when the fuel fill
door is open. It can cause damage to the fuel system
or engine.

If you need to lift the wiper arms away from the
windshield, first set the wiper arms to the
maintenance position.

Lifting the Front Wiper Arms

P. 611

Air
Intake
Vents

Continued

633

Cleaning

Exterior Care

Main

tenan

•

Make sure to follow the instructions indicated on the automated car wash.

•

Fold in the door mirrors.

•

For models equipped with automatic intermittent wipers, turn the wipers off.

•

Keep sufficient distance between the cleaning nozzle and the vehicle body.

•

Take particular care around the windows. Standing too close may cause water to
enter the vehicle interior.

•

Do not spray high pressure water directly into the engine compartment. Instead,
use low pressure water and a mild detergent.

•

Do not spray water directly onto the camera or the area around it. Water may
enter the lens and cause the camera to malfunction.

A good coat of automotive body wax helps protect your vehicle’s paint from the
elements. Wax will wear off over time and expose your vehicle’s paint to the
elements, so reapply as necessary.

If you get gasoline, oil, engine coolant, or battery fluid on resin-coated parts, they
may stain or the coating may peel. Promptly wipe it away using a soft cloth and
clean water.

■

Using an Automated Car Wash

■

Using High Pressure Cleaners

■

Applying Wax

■

Maintaining the Bumpers and Other Resin-Coated Parts

Using an Automated Car Wash

When using an automated car wash that pulls the
vehicle through with a conveyor, make sure the
transmission in

(

position.

If you want to keep the transmission in

(

position [car wash mode]

P. 482

Applying Wax

NOTICE

Chemical solvents and strong cleaners can damage
the paint, metal, and plastic on your vehicle. Wipe
away spills immediately.

Maintaining the Bumpers and Other Resin-Coated Parts

Ask a dealer about the correct coating material when
you want to repair the painted surface of the parts
made of resin.

634

Cleaning

Exterior Care

Main

tenan

Wipe using a glass cleaner.

Aluminum is susceptible to deterioration caused by salt and other road
contaminants. When necessary, as early as possible use a sponge and mild detergent
to wipe away these contaminants. Do not use a stiff brush or harsh chemicals
(including some commercial wheel cleaners). These can damage the protective finish
on aluminum alloy wheels, resulting in corrosion. Depending on the type of finish,
the wheels also may lose their luster or appear burnished. To avoid water stains,
wipe the wheels dry with a cloth while they are still wet.

The inside lenses of exterior lights (headlights, brake lights, etc.) may fog temporarily
if you have driven in the rain, or after the vehicle has been run through a car wash.
Dew condensation also may build up inside the lenses when there is a significant
enough difference between the ambient and inside lens temperatures (similar to
vehicle windows fogging up in rainy conditions). These conditions are natural
processes, not structural design problems in the exterior lights.
Lens design characteristics may result in moisture developing on the light lens frame
surfaces. This also is not a malfunction.
However, if you see large amounts of water accumulation, or large water drops
building up inside the lenses, have your vehicle inspected by a dealer.

■

Cleaning the Window

■

Maintaining Aluminum Wheels

■

Fogged Exterior Light Lenses

635

Main

tenan

Accessories and Modifications

Accessories

When installing accessories, check the following:

•

Do not install accessories on the windshield. They can obstruct your view and
delay your reaction to driving conditions.

•

Do not install any items other than Honda Genuine Accessories designated for
your vehicle over areas marked

SRS AIRBAG

, on the sides or backs of the front

seats, on front or side pillars, or near the side windows.
Items other than Honda Genuine Accessories designated for your vehicle installed
in these areas may interfere with proper operation of the vehicle’s airbags or may
be propelled into you or another occupant if the airbags deploy.

•

Be sure electronic accessories do not overload electrical circuits or interfere with
proper operation of your vehicle.

Fuses

P. 662

•

Before installing any electronic accessory, have the installer contact a dealer for
assistance. If possible, have a dealer inspect the final installation.

Accessories and Modifications

Honda Genuine Accessories are recommended to
ensure proper operation on your vehicle.

Some Honda Genuine Accessories are supplied with
an exclusive owner’s manual for the operation and
care detail of the product. If an accessory owner’s
manual is provided to you, please refer to it for full
detail.

If any Honda Genuine Accessories become
inoperable, refer to the separate accessory owner’s
manual (if applicable) or consult a dealer for
assistance to troubleshoot the potential faulty
condition.

WARNING

Improper accessories or modifications can
affect your vehicle’s handling, stability, and
performance, and cause a crash in which
you can be seriously hurt or killed.

Follow all instructions in this owner’s
manual regarding accessories and
modifications.

636

Accessories and Modifications

Modifications

Main

tenan

Modifications

Do not modify your vehicle in a manner that may affect its handling, stability, or
reliability, or install non-genuine Honda parts or accessories that may have a similar
effect.

Even minor modifications to vehicle systems can affect overall vehicle performance.
Always make sure all equipment is properly installed and maintained, and do not
make any modification to your vehicle or its systems that might cause your vehicle
to no longer meet federal, state, province, territory, and local regulations.

The on-board diagnostic port (OBD-II/SAE J1962 connector) installed on this vehicle
is intended to be used with automobile system diagnostic devices or with other
devices that Honda has approved. Use of any other type of device may adversely
affect the vehicle’s electronic systems or allow them to be compromised, possibly
resulting in a system malfunction, drained battery, or other unexpected problems.

Do not modify or attempt to repair any of the electrical components.

638

Han

lin
g the U

expected

Tools

Types of Tools

Types of Tools

The tools are stored in front of the second row seat
and in the right side panel of the cargo area.

Wheel Nut Wrench/

Jack Handle

Jack

Jack Handle Bar

Bracket

Mounting Wing

Bolt (B)

Mounting Wing

Bolt (A)

Tire Strap/

Tire Storage Bag

Funnel

639

Continued

Han

lin
g the U

expected

If a Tire Goes Flat

Changing a Flat Tire

If a tire goes flat while driving, grasp the steering wheel firmly and brake gradually
to reduce speed. Then, stop in a safe place. Replace the flat tire with a compact
spare tire. Go to a dealer as soon as possible to have the regular tire repaired or
replaced.

Park the vehicle on a firm, level, non-slippery surface and apply the parking brake.

Put the transmission into

(

Turn on the hazard warning lights and set the power mode to VEHICLE OFF.

Changing a Flat Tire

Follow compact spare precautions:
Periodically check the tire pressure of the compact
spare. It should be set to the specified pressure.
Specified Pressure: 60 psi (420 kPa, 4.2 kgf/cm

)

When driving with the compact spare tire, keep the
vehicle speed under 50 mph (80 km/h). Replace with
a regular tire as soon as possible.

The compact spare tire and wheel in your vehicle are
specifically for this model. Do not use them with
another vehicle. Do not use another type of compact
spare tire or wheel with your vehicle.

Do not mount tire chains on a compact spare tire.
If a chain-mounted front tire goes flat, remove one of
the regular rear tires and replace it with the compact
spare tire. Remove the flat front tire and replace it
with the regular tire that was removed from the rear.
Mount the tire chains on the front tire.

Do not use the jack if it doesn’t work properly. Call
your dealer or a professional towing service.

640

If a Tire Goes Flat

Changing a Flat Tire

Han

lin
g the U

expected

Remove the second row floor mat.

Floor Mats

P. 631

Pull up the floor carpet.

Lift up the floor lid using the handle and
remove it.

Take the tool case out of the spare tire well.
Take the jack and wheel nut wrench out of
the tool case.

Unscrew the wing bolt, then remove the
compact spare tire.

Place a wheel block or rock in front and rear
of the wheel diagonal to the flat tire.

■

Getting Ready to Replace the Flat Tire

Floor Carpet

Handle

Floor Lid

Compact
Spare Tire

Tool Case

Wheel
Blocks

The tire to be replaced.

641

If a Tire Goes Flat

Changing a Flat Tire

Continued

Han

lin
g the U

expected

Place the compact spare tire (wheel side up)
under the vehicle body, near the tire that
needs to be replaced.

Loosen each wheel nut about one turn
using the wheel nut wrench.

If a Tire Goes Flat

Changing a Flat Tire

642

Han

lin
g the U

expected

Place the jack under the jacking point
closest to the tire to be changed.

Turn the end bracket clockwise as shown in
the image until the top of the jack contacts
the jacking point.

Make sure that the jacking point tab is
resting in the jack notch.

Raise the vehicle, using the jack handle bar
and the jack handle, until the tire is off the
ground.

■

How to Set Up the Jack

How to Set Up the Jack

Do not use the jack with people or luggage in the
vehicle.

Use the jack provided in your vehicle.
Other jacks may not support the weight (“load”) or
may not fit the jacking point.

The following instructions must be followed to use
the jack safely:

•

Do not use while the engine is running.

•

Use only where the ground is firm and level.

•

Use only at the jacking points.

•

Do not get in the vehicle while using the jack.

•

Do not put anything on top of or underneath the
jack.

Turn off the sliding door main switch before
replacing a rear tire. If the main switch is on, the
power sliding door may accidentally operate, causing
an accident.

WARNING

The vehicle can easily roll off the jack,
seriously injuring anyone underneath.

Follow the directions for changing a tire
exactly, and never get under the vehicle
when it is supported only by the jack.

Jack
Handle
Bar

Wheel Nut

Wrench as Jack Handle

Honda Odyssey (2024 year). Manual in english - page 19
