Honda CR-V (2024 year). Manual in english - page 20

648

Indicator, Coming On/Blinking

If the Charging System Indicator Comes On

Han

lin
g the U

expected

If the Charging System Indicator Comes On

■

Reasons for the indicator to come on

Comes on when there is a problem with the charging system.

■

What to do when the indicator comes on

Stop in a safe place and have your vehicle checked by a dealer
immediately.

If the Malfunction Indicator Lamp Comes On or Blinks

■

Reasons for the indicator lamp to come on or blink

•

Comes on when there is a problem with the engine emissions control
system.

•

Blinks when engine misfiring is detected.

■

What to do when the indicator lamp comes on

Avoid high speeds and immediately get your vehicle inspected at a
dealer.

■

What to do when the indicator lamp blinks

Park the vehicle in a safe place with no flammable items and wait at least
10 minutes or more with the engine stopped until it cools.

If the Charging System Indicator Comes On

If you need to stop temporarily, do not turn off the
engine. Restarting the engine may rapidly discharge
the battery.

If the Malfunction Indicator Lamp Comes On or Blinks

NOTICE

If you drive with the malfunction indicator lamp on,
the emissions control system and the engine could be
damaged.

If the malfunction indicator lamp blinks again when
restarting the engine, drive to the nearest dealer at
31 mph (50 km/h) or less. Have your vehicle
inspected.

649

Indicator, Coming On/Blinking

If the Brake System Indicator (Red) Comes On or Blinks

Han

lin
g the U

expected

If the Brake System Indicator (Red) Comes On or Blinks

■

Reasons for the indicator to come on

•

The brake fluid is low.

•

There is a malfunction in the brake system.

■

What to do when the indicator comes on while driving

Depress the brake pedal lightly to check pedal pressure.

•

If normal, check the brake fluid level the next time you stop.

•

If abnormal, take immediate action. If necessary, downshift the
transmission to slow the vehicle using engine braking.

■

Reason for the indicator to blink

There is a problem with the electric parking brake system.

■

What to do when the indicator blinks

Avoid using the parking brake and have your vehicle checked by a dealer
immediately.

If the Brake System Indicator (Red) Comes On or Blinks

Have your vehicle repaired immediately.
It is dangerous to drive with low brake fluid. If there
is no resistance from the brake pedal, stop
immediately in a safe place. If necessary downshift
the gears.

If the brake system indicator (red) and

ABS

indicator

come on simultaneously, the electronic brake
distribution system is not working. This can result in
vehicle instability under sudden braking.
Have your vehicle inspected by a dealer immediately.

If the brake system indicator (red) blinks at the same
time when the brake system indicator (amber) comes
on, the parking brake may not work.
Avoid using the parking brake and have your vehicle
checked by a dealer immediately.

If the Brake System Indicator (Red) Comes
On or Blinks at the Same Time When the
Brake System Indicator (Amber) Comes On

P. 650

U.S.

Canada

(Red)

650

Indicator, Coming On/Blinking

If the Brake System Indicator (Red) Comes On or Blinks at the Same Time When the Brake System Indicator (Amber) Comes On

Han

lin
g the U

expected

If the Brake System Indicator (Red) Comes On or Blinks at the
Same Time When the Brake System Indicator (Amber) Comes On

■

If the brake system indicator (red) comes on or blinks at the
same time when the brake system indicator (amber) comes on,
release the parking brake manually or automatically.

Parking Brake

P. 546

•

If the brake system indicator (red) continuously comes on or blinks at
the same time when the brake system indicator (amber) comes on,
stop the vehicle in a safe place and have it inspected by a dealer
immediately.

Preventing the vehicle from moving, put the transmission into

(

•

If only the brake system indicator (red) is turned off, avoid using the
parking brake and have your vehicle checked by a dealer immediately.

If the Brake System Indicator (Red) Comes On or Blinks at the Same
Time When the Brake System Indicator (Amber) Comes On

If you apply the parking brake, you may not be able
to release it.

If the brake system indicator (red) and the brake
system indicator (amber) come on at the same time,
the parking brake is working.

If the brake system indicator (red) blinks at the same
time when the brake system indicator (amber) comes
on, the parking brake may not work because it is
checking the system.

U.S.

Canada

(Red)

U.S.

Canada

(Amber)

651

Indicator, Coming On/Blinking

If the Electric Power Steering (EPS) System Indicator Comes On

Han

lin
g the U

expected

If the Electric Power Steering (EPS) System Indicator Comes On

■

Reasons for the indicator to come on

Comes on when there is a problem with the EPS system.

■

What to do when the indicator comes on

•

Stop the vehicle in a safe place and restart the engine.
If the indicator comes on and stays on, immediately have your vehicle
inspected by a dealer.

•

Do not drive

displays on the driver information interface,

immediately stop in a safe place and contact a dealer.

652

Indicator, Coming On/Blinking

If the Low Tire Pressure/TPMS Indicator Comes On or Blinks

Han

lin
g the U

expected

If the Low Tire Pressure/TPMS Indicator Comes On or Blinks

■

Reasons for the indicator to come on or blink

A tire pressure is significantly low, or the TPMS has not been calibrated.
If there is a problem with the TPMS, the indicator blinks for about one
minute, and then stay on.
If the compact spare tire is installed, the indicator will either come on or
it will first blink for about one minute, then stay on.

■

What to do when the indicator comes on

Drive carefully and avoid abrupt cornering and hard braking.
Stop your vehicle in a safe place. Check the tire pressure and adjust the
pressure to the specified level. The specified tire pressure is on a label on
the driver side doorjamb.

Calibrate the TPMS after the tire pressure is adjusted.

TPMS Calibration

P. 456

If the compact spare tire causes the indicator to come on, change the
tire to a full-size tire. The indicator goes off after calibrating the TPMS.

■

What to do when the indicator blinks, then remains on

Have the tire inspected by a dealer as soon as possible. If the compact
spare tire causes the indicator to first blink, and then stay on, change the
tire to a full-size tire.
The indicator goes off after calibrating the TPMS.

U.S. models

If the Low Tire Pressure/TPMS Indicator Comes On or Blinks

NOTICE

Driving on an extremely underinflated tire can cause
it to overheat. An overheated tire can fail. Always
inflate your tires to the prescribed level.

653

Continued

Han

lin
g the U

expected

Fuses

Fuse Locations

If any electrical devices are not working, set the power mode to VEHICLE OFF and
check to see if any applicable fuse is blown.

Located near the battery. Push the tabs to open the box.
Fuse locations are shown on the fuse box cover. Locate the fuse in question by the
fuse number and box cover number.

■

Engine Compartment Fuse Box

Fuse Box

Tab

654

Fuses

Fuse Locations

Han

lin
g the U

expected

■

Circuit protected and fuse rating

Circuit Protected

Amps

MAIN FUSE

125 A

I/S2

(30 A)

40 A

F/BOX OPTION1

60 A

PTC HTR1

(40 A)

F/BOX OPTION2

60 A

F/BOX MAIN1

60 A

AUDIO AMP

(30 A)

ST MAGNETIC SW

30 A

PTC HTR3

(40 A)

RR DEF

30 A

50 A

HTR MTR

40 A

PTG MTR

(40 A)

ABS/VSA FSR

40 A

ABS/VSA MTR

40 A

E BOOSTER

40 A

IG1 MAIN1

30 A

40 A

IG1 MAIN2

30 A

I/S1

(30 A)

WIPER

30 A

EPS

70 A

30 A

40 A

MAIN FAN

30 A

F/BOX MAIN2

60 A

SUB FAN

30 A

SRM2

20 A

BACK UP

10 A

FR WIPER DEICER

(15 A)

RR FOG

(10 A)

AUDIO SUB

7.5 A

FR FOG

(10 A)

A/C MG CLUTCH

10 A

HORN

15 A

FR WASHER

15 A

AUDIO

15 A

SRM1

20 A

DBW

15 A

HAZARD

10 A

VBU

10 A

IGP

15 A

Circuit Protected

Amps

TCU

10 A

LCM L

20 A

INJ

20 A

STOP

10 A

LCM R

20 A

IG COIL

15 A

AUDIO MAIN VST

(15 A)

AUDIO SUB VST

(7.5 A)

IGPS VBACT

7.5 A

IGPS FAN

7.5 A

IGPS LAF

7.5 A

IG1 MON2

5 A

Circuit Protected

Amps

* Not available on all models

655

Fuses

Fuse Locations

Continued

Han

lin
g the U

expected

Located under the dashboard.
Fuse locations are shown on the label under the steering column.
Locate the fuse in question by the fuse number and label number.

■

Interior Main Fuse Box

Main Fuse
Box

Fuse Label

656

Fuses

Fuse Locations

Han

lin
g the U

expected

■

Circuit protected and fuse rating

Circuit Protected

Amps

P/W DR

20 A

P/W AS

20 A

P/W RR R

20 A

P/W RR L

20 A

OPTION

10 A

SRS

10 A

T/G MTR / TRUNK ACT

(10 A)

RVU

10 A

FR ACC SOCKET

20 A

DOOR LOCK

20 A

METER

10 A

OPTION 3 (ST CUT)

10 A

OPTION 2

10 A

OPTION 6 (VB SOL)

10 A

DR DOOR UNLOCK

(10 A)


10 A

YOP TRAILER

(20 A)

HAC OP

(20 A)

USB CHG

10 A

CARGO ACC SOCKET

20 A

SMART

10 A

DR DOOR LOCK

(10 A)

E-DPS

20 A

SRS

10 A

ACG

10 A

OPTION 5 (ABS)

10 A

FUEL PUMP

20 A

L SIDE DOOR UNLOCK

10 A

R SIDE DOOR UNLOCK

10 A

SUN ROOF

20 A

SUN SHADE

20 A

RR H/SEAT

(20 A)

RR BLOWER

20 A

R SIDE DOOR LOCK

10 A

DR P/SEAT SLIDE

20 A

DR P/SEAT REC

20 A

ETHANOL

5 A

A/C

10 A

DRL

5 A

ACC

10 A

L SIDE DOOR LOCK

10 A

H/SEAT

(20 A)

AS P/SEAT REC

20 A

P/LUMBAR DR/AS

10 A

PTG CLOSER

(20 A)

Circuit Protected

Amps

AS P/SEAT SLI

20 A

OPTION1

10 A

Circuit Protected

Amps

* Not available on all models

657

Fuses

Fuse Locations

Han

lin
g the U

expected

Located under the dashboard.
Fuse locations are shown on the label under
the steering column.
Locate the fuse in question by the fuse
number and label number.

■

Interior Sub Fuse Box

Sub Fuse Box

Fuse Label

■

Circuit protected and fuse rating

Circuit Protected

Amps

ACC

(5 A)

EOP

(10 A)

METER

(10 A)

OPTION

(10 A)

* Not available on all models

658

Fuses

Inspecting and Changing Fuses

Han

lin
g the U

expected

Inspecting and Changing Fuses

Set the power mode to VEHICLE OFF. Turn
headlights and all accessories off.

Remove the fuse box cover.

Check the main fuse in the engine
compartment fuse box.

Look at the fuse through the hole.

If the fuse is blown, have it replaced by a
dealer.

Inspecting and Changing Fuses

NOTICE

Replacing a fuse with one that has a higher rating
greatly increases the chances of damaging the
electrical system.

Use the charts to locate the fuse in question and
confirm the specified amperage on the fuse label.

Fuse Locations

P. 653

Replace a fuse with a spare fuse of the same specified
amperage.

Main Fuse

Hole

659

Fuses

Inspecting and Changing Fuses

Han

lin
g the U

expected

Check the combined fuses in the engine
compartment fuse box.

Look into the space between the fuses.

If the fuse is blown, have it replaced by a
dealer.

Inspect the small fuses in the engine
compartment and the vehicle interior.

If there is a blown fuse, remove it with
the fuse puller and replace it with a new
one.

Inspecting and Changing Fuses

There is a fuse puller on the back of the engine
compartment fuse box cover.

Combined Fuse

Blown Fuse

Fuse Puller

660

Han

lin
g the U

expected

Emergency Towing

Call a professional towing service if you need to tow your vehicle.

■

Flatbed equipment

The operator loads your vehicle on the back of a truck.

This is the best way to transport your vehicle.

■

Wheel lift equipment

The tow truck uses two pivoting arms that go under the front tires and lift them off
the ground. The rear tires remain on the ground.

This is an acceptable way to

tow your vehicle.

Emergency Towing

NOTICE

Trying to lift or tow your vehicle by the bumpers will
cause serious damage. The bumpers are not designed
to support the vehicle's weight.

NOTICE

Improper towing such as towing behind a
motorhome or other motor vehicle can damage the
transmission.

Never tow your vehicle with just a rope or chain.
It is very dangerous since ropes or chains may shift
from side to side or break.

Make sure the parking brake is released. If you
cannot release the parking brake, your vehicle must
be transported by the flatbed equipment.

Parking Brake

P. 546

2WD models

661

Han

lin
g the U

expected

If You Cannot Unlock the Fuel Fill Door

If you cannot unlock the fuel fill door, use the following procedure.

Open the tailgate and remove the cover.

Pull the release cord toward you.

The release cord unlocks the fuel fill door
when it is pulled.

Open the fuel fill door.

How to Refuel

P. 570

■

What to Do if Unable to Unlock the Fuel Fill Door

If You Cannot Unlock the Fuel Fill Door

After taking these steps, contact a dealer to have the
vehicle checked.

Cover

Release Cord

662

Han

lin
g the U

expected

If You Cannot Open the Tailgate

If you cannot open the tailgate, use the following procedure.

Use a flat-tip screwdriver and remove the
cover on the back of the tailgate.

Wrap the flat-tip screwdriver with a cloth
to prevent scratches.

To open the tailgate, push the tailgate
while pushing the lever to the right using a
flat-tip screw driver.

■

What to Do If Unable to Open the Tailgate

If You Cannot Open the Tailgate

Following up:
After taking these steps, contact a dealer to have the
vehicle checked.

When you open the tailgate from inside, make sure
there is enough space around the tailgate, and it
does not hit anyone or any object.

Cover

Lever

Models with power tailgate

Models without power tailgate

Lever

663

Han

lin
g the U

expected

Refueling

Refueling From a Portable Fuel Container

If you have run out of fuel and need to refuel your vehicle from a portable fuel
container, use the funnel provided with your vehicle.

Turn off the engine.

Press on the edge of the fuel fill door until
you hear a click when the driver’s door is
unlocked.

The fuel fill door opens.

Take the funnel out of the spare tire area in
the cargo area.

Types of Tools

P. 628

Place the end of the funnel on the lower
part of filler opening, then insert it slowly
and fully.

Make sure that the end of the funnel
goes down along with the filler pipe.

Fill the tank with fuel from the portable fuel
container.

Pour fuel carefully so you do not spill any.

Remove the funnel from the filler neck.

Wipe up any fuel from the funnel before
storing it.

Shut the fuel fill door by hand.

Refueling From a Portable Fuel Container

NOTICE

Do not insert the nozzle of a portable fuel container
or any funnel other than the one provided with your
vehicle. Doing so can damage the fuel system.
Do not try to pry open or push open the sealed fuel
tank with foreign objects. This can damage the fuel
system and its seal.

Make sure the fuel in the portable fuel container is
gasoline before you refuel.

WARNING

Gasoline is highly flammable and explosive.
You can be burned or seriously injured
when handling fuel.

•

Stop the engine, and keep heat, sparks,
and flames away.

•

Handle fuel only outdoors.

•

Wipe up spills immediately.

Funnel

665

Information

This chapter includes your vehicle's specifications, locations of identification numbers, and other

information required by regulation.

Specifications

.................................... 666

Identification Numbers

Vehicle Identification Number (VIN),

Engine Number, and Transmission
Number ......................................... 668

Devices that Emit Radio Waves

....... 669

Reporting Safety Defects

................. 672

Emissions Testing

Testing of Readiness Codes.............. 673

Warranty Coverages

........................ 675

Authorized Manuals

......................... 678

Customer Service Information

......... 679

Open Source Licenses

Meter Open Source License ............. 680

Front Sensor Camera Open Source

License ....................................... 681

666

Info

ation

Specifications

■

Vehicle Specifications

Model

CR-V

No. of Passengers:
Front

Rear

Total

Weights:
Gross Vehicle Weight
Rating

See the certification label on the driver's
doorjamb

Gross Axle Weight
Rating (Front)

See the certification label on the driver's
doorjamb

Gross Axle Weight
Rating (Rear)

See the certification label on the driver's
doorjamb

■

Air Conditioning

■

Engine Specifications

■

Fuel

■

Washer Fluid

Refrigerant Type

HFO-1234yf (R-1234yf)

Charge Quantity

17.1-18.9 oz (485-535 g)

Lubricant Type

RB100EV-01 (POE)

Quantity

6.71-7.50 cu-in (110-123 cm

)

Displacement

91.38 cu-in (1,498 cm

)

Spark Plugs

NGK

DILKAR8P8SY

Type

Unleaded gasoline, pump octane number
87 or higher

Fuel Tank Capacity

14 US gal (53 L)

Tank Capacity

U.S.: 1.6 US qt (1.5 L)
Canada: 4.8 US qt (4.5 L)

■

Light Bulbs

Headlights (Low Beam)

LED

Headlights (High Beam)

LED

Front Turn Signal/Parking/Daytime
Running Lights

LED

Front Side Marker Lights

LED

Side Turn Signal Lights
(on Door Mirrors)

LED

Brake Lights

LED

Rear Side Marker Lights

LED

Taillights

LED

Back-Up Lights

LED

Rear Turn Signal Lights

21 W (Amber)

High-Mount Brake Light

LED

Rear License Plate Light

LED

Interior Lights

Map Lights

LED

Ceiling Light

LED

Cargo Area Lights

LED

Ambient Lights

LED

Center Console Light LED
Vanity Mirror Lights

1.4 W

* Not available on all models

667

Specifications

Info

ation

■

Brake Fluid

■

Continuously Variable Transmission

Fluid

*1: 2WD models
*2: AWD models

■

Rear Differential Fluid

Specified

Honda Heavy Duty Brake Fluid DOT 3

Specified

Honda HCF-2

Capacity

Change

3.7 US qt (3.5 L)

4.1 US qt (3.9 L)

Specified

Honda DPSF-II

Capacity

Change

1.32 US qt (1.247 L)

■

Engine Oil

■

Engine Coolant

Recommended

·Honda Genuine Motor Oil 0W-20
·API service SN or higher grade 0W-20

Capacity

Change

3.4 US qt (3.2 L)

Change including
filter

3.7 US qt (3.5 L)

Specified

Honda Long Life Antifreeze/Coolant Type2

Ratio

50/50 with distilled water

Capacity

1.56 US gal (5.91 L)
(change including the remaining 0.16 US gal
(0.61 L) in the reserve tank)

■

Tire

*1: Models with 17 inch wheel
*2: Models with 18 inch wheel

Regular

Size

235/65R17 104H

Pressure

psi (kPa [kgf/cm

])

Front

33 (230 [2.3])

Rear

32 (220 [2.2])

Size

235/60R18 103H

Pressure

psi (kPa [kgf/cm

])

Front

35 (240 [2.4])

Rear

32 (220 [2.2])

Compact
Spare

Size

T155/90D17 112M

Pressure
psi (kPa [kgf/cm

])

60 (420 [4.2])

Wheel Size

Regular

17 x 7 1/2J

18 x 7 1/2J

Compact Spare

17 x 4T

* Not available on all models

668

Info

ation

Identification Numbers

Vehicle Identification Number (VIN), Engine Number,
and Transmission Number

Your vehicle has a 17-digit vehicle identification number (VIN) used to register your
vehicle for warranty purposes, and for licensing and insuring your vehicle.
The locations of your vehicle’s VIN, engine number, and transmission number are
shown as follows:

Vehicle Identification Number

Engine Number

Certification Label/
Vehicle Identification Number

Continuously Variable
Transmission Number

669

Continued

Info

ation

Devices that Emit Radio Waves

Each radio frequency device installed in the vehicle conforms to the requirements and
standards of the regulation listed below:

As required by the FCC:
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.

Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.

This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.

670

Devices that Emit Radio Waves

Info

ation

Adaptive Cruise Control (ACC)/Collision Mitigation Braking System

(CMBS

)

●

User manual statements:

User Manual statement according to §15.19:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. this device may not cause harmful interference and
2. this device must accept any interference received, including interference that may cause undesired operation.

User Manual statement according to §15.105:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
RF Exposure Information according 2.1091 / 2.1093 / OET bulletin 65:
Radiofrequency radiation exposure Information:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance of 20 cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

671

Devices that Emit Radio Waves

Info

ation

Wireless Charger

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications (including the antennas) to this device that are not expressly approved by the manufacturer may void the
user's authority to operate the equipment.
This equipment complies with FCC RF Radiation exposure limits set forth for an uncontrolled environment. This device and its antenna
must not be co-located or operating in conjunction with any other antenna or transmitter.

* Not available on all models

672

Info

ation

Reporting Safety Defects

In the U.S.
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you
should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to
notifying American Honda Motor Co., Inc.

If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists
in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer, or American Honda Motor Co., Inc.

To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-
9153); go to

http://www.safercar.gov

; or write to: Administrator, NHTSA, 1200 New Jersey Avenue, SE.,

Washington, DC 20590. You can also obtain other information about motor vehicle safety from

http://www.safercar.gov

In Canada
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you
should immediately inform Honda Canada Inc. and you may also inform Transport Canada.

If Transport Canada receives similar complaints, it may open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may lead to a recall and remedy campaign. However, Transport Canada
cannot become involved in individual problems between you, your dealer, or Honda Canada Inc.

To contact Transport Canada’s Defect Investigations and Recalls Division, you may call 1-800-333-0510. For
more information on reporting safety defects or about motor vehicle safety, go to

http://www.tc.gc.ca/roadsafety

673

Continued

Info

ation

Emissions Testing

Testing of Readiness Codes

Your vehicle has readiness code as part of the onboard self diagnostic system.
Some states use these codes for testing to verify whether your vehicle's emissions
components are working properly.
The codes may not be read properly if testing is performed just after the battery has
gone dead or been disconnected.

To check if they are set, set the power mode to ON, without starting the engine. The
malfunction indicator lamp will come on for several seconds. If it then goes off, the
readiness codes are set. If it blinks five times, the readiness codes are not set.

If you are required to have your vehicle tested before the readiness codes are ready,
prepare the vehicle for retesting by doing the following:

Fill the gas tank to approximately 3/4 full.

Park the vehicle and leave the engine off for 6 hours or more.

Make sure the ambient temperature is between 40°F and 95°F (4°C and 35°C).

Start the engine without touching the accelerator pedal, and let it idle for 20
seconds.

Keep the vehicle in

(

. Increase the engine speed to 2,000 rpm, and hold it there

for about 3 minutes.

Let the engine idle with your foot off the accelerator for 20 seconds.

Testing of Readiness Codes

The readiness codes are erased when the battery is
disconnected, and set again only after several days of
driving under a variety of conditions.

If a testing facility determines that the readiness
codes are not set, you may be requested to return at
a later date to complete the test.

If the testing facility determines the readiness codes
are still not set, see a dealer.

674

Emissions Testing

Testing of Readiness Codes

Info

ation

Select a nearby, lightly traveled major highway where you can maintain a speed
of 50 to 60 mph (80 to 97 km/h) for at least 20 minutes. Drive on the highway in

(

. Do not use cruise control. When traffic allows, drive for 90 seconds without

moving the accelerator pedal. (Vehicle speed may vary slightly; this is okay.) If you
cannot do this for a continuous 90 seconds because of traffic conditions, drive for
at least 30 seconds, then repeat it two more times (for a total of 90 seconds).

Drive in city or suburban traffic for at least 10 minutes. When traffic conditions
allow, let the vehicle coast for several seconds without using the accelerator pedal
or the brake pedal.

Park the vehicle and leave the engine off for 30 minutes.

675

Continued

Info

ation

Warranty Coverages

■

U.S. Owners

Your new vehicle is covered by these warranties:

New Vehicle Limited Warranty –

covers your new vehicle, except for the

emissions control systems and accessories, against defects in materials and
workmanship.

Emissions Control Systems Defects Warranty and Emissions Performance
Warranty –

these two warranties cover your vehicle’s emissions control systems.

Time, mileage, and coverage are conditional. Please read your warranty booklet for
exact information.

Seat Belt Limited Warranty –

a seat belt that fails to function properly is covered

by a limited warranty. Please read your warranty booklet for details.

Rust Perforation Limited Warranty –

all exterior body panels are covered against

rusting from the inside out for the specified time period, regardless of mileage.

Accessory Limited Warranty –

Honda accessories are covered under this

warranty. Time and mileage limits depend on the type of accessory and other
factors. Please read your warranty booklet for details.

Replacement Parts Limited Warranty –

covers all Honda replacement parts

against defects in materials and workmanship.

676

Warranty Coverages

Info

ation

Replacement Battery Limited Warranty –

provides prorated coverage for a

replacement battery purchased from your dealer.

Replacement Muffler Lifetime Limited Warranty –

provides coverage for as

long as the purchaser of the muffler owns the vehicle.

Restrictions and exclusions apply to all these warranties. Please read the Honda
warranty information booklet that came with your vehicle for precise information on
warranty coverages. Your vehicle’s original tires are covered by their manufacturer.
Tire warranty information is in a separate booklet.

■

Statement on Warranty Coverage for Aftermarket and Recycled Parts

The Magnuson-Moss Warranty Act, 15 U.S.C. s.2301 et seq., makes it illegal for
motor vehicle manufacturers to void a motor vehicle warranty or deny warranty
coverage solely because an aftermarket or recycled part has been used to repair the
vehicle or someone other than the authorized service provider performed service on
the vehicle. This provision does not apply to a new motor vehicle purchased solely
for commercial or industrial use.

677

Warranty Coverages

Info

ation

Under federal law, a manufacturer may deny warranty coverage and charge for
repairs to a vehicle if it is discovered that an aftermarket or recycled part installed on
the vehicle is defective or was installed incorrectly and caused damage to another
part of the vehicle otherwise covered under warranty. The Federal Trade
Commission requires that a manufacturer demonstrate that an aftermarket or
recycled part or service performed by a person other than an authorized service
provider caused damage to another part of the vehicle otherwise covered under
warranty before denying warranty coverage. Additionally, federal law allows a
manufacturer to void a motor vehicle warranty or deny warranty coverage if the
manufacturer provides the article or service to consumers free of charge under the
warranty or the manufacturer has secured a waiver from the Federal Trade
Commission.

■

Canadian Owners

Please refer to the warranty manual that came with your vehicle.

■

EPA Contact Information

An owner may obtain further information concerning emission warranties or report
violations of the terms of the emission warranties by contacting:

Director,
Light-Duty Vehicle Center,
U.S. Environmental Protection Agency,
Attention: Warranty Claim
2000 Traverwood Drive,
Ann Arbor, MI 48105;
complianceinfo@epa.gov

678

Info

ation

Authorized Manuals

■

Service Express

For electronic copies of service publications, you can purchase a subscription to
Service Express. Visit

www.techinfo.honda.com

for pricing and options.

■

For U.S. Owners

Manuals can be purchased from Helm Incorporated. You can order a manual by
phone at 1 (800) 782-4356 (credit card orders only), or online at

www.helminc.com

■

For Canadian Owners

Please contact a dealer to order any manuals that you may require.

679

Info

ation

Customer Service Information

Honda dealership personnel are trained professionals able to deal with any problems
you may encounter with your vehicle. If, however, you are faced with a problem that
they cannot resolve to your satisfaction, contact Honda Customer Services.

U.S. Owners

American Honda Motor Co., Inc.
Honda Automobile Customer Service
Mail Stop CHI-5
1919 Torrance Blvd.
Torrance, CA 90501-2746
Tel: 1 (800) 999-1009

Canadian Owners

Honda Canada Inc.
Customer Relations
180 Honda Boulevard
Markham, ON
L6C 0H9
Tel: 1-888-9-HONDA-9
Fax: 1-877-939-0909
E-mail: Honda_cr@ch.honda.com

In Puerto Rico and the U.S. Virgin
Islands

Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: 1 (787) 620-7546

In Guam

Triple J Autogroup
157 S. Marine Corps Drive
Tamuning, GU 96913
Tel: (671) 648-2277

In Saipan, Commonwealth of the
Northern Mariana Island

Joeten Motor Company, Inc.
P.O Box 500680
Saipan, MP 96950
Tel: (670) 234-5562

Customer Service Information

When you call or write, please give us the following
information:

•

Vehicle Identification Number

Vehicle Identification Number (VIN),
Engine Number, and Transmission
Number

P. 668

•

Date of purchase

•

Odometer reading of your vehicle

•

Your name, address, and telephone number

•

A detailed description of the problem

•

Name of the dealer who sold the vehicle to you

680

Info

ation

Open Source Licenses

Meter Open Source License

The software embedded in this product includes open source software. Refer to the
following website for details regarding the open source software.

https://www.nippon-seiki.co.jp/business_ic_meter/

Content .. 18 19 20
