Honda Accord (2024 year). Manual in english

451

Continued

Main

tenan

Checking and Maintaining Tires

Checking Tires

To safely operate your vehicle, your tires must be of the proper type and size, in
good condition with adequate tread, and properly inflated.

■

Inflation guidelines

Properly inflated tires provide the best combination of handling, tread life, and comfort.
Refer to the driver’s doorjamb label or specifications page for the specified pressure.

Underinflated tires wear unevenly, adversely affect handling and fuel economy, and
are more likely to fail from overheating.

Overinflated tires make your vehicle ride harshly, are more prone to road hazards,
and wear unevenly.

Every day before you drive, look at each of the tires. If one looks lower than the
others, check the pressure with a tire gauge.

At least once a month or before long trips, use a gauge to measure the pressure in all
tires, including the spare. Even tires in good condition can lose 1–2 psi (10–20 kPa,
0.1–0.2 kgf/cm

) per month.

■

Inspection guidelines

Every time you check inflation, also examine the tires and valve stems.
Look for:

•

Bumps or bulges on the side or in the tread. Replace the tire if you find any cuts,
splits, or cracks in the side of the tire. Replace it if you see fabric or cord.

•

Remove any foreign objects and inspect for air leaks.

•

Uneven tread wear. Have a dealer check the wheel alignment.

•

Excessive tread wear.

Wear Indicators

P. 457

•

Cracks or other damage around valve stem.

Checking Tires

Measure the air pressure when tires are cold. This
means the vehicle has been parked for at least three
hours, or driven less than 1 mile (1.6 km). If
necessary, add or release air until the specified
pressure is reached.

If checked when hot, tire pressure can be as much as
4–6 psi (30–40 kPa, 0.3–0.4 kgf/cm

) higher than if

checked when cold.

Whenever tire pressure is adjusted, you must
calibrate the TPMS

TPMS Calibration

P. 318

Have a dealer check the tires if you feel a consistent
vibration while driving. New tires and any that have
been removed and reinstalled should be properly
balanced.

WARNING

Using tires that are excessively worn or

improperly inflated can cause a crash in

which you can be seriously hurt or killed.

Follow all instructions in this owner’s

manual regarding tire inflation and

maintenance.

* Not available on all models

Checking and Maintaining Tires

Checking Tires

452

Main

tenan

Checking Tires

High speed driving

We recommend that you do not drive faster than the
posted speed limits and conditions allow. If you drive
at sustained high speeds (over 99 mph or 160 km/h),
adjust the cold tire pressures as shown below to
avoid excessive heat buildup and sudden tire failure.

Tire Size

225/50R17 94V

Pressure

Front: 35 psi (240 kPa, 2.4 kgf/cm

)

Rear: 33 psi (230 kPa, 2.3 kgf/cm

)

453

Checking and Maintaining Tires

Tire and Loading Information Label

Continued

Main

tenan

Tire and Loading Information Label

The label attached to the driver’s doorjamb provides necessary tire and loading
information.

Tire Labeling

The tires that came on your vehicle have a
number of markings. Those you should be
aware of are described as shown.

Whenever tires are replaced, they should be replaced with tires of the same size.

Tire and Loading Information Label

The tire and loading information label attached to the
driver’s doorjamb contains:

The number of people your vehicle can carry.

The total weight your vehicle can carry. Do not
exceed this weight.

The original tire sizes for front, rear, and spare.

The proper cold tire pressure for front, rear, and
spare.

Label
Example

Example

Tire Size

Tire
Identification
Number (TIN)

Maximum
Tire Load

Maximum
Tire Pressure

Tire Size

■

Tire Sizes

Tire Sizes

Following is an example of tire size with an
explanation of what each component means.

P235/60 R18 102T

P: Vehicle type (P indicates passenger vehicle).
235: Tire width in millimeters.
60: Aspect ratio (the tire’s section height as a
percentage of its width).
R: Tire construction code (R indicates radial).
18: Rim diameter in inches.
102: Load index (a numerical code associated with
the maximum load the tire can carry).
T: Speed symbol (an alphabetical code indicating the
maximum speed rating).

Checking and Maintaining Tires

Tire Labeling

454

Main

tenan

The tire identification number (TIN) is a group of numbers and letters that look like
the examples in the side column. TIN is located on the sidewall of the tire.

Cold Tire Pressure

– The tire air pressure when the vehicle has been parked for at

least three hours or driven less than 1 mile (1.6 km).

Load Rating

– Means the maximum load that a tire is rated to carry for a given

inflation pressure.

Maximum Inflation Pressure

– The maximum tire air pressure that the tire can

hold.

Maximum Load Rating

– Means the load rating for a tire at the maximum

permissible inflation pressure for that tire.

Recommended Inflation Pressure

– The cold tire inflation pressure recommended

by the manufacturer.

Treadwear Indicators (TWI)

– Means the projections within the principal grooves

designed to give a visual indication of the degrees of wear of the tread.

■

Tire Identification Number (TIN)

■

Glossary of Tire Terminology

Tire Identification Number (TIN)

There are two different formats that TIN may be listed
in.

Format A

Format B

DOT B97R FW6X 2209

DOT: This indicates that the tire meets all
requirements of the U.S. Department of
Transportation.
B97R: Manufacturer’s identification mark.
FW6X: Tire type code.
22 09: Date of manufacture.

Year
Week

DOT 1A3 OFBEKP 1522

DOT: This indicates that the tire meets all
requirements of the U.S. Department of
Transportation.
1A3: PLANT CODE
OFBEKP: MANUFACTURE CODE
15 22: DATE CODE

Year
Week

455

Checking and Maintaining Tires

DOT Tire Quality Grading (U.S. Vehicles)

Continued

Main

tenan

DOT Tire Quality Grading (U.S. Vehicles)

The tires on your vehicle meet all U.S. Federal Safety
Requirements. All tires are also graded for treadwear, traction,
and temperature performance according to Department of
Transportation (DOT) standards. The following explains these
gradings.

Quality grades can be found where applicable on the tire sidewall
between tread shoulder and maximum section width.

The treadwear grade is a comparative rating based on the wear
rate of the tire when tested under controlled conditions on a
specified government test course. For example, a tire graded 150
would wear one and one-half (1 1/2) times as well on the
government course as a tire graded 100. The relative performance
of tires depends upon the actual conditions of their use, however,
and may depart significantly from the norm due to variations in
driving habits, service practices and differences in road
characteristics and climate.

■

Uniform Tire Quality Grading

■

Treadwear

Uniform Tire Quality Grading

For example:

Treadwear 200
Traction AA
Temperature A

All passenger car tires must conform
to Federal Safety Requirements in
addition to these grades.

Checking and Maintaining Tires

DOT Tire Quality Grading (U.S. Vehicles)

456

Main

tenan

The traction grades, from highest to lowest, are AA, A, B, and C.
Those grades represent the tire's ability to stop on wet pavement
as measured under controlled conditions on specified
government test surfaces of asphalt and concrete. A tire marked
C may have poor traction performance.

The temperature grades are A (the highest), B, and C,
representing the tire's resistance to the generation of heat and its
ability to dissipate heat when tested under controlled conditions
on a specified indoor laboratory test wheel. Sustained high
temperature can cause the material of the tire to degenerate and
reduce tire life, and excessive temperature can lead to sudden tire
failure. The grade C corresponds to a level of performance which
all passenger car tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A represent higher levels
of performance on the laboratory test wheel than the minimum
required by law.

■

Traction

■

Temperature

Traction

Warning: The traction grade
assigned to this tire is based on
straight-ahead braking traction tests,
and does not include acceleration,
cornering, hydroplaning, or peak
traction characteristics.

Temperature

Warning: The temperature grade for
this tire is established for a tire that is
properly inflated and not
overloaded. Excessive speed,
underinflation, or excessive loading,
either separately or in combination,
can cause heat buildup and possible
tire failure.

457

Checking and Maintaining Tires

Wear Indicators

Main

tenan

Wear Indicators

The groove where the wear indicator is
located is about 1/16 inch (about 1.6 mm)
shallower than elsewhere on the tire. If the
tread has worn so that the indicator is
exposed, replace the tire.

Worn out tires have poor traction on wet
roads.

Tire Service Life

The life of your tires is dependent on many factors, including driving habits, road
conditions, vehicle loading, inflation pressure, maintenance history, speed, and
environmental conditions (even when the tires are not in use).

In addition to regular inspections and inflation pressure maintenance, it is
recommended that you have annual inspections performed once the tires reach five
years old. All tires, including the spare, should be removed from service after 10
years from the date of manufacture, regardless of their condition or state of wear.

Example of a Wear
Indicator mark

458

Checking and Maintaining Tires

Tire and Wheel Replacement

Main

tenan

Tire and Wheel Replacement

Replace your tires with radials of the same size, load range, speed rating, and
maximum cold tire pressure rating (as shown on the tire’s sidewall). Using tires of a
different size or construction can cause certain vehicle systems such as the ABS and
Vehicle Stability Assist

(VSA

) system to work incorrectly.

It is best to replace all four tires at the same time. If that isn’t possible, replace the
front or rear tires in pairs.

Make sure that the wheel’s specifications match those of the original wheels.

Tire and Wheel Replacement

WARNING

Installing improper tires on your vehicle can

affect handling and stability. This can cause

a crash in which you can be seriously hurt or

killed.

Always use the size and type of tires

recommended in this owner’s manual.

459

Checking and Maintaining Tires

Tire Rotation

Main

tenan

Tire Rotation

Rotating tires according to the maintenance messages on the driver information
interface helps to distribute wear more evenly and increase tire life.

■

Tires without rotation marks

Rotate the tires as shown here.

■

Tires with rotation marks

Rotate the tires as shown here.

Tire Rotation

Tires with directional tread patterns should only be
rotated front to back (not from one side to the other).
Directional tires should be mounted with the rotation
indication mark facing forward, as shown below.

Whenever tires are rotated, you must calibrate the
TPMS

TPMS Calibration

P. 318

Front

Direction Mark

Front

* Not available on all models

460

Checking and Maintaining Tires

Winter Tires

Main

tenan

Winter Tires

If driving on snowy or frozen roads, mount all season marked

M+S

tires, snow tires,

or tire chains; reduce speed; and maintain sufficient distance between vehicles when
driving.

Be particularly careful when operating the steering wheel or brakes to prevent
skidding.

Use tire chains, snow tires, or all season tires when necessary or according to the
law.

When mounting, refer to the following points.

For winter tires:

•

Select the size and load ranges that are the same as the original tires.

•

Mount the tires to all four wheels.

For tire chains:

•

Install them on the front tires only.

•

Because your vehicle has limited tire clearance, we strongly recommend using the
chains listed below:

•

Follow the chain manufacturer’s instruction when installing. Mount them as
tightly as you can.

•

Check that the chains do not touch the brake lines or suspension.

•

Drive slowly.

Cable-type: SCC Radial Chain SC1036

Winter Tires

NOTICE

Traction devices that are the wrong size or improperly
installed can damage your vehicle’s brake lines,
suspension, body, and wheels. Stop driving if they are
hitting any part of the vehicle.

When tire chains are mounted, follow the chain
manufacturer’s instructions regarding vehicle
operational limits.

If your vehicle is equipped with summer tires, be
aware that these tires are not designed for winter
driving conditions. For more information, contact a
dealer.

WARNING

Using the wrong chains, or not properly

installing chains, can damage the brake

lines and cause a crash in which you can be

seriously injured or killed.

Follow all instructions in this owner’s

manual regarding the selection and use of

tire chains.

461

Main

tenan

Battery

Checking the Battery

The condition of the battery is monitored by a
sensor located on the negative terminal of the
battery. If there is a problem with this sensor,
the driver information interface will display a
warning message. If this happens, have your
vehicle inspected by a dealer.

Check the battery terminals for corrosion
monthly.

If your vehicle’s battery is disconnected or goes dead:

•

The audio system is disabled.

Reactivating the audio system

P. 208

•

The clock resets.

Clock

P. 136

•

The immobilizer system needs to be reset.

Immobilizer System Indicator

P. 95

Battery

WARNING:

Battery post, terminals,

and related accessories contain lead
and lead compounds.

Wash your hands after handling.

When you find corrosion, clean the battery terminals
by applying a baking powder and water solution.
Clean the terminals with a damp towel. Cloth/towel
dry the battery. Coat the terminals with grease to
help prevent future corrosion.

WARNING

The battery gives off explosive hydrogen

gas during normal operation.

A spark or flame can cause the battery to

explode with enough force to kill or

seriously hurt you.

When conducting any battery

maintenance, wear protective clothing and

a face shield, or have a skilled technician do

it.

Canadian models

462

Battery

Charging the Battery

Main

tenan

Charging the Battery

Disconnect both battery cables to prevent damaging your vehicle’s electrical system.
Always disconnect the negative (–) cable first, and reconnect it last.

If the battery cable is removed while a system update is being performed, the
electrical system can be permanently damaged. Only remove the battery cable when
a system update is not being performed.

Charging the Battery

When replacing the battery, the replacement must be
of the same specifications.
Consult a dealer for more information.

The battery installed in this vehicle is specifically
designed for a model with Auto Idle Stop or System
Updates.
Using a battery other than this specified type may
shorten the battery life, and prevent Auto Idle Stop or
System Updates from activating. If you need to
replace the battery, make sure to select the specified
type and size. Ask a dealer for more details.

The Vehicle Stability Assist

(VSA

) system, Adaptive

Cruise Control (ACC) with Low Speed Follow, safety
support, low tire pressure/TPMS

, and parking brake

and brake system (amber) indicators may come on in
amber along with a message in the driver information
interface when you set the power mode to ON after
reconnecting the battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

* Not available on all models

463

Main

tenan

Remote Transmitter Care

Replacing the Remote Battery

If the indicator does not come on when the button is pressed, replace the battery.

Remove the built-in key.

With the buttons facing down, remove the
upper half of the cover by carefully prying
on the slot with the key grip.

Wrap a key grip with a cloth to prevent
scratching the keyless remote.

Remove the battery by prying on the edge
with flat-tip screwdriver. Make sure to
replace the battery with the correct polarity.

Wrap a flat-tip screwdriver with a cloth
to prevent scratching the keyless remote.

Replacing the Remote Battery

NOTICE

An improperly disposed of battery can damage the
environment. Always confirm local regulations for
battery disposal.

Replacement batteries are commercially available or
at a dealer.

WARNING

CHEMICAL BURN HAZARD

The battery that powers the remote

transmitter can cause severe internal burns

and can even lead to death if swallowed.

Keep new and used batteries away from

children.

If you suspect that a child has swallowed

the battery, seek medical attention

immediately.

Battery type: CR2032

Battery

464

Main

tenan

Climate Control System Maintenance

Air Conditioning

To ensure proper and safe operation, the Society of Automotive Engineers (SAE
J2845) recommends that the refrigerant system only be serviced by trained and
certified technicians.

Never repair or replace the air conditioning evaporator (cooling coil) with one
removed from a used or salvaged vehicle.

New replacement mobile air conditioning evaporators must be certified (and
labeled) as meeting SAE Standard J2842.

Dust and Pollen Filter

The climate control system is equipped with a dust and pollen filter that collects
pollen, dust, and other debris in the air. The Maintenance Minder

messages will let

you know when to replace the filter.

We recommend that you replace the dust and pollen filter sooner when using your
vehicle in areas with high concentrations of dust.

Air Conditioning

NOTICE

Vented refrigerant is harmful to the environment.
To avoid refrigerant from venting, never replace the
evaporator with one removed from a used or
salvaged vehicle.

Refrigerant in your vehicle’s air conditioning system is
flammable and can be ignited during servicing if
proper procedures are not followed.

The air conditioner label is found under the hood:

Safety Labels

P. 82

Specifications

P. 510

Canadian models

Caution
Flammable

Refrigerant
Requires Registered

Technician to Service
Air Conditioning

System

Dust and Pollen Filter

If the airflow from the climate control system
deteriorates noticeably, and the windows fog up
easily, the filter may need to be replaced. Please
contact a dealer for replacement.

465

Continued

Main

tenan

Cleaning

Interior Care

Use a damp cloth with a mixture of mild detergent and warm water to remove dirt.
Use a clean cloth to remove detergent residue.

Use a soft brush with a mixture of mild soap and warm water to clean the seat belts.
Let the belts air dry. Wipe the openings of the seat belt anchors using a clean cloth.

Wipe using a glass cleaner.

■

Cleaning Seat Belts

Interior Care

Do not spill liquids inside the vehicle. Electrical
devices and systems may malfunction if liquids are
splashed on them.

Do not use silicone-based sprays on electrical devices
such as audio devices and switches. Doing so may
cause the items to malfunction or cause a fire inside
the vehicle.
If a silicone-based spray is inadvertently used on
electrical devices, consult a dealer.

Depending on their composition, chemicals and
liquid aromatics may cause discoloration, wrinkles,
and cracking to resin-based parts and textiles.
Do not use alkali solvents or organic solvents such as
benzene or gasoline.

After using chemicals, make sure to gently wipe them
away using a dry cloth.
Do not place used cloths on top of resin-based parts
or textiles for long periods of time without washing.

Opening

■

Cleaning the Window

Cleaning the Window

Wires are mounted to the inside of the rear window.
Wipe along the same direction as the wires with a
soft cloth so as not to damage them.

Be careful not to spill fluids, such as water or glass
cleaner, on or around the cover of the electrical
components around the rearview mirror.

Cleaning

Interior Care

466

Main

tenan

The driver’s floor mat hooks over floor
anchors, which keep the mat from sliding
forward.

Do not put any additional floor mats on
top of the anchored mat.

To properly clean leather:

Use a vacuum or soft dry cloth first to remove any dirt or dust.

Clean the leather with a soft cloth dampened with a solution comprised of 90%
water and 10% neutral soap.

Wipe away any soap residue with a clean damp cloth.

Wipe away residual water and allow leather to air dry in the shade.

■

Floor Mats

Floor Mats

If you use any floor mats that were not originally
provided with your vehicle, make sure they are
designed for your specific vehicle, fit correctly, and
are securely anchored by the floor anchors.
Position any rear seat floor mats properly. If not
properly positioned, the floor mats can interfere with
the front seat functions.

Lock

Unlock

Example

■

Maintaining Genuine Leather

Maintaining Genuine Leather

It is important to clean or wipe away dirt or dust as
soon as possible. Spills can soak into leather, resulting
in stains. Dirt or dust can cause abrasions in the
leather. In addition, please note that some dark
colored clothing can rub onto the leather seats,
resulting in discoloration or stains.

* Not available on all models

467

Cleaning

Exterior Care

Continued

Main

tenan

Exterior Care

Dust off the vehicle body after you drive.
Regularly inspect your vehicle for scratches on painted surfaces. A scratch on a
painted surface can result in body rust. If you find a scratch, promptly repair it.

Wash the vehicle regularly. Wash more frequently when driving in the following
conditions:

•

If driving on roads with road salt.

•

If driving in coastal areas.

•

If tar, soot, bird droppings, insects, or tree sap is stuck to painted surfaces.

•

Make sure to follow the instructions indicated on the automated car wash.

•

Fold in the door mirrors.

•

Keep sufficient distance between the cleaning nozzle and the vehicle body.

•

Take particular care around the windows. Standing too close may cause water to
enter the vehicle interior.

•

Do not spray high pressure water directly into the engine compartment. Instead,
use low pressure water and a mild detergent.

•

Do not spray water directly onto the camera or the area around it. Water may
enter the lens and cause the camera to malfunction.

■

Washing the Vehicle

■

Using an Automated Car Wash

■

Using High Pressure Cleaners

Washing the Vehicle

Do not spray water into the air intake vents. It can
cause a malfunction.

Lock the doors when washing the vehicle.
Do not spray water onto the fuel fill door directly. A
high-pressure spray may cause it to open.

Do not spray water onto the capless unit when the
fuel fill door is open. It can cause damage to the fuel
system or engine.

If you need to lift the wiper arms away from the
windshield, first set the wiper arms to the
maintenance position.

Lifting the Front Wiper Arms

P. 448

Air Intake Vents

Cleaning

Exterior Care

468

Main

tenan

A good coat of automotive body wax helps protect your vehicle’s paint from the
elements. Wax will wear off over time and expose your vehicle’s paint to the
elements, so reapply as necessary.

If you get gasoline, oil, engine coolant, or battery fluid on resin-coated parts, they
may stain or the coating may peel. Promptly wipe it away using a soft cloth and
clean water.

Wipe using a glass cleaner.

Aluminum is susceptible to deterioration caused by salt and other road
contaminants. When necessary, as early as possible use a sponge and mild detergent
to wipe away these contaminants. Do not use a stiff brush or harsh chemicals
(including some commercial wheel cleaners). These can damage the protective finish
on aluminum alloy wheels, resulting in corrosion. Depending on the type of finish,
the wheels also may lose their luster or appear burnished. To avoid water stains,
wipe the wheels dry with a cloth while they are still wet.

■

Applying Wax

■

Maintaining the Bumpers and Other Resin-Coated Parts

■

Cleaning the Window

■

Maintaining Aluminum Wheels

Applying Wax

NOTICE

Chemical solvents and strong cleaners can damage
the paint, metal, and plastic on your vehicle. Wipe
away spills immediately.

Maintaining the Bumpers and Other Resin-Coated Parts

Ask a dealer about the correct coating material when
you want to repair the painted surface of the parts
made of resin.

469

Cleaning

Exterior Care

Main

tenan

The inside lenses of exterior lights (headlights, brake lights, etc.) may fog temporarily
if you have driven in the rain, or after the vehicle has been run through a car wash.
Dew condensation also may build up inside the lenses when there is a significant
enough difference between the ambient and inside lens temperatures (similar to
vehicle windows fogging up in rainy conditions). These conditions are natural
processes, not structural design problems in the exterior lights.

Lens design characteristics may result in moisture developing on the light lens frame
surfaces. This also is not a malfunction.

However, if you see large amounts of water accumulation, or large water drops
building up inside the lenses, have your vehicle inspected by a dealer.

■

Fogged Exterior Light Lenses

470

Main

tenan

Accessories and Modifications

Accessories

When installing accessories, check the following:

•

Do not install accessories on the windshield. They can obstruct your view and
delay your reaction to driving conditions.

•

Do not install any items other than Honda Genuine Accessories designated for
your vehicle over areas marked

SRS AIRBAG

, on the sides or backs of the front

seats, on the sides of the rear seats, on front or side pillars, or near the side
windows.
Items other than Honda Genuine Accessories designated for your vehicle installed
in these areas may interfere with proper operation of the vehicle’s airbags or may
be propelled into you or another occupant if the airbags deploy.

•

Be sure electronic accessories do not overload electrical circuits or interfere with
proper operation of your vehicle.

Fuses

P. 497

•

Before installing any electronic accessory, have the installer contact a dealer for
assistance. If possible, have a dealer inspect the final installation.

Accessories and Modifications

Honda Genuine Accessories are recommended to
ensure proper operation on your vehicle.

Some Honda Genuine Accessories are supplied with
an exclusive owner’s manual for the operation and
care detail of the product. If an accessory owner’s
manual is provided to you, please refer to it for full
detail.

If any Honda Genuine Accessories become
inoperable, refer to the separate accessory owner’s
manual (if applicable) or consult a dealer for
assistance to troubleshoot the potential faulty
condition.

WARNING

Improper accessories or modifications can

affect your vehicle’s handling, stability, and

performance, and cause a crash in which

you can be seriously hurt or killed.

Follow all instructions in this owner’s

manual regarding accessories and

modifications.

471

Accessories and Modifications

Modifications

Main

tenan

Modifications

Do not modify your vehicle in a manner that may affect its handling, stability, or
reliability, or install non-genuine Honda parts or accessories that may have a similar
effect.

Even minor modifications to vehicle systems can affect overall vehicle performance.
Always make sure all equipment is properly installed and maintained, and do not
make any modification to your vehicle or its systems that might cause your vehicle
to no longer meet federal, state, province, territory, and local regulations.

The on-board diagnostic port (OBD-II/SAE J1962 connector) installed on this vehicle
is intended to be used with automobile system diagnostic devices or with other
devices that Honda has approved. Use of any other type of device may adversely
affect the vehicle’s electronic systems or allow them to be compromised, possibly
resulting in a system malfunction, drained battery, or other unexpected problems.

Do not modify or attempt to repair any of the electrical components.

475

Continued

Han
dlin

g the U

nexpected

If a Tire Goes Flat

Changing a Flat Tire

If a tire goes flat while driving, grasp the steering wheel firmly and brake gradually
to reduce speed. Then, stop in a safe place. Replace the flat tire with a spare tire. Go
to a dealer as soon as possible to have the regular tire repaired or replaced.

Park the vehicle on a firm, level, non-slippery surface and apply the parking brake.

Put the transmission into

(

Turn on the hazard warning lights and set the power mode to VEHICLE OFF.

Changing a Flat Tire

Follow compact spare precautions:
Periodically check the tire pressure of the compact
spare. It should be set to the specified pressure.
Specified Pressure: 60 psi (420 kPa, 4.2 kgf/cm

)

When driving with the compact spare tire, keep the
vehicle speed under 50 mph (80 km/h). Replace with
a regular tire as soon as possible.

The compact spare tire and wheel in your vehicle are
specifically for this model. Do not use them with
another vehicle. Do not use another type of compact
spare tire or wheel with your vehicle.

Do not mount tire chains on a compact spare tire.
If a chain-mounted front tire goes flat, remove one of
the regular rear tires and replace it with the compact
spare tire. Remove the flat front tire and replace it
with the regular tire that was removed from the rear.
Mount the tire chains on the front tire.

NOTICE

Do not use the jack if it doesn’t work properly.
Call your dealer or a professional towing service.

476

If a Tire Goes Flat

Changing a Flat Tire

Han
dlin

g the U

nexpected

Open the trunk floor lid.

Take the tool case out of the trunk.

Take the jack, wheel nut wrench, and jack
handle bar out of the tool case.

Unscrew the wing bolt and remove the
spacer cone. Then, remove the compact
spare tire.

Place a wheel block or rock in front and rear
of the wheel diagonal to the flat tire.

■

Getting Ready to Replace the Flat Tire

Tool Case

Compact

Spare Tire

Wheel

Blocks

The tire to be replaced.

If a Tire Goes Flat

Changing a Flat Tire

478

Han
dlin

g the U

nexpected

Place the jack under the jacking point
closest to the tire to be changed.

Turn the end bracket clockwise as shown in
the image until the top of the jack contacts
the jacking point.

Make sure that the jacking point tab is
resting in the jack notch.

Raise the vehicle, using the jack handle bar
and the jack handle, until the tire is off the
ground.

■

How to Set Up the Jack

How to Set Up the Jack

Do not use the jack with people or luggage in the
vehicle.

Use the jack provided in your vehicle.
Other jacks may not support the weight (“load”) or
may not fit the jacking point.

The following instructions must be followed to use
the jack safely:

•

Do not use while the engine is running.

•

Use only where the ground is firm and level.

•

Use only at the jacking points.

•

Do not get in the vehicle while using the jack.

•

Do not put anything on top of or underneath the
jack.

WARNING

The vehicle can easily roll off the jack,

seriously injuring anyone underneath.

Follow the directions for changing a tire

exactly, and never get under the vehicle

when it is supported only by the jack.

Jacking Points

Jacking Point

Jack

Handle

Bar

Wheel Nut

Wrench as Jack Handle

Continued

479

If a Tire Goes Flat

Changing a Flat Tire

Han
dlin

g the U

nexpected

Remove the wheel nuts and flat tire.

Wipe the mounting surfaces of the wheel
with a clean cloth.

Mount the compact spare tire.

Screw the wheel nuts until they touch the
lips around the mounting holes, then stop
rotating.

Lower the vehicle and remove the jack.
Tighten the wheel nuts in the order
indicated in the image. Go around
tightening the nuts two to three times in
this order.

Wheel nut torque:

80 lbf∙ft (108 N∙m, 11 kgf∙m)

■

Replacing the Flat Tire

Replacing the Flat Tire

Do not over tighten the wheel nuts by applying extra
torque using your foot or a pipe.

If a Tire Goes Flat

Changing a Flat Tire

480

Han
dlin

g the U

nexpected

Remove the center cap.

Place the flat tire face down in the compact
spare tire well.

Remove the spacer cone from the wing
bolt, flip it over, and insert it back on the
bolt. Secure the flat tire with the wing bolt.

Securely store the jack, wheel nut wrench,
and jack handle bar back in the tool case.

Store the case in the trunk.

■

Storing the Flat Tire

Storing the Flat Tire

WARNING

Loose items can fly around the interior in a

crash and can seriously injure the

occupants.

Store the wheel, jack, and tools securely

before driving.

Center Cap

Spacer Cone

Wing Bolt

For

compact

spare tire

For

regular

tire

481

If a Tire Goes Flat

Changing a Flat Tire

Han
dlin

g the U

nexpected

If you replace a flat tire with the compact spare tire, the low tire pressure/TPMS
indicator comes on while you are driving. After driving for a few miles (kilometers),

Tire pressure monitor system problem. Check tire pressure. See your dealer.

will appear on the driver information interface and the indicator will start blinking
for a short time and then stay on; however, this is normal and is no cause for
concern.

Calibrate the TPMS when you replace the tire with a specified regular tire.

TPMS Calibration

P. 318

■

TPMS and the Compact Spare Tire

* Not available on all models

482

Han
dlin

g the U

nexpected

Engine Does Not Start

Checking the Engine
