Honda Accord (2024 year). Manual in english

387

Honda Sensing

Traffic Jam Assist

Continued

Driving

■

Roadway conditions

•

Driving on a road with temporary lane markings.

•

Faint, multiple, or varied lane markings are visible on the roadway due to road
repairs or old lane markings.

•

The roadway has merging, split, or crossing lines, such as at an intersection or
crosswalk.

•

The lane markings are extremely narrow, wide, or changing.

•

Part of the lane markings are hidden by an object, such as a vehicle.

•

The road is hilly or the vehicle is approaching the crest of a hill.

•

Your vehicle is strongly shaken on uneven road surfaces.

Faded lines

Duplicate lines

Tire tracks

Very wide or narrow traffic lane

388

Honda Sensing

Traffic Jam Assist

Driving

•

When objects on the road (curb, guard rail, pylons, etc.) are recognized as white
(or yellow) lines.

•

Driving on rough or unpaved roads, or over bumpy surfaces.

•

Driving on roads with double lane lines.

•

Driving on snowy or slippery roads.

•

The pavement is only partially visible due to snow or puddles on the road.

•

There is a film of water or puddles on the road surface.

•

White (or yellow) lines are not recognized correctly due to road conditions such as
curves, twists, or hills.

•

Driving on unpaved or rutted roads.

•

Passing through an exit or an interchange.

Lane void of lines at exit or

interchange

389

Honda Sensing

Traffic Jam Assist

Driving

■

Vehicle conditions

•

When lighting is weak due to dirt covering the headlight lenses, or there is poor
visibility in a dark place due to the headlights being improperly adjusted.

•

The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals,
accessories, stickers, or film on the windshield.

•

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

•

There is residue on the windshield from the windshield wipers.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

•

The vehicle is tilted due to a heavy load in the trunk or rear seats.

•

The suspension has been modified.

•

Tire chains are installed.

390

Honda Sensing

Traffic Sign Recognition System

Driving

Traffic Sign Recognition System

Reminds you of road sign information, such as the current speed limit your vehicle
has just passed through, showing it on the gauge.

When the camera located behind the rearview mirror captures traffic signs while
driving, the system displays the ones that are recognized as designated for your
vehicle. If speed limit warning is activated, the sign icon blinks when the maximum
speed of the traffic sign detected is exceeded by a threshold, when compared with
the vehicle speed. The sign icon will be displayed until the vehicle reaches a
predetermined time and distance.
If the system does not detect any traffic signs while you are driving, the sign icon will
not be displayed.

The sign icon also may switch to another one, or disappear when:

•

The end of speed limit or other designated limit is detected.

•

You make a turn with a turn signal at an intersection.

■

How the System Works

Traffic Sign Recognition System

Not all signs may be displayed, but any signs posted
on roadsides should not be ignored. The system does
not work on the designated traffic signs of all the
countries you travel, nor in all situations.
Do not rely too much on the system. Always drive at
speeds appropriate for the road conditions.

Never apply a film or attach any objects to the
windshield that could obstruct the camera’s field of
vision and cause the system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making even
minor repairs within the camera’s field of vision or
installing an aftermarket replacement windshield may
also cause the system to operate abnormally. After
replacing the windshield, have a dealer recalibrate the
camera. Proper calibration of the camera is necessary
for the system to operate properly.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing system
to shut off, find a shady area or face the front of the
vehicle away from the sun when parking. If you use a
reflective sun shade, do not allow it to cover the
camera housing.
Covering the camera can concentrate heat on it.

Speed Limit Sign

Continued

391

Honda Sensing

Traffic Sign Recognition System

Driving

Traffic Sign Recognition System

You can read about handling information for the
camera equipped with this system.

Front Sensor Camera

P. 396

You can turn the Traffic Sign Recognition system on
and off.

Vehicle Settings

P. 126

The default speed limit warning threshold is the
maximum speed of the traffic sign detected.
You can adjust the threshold for speed limit warning.

Vehicle Settings

P. 126

The system’s ability to accurately notify the driver of
the speed limit is dependent on certain conditions
such as the units displayed on the traffic sign as well
as the speed and direction of travel of the vehicle. In
some cases, the system may display false warnings or
other inaccurate information.

Traffic Sign Recognition System Conditions
and Limitations

P. 392

The unit for speed limits (mph or km/h) varies from
country to country. Just after entering a country
whose unit differs to the one of the country from
which you came, the Traffic Sign Recognition system
may not work correctly.

Vehicle Settings

P. 126

Speed/distance units

P. 123

Honda Sensing

Traffic Sign Recognition System

392

Driving

The Traffic Sign Recognition system may incorrectly recognize, be slow to identify,
or fail to recognize the traffic sign in the following cases.

■

Environmental conditions

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Driving at night, in dark areas such as long tunnels.

•

Driving in bad weather (rain, fog, snow, etc.).

•

Sudden changes between light and dark, such as the entrance or exit of a tunnel
or the shadows of trees, buildings, etc.

•

Water is sprayed by or snow blown from a vehicle ahead.

■

Roadway conditions

•

Your vehicle is strongly shaken on uneven road surfaces.

■

Vehicle conditions

•

When lighting is weak due to dirt covering the headlight lenses, or there is poor
visibility in a dark place due to the headlights being improperly adjusted.

•

The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals,
accessories, stickers, or film on the windshield.

•

There is residue on the windshield from the windshield wipers.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

•

The vehicle is tilted due to heavy load in the trunk or rear seats.

•

The suspension has been modified.

•

Tire chains are installed.

•

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

■

Traffic Sign Recognition System Conditions and Limitations

Traffic Sign Recognition System Conditions and Limitations

When the Traffic Sign Recognition system
malfunctions,

appears on the gauge. If this

message does not disappear, have your vehicle
checked by a dealer.

393

Honda Sensing

Traffic Sign Recognition System

Continued

Driving

■

The position or the condition of the traffic sign

•

The sign is in a place that makes it hard to find.

•

The sign is located far away from your vehicle.

•

The sign is located where it is hard for headlight beams to reach.

•

The sign is on a corner or bend in the road.

•

The sign is faded or bent.

•

The sign is rotated or damaged.

•

The sign is covered with mud, snow, or frost.

•

Part of the sign is hidden by the trees, or is in the shadow of a vehicle or other
object.

•

Light (such as a streetlight) is reflected on the surface of the sign, or it is hidden
in shadow.

•

The sign is too bright or too dark (electric signs).

•

Small signs (auxiliary signs, etc.).

■

Other conditions

•

When you are driving at a high speed.

394

Honda Sensing

Traffic Sign Recognition System

Driving

The Traffic Sign Recognition system may not operate correctly, such as displaying
signs that do not adhere to the actual regulations for the roadway or do not exist at
all in the following cases.

A speed limit sign may display at a higher or lower speed than the actual speed
limit.

•

There is a supplementary sign with further information such as weather, time,
vehicle type, school zone, etc.

•

Figures on the sign are hard to read (electric signs, numbers on the sign are
blurred, etc.).

•

The sign is in the vicinity of the lane you are driving in, even though it is not for
the lane, such as a speed limit sign situated at an exit or an intersection between
the side road and the main road.

•

There are things that look similar in color or shape to recognized objects (similar
sign, electric sign, signboard, structure, etc.).

395

Honda Sensing

Traffic Sign Recognition System

Driving

Up to two traffic signs can be simultaneously displayed next to each other when
detected. Speed limit, do not pass, stop, do not enter, and yield icons can be
displayed on the gauge.
Additional signs that indicate speed limit based on zones such as school zones can
also appear.

■

Signs Displayed on the Gauge

Speed Limit Sign

Do Not Pass Sign

396

Honda Sensing

Front Sensor Camera

Driving

Front Sensor Camera

The camera, used in systems such as Collision Mitigation Braking System

(CMBS

), Road Departure Mitigation system, Adaptive Cruise Control (ACC) with

Low Speed Follow, Lane Keeping Assist System (LKAS), Traffic Jam Assist, Traffic
Sign Recognition system, and auto high-beam system, is designed to detect an
object that triggers any of the systems to operate their functions.

This camera is located behind the rearview
mirror.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing
system to shut off, find a shady area or face
the front of the vehicle away from the sun
when parking. If you use a reflective sun
shade, do not allow it to cover the camera
housing. Covering the camera can
concentrate heat on it.

■

Camera Location and Handling Tips

Front Sensor Camera

Never apply a film or attach any objects to the
windshield, the hood, or the front grille that could
obstruct the camera’s field of vision and cause the
system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making
even minor repairs within the camera’s field of vision
or installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Do not place an object on the top of the instrument
panel. It may reflect onto the windshield and prevent
the system from detecting lane lines properly.

Front Sensor

Camera

397

Honda Sensing

Front Sensor Camera

Driving

Front Sensor Camera

If the

Some driver assist systems cannot operate:

Camera temperature too high

message appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed towards the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the

Some driver assist systems cannot operate:

Clean front windshield or poor viewing
condition.

message appears:

•

Park your vehicle in a safe place, and make sure the
windshield is clean. Clean the windshield if it is
dirty. If the message does not disappear after
driven for a while, have your vehicle checked by a
dealer.

398

Honda Sensing

Radar Sensor

Driving

Radar Sensor

The radar sensor is behind the Honda emblem
on the front grille.

Radar Sensor

For the system to work properly, observe the
following precautions.

•

Always keep the emblem and front grille clean.

•

Never use chemical solvents or polishing powder
for cleaning the emblem and front grille. Clean it
with water or a mild detergent.

•

Do not put any stickers or paint on the emblem or
front grille.

•

Do not scratch or damage the emblem or front
grille.

•

Do not replace the emblem, front grille, or bumper.

•

Do not remove or disassemble the radar sensor.

Consult a dealer if:

•

The radar sensor cover is strongly impacted.

•

The front grille or bumper needs to be repaired.

If the vehicle is involved in any of the following
situations, the radar sensor may not work properly.
Have your vehicle checked by a dealer:

•

Your vehicle is involved in a frontal collision.

•

Your vehicle drives through deep water or is
submerged in deep water.

•

Your vehicle strongly strikes a bump, curb, chock,
slope, or embankment that could jar the radar
sensor.

Radar

Sensor

399

Continued

Driving

Braking

Brake System

Use the parking brake to keep the vehicle stationary when parked. When the
parking brake is applied, you can manually or automatically release it.

■

To apply

The electric parking brake can be applied any
time the vehicle has battery, no matter which
position the power mode is in.

Pull the electric parking brake switch up gently
and securely.

The indicator in the switch comes on.

The parking brake and brake system
indicator (red) comes on.

■

To release

The power mode must be in ON in order to
release the electric parking brake.

Depress the brake pedal.

Press the electric parking brake switch.

The indicator in the switch goes off.

The parking brake and brake system
indicator (red) goes off.

Manually releasing the parking brake using
the switch helps your vehicle start slowly and
smoothly when facing downhill on steep hills.

■

Parking Brake

Braking

When you depress the brake pedal, you may hear a
whirring sound from the engine compartment. This is
because the brake system is in operation, and it is
normal.

Parking Brake

You may hear the electric parking brake system
motor operating from the rear wheel area when you
apply or release the parking brake. This is normal.

The brake pedal may slightly move due to the electric
parking brake system operation when you apply or
release the parking brake. This is normal.

You cannot apply or release the parking brake if the
battery goes dead.

If the Battery Is Dead

P. 486

If you pull up and hold the electric parking brake
switch while driving, the brakes on all four
wheels are applied by the VSA

system until the

vehicle comes to a stop. The electric parking
brake then applies, and the switch should be
released.

Electric Parking Brake Switch

Braking

Brake System

400

Driving

Parking Brake

In the following situations, the parking brake
automatically operates.

•

When the vehicle stops more than 10 minutes
while ACC with Low Speed Follow is activated.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped automatically by ACC with
Low Speed Follow.

•

When the engine is turned off, except by Auto Idle
Stop system, while ACC with Low Speed Follow is
activated.

•

When the vehicle stops with the automatic brake
hold system activated for more than 10 minutes.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped and brake hold is applied.

•

When the engine is turned off, except by Auto Idle
Stop system, while brake hold system is applied.

•

When there is a problem with the automatic brake
hold system while brake hold is applied.

Continued

401

Braking

Brake System

Driving

■

Automatic parking brake feature operation

If the automatic parking brake feature has been activated:

•

The parking brake is applied automatically when you set the power mode to
VEHICLE OFF.

•

To confirm that the parking brake is applied, check if the parking brake and brake
system indicator (red) is on.

Activating and deactivating the automatic parking brake feature

P. 402

■

To release automatically

Depressing the accelerator pedal releases the parking brake.

Use the accelerator pedal to release the brake when you are starting the vehicle
facing uphill, or in a traffic jam.

Gently depress the accelerator pedal.
When on a hill, it may require more
accelerator input to release.

The parking brake and brake system
indicator (red) goes off.

You can release the parking brake automatically when:

•

You are wearing the driver’s seat belt.

•

The engine is running.

•

The transmission is not in

(

Parking Brake

If the parking brake cannot be released
automatically, release it manually.

When the vehicle is traveling uphill, the accelerator
pedal may need to be pressed farther to
automatically release the electric parking brake.

The parking brake cannot be released automatically
while the following indicators are on:

•

Malfunction indicator lamp

•

Transmission system indicator

The parking brake may not be released automatically
while the following indicators are on:

•

Parking brake and brake system indicator (amber)

•

Vehicle Stability Assist

(VSA

) System indicator

•

Anti-lock Brake System (

ABS

) indicator

•

Supplemental restraint system indicator

Accelerator Pedal

Braking

Brake System

402

Driving

■

Activating and deactivating the automatic parking brake feature

With the power mode is in ON, carry out the following steps to either activate or
deactivate the automatic parking brake feature.

Shift the select lever to

(

Without depressing the brake pedal, pull up and release the electric parking brake
switch.

Check that the parking brake and brake system indicator (red) has come on.

Pull up and hold the electric parking brake switch. When you hear a beeping
sound, release the switch and within three seconds pull up and hold the switch
again.

When you hear a sound indicating that the procedure is completed, release the
switch.

Two beeps indicates that the feature has been activated.

One beep indicates that the feature has been deactivated.

When you have completed activating the feature, the parking brake will
remain applied after you turn off the engine.

To confirm that the parking brake is applied, check if the parking brake and
brake system indicator (red) is on.

Activating and deactivating the automatic parking brake feature

In cold climates, the parking brake may freeze in
place if applied.
When parking the vehicle, chock the wheels and
make sure the automatic parking brake feature is
deactivated.
Also, when putting your vehicle through a conveyor-
type car wash or when having your vehicle towed,
deactivate the automatic parking brake feature and
leave the parking brake released.

Continued

403

Braking

Brake System

Driving

If you need to temporarily deactivate the feature while putting your vehicle through
a conveyor type car wash or when having your vehicle towed, follow the procedure
explained below.

Depress the brake pedal and bring the vehicle to a stop.

Set the power mode to VEHICLE OFF and then within two seconds push down the
electric parking brake switch.

Activation and deactivation settings for the feature will not be affected.

Before temporarily deactivating the feature, make sure to first turn off both
ACC with Low Speed Follow and the automatic brake hold system.

To confirm that the parking brake is applied, check if the parking brake and
brake system indicator (red) is on.

Your vehicle is equipped with disc brakes at all four wheels. The brake assist system
increases the stopping force when you depress the brake pedal hard in an
emergency situation. The anti-lock brake system (ABS) helps you retain steering
control when braking very hard.

Brake Assist System

P. 408

Anti-lock Brake System (ABS)

P. 407

■

Foot Brake

Foot Brake

Check the brakes after driving through deep water,
or if there is a buildup of road surface water. If
necessary, dry the brakes by lightly depressing the
pedal several times.

If you hear a continuous metallic friction sound when
applying the brakes, this is caused by the brake wear
indicator rubbing on the brake rotor and indicates
that the brake pads need to be replaced. Have the
vehicle checked by a dealer. If you hear only an
occasional squeak or squeal when you initially apply
the brake pedal, this may be normal and caused by
high frequency vibration of the brake pads against
the rotating brake disc.

Constantly using the brake pedal while going down a
long hill builds up heat, which reduces the brake
effectiveness. Apply engine braking by taking your
foot off the accelerator pedal and downshifting to a
speed position.

Do not rest your foot on the brake pedal while
driving, as it will lightly apply the brakes and cause
them to lose effectiveness over time and reduce pad
life. It will also confuse drivers behind you.

Whenever the brakes are activated by CMBS

another system that automatically controls braking,
the brake pedal is depressed and released in
accordance with braking function.

Braking

Brake System

404

Driving

Keeps the brake applied after releasing the brake pedal until the accelerator pedal is
pressed. You can use this system while the vehicle is temporarily stopped, like at
traffic lights and in heavy traffic.

■

Turning on the system

Fasten your seat belt properly, then start the
engine. Press the automatic brake hold
button.

The automatic brake hold system
indicator comes on. The system is turned
on.

The system is in the previously selected on or
off setting each time you fasten the driver’s
seat belt and start the engine.

■

Activating the system

Depress the brake pedal to come to a
complete stop. The shift lever must not be in

(

The automatic brake hold indicator
comes on. Braking is kept for up to 10
minutes.

Release the brake pedal after the
automatic brake hold indicator comes
on.

■

Automatic Brake Hold

Automatic Brake Hold

WARNING

Activating the automatic brake hold system

on steep hills or slippery roads may still

allow the vehicle to move if you remove

your foot from the brake pedal.
If a vehicle unexpectedly moves, it may

cause a crash resulting in serious injury or

death.
Never activate the automatic brake hold

system or rely on it to keep a vehicle from

moving when stopped on a steep hill or

slippery roads.

WARNING

Using the automatic brake hold system to

park the vehicle may result in the vehicle

unexpectedly moving.
If a vehicle moves unexpectedly, it may

cause a crash, resulting in serious injury or

death.
Never leave the vehicle when braking is

temporarily kept by automatic brake hold

and always park the vehicle by putting the

transmission in

(

and applying the parking

brake.

Comes

Automatic Brake

Hold Button

Comes

Brake Pedal

Comes

U.S.

Canada

Continued

405

Braking

Brake System

Driving

■

Canceling the system

Depress the accelerator pedal while the shift
lever is in a position other than

(

. The

system is canceled and the vehicle starts to
move.

The automatic brake hold indicator goes
off. The system continues to be on.

■

The system automatically cancels when:

•

You engage the parking brake.

•

You depress the brake pedal and put the transmission into

(

■

The system automatically cancels and the parking brake is applied when:

•

Braking is kept for more than 10 minutes.

•

The driver’s seat belt is unfastened.

•

The engine is turned off.

•

There is a problem with automatic brake hold system.

Automatic Brake Hold

While the system is activated, you can turn off the
engine or park the vehicle through the same
procedure as you normally do.

When Stopped

P. 409

You may hear an operating noise if the vehicle moves
while the automatic brake hold system is in
operation.

WARNING

When using the automatic brake hold,

keep your foot on the brake pedal until the

automatic brake hold indicator comes on.

If the vehicle unexpectedly moves, it may

cause a crash resulting in serious injury or

death.

Release your foot from the brake pedal

after the automatic brake hold indicator

comes on.

Goes

Off

Accelerator Pedal

Braking

Brake System

406

Driving

■

Turning off the automatic brake hold system

Only the automatic brake hold system
indicator comes on:

•

Press the automatic brake hold button.

The automatic brake hold system
indicator goes off.

When the automatic brake hold indicator
comes on at the same time:

•

Press the automatic brake hold button with
the brake pedal depressed.

The automatic brake hold system
indicator and the automatic brake hold
indicator go off.

Turning off the automatic brake hold system

Make sure to turn off the automatic brake hold
system before using an automated car wash.

If you turn off the engine or unfasten the driver’s seat
belt while the automatic brake hold system is on, the
automatic brake hold system will automatically turn
off. In this case, when the driver’s seat belt is
fastened and the engine is restarted, the automatic
brake hold system will turn on without needing to
press the automatic brake hold button.

Automatic Brake

Hold Button

Goes

Off
Goes

Off

407

Braking

Anti-lock Brake System (ABS)

Driving

Anti-lock Brake System (ABS)

Helps prevent the wheels from locking up, and helps you retain steering control by
pumping the brakes rapidly, much faster than you can.

The electronic brake distribution (EBD) system, which is part of the ABS, also
balances the front-to-rear braking distribution according to vehicle loading.

You should never pump the brake pedal. Let the ABS work for you by always
keeping firm, steady pressure on the brake pedal. This is sometimes referred to as
“stomp and steer.”

■

ABS operation

The brake pedal may pulsate slightly when the ABS is working. Depress the brake
pedal and keep holding the pedal firmly down. On dry pavement, you will need to
press on the brake pedal very hard before the ABS activates. However, you may feel
the ABS activate immediately if you are trying to stop on snow or ice.

ABS may activate when you depress the brake pedal when driving on:

•

Wet or snow covered roads.

•

Roads paved with stone.

•

Roads with uneven surfaces, such as potholes, cracks, manholes, etc.

When the vehicle speed goes under 6 mph (10 km/h), the ABS stops.

■

ABS

Anti-lock Brake System (ABS)

NOTICE

The ABS may not function correctly if you use a tire of
the incorrect size or type.

If the ABS indicator comes on while driving, there
may be a problem with the system. While normal
braking will not be affected, there is a possibility that
the ABS will not be operating. Have your vehicle
checked by a dealer immediately.

The ABS is not designed for the purpose of reducing
the time or distance it takes for a vehicle to stop: It is
designed to limit brake lockup which can lead to
skidding and loss of steering control.

In the following cases, your vehicle may need more
distance to stop than a vehicle without the ABS:

•

You are driving on rough or uneven road surfaces,
such as gravel or snow.

•

The tires are equipped with tire chains.

The following may be observed with the ABS system:

•

Motor sounds coming from the engine
compartment when the brakes are applied, or
when system checks are being performed after the
engine has been started and while the vehicle
accelerates.

•

Brake pedal and/or the vehicle body vibration when
ABS activates.

These vibrations and sounds are normal to ABS
systems and are no cause for concern.

408

Braking

Brake Assist System

Driving

Brake Assist System

Designed to assist the driver by generating greater braking force when you depress
the brake pedal hard during emergency braking.

■

Brake assist system operation

Press the brake pedal firmly for more powerful braking.

When brake assist operates, the pedal may wiggle slightly and an operating noise
may be heard. This is normal. Keep holding the brake pedal firmly down.

409

Continued

Driving

Parking Your Vehicle

When Stopped

Depress the brake pedal firmly.

With the brake pedal depressed, pull up the electric parking brake switch slowly,
but fully.

Change the shift position to

(

Turn off the engine.

The parking brake and brake system indicator (red) goes off in about 30
seconds.

Always set the parking brake, especially if you are parked on an incline.

Parking Your Vehicle

Do not park your vehicle near flammable objects,
such as dry grass, oil, or timber.
Heat from the exhaust can cause a fire.

NOTICE

The following can damage the transmission:

•

Depressing the accelerator and brake pedals
simultaneously.

•

Holding the vehicle in place when facing uphill by
depressing the accelerator pedal.

•

Moving the shift lever into

(

before the vehicle

stops completely.

WARNING

The vehicle can roll away if left unattended

without confirming that Park is engaged.

A vehicle that rolls away could cause a crash

resulting in serious injury or death.

Always keep your foot on the brake pedal

until you have confirmed that

(

is shown

on the shift position indicator.

411

Parking Your Vehicle

Cross Traffic Monitor

Continued

Driving

Cross Traffic Monitor

Monitors the rear corner areas using the radar sensors when reversing, and alerts
you if a vehicle approaching from a rear corner is detected.

The system is convenient when you are backing out of a parking space.

Cross Traffic Monitor

CAUTION

Cross Traffic Monitor cannot detect all

approaching vehicles and may not detect

an approaching vehicle at all.

Failure to visually confirm that it is safe to

back up the vehicle before doing so may

result in a collision.

Do not solely rely on the system when

reversing; always also use your mirrors, and

look behind and to the sides of your vehicle

before reversing.

* Not available on all models

Parking Your Vehicle

Cross Traffic Monitor

412

Driving

The system activates when:

•

The power mode is in ON.

•

The Cross Traffic Monitor is turned on.

Cross Traffic Monitor On and Off

P. 414

•

The transmission is in

(

•

Your vehicle is moving at 3 mph (5 km/h) or
lower.

When a vehicle is detected approaching from a rear corner, Cross Traffic Monitor
alerts you with a buzzer and a displayed warning.

The system will not detect a vehicle that approaches from directly behind your
vehicle, nor will it provide alerts about a detected vehicle when it moves directly
behind your vehicle.

The system does not provide alerts for a vehicle that is moving away from your
vehicle, and it may alert for pedestrians, bicycles, or stationary objects.

■

How the System Works

Cross Traffic Monitor

Cross Traffic Monitor may not detect or may delay
alerting an approaching vehicle, or may alert without
an approaching vehicle under the following
conditions:

•

An obstacle, such as another vehicle or a wall near
your vehicle’s rear bumper, is blocking the radar
sensor’s scope.

•

Your vehicle is moving at a speed of about 3 mph
(5 km/h) or higher.

•

A vehicle is approaching at a speed other than
between about 6 mph (10 km/h) and 16 mph (25
km/h).

•

The system picks up external interference such as
other radar sensors from another vehicle or strong
radio wave transmitted from a facility nearby.

•

Either corner of the rear bumper is covered with
snow, ice, mud or dirt.

•

When there is bad weather.

•

Your vehicle is on an incline.

•

Your vehicle is tilted due to a heavy load in the rear.

•

Your vehicle is reversing towards a wall, a pole, a
vehicle, and so on.

If the rear bumper or the sensors have been
improperly repaired or the rear bumper has been
deformed. Have your vehicle checked by a dealer.

For proper operation, always keep the rear bumper
corner area clean.
Do not cover the rear bumper corner area with labels
or stickers of any kind.

Radar sensors:

Underneath the rear bumper

corners

* Not available on all models

Continued

413

Parking Your Vehicle

Cross Traffic Monitor

Driving

An arrow icon appears on the side a vehicle is approaching on the audio/information
screen.

■

When the System Detects a Vehicle

When the System Detects a Vehicle

If the

on the lower right changes to

in amber

when the transmission is in

(

, mud, snow or ice,

etc. may have accumulated in the vicinity of the
sensor. The system is temporarily canceled. Check the
bumper corners for any obstructions, and thoroughly
clean the area if necessary.

If the

comes on when the transmission is in

(

there may be a problem with the Cross Traffic
Monitor system. Do not use the system and have your
vehicle checked by a dealer.

If the display remains the same with the transmission
in

(

, there may be a problem with the rear camera

system and the Cross Traffic Monitor system.
Do not use the system and have your vehicle checked
by a dealer.

Wide View

Normal View

Arrow Icon

Top Down View

414

Parking Your Vehicle

Cross Traffic Monitor

Driving

The system can be turned on and off on the
audio/information screen by selecting the
Cross Traffic Monitor icon.

You can also switch the system on and off
using the audio/information screen.

Customized Features

P. 259

■

Cross Traffic Monitor On and Off

Cross Traffic Monitor icon

415

Continued

Driving

Multi-View Rear Camera

About Your Multi-View Rear Camera

The audio/information screen can display your vehicle’s rear view.
The display automatically changes to the rear view when the transmission is put into

(

■

Multi-View Rear Camera Display Area

About Your Multi-View Rear Camera

The rear camera view is restricted. You cannot see
the corner ends of the bumper or what is underneath
the bumper. Its unique lens also makes objects
appear closer or farther than they actually are.

Visually confirm that it is safe to drive before backing
up. Certain conditions (such as weather, lighting, and
high temperatures) may also restrict the rear view. Do
not rely on the rearview display which does not give
you all information about conditions at the back of
your vehicle.

The rear camera view is displayed prior to the audio/
information screen.

If the camera lens is covered with dirt or moisture,
use a soft, moist cloth to keep the lens clean and free
of debris.

You can change the

Fixed Guideline

and

Dynamic

Guideline

settings.

Customized Features

P. 259

Fixed Guideline
ON:

Guidelines appear when you put the

transmission into

(

OFF:

Guidelines do not appear.

Dynamic Guideline
ON:

Guidelines move according to the steering wheel

direction.

OFF:

Guidelines do not move.

Approx. 20 inches (50 cm)

Approx. 39 inches (1 m)

Camera

Multi-View Rear Camera

About Your Multi-View Rear Camera

416

Driving

You can view three different camera modes on the audio/information screen.
Select appropriate icon to switch the mode.

•

If you were last using Wide view mode or Normal view mode, the same view
mode will be activated the next time you put the transmission into

(

•

If you were using Top down view mode before you turned off the engine, Wide
view mode will be activated the next time you set the power mode to ON and put
the transmission into

(

•

If you were using Top down view mode and 10 seconds elapsed after you took
the transmission out of

(

, Wide view mode will be activated the next time you

put the transmission into

(

•

If you were using Top down view mode and put the transmission back into

(

within 10 seconds after you took it out of

(

, Top down view mode will be

activated.

About Your Multi-View Rear Camera

If the vehicle’s rear view is not displayed on the audio/
information screen while the shift position is in

(

there may be a problem with the system. Have your
vehicle checked by a dealer immediately.

Wide view

mode

Normal view

mode

Top down view

mode

Bumper

417

Driving

Refueling

Fuel Information

■

Fuel recommendation

Use of a lower octane gasoline can cause a persistent, heavy metallic knocking noise
that can lead to engine damage.

■

Top tier detergent gasoline

Because the level of detergency and additives in gasoline vary in the market, Honda
endorses the use of “TOP TIER Detergent Gasoline” where available to help
maintain the performance and reliability of your vehicle. TOP TIER Detergent
Gasoline meets a new gasoline standard jointly established by leading automotive
manufacturers to meet the needs of today’s advanced engines.

Qualifying gasoline retailers will, in most cases, identify their gasoline as having met
“TOP TIER Detergent Gasoline” standards at the retail location. This fuel is
guaranteed to contain the proper level of detergent additives and be free of metallic
additives. The proper level of detergent additives, and absence of harmful metallic
additives in gasoline, help avoid buildup of deposits in your engine and emission
control system.

For further important fuel-related information for your vehicle, or on information on
gasoline that does not contain MMT, visit

www.hondacars.com.

In Canada, visit

www.honda.ca

for additional information on gasoline. For more information on top

tier gasoline, visit

www.toptiergas.com

■

Fuel tank capacity: 14.8 US gal (56 L)

Unleaded gasoline, pump octane number 87 or higher

Fuel Information

NOTICE

We recommend quality gasoline containing
detergent additives that help prevent fuel system and
engine deposits. In addition, in order to maintain
good performance, fuel economy, and emissions
control, we strongly recommend the use of gasoline
that does NOT contain harmful manganese-based
fuel additives such as MMT, if such gasoline is
available.

Use of gasoline with these additives may adversely
affect performance, and cause the malfunction
indicator lamp on your instrument panel to come on.
If this happens, contact a dealer for service.
Some gasoline today is blended with oxygenates such
as ethanol. Your vehicle is designed to operate on
oxygenated gasoline containing up to 15% ethanol
by volume. Do not use gasoline containing methanol.
If you notice any undesirable operating symptoms, try
another service station or switch to another brand of
gasoline.

418

Refueling

How to Refuel

Driving

How to Refuel

Your fuel tank is not equipped with a fuel filler cap. You can insert the filler nozzle
directly into the filler neck. The tank seals itself again when you pull out the filler
nozzle.

Stop your vehicle with the service station
pump on the left side of the vehicle in the
rear.

Turn off the engine.

Unlock the driver’s door.

The fuel fill door on the outer side of the
vehicle will unlock.

Press and release the area indicated by the
arrow to release the fuel fill door. You will
hear a click and the lid will open slightly.

Manually pull the fuel fill door to a fully
open position.

How to Refuel

The fuel filler opening is designed to accept only
service station filler nozzles for refueling. Use of
smaller diameter tubes (e.g., those used to siphon fuel
for other uses) or other non-service station devices can
damage the area in and around the filler opening.

Use the master door lock switch to unlock the fuel fill
door.
The vehicle doors and fuel fill door automatically
relock if the keyless remote unlock function is used.
This can be deactivated by briefly opening then
closing the driver’s door.

Using the Walk away auto lock

feature will also lock

the fuel fill door. Always make sure both the driver’s
door and fuel fill door are unlocked before
attempting to open the fuel fill door.

Locking the doors and trunk (Walk away
auto lock

)

P. 141

WARNING

Gasoline is highly flammable and explosive.

You can be burned or seriously injured

when handling fuel.

•

Stop the engine, and keep heat, sparks,
