Continued

291

uu

Before Driving

u

Driving Preparation

Driving

•

Store or secure all items on board properly.

u

Carrying too much cargo, or improperly storing it, can affect your vehicle’s
handling, stability, stopping distance, and tires, and make it unsafe.

2

Maximum Load Limit

 P. 293

•

Do not pile items higher than the seat height.

u

They can block your view and may be thrown forward in the event of sudden
braking.

•

Do not place anything in the front seat footwells. Make sure to secure the floor
mat.

u

An object or unsecured floor mat can interfere with your brake and accelerator
pedal operation while driving.

•

If you have any animals on board, do not let them move around in the vehicle.

u

They may interfere with driving and a crash could occur.

•

Securely close and lock all doors and the trunk.

2

Locking/Unlocking the Doors from the Inside

 P. 148

•

Adjust your seating position properly.

u

Adjust the head restraint, too.

2

Seats

 P. 180

2

Adjusting the Front Head Restraint Positions

 P. 187

•

Adjust the mirrors and steering wheel properly.

u

Adjust them while sitting in the proper driving position.

2

Mirrors

 P. 178

2

Adjusting the Steering Wheel

 P. 177

■

Interior Checks

1

Interior Checks

The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the trunk, have the aiming readjusted
at a dealer or by a qualified technician.

292

uu

Before Driving

u

Driving Preparation

Driving

•

Be sure items placed on the floor behind the front seats cannot roll under the
seats.

u

They can interfere with the driver’s ability to operate the pedals, the operation
of the seats, or the operation of the sensors under the seats.

•

Everyone in the vehicle must fasten their seat belt.

2

Fastening a Seat Belt

 P. 45

•

Make sure that the indicators in the instrument panel come on when you start the
vehicle, and go off soon after.

u

Always have a dealer check the vehicle if a problem is indicated.

2

Indicators

 P. 84

293

uu

Before Driving

u

Maximum Load Limit

Continued

Driving

Maximum Load Limit

The maximum load for your vehicle is 850 lbs (385 kg). See the
Tire and Loading Information label attached to the driver’s
doorjamb.

This figure includes the total weight of all occupants, cargo, and
accessories, and the tongue load if you are towing a trailer

.

Steps for Determining Correct Load Limit -

(1)

Locate the statement “The combined weight of occupants and
cargo should never exceed XXX kg or XXX lbs.” on your
vehicle’s placard.

(2)

Determine the combined weight of the driver and passengers
that will be riding in your vehicle.

(3)

Subtract the combined weight of the driver and passengers
from XXX kg or XXX lbs.

(4)

The resulting figure equals the available amount of cargo and
luggage load capacity. For example, if the “XXX” amount
equals 1,400 lbs. and there will be five 150 lb. passengers in
your vehicle, the amount of available cargo and luggage load
capacity is 650 lbs. (1,400 - 750 (5 x 150) = 650 lbs.)

1

Maximum Load Limit

Gross Vehicle Weight Rating (GVWR):
The maximum allowable weight of the vehicle, all
occupants, all accessories, all cargo.

2

Specifications

 P. 510

Gross Axle Weight Rating (GAWR):
The maximum allowable weight of the vehicle axle.

2

Specifications

 P. 510

3

WARNING

Overloading or improper loading

can affect handling and stability

and cause a crash in which you

can be hurt or killed.
Follow all load limits and other

loading guidelines in this manual.

Label Example

uu

Before Driving

u

Maximum Load Limit

294

Driving

(5)

Determine the combined weight of luggage and cargo being
loaded on the vehicle. That weight may not safely exceed the
available cargo and luggage load capacity calculated in step 4.

(6)

If your vehicle will be towing a trailer, load from your trailer will
be transferred to your vehicle. Consult this manual to
determine how this reduces the available cargo and luggage
load capacity of your vehicle.

In addition, the total weight of the vehicle, all occupants,
accessories, cargo, and trailer tongue load must not exceed the
Gross Vehicle Weight Rating (GVWR) or the Gross Axle Weight
Rating (GAWR). Both are on a label on the driver’s doorjamb.

1

Maximum Load Limit

Towing a Trailer:
See Towing a Trailer to determine whether your
vehicle is designed to tow a trailer.

2

Towing a Trailer

 P. 295

Load Limits Example

Example1

Max Load

850 lbs

(385 kg)

Passenger Weight

150 lbs x 2 = 300 lbs

(68 kg x 2 = 136 kg)

Cargo Weight

550 lbs

(249 kg)

Example2

Max Load

850 lbs

(385 kg)

Passenger Weight

150 lbs x 5 = 750 lbs

(68 kg x 5 = 340 kg)

Cargo Weight

100 lbs

(45 kg)

295

Driving

Towing a Trailer

Your vehicle is not designed to tow a trailer. Attempting to do so can void your
warranties.

Towing Behind a Motorhome

Your vehicle is not designed to be towed behind a motorhome. If your vehicle needs
to be towed in an emergency, refer to the emergency towing information.

2

Emergency Towing

 P. 504

296

Driving

When Driving

Starting the Engine

1.

Make sure the parking brake is applied.

u

The parking brake and brake system
indicator (red) comes on for 30 seconds
when you pull up the electric parking
brake switch.

2.

Check that the transmission is in

(

P

, then

depress the brake pedal.

u

Although it is possible to start the vehicle
in

(

N

, it is safer to start it in

(

P

.

3.

Press the

ENGINE START/STOP

 button

without depressing the accelerator pedal.

1

Starting the Engine

Keep your foot firmly on the brake pedal when
starting the engine.

The engine is harder to start in cold weather and in
thinner air found at altitudes above 8,000 feet (2,400
meters).

When starting the engine in cold weather, turn off all
electrical accessories such as the lights, climate
control system and rear defogger in order to reduce
battery drain.

If you live in a region where winter is extremely cold,
an engine block heater will improve starting and
warming of the engine. Consult a dealer for details.

If the exhaust system sounds abnormal or you can
smell exhaust gas inside the vehicle, have your vehicle
checked by a dealer. There may be a problem with
the engine or exhaust system.

Bring the keyless remote close to the

ENGINE

START/STOP

 button if the battery in the keyless

remote is weak.

2

If the Keyless Remote Battery is Weak



P. 483

Electric Parking Brake Switch

Brake Pedal

Continued

297

uu

When Driving

u

Starting the Engine

Driving

1

Starting the Engine

Do not hold the

ENGINE START/STOP

 button to

start the engine.
If the engine does not start, wait at least 30 seconds
before starting the engine again.

The engine may not start if the keyless remote is
subjected to strong radio waves.

The immobilizer system protects your vehicle from
theft.
If an improperly coded device is used, the engine’s
fuel system is disabled.

2

Immobilizer System

 P. 155

uu

When Driving

u

Starting the Engine

298

Driving

You can remotely start the engine using the keyless remote.

■

To start the engine

Press the

 button, then press and hold

the

button.

u

Some exterior lights flash once.

If the engine starts successfully, some exterior
lights flash six times.

If the engine does not start, exterior lights will
not flash.

u

Go within the range, and try again.

■

Remote Engine Start

1

Remote Engine Start

The remote engine start may violate local laws.
Before using the remote engine start, check your
local laws.

If there are buildings and obstacles between your
vehicle and the keyless remote, the range will be
reduced.
This distance may vary by external electrical
interference.

3

WARNING

Carbon monoxide gas is toxic and can

rapidly accumulate in closed or even partly

enclosed areas.

Breathing it can cause unconsciousness and

even kill you.

Never use the remote engine starter with

the vehicle parked in a garage or other

areas with limited ventilation.

LED: Blinks when any

button is pressed.

Continued

299

uu

When Driving

u

Starting the Engine

Driving

When started remotely, the engine automatically shuts off after 10 minutes of idling
and/or the brake pedal and

ENGINE START/STOP

 button have not been pressed

simultaneously.
To extend the run time for another 10 minutes during the first run, press the



button, then press and hold the

 button.

u

Some exterior lights flash six times if a 10-minute extension request was
transmitted successfully.

1

Remote Engine Start

The engine may not start by the remote engine start
if:

•

You have disabled a remote engine start setting.

2

Vehicle Settings

 P. 126

•

The power mode is not in VEHICLE OFF.

•

The transmission is in a position other than

(

P

.

•

The hood is open, or any door or the trunk is
unlocked.

•

You have already used the remote twice to start
the engine.

•

Another registered keyless remote is in the vehicle.

•

There is any antenna failure.

•

The door is unlocked with the built-in key.

•

The engine oil pressure is low.

•

The engine coolant temperature is extremely high.

•

The security system alarm is not set.

•

The shift lever release button is pressed.

•

The battery charge is too low.

•

You press the

ENGINE START/STOP

 button.

•

The system is updating.

uu

When Driving

u

Starting the Engine

300

Driving

■

To stop the engine

Press and hold the

 button for one

second.

If the engine stops successfully, the exterior
lights flash once.

When the keyless remote is out of the keyless
access system range, the exterior lights will
not flash.
The engine will not stop.

u

Go within the range, and try again.

1

Remote Engine Start

The engine may stop while it is running if:

•

You do not start the vehicle within 10 minutes of
starting the engine with the keyless remote.

•

The engine is stopped by using the keyless remote.

•

The security system alarm is activated.

•

The door is unlocked with the built-in key.

•

The hood is open.

•

The trunk, or any door is unlocked without using
the keyless remote or keyless access system.

•

You press the shift lever release button.

•

The engine coolant temperature is extremely high.

•

The engine oil pressure is low.

•

The malfunction indicator lamp comes on if there is
a problem with the emissions control systems.

•

The

ENGINE START/STOP

 button is pressed while

a door has been opened without using the keyless
remote or keyless access system.

While the engine is running, the vehicle will
automatically precondition inside the vehicle.
When it is warm outside:

•

The climate control system is activated in
recirculation mode.

When it is cold outside:

•

The defroster is activated at a moderately warm
temperature.

•

The rear defogger, heated door mirrors

*

, and front

seat heaters

*

 are activated.

2

Rear Defogger/Heated Door Mirror

*



Button

 P. 176

2

Front Seat Heaters

*

 P. 198

* Not available on all models

301

uu

When Driving

u

Starting the Engine

Driving

1.

Depress and hold the brake pedal, then press the

ENGINE START/STOP

 button.

2.

Keeping your right foot on the brake pedal, put the transmission into

(

D

. Select

(

R

 when reversing.

3.

With the parking brake applied, release the brake pedal and gently depress the
accelerator pedal.

u

Make sure the parking brake and brake system indicator (red) goes off.

2

Parking Brake

 P. 399

■

Hill start assist system

Hill start assist keeps the brake engaged briefly to help prevent the vehicle from
rolling on inclines as you move your foot from the brake pedal to the accelerator.

Put the transmission into

(

D

,

(

S

, or

(

L

 when facing uphill, or

(

R

 when facing

downhill, then release the brake pedal.

You can turn the engine off when the vehicle is completely stopped.

1.

Put the transmission into

(

P

.

2.

Press the

ENGINE START/STOP

 button.

■

Starting to Drive

■

Stopping the Engine

1

Starting to Drive

The engine stops when the transmission is taken out
of

(

P

 before the

ENGINE START/STOP

 button is

pressed. Follow the step 1 when starting to drive.

You can also release the parking brake by pressing
the electric parking brake switch while depressing the
brake pedal.
When facing downhill, you can start your vehicle
more smoothly by manually releasing it with the
electric parking brake switch than by releasing it with
the accelerator pedal.

When the engine was started using the

 button

on the keyless remote

When the engine was started using the

 button on the keyless remote

When the engine was started in any case

1

Hill start assist system

Hill start assist may not prevent the vehicle from
rolling downhill on a very steep or slippery slope, and
will not operate on small inclines.

Hill start assist is not a replacement for the parking brake.

Hill start assist will operate even when VSA

®

 is

switched off.

1

Stopping the Engine

The power mode will automatically turn to VEHICLE
OFF about 20 minutes after the following conditions
have been met:

•

A door has been opened, such as when leaving the
vehicle.

•

The transmission is in

(

P

.

•

The driver’s seat belt is not fastened.

302

uu

When Driving

u

Precautions While Driving

Driving

Precautions While Driving

Avoid driving in deep water and on flooded roads. This can damage the engine or
driveline, or cause electrical component failure.

If there is a strong impact with something under the vehicle, stop in a safe location.
Check the underside of the vehicle for damage or any fluid leaks.

■

In Rain

■

Other Precautions

1

Precautions While Driving

NOTICE

Do not operate the shift lever while pressing the
accelerator pedal. You could damage the
transmission.

NOTICE

If you repeatedly turn the steering wheel at an
extremely low speed, or hold the steering wheel in
the full left or right position for a while, the electric
power steering (EPS) system heats up. The system
goes into a protective mode and limits its
performance. The steering wheel becomes harder
and harder to operate. Once the system cools down,
the EPS system is restored.
Repeated operation under these conditions can
eventually damage the system.

If the power mode is set to ACCESSORY while
driving, the engine will shut down and all steering
and brake power assist functions will stop, making it
difficult to control the vehicle.

Do not select

(

N

 while driving as you will lose engine

braking (and acceleration) performance.

During the first 600 miles (1,000 km) of operation,
avoid sudden acceleration or full throttle operation so
as not to damage the engine or powertrain.

Avoid hard braking for the first 200 miles (300 km)
after purchasing your new vehicle or replacing the
brake pads or rotors to allow for proper break-in.

303

uu

When Driving

u

Continuously Variable Transmission

Driving

Continuously Variable Transmission

When the engine runs at higher idle speeds, the creeping force increases.
Keep the brake pedal firmly depressed when stopped.

Quickly depressing the accelerator pedal while driving uphill may cause the
transmission to drop to a lower ratio, unexpectedly increasing vehicle speed.
Depress the accelerator pedal carefully, especially on slippery roads and curves.

■

Creeping

■

Kickdown

304

uu

When Driving

u

Shifting

Driving

Shifting

Change the shift position in accordance with your driving needs.

■

Shift lever positions

1

Shifting

You cannot change the power mode from ON to
VEHICLE OFF unless the shift lever is in

(

P

.

The vehicle may move very slightly even in

(

N

 while

the engine is cold.
Depress the brake pedal firmly and, when necessary,
apply the parking brake.

Reverse

Used when reversing.

Drive

Used for normal driving.

Park

Used when parking or starting the engine.

Neutral

Transmission is not locked.

Release Button

Drive (S)

Used:

●

For better acceleration

●

To increase engine braking

●

When going up or down hills

Low

Used:

●

To further increase engine braking

●

When going up or down hills

305

uu

When Driving

u

Shifting

Driving

■

Shift Lever Operation

1

Shift Lever Operation

NOTICE

When you change the shift lever from

(

D

 to

(

R

 and

vice versa, come to a complete stop and keep the
brake pedal depressed.
Operating the shift lever before the vehicle has come
to a complete standstill can damage the transmission.

Use the shift position indicator to check the lever
position before pulling away.

If the transmission system indicator blinks when
driving, in any shift position, there is a problem with
the transmission.
Avoid sudden acceleration and have the transmission
checked by a dealer as soon as possible.

The fuel supply may be cut off if you drive at engine
speeds in or over the tachometer red zone (engine
speed limit). If this happens, you may experience a
slight jolt.

It may not be possible to operate the shift lever if the
brake pedal is applied while the shift lever release
button is held down.
Depress the brake pedal first.

When shifting positions in extremely low
temperatures (-22°F/-30°C), there may be a short
delay before the shift position is displayed. Always
confirm you are in the correct shift position before
driving.

Depress the brake pedal and press the shift lever release

button to shift.

Shift without pressing the shift lever release button.

Press the shift lever release button and shift.

Shift Position Indicator

(Transmission System Indicator)

Tachometer Red Zone

306

uu

When Driving

u

ECON Mode

Driving

ECON Mode

The

ECON

 button turns the ECON mode on and off.

The ECON mode helps you improve your fuel economy by adjusting the
performance of the engine, climate control system, and Adaptive Cruise Control
(ACC) with Low Speed Follow.

1

ECON Mode

While in ECON mode, the climate control system has
greater temperature fluctuation.

The mode may not be able to be changed under
some driving conditions.
If there is a vehicle system failure, the following
message will also appear on the driver information
interface, and you cannot select any other mode.

ECON

 Button

307

uu

When Driving

u

Auto Idle Stop

Continued

Driving

Auto Idle Stop

To help maximize fuel economy, the engine automatically stops when the vehicle
comes to a stop, depending on environmental and vehicle operating conditions. The
indicator (green) comes on at this time.

The environmental and vehicle conditions that
impact Auto Idle Stop system operation are
varied.

2

Auto Idle Stop Activates When:

 P. 310, 311

The engine then restarts once the vehicle is
about to move again, and the indicator
(green) goes off.

2

The Engine Automatically Restarts When:



P. 312

If the driver’s door is opened while the
indicator (green) comes on, a buzzer sounds
to notify you that the Auto Idle Stop function
is in operation.

A message associated with Auto Idle Stop
appears on the driver information interface.

1

Auto Idle Stop

The 12-volt battery installed in this vehicle is
specifically designed for a model with Auto Idle Stop.
Using a 12-volt battery other than this specified type
may shorten the 12-volt battery life, and prevent
Auto Idle Stop from activating. If you need to replace
the 12-volt battery, make sure to select the specified
type. Ask a dealer for more details.

The duration of the Auto Idle Stop operation:

•

Increase in the ECON mode, compared to when the
ECON mode is off, with climate control in use.

2

ECON Mode

 P. 306

Auto Idle Stop

Indicator (Green)

308

uu

When Driving

u

Auto Idle Stop

Driving

The Auto Idle Stop suspend indicator comes
on and a message appears on the driver
information interface when the Auto Idle Stop
system cannot be activated.

2

Indicators

 P. 84

2

Auto Idle Stop System ON/OFF

 P. 309

Auto Idle Stop

Suspend Indicator

Continued

309

uu

When Driving

u

Auto Idle Stop

Driving

To turn the Auto Idle Stop system off, press
this button. The Auto Idle Stop system stops.

u

Auto Idle Stop system will stop and the
indicator will come on and a message
appears on the driver information
interface.

The Auto Idle Stop system is turned on every
time you start the engine, even if you turned it
off the last time you drove the vehicle.

■

Auto Idle Stop System ON/OFF

1

Auto Idle Stop System ON/OFF

If you turn off the Auto Idle Stop system while it is
activated, the engine will restart.

2

Auto Idle Stop Activates When:

 P. 310

If you press and hold the Auto Idle Stop

OFF

 button,

you can select whether to display the status messages
or not.

Auto Idle Stop

OFF

 Button

Auto Idle Stop

OFF



Indicator

uu

When Driving

u

Auto Idle Stop

310

Driving

The vehicle stops with the transmission in

(

D

 and the brake pedal depressed.

When you put the transmission into

(

P

 quickly with depressing the brake pedal, the

Auto Idle Stop continues to operate, even if the brake pedal is released.

u

If you depress the brake pedal, the engine may automatically restart.

■

Auto Idle Stop does not activate when:

•

The Auto Idle Stop

OFF

 button is pressed.

•

The driver’s seat belt is not fastened.

•

The engine is not adequately warmed up or coolant temperature is high.

•

The engine is started with the hood open.

u

Turn off the engine. Close the hood before you restart the engine to activate
Auto Idle Stop.

•

The battery charge is low.

•

The internal temperature of the battery is 41°F (5°C) or less.

•

The transmission fluid temperature is low or high.

•

The transmission is in a position other than

(

D

.

•

The vehicle comes to a stop again before the vehicle speed reaches 3 mph (5 km/h)
after the engine starts.

•

The vehicle is stopped on a steep incline.

•

 is on (indicator on).

•

The climate control system is in use, and the temperature is set to

Hi

 or

Lo

.

•

The climate control system is in use, and the outside temperature is below -4°F
(-20°C) or over 104°F (40°C).

■

Auto Idle Stop Activates When:

1

Auto Idle Stop Activates When:

Do not open the hood while the Auto Idle Stop
function is activated. If the hood is opened, the
engine will not restart automatically.

In this case, restart the engine with the

ENGINE

START/STOP

 button.

2

Starting the Engine

 P. 296

Pressing the

ENGINE START/STOP

 button causes

the engine to no longer restarts automatically. Follow
the standard procedure to start the engine.

2

Starting the Engine

 P. 296

When ACC with Low Speed Follow is in operation,
the vehicle stops without depressing the brake pedal
and Auto Idle Stop may activate.
In such cases, the engine may restart if you change
the shift position other than

(

D

.

311

uu

When Driving

u

Auto Idle Stop

Continued

Driving

■

Auto Idle Stop may not activate when:

•

The steering wheel is operated.

•

Altitude is high.

•

The vehicle is stopped by braking suddenly.

•

The vehicle is repeatedly accelerated and decelerated at a low speed.

•

The fan speed is high.

•

The climate control system is in use, and there is a significant difference between
the set temperature and the actual interior temperature.

•

The climate control system is in use, and humidity in the interior is high.

uu

When Driving

u

Auto Idle Stop

312

Driving

•

The brake pedal is released (without the automatic brake hold system activated).

•

The accelerator pedal is depressed (with the automatic brake hold system activated).

2

Automatic Brake Hold

 P. 404

■

The engine restarts even if the brake pedal is depressed

*1

 when:

•

The Auto Idle Stop

OFF

 button is pressed.

•

The steering wheel is operated.

•

The transmission is put into

(

R

,

(

S

, or

(

L

, or when it is set from

(

N

 to

(

D

.

u

If you put the transmission into

(

P

 after the Auto Idle Stop activates, the Auto

Idle Stop continues to operate. In this case, the engine restarts when you
depress the brake pedal.

•

The pressure on the brake pedal is reduced and the vehicle starts moving while
stopped on an incline.

•

The brake pedal is released slightly during a stop.

•

The battery charge becomes low.

•

The accelerator pedal is depressed.

•

The driver’s seat belt is unlatched.

•

 is on (indicator on).

•

The climate control system is in use, and the difference between the set
temperature and actual interior temperature becomes significant.

•

The climate control system is being used to dehumidify the interior.

•

The vehicle ahead of you starts again when your vehicle stops automatically with
ACC with Low Speed Follow.

Briefly keeps the brake applied after releasing the brake pedal to restart the engine.
This can keep your vehicle from unexpectedly moving while on an incline.

■

The Engine Automatically Restarts When:

■

Starting Assist Brake Function

1

The Engine Automatically Restarts When:

If you are using an electronic device during Auto Idle
Stop, the device may temporarily be turned off when
the engine restarts.

1

The engine restarts even if the brake pedal is depressed

*1

 when:

*1: With the automatic brake hold system activated,
you can release the brake pedal while Auto Idle Stop
is in operation.

If the automatic brake hold system has been turned
off, or if there is a problem with the system, the
engine will restart automatically when you release
the brake pedal.

2

Automatic Brake Hold

 P. 404

313

uu

When Driving

u

Vehicle Stability Assist

TM

 (VSA

®

), aka Electronic Stability Control (ESC), System

Continued

Driving

Vehicle Stability Assist

TM

 (VSA

®

), aka Electronic

Stability Control (ESC), System

VSA

®

 helps stabilize the vehicle during cornering if the vehicle turns more or less

than what was intended. It also assists in maintaining traction on slippery surfaces.
It does so by regulating engine output and selectively applying the brakes.

When VSA

®

 activates, you may notice that the

engine does not respond to the accelerator.
You may also notice some noise from the
hydraulic brake system. You will also see the
indicator blink.

■

VSA

®

 Operation

1

Vehicle Stability Assist

TM

 (VSA

®

), aka Electronic Stability Control

(ESC), System

The VSA

®

 may not function properly if tire type and

size are mixed. Make sure to use the same size and
type of tire, and the air pressures as specified.

When the VSA

®

 system indicator comes on and stays

on while driving, there may be a problem with the
system. While this may not interfere with normal
driving, have your vehicle checked by a dealer
immediately.

VSA

®

 cannot enhance stability in all driving situations

and does not control the entire braking system. You
still need to drive and corner at speeds appropriate
for the conditions and always leave a sufficient
margin of safety.

The main function of the VSA

®

 system is generally

known as Electronic Stability Control (ESC). The
system also includes a traction control function.

The Vehicle Stability Assist

TM

 (VSA

®

) system, Adaptive

Cruise Control (ACC) with Low Speed Follow, safety
support, low tire pressure/TPMS

*

, and parking brake

and brake system (amber) indicators may come on in
amber along with a message in the driver information
interface when you set the power mode to ON after
reconnecting the battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

VSA

®

 System

Indicator

* Not available on all models

uu

When Driving

u

Vehicle Stability Assist

TM

 (VSA

®

), aka Electronic Stability Control (ESC), System

314

Driving

You can partially disable VSA

®

 features using the driver information interface.

2

Switching the Display

 P. 112

2

Vehicle Stability Assist Mode

 P. 122

Your vehicle will have normal braking and cornering ability, but traction control
function will be less effective.

VSA

®

 is turned on every time you start the engine, even if you turned it off the last

time you drove the vehicle.

■

VSA

®

 On and Off

1

Vehicle Stability Assist

TM

 (VSA

®

), aka Electronic Stability Control

(ESC), System

In certain unusual conditions when your vehicle gets
stuck in shallow mud or fresh snow, it may be easier
to free it with the VSA

®

 temporarily switched off.

When the VSA

®

 system is off, the traction control

function becomes less effective. This allows for the
wheels to spin more freely at low speed. You should
only attempt to free your vehicle with the VSA

®

 off if

you are not able to free it when the VSA

®

 is on.

Immediately after freeing your vehicle, be sure to
switch VSA

®

 on again. We do not recommend driving

your vehicle with the VSA

®

 system switched off.

You may hear a motor sound coming from the
engine compartment while system checks are being
performed immediately after starting the engine or
while driving. This is normal.

315

uu

When Driving

u

Agile Handling Assist

Driving

Agile Handling Assist

Lightly brakes each of the front and rear wheels, as needed, when you turn the
steering wheel, and helps support the vehicle’s stability and performance during
cornering.

1

Agile Handling Assist

The agile handling assist cannot enhance stability in
all driving situations. You still need to drive and
corner at speeds appropriate for the conditions and
always leave a sufficient margin of safety.

When the VSA

®

 system indicator comes on and stays

on while driving, the agile handling assist does not
activate.

You may hear a sound coming from the engine
compartment while the agile handling assist is
activated. This is normal.

316

uu

When Driving

u

Tire Pressure Monitoring System (TPMS)

*

Driving

Tire Pressure Monitoring System (TPMS)

*

Instead of directly measuring the pressure in each tire, the TPMS on this vehicle
monitors and compares the rolling radius and rotational characteristics of each
wheel and tire while you are driving to determine if one or more tires are
significantly under-inflated.

This will cause the low tire pressure/TPMS
indicator to come on and a message to appear
on the driver information interface.

*1 : Appears when any one tire is significantly under-inflated. (e.g., a front right side tire)
*2 : Appears when two or more tires are significantly under-inflated.

1

Tire Pressure Monitoring System (TPMS)

*

The system does not monitor the tires when driving
at low speed.

Conditions such as low ambient temperature and
altitude change directly affect tire pressure and can
trigger the low tire pressure/TPMS indicator to come on.

Tire pressure checked and inflated in:

•

Warm weather can become under-inflated in
colder weather.

•

Cold weather can become overinflated in warmer
weather.

The low tire pressure/TPMS indicator will not come
on as a result of overinflation.

The TPMS may not function properly if tire type and
size are mixed. Make sure to use the same size and
type of tire.

2

Checking and Maintaining Tires

 P. 451

The low tire pressure/TPMS indicator may come on
with a delay or may not come on at all when:

•

You rapidly accelerate, decelerate, or turn the
steering wheel.

•

You drive on snowy or slippery roads.

•

Tire chains are used.

•

The tire loses air pressure rapidly.

Low Tire

Pressure/TPMS

Indicator

*1

*2

* Not available on all models

Continued

317

uu

When Driving

u

Tire Pressure Monitoring System (TPMS)

*

Driving

1

Tire Pressure Monitoring System (TPMS)

*

The low tire pressure/TPMS indicator may come on
under the following conditions:

•

A compact spare tire is used.

•

There is a heavier and uneven load on the tires than
the condition at calibration.

•

Tire chains are used.

The Vehicle Stability Assist

TM

 (VSA

®

) system, Adaptive

Cruise Control (ACC) with Low Speed Follow, safety
support, low tire pressure/TPMS, and parking brake
and brake system (amber) indicators may come on in
amber along with a message in the driver information
interface when you set the power mode to ON after
reconnecting the battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

* Not available on all models

uu

When Driving

u

Tire Pressure Monitoring System (TPMS)

*

318

Driving

You must start TPMS calibration every time you:

•

Adjust the pressure in one or more tires.

•

Rotate the tires.

•

Replace one or more tires.

Before calibrating the TPMS:

•

Set the cold tire pressure in all four tires.

2

Checking Tires

 P. 451

Make sure:

•

The vehicle is at a complete stop.

•

The transmission is in

(

P

.

•

The power mode is in ON.

■

TPMS Calibration

1

TPMS Calibration

TPMS cannot be calibrated if a compact spare tire is
installed.
The calibration process requires approximately 30
minutes of cumulative driving at speeds between 30-
60 mph (48-97 km/h).
During this period, if the power mode is set to ON and
the vehicle is not moved within 45 seconds, you may
notice the low tire pressure/TPMS indicator comes on
briefly. This is normal and indicates that the calibration
process is not yet complete.

Continued

319

uu

When Driving

u

Tire Pressure Monitoring System (TPMS)

*

Driving

When you calibrate the TPMS, do the
following.

1.

Roll the right selector wheel to select

Vehicle settings

, then press the right

selector wheel.

u

TPMS calibration

 appears on the

display.

1

TPMS Calibration

If the tire chains are installed, remove them before
calibrating the TPMS.

If the low tire pressure/TPMS indicator comes on even
when the properly inflated specified regular tires are
installed, have your vehicle checked by a dealer.

We recommend that the tires be replaced with the
same brand, model, and size as the originals. Ask a
dealer for details.

320

uu

When Driving

u

Tire Pressure Monitoring System (TPMS)

*

Driving

2.

Press the right selector wheel.

u

The display switches to the
customization setup screen, where you
can select

Cancel

 or

Calibrate

.

3.

Roll the right selector wheel and select

Calibrate

, then press the right selector

wheel.

u

Calibration started

 screen appears,

then the display returns to the
customization menu screen.

•

If the

Calibration failed to start

 message

appears, repeat step 4.

•

The calibration process finishes
automatically.

321

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) - Required Federal Explanation

Continued

Driving

Tire Pressure Monitoring System (TPMS) - Required
Federal Explanation

Each tire, including the spare (if provided), should be checked
monthly when cold and inflated to the inflation pressure
recommended by the vehicle manufacturer on the vehicle placard
or tire inflation pressure label.

(If your vehicle has tires of a different size than the size indicated
on the vehicle placard or tire inflation pressure label, you should
determine the proper tire inflation pressure for those tires.)

As an added safety feature, your vehicle has been equipped with
a tire pressure monitoring system (TPMS) that illuminates a low
tire pressure telltale

when one or more of your tires is significantly under-inflated.

Accordingly, when the low tire pressure telltale illuminates, you
should stop and check your tires as soon as possible, and inflate
them to the proper pressure.

Driving on a significantly under-inflated tire causes the tire to
overheat and can lead to tire failure. Under-inflation also reduces
fuel efficiency and tire tread life, and may affect the vehicle's
handling and stopping ability.

U.S. models

322

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) - Required Federal Explanation

Driving

Please note that the TPMS is not a substitute for proper tire
maintenance, and it is the driver's responsibility to maintain
correct tire pressure, even if under-inflation has not reached the
level to trigger illumination of the TPMS low tire pressure telltale.

Your vehicle has also been equipped with a TPMS malfunction
indicator to indicate when the system is not operating properly.
The TPMS malfunction indicator is combined with the low tire
pressure telltale. When the system detects a malfunction, the
telltale will flash for approximately one minute and then remain
continuously illuminated. This sequence will continue upon
subsequent vehicle start-ups as long as the malfunction exists.

When the malfunction indicator is illuminated, the system may
not be able to detect or signal low tire pressure as intended.

TPMS malfunctions may occur for a variety of reasons, including
the installation of replacement or alternate tires or wheels on the
vehicle that prevent the TPMS from functioning properly.

Always check the TPMS malfunction telltale after replacing one or
more tires or wheels on your vehicle to ensure that the
replacement or alternate tires and wheels allow the TPMS to
continue to function properly.
