544

Maintenance Minder

To Use Maintenance Minder

Main

tenan

The system message indicator (

) comes on along with the Maintenance Minder

message.

Maintenance Due Now

5 %

The remaining engine oil life is 5 to 1

percent. Press the

(home)

button to switch to another display.

The engine oil has almost reached the
end of its service life, and the
maintenance items should be inspected
and serviced as soon as possible.

Maintenance Past Due

Negative Distance

The engine oil has passed its service
life, and a negative distance appears
after driving over 10 miles (U.S.
models) or 10 km (Canadian
models). The negative distance on
the display blinks.

The engine oil life has passed.
The maintenance items must be
inspected and serviced immediately.

Maintenance Message

Oil Life Display

Explanation

Information

5 %

545

Maintenance Minder

To Use Maintenance Minder

Continued

Main

tenan

■

Maintenance Service Items

Maintenance Service Items

•

Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.

Maintenance Minder Message

System Message
Indicator

Sub Items

Main Item

U.S. models

*1: If a Maintenance Minder message does not appear more than 12 months after the display is reset,

change the engine oil every year.

# : See information on maintenance and emissions warranty in the first column on page

641

*2: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).
*3: If you drive primarily in urban areas that have high concentrations of soot in the air from industry and

from diesel-powered vehicles, replace the dust and pollen filter every 15,000 miles (24,000 km).

CODE

Maintenance Main Items

●

Replace engine oil

●

Replace engine oil

and oil filter

●

Inspect front and rear brakes

●

Inspect tie rod ends, steering gearbox, and boots

●

Inspect suspension components

●

Inspect driveshaft boots

●

Inspect brake hoses and lines (Including ABS/VSA

)

●

Inspect all fluid levels and condition of fluids

●

Inspect exhaust system

●

Inspect fuel lines and connections

*4:

Driving in mountainous areas at very low vehicle speeds results in higher transmission temperatures.
This requires transmission fluid changes more frequently than recommended by the Maintenance
Minder. If you regularly drive your vehicle under these conditions, have the transmission fluid changed
every 25,000 miles (40,000 km).

*5: If a Maintenance Minder message does not appear more than 36 months after the display for item 7 is

reset, change the brake fluid every 3 years.

CODE

Maintenance Sub Items

●

Rotate tires

●

Replace air cleaner element

●

Replace dust and pollen filter

●

Inspect drive belt

●

Replace transmission fluid

●

Replace spark plugs

●

Inspect valve clearance

●

Replace engine coolant

●

Replace brake fluid

Continuously variable transmission models

546

Maintenance Minder

To Use Maintenance Minder

Main

tenan

Maintenance Service Items

•

Adjust the valves during services A, 0, 9, 1, 2, or 3
if they are noisy.

Canadian models

*1: If a Maintenance Minder Message does not appear more than 12 months after the display is reset,

change the engine oil every year.

from diesel-powered vehicles, replace the dust and pollen filter every 15,000 miles (24,000 km).

*4:

*5: If a Maintenance Minder Message does not appear more than 36 months after the display for item 7 is

reset, change the brake fluid every 3 years.

# : See information on maintenance and emissions warranty in the first column on page

641

CODE

Maintenance Main Items

●

Replace engine oil

●

Replace engine oil

and oil filter

Continuously variable transmission models

CODE

Maintenance Sub Items

●

Rotate tires

●

Replace air cleaner element

●

Replace dust and pollen filter

●

Inspect drive belt

●

Replace transmission fluid

●

Replace spark plugs

●

Inspect valve clearance

●

Replace engine coolant

●

Replace brake fluid

●

Service front and rear brakes

●

Inspect tie rod ends, steering gearbox, and boots

●

Inspect suspension components

●

Inspect driveshaft boots

●

Inspect brake hoses and lines (including ABS/VSA

)

●

Inspect all fluid levels and condition of fluids

●

Inspect exhaust system

●

Inspect fuel lines and connections

547

Maintenance Minder

To Use Maintenance Minder

Main

tenan

Reset the maintenance minder information display if you have performed the
maintenance service.

Set the power mode to ON.

Press the

(home) button.

Roll the left selector wheel until

is displayed.

Press the left selector wheel to go to the

Maintenance Minder

screen.

Press the left selector wheel to enter the reset mode.

Roll the left selector wheel select a maintenance item to reset, or to select

All Due

Items

(You can also select

Cancel

to end the process).

Press the left selector wheel to reset the selected item.

Repeat from step 5 for other items you wish to reset.

■

Resetting the Display

Resetting the Display

NOTICE

Failure to reset the Maintenance Minder

display

after a maintenance service results in the system
showing incorrect maintenance intervals, which can
lead to serious mechanical problems.

The dealer will reset the Maintenance Minder

display after completing the required maintenance
service. If someone other than a dealer performs
maintenance service, reset the Maintenance
Minder

display yourself.

You can also reset the Maintenance Minder

display

using the audio/information screen.

Customized Features

P. 351

Left Selector Wheel

(home) Button

548

Main

tenan

Maintenance Under the Hood

Maintenance Items Under the Hood

1.5 L engine models

Brake Fluid
(Black Cap)

Engine Coolant
Reserve Tank

Radiator Cap

Washer Fluid
(Blue Cap)

Engine Oil Dipstick
(Orange)

Engine Oil Fill Cap

Battery

549

Maintenance Under the Hood

Maintenance Items Under the Hood

Main

tenan

2.0 L engine models

Engine Oil Dipstick
(Orange)

Washer Fluid
(Blue Cap)

Engine Coolant
Reserve Tank

Radiator Cap

Brake Fluid
(Black Cap)

Engine Oil Fill Cap

Battery

550

Maintenance Under the Hood

Opening the Hood

Main

tenan

Opening the Hood

Park the vehicle on a level surface, and set
the parking brake.

Pull the hood release handle under the
driver’s side lower corner of the dashboard.

The hood will pop up slightly.

Push the hood latch lever (located under
the front edge of the hood to the center) to
the side and raise the hood. Once you have
raised the hood slightly, you can release the
lever.

Remove the support rod from the clamp
using the grip. Mount the support rod in
the hood.

When closing, remove the support rod, and
stow it in the clamp, then gently lower the
hood. Remove your hand at a height of
approximately 12 inches (30 cm) and let the
hood close.

Opening the Hood

NOTICE

Do not open the hood when the wiper arms are
raised.
The hood will strike the wipers, resulting in possible
damage to the hood and/or the wipers.

Do not press the engine cover forcibly. This may
damage the engine cover and component parts.

When closing the hood, check that the hood is
securely latched.

If the hood latch lever moves stiffly, or if you can
open the hood without lifting the lever, the latch
mechanism should be cleaned and lubricated.

Do not open the hood while the Auto Idle Stop
function is activated.

WARNING

The hood support rod can become very hot
due to heat from the engine.

To ensure against possible burns, do not
handle the metal section of the rod:
Use the foam grip instead.

2.0 L engine models

Models with Auto Idle Stop

Hood Release Handle

Pull

Lever

Support Rod

Grip

Clamp

551

Maintenance Under the Hood

Recommended Engine Oil

Main

tenan

Recommended Engine Oil

Oil is a major contributor to your engine’s
performance and longevity. If you drive the
vehicle with insufficient or deteriorated oil,
the engine may fail or be damaged.

This seal indicates the oil is energy conserving
and that it meets the American Petroleum
Institute’s latest requirements.

Use Honda Genuine Motor Oil or another
commercial engine oil of suitable viscosity for
the ambient temperature as shown.

■

Synthetic oil

You may also use synthetic motor oil if it is labeled with the API Certification Seal
and is the specified viscosity grade.

•

Honda Genuine Motor Oil

•

Premium-grade 0W-20 detergent oil with an API Certification Seal on the
container.

Recommended Engine Oil

Engine Oil Additives
Your vehicle does not require oil additives. In fact,
they may adversely affect the engine performance
and durability.

Ambient Temperature

552

Maintenance Under the Hood

Oil Check

Main

tenan

Oil Check

We recommend that you check the engine oil level every time you refuel.
Park the vehicle on level ground.
Wait approximately three minutes after turning the engine off before you check the
oil.

Remove the dipstick (orange).

Wipe the dipstick with a clean cloth or
paper towel.

Insert the dipstick back all the way into its
hole.

Oil Check

If the oil level is near or below the lower mark, slowly
add oil, being careful not to overfill.

1.5 L engine models

2.0 L engine models

553

Maintenance Under the Hood

Oil Check

Main

tenan

Remove the dipstick again, and check the
level. It should be between the upper and
lower marks. Add oil if necessary.

Oil Check

NOTICE

Under certain driving conditions, it is normal for the
engine oil level to rise above the upper mark. If you
have a concern, consult a dealer for details.

1.5 L engine models

2.0 L engine models

Upper Mark

Lower Mark

Upper Mark

Lower Mark

554

Maintenance Under the Hood

Adding Engine Oil

Main

tenan

Adding Engine Oil

Unscrew and remove the engine oil fill cap.

Add oil slowly.

Reinstall the engine oil fill cap, and tighten
it securely.

Wait for three minutes and recheck the
engine oil dipstick.

Adding Engine Oil

NOTICE

Do not fill the engine oil above the upper mark.
Overfilling the engine oil may result in leaks and
engine damage.

If any oil spills, wipe it away immediately. Spilled oil
may damage the engine compartment components.

1.5 L engine models

2.0 L engine models

Engine Oil Fill Cap

555

Maintenance Under the Hood

Changing the Engine Oil and Oil Filter

Continued

Main

tenan

Changing the Engine Oil and Oil Filter

You must change the engine oil and oil filter regularly in order to maintain the
engine’s lubrication. The engine may be damaged if they are not changed regularly.

Change the oil and filter in accordance with the maintenance message on the driver
information interface.

Run the engine until it reaches normal
operating temperature, and then turn the
engine off.

Open the hood and remove the engine oil
fill cap.

Remove the Phillips-head screws and
slotted head screws by turning 90°
counter-clockwise on the undercarriage
and remove the under cover.

Changing the Engine Oil and Oil Filter

NOTICE

You may damage the environment if you do not
dispose of the oil in a suitable way. If you are
changing the oil by yourself, appropriately dispose of
the used oil. Put the oil in a sealed container and take
it to a recycling center. Do not throw the oil away
into a garbage can or onto the ground.

1.5 L engine models

2.0 L engine models

Under Cover

Screw

Under Cover

Screw

556

Maintenance Under the Hood

Changing the Engine Oil and Oil Filter

Main

tenan

Remove the drain bolt and washer from
the bottom of the engine, and drain the
oil into a suitable container.

1.5 L engine models

2.0 L engine models

Drain Bolt

Washer

Drain Bolt

Washer

557

Maintenance Under the Hood

Changing the Engine Oil and Oil Filter

Continued

Main

tenan

Remove the slotted head screws by
turning 90° counter-clockwise on the
undercarriage and remove the under
cover.

1.5 L engine models

2.0 L engine models

Under Cover

Screw

Under Cover

Screw

Maintenance Under the Hood

Changing the Engine Oil and Oil Filter

558

Main

tenan

Remove the oil filter and dispose of the
remaining oil.

Check that the filter gasket is not stuck to
the engine contact surface.

If it is stuck, you must detach it.

Wipe away dirt and dust adhering to the
contact surface of the engine block, and
install a new oil filter.

Apply a light coat of new engine oil to
the filter gasket.

Put a new washer on the drain bolt, then
reinstall the drain bolt.

Tightening torque:
30 lbf∙ft (40 N∙m, 4.0 kgf∙m)

10.

Pour the recommended engine oil into the
engine.

Engine oil change capacity (including
filter):

3.7 US qt (3.5 L)

5.0 US qt (4.8 L)

11.

Reinstall the engine oil fill cap securely and
start the engine.

12.

Run the engine for a few minutes, and
then check that there is no leak from the
drain bolt or oil filter.

13.

Stop the engine, wait for three minutes,
and then check the oil level on the dipstick.

If necessary, add more engine oil.

Changing the Engine Oil and Oil Filter

You will need a special wrench to replace the oil
filter. You can buy this wrench from a dealer.

When installing the new oil filter, follow the
instructions supplied with the oil filter.

Reinstall the engine oil fill cap. Start the engine. If the
low oil pressure warning appears, turn off the
engine, and check your work.

1.5 L engine models

2.0 L engine models

Oil Filter

1.5 L engine models

2.0 L engine models

559

Maintenance Under the Hood

Engine Coolant

Continued

Main

tenan

Engine Coolant

This coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.

We recommend you check the engine coolant level every time you refuel. Check the
reserve tank first. If it is completely empty, also check the coolant level in the
radiator. Add the engine coolant accordingly.

1. Make sure the engine and radiator are

cool.

Check the amount of coolant in the reserve
tank.

If the coolant level is below the

MIN

mark, add the specified coolant until it
reaches the

MAX

mark.

Inspect the cooling system for leaks.

Specified coolant: Honda Long Life Antifreeze/Coolant Type 2

■

Reserve Tank

Engine Coolant

NOTICE

Genuine Honda engine coolant is a 50/50 mixture of
antifreeze and water that can withstand freezing at
temperatures as low as about -31°F (-35°C). If your
vehicle is consistently subjected to temperatures
below this, the concentration of antifreeze in the
coolant should be increased. Consult a dealer for
details.

If Honda antifreeze/coolant is not available, you may
use another major brand of non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminum engines.
Continued use of any non-Honda coolant can result
in corrosion, causing the cooling system to
malfunction or fail. Have the cooling system flushed
and refilled with Honda antifreeze/coolant as soon as
possible.

Do not add rust inhibitors or other additives to your
vehicle’s cooling system. They may not be compatible
with the coolant or with the engine components.

WARNING

Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.

Always let the engine and radiator cool
down before removing the radiator cap.

Reserve
Tank

MAX
MIN

Content .. 32 33 34 35 ..
