Honda Accord (2022 year). Manual in english

494

Honda Sensing

Road Departure Mitigation (RDM) System

Driving

Road Departure Mitigation (RDM) System

Alerts and helps to assist you when the system detects a possibility of your vehicle
unintentionally crossing over detected lane markings and/or leaving the roadway
altogether.

The front camera behind the rearview mirror
monitors left and right lane markings (in white
or yellow). If your vehicle is getting too close
to detected lane markings without a turn
signal activated, the system, in addition to a
visual alert, applies steering torque and alerts
you with rapid vibrations on the steering
wheel, to help you remain within the detected
lane.

Customized Features

P. 351

As a visual alert, the

Lane Departure

message appears on the driver information
interface.

If the system determines that its steering input is insufficient to keep your vehicle on
the roadway, it may apply braking.

Braking is applied only when the lane markings are solid continuous lines.

The system cancels assisting operations when you turn the steering wheel to avoid
crossing over detected lane markings.

If the system operates several times without detecting driver response, the system
beeps to alert you.

■

How the System Works

Road Departure Mitigation (RDM) System

Important Safety Reminder

Like all assistance systems, the RDM system has
limitations.
Overreliance on the RDM system may result in a
collision. It is always your responsibility to keep the
vehicle within your driving lane.

The RDM system only alerts you when lane drift is
detected without a turn signal in use. The RDM
system may not detect all lane markings or lane or
roadway departures; accuracy will vary based on
weather, speed and lane marker condition. It is
always your responsibility to safely operate the
vehicle and avoid collisions.

You can read about handling information for the
camera equipped with this system.

Front Sensor Camera

P. 504

The RDM system may not work properly or may work
improperly under the certain conditions:

RDM Conditions and Limitations

P. 496

There are times when you may not notice RDM
functions due to your operation of the vehicle, or
road surface conditions.

In the following case, a beeper sounds, a message
related to the ACC with Low Speed Follow appears
on the driver information interface, and the braking
function controlled by the RDM system is canceled.

•

The vehicle has repeatedly applied the brakes to
maintain the set speed (for example, you are
descending a long slope).

Continued

495

Honda Sensing

Road Departure Mitigation (RDM) System

Driving

The system activates when all the following conditions are met:

•

The vehicle is traveling between about 45 and 90 mph (72 and 145 km/h).

•

The vehicle is on a straight or slightly curved road.

•

The turn signals are off.

•

The brake pedal is not depressed.

•

The wipers are not in high speed operation.

•

The system makes a determination that the driver is not actively accelerating,
braking, or steering.

■

How the System Activates

Road Departure Mitigation (RDM) System

If LKAS is off and you have selected

Narrow

from the

customized options using the audio/information
screen, the message below will appear in case the
system determines a possibility of your vehicle
crossing over detected lane markings.

Customized Features

P. 351

How the System Activates

The RDM system may automatically shut off and the
safety support indicator (amber) comes and stays on.

Indicators

P. 82

RDM system function can be impacted when the
vehicle is:

•

Not driven within a traffic lane.

•

Driven on the inside edge of a curve, or outside of
a lane.

•

Driven in a narrow lane.

Honda Sensing

Road Departure Mitigation (RDM) System

496

Driving

When you turn the RDM on and off, do the
following.

Press the safety support switch.

Roll the left selector wheel to the

symbol and push it.

A message appears on the driver
information interface when the system
turns on or off.

The RDM is in the previously selected

OFF

setting each time you start the engine.

The system may not properly detect lane markings and the position of your vehicle
under certain conditions. Some examples of these conditions are listed below.

■

Environmental conditions

•

Driving in bad weather (rain, fog, snow, etc.).

•

Sudden changes between light and dark, such as an entrance or exit of a tunnel.

•

There is little contrast between lane lines and the roadway surface.

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Driving in the shadows of trees, buildings, etc.

•

Shadows of adjacent objects are parallel to lane markings.

•

Roadway objects or structures are misinterpreted as lane markers.

•

Reflections on the interior of the windshield.

•

Driving at night or in a dark condition such as a tunnel.

■

RDM On and Off

RDM On and Off

When you have selected

Warning Only

from the

customized options using the audio/information
screen, the system does not operate the steering
wheel and braking.

Customized Features

P. 351

The Vehicle Stability Assist

(VSA

) system, Vehicle

Stability Assist

(VSA

)

OFF

, adaptive cruise control

(ACC) with Low Speed Follow, safety support and
low tire pressure/TPMS indicators may come on in
amber along with a message in the driver information
interface when you set the power mode to ON after
reconnecting the battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

Safety Support Switch

Left Selector Wheel

■

RDM Conditions and Limitations

497

Honda Sensing

Road Departure Mitigation (RDM) System

Driving

■

Roadway conditions

•

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

•

Driving on a road with temporary lane markings.

•

Faint, multiple, or varied lane markings are visible on the roadway due to road
repairs or old lane markings.

•

The roadway has merging, split, or crossing lines (e.g., such as at an intersection
or crosswalk).

•

The lane markings are extremely narrow, wide, or changing.

•

The vehicle in front of you is driving near the lane lines.

•

The road is hilly or the vehicle is approaching the crest of a hill.

•

Driving on rough or unpaved roads, or over bumpy surfaces.

•

When objects on the road (curb, guard rail, pylons, etc.) are recognized as white
(or yellow) lines.

•

Driving on roads with double lines.

■

Vehicle conditions

•

Headlight lenses are dirty or the headlights are not properly adjusted.

•

The outside of the windshield is streaked or blocked by dirt, mud, leaves, wet
snow, etc.

•

The inside of the windshield is fogged.

•

The camera temperature gets too high.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

When tire chains

are installed.

•

The vehicle is towing a trailer

* Not available on all models

498

Honda Sensing

Traffic Sign Recognition System

Driving

Traffic Sign Recognition System

Reminds you of road sign information, such as the current speed limit, your vehicle
has just passed through, showing it on the driver information interface and the
head-up display

When the camera located behind the rearview mirror captures traffic signs while
driving, the system displays the ones that are recognized as designated for your
vehicle. The sign icon will be displayed until the vehicle reaches a predetermined
time and distance.

The sign icon also may switch to another one or disappear when:

•

The other designated limit is detected.

•

You make a turn with a turn signal at an intersection.

■

How the System Works

Traffic Sign Recognition System

Not all signs may be displayed, but any signs posted
on roadsides should not be ignored. The system does
not work on the designated traffic signs of all the
countries you travel, nor in all situations.
Do not rely too much on the system. Always drive at
speeds appropriate for the road conditions.

Never apply a film or attach any objects to the
windshield that could obstruct the camera’s field of
vision and cause the system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making
even minor repairs within the camera’s field of vision
or installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Driver information interface

Head-up display

* Not available on all models

Continued

499

Honda Sensing

Traffic Sign Recognition System

Driving

If the system does not detect any traffic signs while you are driving, the image below
may appear.

Traffic Sign Recognition System

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing system
to shut off, when parking, find a shady area or face
the front of the vehicle away from the sun. If you use
a reflective sun shade, do not allow it to cover the
camera housing.
Covering the camera can concentrate heat on it.

You can read about handling information for the
camera equipped with this system.

Front Sensor Camera

P. 504

Driver information interface

Head-up display

* Not available on all models

Honda Sensing

Traffic Sign Recognition System

500

Driving

The traffic sign recognition system may not be able to recognize a traffic sign in the
following cases.

■

Vehicle conditions

•

Headlight lenses are dirty or the headlights are not properly adjusted.

•

The outside of the windshield is blocked by dirt, mud, leaves, wet snow, etc.

•

The inside of the windshield is fogged.

•

There are portions remaining to be wiped.

•

An abnormal tire or wheel condition (wrong sized, varied size or construction,
improperly inflated, compact spare tire, etc.).

•

The vehicle is tilted due to a heavy load or suspension modifications.

■

Environmental conditions

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Sudden changes between light and dark, such as an entrance or exit of a tunnel.

•

When you drive in the shadows of trees, buildings, etc.

•

Driving at night, in dark areas such as long tunnels.

•

Driving in bad weather (rain, fog, snow, etc.).

•

A vehicle in front of you is kicking up spray or snow.

■

Traffic Sign Recognition System Conditions and Limitations

Traffic Sign Recognition System Conditions and Limitations

When the traffic sign recognition system
malfunctions,

appears on the driver information

interface. If this message does not disappear, have
your vehicle checked by a dealer.

Driver information interface

Head-up display

* Not available on all models

501

Honda Sensing

Traffic Sign Recognition System

Continued

Driving

■

The position or the condition of the traffic sign

•

A sign is hard to be found since it is in a complicated area.

•

A sign is located far away from your vehicle.

•

A sign is located where the beam of the headlight is hard to reach.

•

A sign is on a corner or bend in the road.

•

Faded or bent signs.

•

Rotated or damaged signs.

•

A sign is covered with mud, snow, or frost.

•

A part of the sign is hidden by the trees, or the sign itself is hidden by a vehicle
and others.

•

Light (a streetlight) or a shadow is reflected on the surface of the sign.

•

A sign is too bright or too dark (an electric sign).

•

A sign of a small size.

■

Other conditions

•

When you are driving at a high speed.

502

Honda Sensing

Traffic Sign Recognition System

Driving

The traffic sign recognition system may not operate correctly, such as displaying a
sign that does not follow the actual regulation for the roadway or does not exist at
all in the following cases.

A speed limit sign may display at a higher or lower speed than the actual speed
limit.

•

There is a supplementary sign with further information such as weather, time,
vehicle type, school zone, etc.

•

Figures on the sign are hard to read (electric signs, numbers on the sign are
blurred etc.).

•

A sign is in the vicinity of the lane you are driving in, even though it is not for the
lane (speed limit sign situated at the junction between the side road and the main
road, etc.).

•

There are things that look similar to the color or shape of the recognition object
(similar sign, electric sign, signboard, structure, etc.).

•

A truck or another large vehicle with a sticker of the speed limit sign on the back
is traveling in front of you.

503

Honda Sensing

Traffic Sign Recognition System

Driving

The speed limit sign icon is displayed on the right half of the screen.

■

Selecting to display traffic signs when main mode is off

You can continue displaying a reduced-size traffic sign icon on the driver
information interface and head-up display

even while the main mode is not

selected.

Customized Features

P. 351

■

Signs Displayed on the Driver information interface and Head-
Up Display

■

When main mode is selected

■

When main mode is not selected

Speed Limit Sign

Driver information interface

Head-up display

Driver information interface

Head-up display

* Not available on all models

504

Honda Sensing

Front Sensor Camera

Driving

Front Sensor Camera

The camera, used in systems such as Lane Keeping Assist System, Road Departure
Mitigation system, Adaptive Cruise Control with Low Speed Follow, Collision
Mitigation Braking System

and traffic sign recognition system, is designed to

detect an object that triggers any of the systems to operate their functions.

This camera is located behind the rearview
mirror.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing
system to shut off, when parking, find a shady
area or face the front of the vehicle away from
the sun. If you use a reflective sun shade, do
not allow it to cover the camera housing.
Covering the camera can concentrate heat on
it.

■

Camera Location and Handling Tips

Front Sensor Camera

Never apply a film or attach any objects to the
windshield, the hood, or the front grille that could
obstruct the camera’s field of vision and cause the
system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making
even minor repairs within the camera’s field of vision
or installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Do not place an object on the top of the instrument
panel. It may reflect onto the windshield and prevent
the system from detecting lane lines properly.

Front Sensor
Camera

505

Honda Sensing

Front Sensor Camera

Driving

Front Sensor Camera

If the

Some Driver Assist Systems Cannot

Operate: Camera Temperature Too High

message

appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed towards the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the

Some Driver Assist Systems Cannot

Operate: Clean Front Windshield

message

appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

506

Honda Sensing

Radar Sensor

Driving

Radar Sensor

The radar sensor is at the lower part of the
front bumper.

•

Do not change the position of the radar
sensor or any of the surrounding parts.

•

Do not apply paint, stickers, or attach non-
genuine accessories to the front part of the
radar sensor or the surrounding area. Be
particularly careful that any custom license
plate frame or other accessory does not
block any part of the radar beam path (see
adjacent illustration).

Radar Sensor

Avoid strong impacts to the radar sensor cover.

For the CMBS

to work properly:

•

Always keep the radar sensor cover clean.

•

Never use chemical solvents or polishing powder
for cleaning the sensor cover. Clean it with water
or a mild detergent.

•

Do not put a sticker on the radar sensor cover or
replace the radar sensor cover.

If you need the radar sensor to be repaired, or
removed, or the radar sensor cover is strongly
impacted, turn off the system by using the safety
support switch and take your vehicle to a dealer.

CMBS

On and Off

P. 459

If the vehicle is involved in any of the following
situations, the radar sensor may not work properly.
Have your vehicle checked by a dealer:

•

Your vehicle is involved in a frontal collision.

•

Your vehicle drives through deep water or is
submerged in deep water.

•

Your vehicle strongly strikes a bump, curb, chock,
or embankment that could jar the radar sensor.

Radar
Sensor

Do not apply paint, stickers, or
attach accessories to the front
part of the radar sensor or the
surrounding area.

507

Honda Sensing

Sonar Sensors

Driving

Sonar Sensors

■

Location and range of sensors

The sonar sensors are situated in the front and rear bumpers.

Sonar Sensors

For the sonar sensors to work properly, do not:

•

Place stickers or other objects on or around the
sensors.

•

Hit the area around the sensors.

•

Attempt to take apart any sensor.

•

Put any accessories on or around the sensors.

Consult with a dealer if:

•

A sensor has been subjected to shock.

•

Work needs to be done to the area around a
sensor.

In the following cases, the sonar sensors may not
work properly. Have your vehicle checked by a dealer.

•

The front or rear bumper has made contact with a
hill, parking block, curb, embankment, etc.

•

The vehicle has been involved in frontal or rear
collision.

•

The vehicle has been driven through a deep
puddle.

Sonar Sensors

Sensor Range

* Not available on all models

508

Driving

Braking

Brake System

Use the parking brake to keep the vehicle stationary when parked. When the
parking brake is applied, you can manually or automatically release it.

■

To apply

The electric parking brake can be applied any
time the vehicle has battery, no matter which
position the power mode is in.

Pull the electric parking brake switch up gently
and securely.

The indicator in the switch comes on.

The parking brake and brake system
indicator (red) comes on.

■

To release

The power mode must be in ON in order to
release the electric parking brake.

Depress the brake pedal.

Press the electric parking brake switch.

The indicator in the switch goes off.

The parking brake and brake system
indicator (red) goes off.

Manually releasing the parking brake using
the switch helps your vehicle start slowly and
smoothly when facing downhill on steep hills.

■

Parking Brake

Braking

When you depress the brake pedal, you may hear a
whirring sound from the engine compartment. This is
because the brake system is in operation, and it is
normal.

Parking Brake

You may hear the electric parking brake system
motor operating from the rear wheel area when you
apply or release the parking brake. This is normal.

The brake pedal may slightly move due to the electric
parking brake system operation when you apply or
release the parking brake. This is normal.

You cannot apply or release the parking brake if the
battery goes dead.

If the Battery Is Dead

P. 606

If you pull up and hold the electric parking brake
switch while driving, the brakes on all four
wheels are applied by the VSA

system until the

vehicle comes to a stop. The electric parking
brake then applies, and the switch should be
released.

Electric Parking Brake Switch

Continued

509

Braking

Brake System

Driving

Parking Brake

In the following situations, the parking brake
automatically operates.

•

When the vehicle stops more than 10 minutes
while ACC with Low Speed Follow is activated.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped automatically by ACC with
Low Speed Follow.

•

When the engine is turned off while ACC with Low
Speed Follow is activated.

•

When the vehicle stops with the automatic brake
hold system activated for more than 10 minutes.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped and brake hold is applied.

•

When the engine is turned off while brake hold is
applied.

•

When there is a problem with the automatic brake
hold system while brake hold is applied.

•

When the engine is turned off, except by Auto Idle
Stop system, while ACC with Low Speed Follow is
activated.

•

When the engine is turned off, except by Auto Idle
Stop system, while brake hold system is applied.

1.5 L engine models

Honda Accord (2022 year). Manual in english - page 31
