Honda Accord (2022 year). Manual in english

462

Honda Sensing

Collision Mitigation Braking System

(CMBS

)

Driving

•

When there is a group of people in front of your vehicle walking together side by
side.

•

Surrounding conditions or belongings of the pedestrian alter the pedestrian’s
shape, preventing the system from recognizing that the person is a pedestrian.

•

When the pedestrian is shorter than about 3.3 feet (1 meter) or taller than about
6.6 feet (2 meters) in height.

•

When a pedestrian blends in with the background.

•

When a pedestrian is bent over or squatting, or when their hands are raised or
they are running.

•

When several pedestrians are walking ahead in a group.

•

When the camera cannot correctly identify that a pedestrian is present due to an
unusual shape (holding luggage, body position, size).

■

Automatic shutoff

The CMBS

may automatically shut itself off and the safety support indicator

(amber) comes and stays on when:

•

The temperature inside the system is high.

•

You drive off-road or on a mountain road, or curved and winding road for an
extended period.

•

An abnormal tire condition is detected (incorrect tire size, flat tire, etc.).

•

The camera behind the rearview mirror, or the area around the camera, including
the windshield, gets dirty.

Once the conditions that caused the CMBS

to shut off improve or are addressed

(e.g., cleaning), the system comes back on.

Limitations applicable to pedestrian detection only

463

Honda Sensing

Collision Mitigation Braking System

(CMBS

)

Continued

Driving

The CMBS

may activate even when you are aware of a vehicle ahead of you, or

when there is no vehicle ahead. Some examples of this are:

■

When Passing

Your vehicle approaches another vehicle ahead of you and you change lanes to pass.

■

At an intersection

Your vehicle approaches or passes another vehicle that is making a left or right turn.

■

With Little Chance of a Collision

464

Honda Sensing

Collision Mitigation Braking System

(CMBS

)

Driving

■

On a curve

When driving through curves, your vehicle comes to a point where an oncoming
vehicle is right in front of you.

■

Through a low bridge at high speed

You drive under a low or narrow bridge at high speed.

■

Speed bumps, road work sites, train tracks, roadside objects, etc.

You drive over speed bumps, steel road plates, etc., or your vehicle approaches train
tracks or roadside objects (such as a traffic sign and guard rail) on a curve or, when
parking, stationary vehicles and walls.

465

Honda Sensing

Low Speed Braking Control

Continued

Driving

Low Speed Braking Control

Using sonar sensors located on the front and rear bumpers, the vehicle detects if
there is danger of a potential collision with a wall or other obstacle. The system is
designed to alert you when a potential collision is determined, as well as assist in
reducing speed, avoiding collisions, and reducing collision severity.

Low Speed Braking Control

If the Low Speed Braking Control activates in a
situation where you do not want automatic brake
application (such as when the vehicle is between two
railroad crossing gates), simply press the brake pedal
to deactivate the system and then continue to drive
as intended.

WARNING

The Low Speed Braking Control System
cannot avoid all collisions and may not
reduce damage in each situation where the
accelerator is mistakenly or aggressively
pressed. Overreliance on the system may
result in a collision with serious injury or
death. Always check your surroundings,
your shift position, and your pedal use.
Driver remains responsible for safely
operating the vehicle.

* Not available on all models

Honda Sensing

Low Speed Braking Control

466

Driving

The Low Speed Braking Control provides a visual and audible alert when the vehicle
is moving between approximately 1 and 6 mph (2 and 10 km/h) and there is the
possibility of a collision with a detected wall or other obstacle, as well as providing
assistance with braking.

If the only rear sensors are turned off using the parking sensor system, the assistive
braking is not working when reversing.

Turning off All Rear Sensors

P. 524

■

How the System Works

Low Speed Braking Control

For directions on the proper handling of the sonar
sensors, please refer to the following page.

Sonar Sensors

P. 507

The vehicle will release the brake and start moving a
few seconds after the system is activated. To keep the
vehicle stopped, keep the brake pedal depressed or
put the transmission into

(

In order to prevent the system from activating when
not needed, always turn it off during vehicle
maintenance, when loading on ships, trucks, and so
on, when using a chassis dynamometer or free rollers
for inspection or when putting your vehicle through a
conveyor type car wash.

Do not make any modifications to the suspension or
the system may not operate correctly.

Always use the size and type of tires recommended,
make, and amount of wear. If these differ, the system
may not operate correctly.

Beep

The vehicle
applies brake

Driver
depresses
brake pedal

Remove
brake after
maintaining
stationary
position

Stop

Audible Alert

* Not available on all models

Continued

467

Honda Sensing

Low Speed Braking Control

Driving

When you turn the system on and off, do the
following.

Press the safety support switch.

Roll the left selector wheel to the

symbol and push it.

A message appears on the driver
information interface when the system
turns on or off.

The system is turned on every time you start
the engine, even if you turned it off the last
time you drove the vehicle.

■

System On and Off

System On and Off

If the battery is disconnected and reconnected, the
Low Speed Braking Control may not turn on right
away when you start the engine.
The system will automatically turn ON after the
vehicle has been moving at over 12mph (20km/h) for
some time.
If the system does not turn on, have your vehicle
checked by a dealer.

Left Selector Wheel

Safety Support Switch

Honda Sensing

Low Speed Braking Control

468

Driving

A certain amount of time has passed since activation.

The system may not operate correctly under the following conditions:

■

Examples of obstacles the sonar sensors cannot detect

•

Obstacles that do not reflect sound waves well, such as people, snow, cloth,
sponges, etc.

•

Thin obstacles such as fences, bicycles, sign posts, etc.

•

Short or small obstacles.

•

Obstacles immediately in front of the bumper.

•

Moving objects or obstacles that suddenly enter the road.

•

Obstacles that are not perpendicular to the ground, such as a wall.

■

Conditions for Cancellation

■

Low Speed Braking Control System Conditions and Limitations

Conditions for Cancellation

After Low Speed Braking Control has activated once,
it will not activate again for the same obstacle.
The system can be activated again after driving for
some time after the last activation.

Low Speed Braking Control activates separately when
moving forward and reversing. (For example, if it
activates when moving forward, it can be activated
again immediately if reversing.)

469

Honda Sensing

Low Speed Braking Control

Driving

■

Examples of situations where the sonar sensors cannot detect obstacles

•

The sonar sensors are dirty (covered by snow, water, mud, etc.).

•

The vehicle is too hot or cold.

•

The steering wheel is turned sharply when approaching the obstacle at an angle.

■

Examples of other cases where the system may not work correctly

•

The vehicle is tilted due to heavy load in the trunk or rear seats.

•

Bad weather conditions such as heavy rain, fog, snow, sandstorms, etc.

•

The ambient temperature/humidity is too high or low.

•

When going down a very steep slope.

•

When close to other vehicles with sonar sensors or other objects that emit
ultrasonic waves.

■

Situations where the system may activate even without risk of a collision

•

When passing through short or narrow gates.

•

When driving on uneven surfaces, grassy areas, or places with steps.

•

When a sloped pillar or wall is protruding from a high position.

•

When there are obstacles next to the road.

•

When driving toward flags, curtains, tree branches, railroad crossing bars, etc.

•

When driving on flooded roads.

470

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

Adaptive Cruise Control (ACC) with Low Speed Follow

Helps maintain a constant vehicle speed and a set following-interval behind a vehicle
detected ahead of yours and, if the detected vehicle comes to a stop, can decelerate
and stop your vehicle, without you having to keep your foot on the brake or the
accelerator.
When ACC with Low Speed Follow slows your vehicle by applying the brakes, your
vehicle’s brake lights will illuminate.

Adaptive Cruise Control (ACC) with Low Speed Follow

Important Reminder

As with any system, there are limits to ACC with Low
Speed Follow. Use the brake pedal whenever
necessary, and always keep a safe interval between
your vehicle and other vehicles.

WARNING

Improper use of ACC with Low Speed
Follow can lead to a crash.

Use ACC with Low Speed Follow only when
driving on expressways or freeways and in
good road and weather conditions.

WARNING

ACC with Low Speed Follow has limited
braking capability and may not stop your
vehicle in time to avoid a collision with a
vehicle that quickly stops in front of you.

Always be prepared to apply the brake
pedal if the conditions require.

When to use

■

Vehicle speed for ACC with Low Speed Follow:

A vehicle is detected ahead

within ACC with Low Speed Follow range

– ACC with Low Speed Follow

operates at speeds up to 90 mph (145 km/h).

No vehicle is detected within ACC with Low Speed Follow range

– ACC with

Low Speed Follow operates at the speed of 25 mph (40 km/h) or above.

■

Shift position for ACC with Low Speed Follow: In

(

The radar sensor is at the
lower part of the front
bumper.

The camera is
located behind
the rearview
mirror.

* Not available on all models

Continued

471

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

How to activate the system

Adaptive Cruise Control (ACC) with Low Speed Follow

For directions on the proper handling of the radar
sensor, refer to the following page.

Radar Sensor

P. 506

You can read about handling information for the
camera equipped with this system.

Front Sensor Camera

P. 504

ACC with Low Speed Follow may not work properly
under certain conditions.

ACC with Low Speed Follow Conditions
and Limitations

P. 476

When not using ACC with Low Speed Follow: Turn
off adaptive cruise by pressing the

button.

Do not use ACC with Low Speed Follow under the
following conditions:

•

On roads with heavy traffic or while driving in
continuous stop and go traffic.

•

On roads with sharp turns.

•

On roads with steep downhill sections, as the set
vehicle speed can be exceeded by coasting. In such
cases, ACC with Low Speed Follow will not apply
the brakes to maintain the set speed.

•

On roads with toll collection facilities or other
objects between lanes of traffic, or in parking
areas, or facilities with drive through access.

How to use

■

Press the

button on the

steering wheel.

(white) is on in the instrument panel.

ACC with Low Speed Follow is ready to use.

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

472

Driving

When driving at about 25 mph (40 km/h) or above:

Take your foot off the

pedal and press the

SET/–

button when you reach the desired speed. The moment

you release the button, the set speed is fixed, and ACC with Low Speed Follow begins.

When driving slower than about 25 mph (40 km/h):

If the vehicle is moving

and the brake pedal is not depressed, pressing the button fixes the set speed to
about 25 mph (40 km/h) regardless of current vehicle speed. If the vehicle is
stationary, you can set the vehicle speed even with the brake pedal depressed.

When ACC with Low Speed Follow starts
operating, the vehicle icon, interval bars and set
speed appear on the driver information interface.

When you use ACC with Low Speed Follow,
Straight Driving Assist (a feature of the Electric
Power Steering system) is activated.
By enabling the steering system to
automatically compensate for natural steering
pull, Straight Driving Assist makes it easier for
you to keep your vehicle in a straight line.

■

To Set the Vehicle Speed

To Set the Vehicle Speed

You can switch the displayed set speed
measurements on the driver information interface or
audio/information screen between mph and km/h.

Speed/Distance Units

P. 151

Customized Features

P. 351

The Vehicle Stability Assist

(VSA

) system, Vehicle

Stability Assist

(VSA

)

OFF

, adaptive cruise control

(ACC) with Low Speed Follow, safety support and
low tire pressure/TPMS indicators may come on in
amber along with a message in the driver information
interface when you set the power mode to ON after
reconnecting the battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

On when ACC with Low
Speed Follow begins

Press and release

SET/−

button

(green)

Set Vehicle Speed

Set Vehicle Interval

(green)

Continued

473

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

There is a vehicle ahead

ACC with Low Speed Follow monitors if a vehicle ahead of you enters the ACC with
Low Speed Follow range. If a vehicle is detected doing so, the ACC with Low Speed
Follow system maintains or decelerates your vehicle’s set speed in order to keep the
vehicle’s set following interval from the vehicle ahead.

To Set or Change Following-interval

P. 480

When a vehicle whose speed is slower than
your set speed is detected in front of you, your
vehicle starts to slow down.

■

When in Operation

When in Operation

If the vehicle ahead of you slows down abruptly, or if
another vehicle cuts in front of you, the beeper
sounds, a message appears on the driver information
interface, and the head-up warning lights

flash.

Depress the brake pedal, and keep an appropriate
interval from the vehicle ahead.

Beep

Head-up Warning Lights

ACC with Low Speed Follow Range: 394 ft. (120 m)

A vehicle icon appears on the
driver information interface.

* Not available on all models

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

474

Driving

■

There is no vehicle ahead

Your vehicle maintains the set speed without
having to keep your foot on the brake or
accelerator pedal.
If there previously was a vehicle detected
ahead that kept your vehicle from traveling at
the set speed, ACC with Low Speed Follow
accelerates your vehicle to the set speed, and
then maintains it.

■

When you depress the accelerator pedal

You can temporarily increase the vehicle speed. In this case, there is no audible or
visual alert even if a vehicle is in the ACC with Low Speed Follow range.
ACC with Low Speed Follow stays on unless you cancel it. Once you release the
accelerator pedal, the system resumes an appropriate speed for keeping the
following interval while a vehicle ahead is within the ACC with Low Speed Follow
range.

When in Operation

Even if the interval between your vehicle and the
vehicle detected ahead is short, ACC with Low Speed
Follow may start accelerating your vehicle under the
following circumstances:

•

The vehicle ahead of you is going at almost the
same speed as, or faster than, your vehicle.

•

A vehicle that cuts in front of you is going faster
than your vehicle, gradually increasing the interval
between the vehicles.

You can also set the system to beep when a vehicle in
front of you comes in and goes out of the ACC with
Low Speed Follow detecting range. A vehicle detect
beep on and off can be selected.

Customized Features

P. 351

Limitations

You may need to use the brake to maintain a safe
interval when using ACC with Low Speed Follow.
Additionally, ACC with Low Speed Follow may not
work properly under certain conditions.

ACC with Low Speed Follow Conditions
and Limitations

P. 476

A vehicle icon with dotted-line
contour appears on the driver
information interface.

Continued

475

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

A vehicle detected ahead is within ACC with Low Speed Follow range and
slows to a stop

Your vehicle also stops, automatically. The

Stopped

message appears on the driver

information interface.
When the vehicle ahead of you starts again,
the vehicle icon on the driver information
interface blinks. If you press the

RES/+

SET/

–

button, or depress the accelerator pedal,

ACC with Low Speed Follow operates again
within the prior set speed.
If no vehicle is ahead of you before you
resume driving, depressing the accelerator
pedal will resume operation of ACC with Low
Speed Follow within the prior set speed.

A vehicle detected ahead is within ACC with Low Speed Follow
range and slows to a stop

WARNING

Exiting a vehicle that has been stopped
while the ACC with Low Speed Follow
system is operating can result in the vehicle
moving without operator control.

A vehicle that moves without operator
control can cause a crash, resulting in
serious injury or death.

Never exit a vehicle when the vehicle is
stopped by ACC with Low Speed Follow.

(green)

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

476

Driving

The system may automatically shut off under certain conditions. Some examples of
these conditions are listed below. Other conditions may reduce some of the ACC
with Low Speed Follow functions.

Front Sensor Camera

P. 504

Radar Sensor

P. 506

■

Environmental conditions

•

Driving in bad weather (rain, fog, snow, etc.).

■

Roadway conditions

•

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

■

Vehicle conditions

•

The outside of the windshield is blocked by dirt, mud, leaves, wet snow, etc.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

•

The camera temperature gets too high.

•

The parking brake is applied.

•

When the radar sensor cover is dirty.

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

When tire chains

are installed.

■

ACC with Low Speed Follow Conditions and Limitations

ACC with Low Speed Follow Conditions and Limitations

If you need the radar sensor to be repaired, or
removed, or the radar sensor cover is strongly
impacted, turn off the system by pressing the

button and take your vehicle to a dealer.

Have your vehicle checked by a dealer if you find any
unusual behavior of the system (e.g., the warning
message appears too frequently).

* Not available on all models

477

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

■

Detection limitations

•

A vehicle suddenly crosses in front of you.

•

The interval between your vehicle and the vehicle ahead of you is too short.

•

A vehicle cuts in front of you at a slow speed, and it brakes suddenly.

•

You accelerate rapidly and approach the vehicle ahead of you at high speed.

•

The vehicle ahead of you is a motorcycle, bicycle, mobility scooter, or other small
vehicle.

•

There are animals in front of your vehicle.

•

You drive on a curved or winding or undulating road that makes it difficult for the
sensor to properly detect a vehicle in front of you.

•

The speed difference between your vehicle and a vehicle in front of you is
significantly large.

•

An oncoming vehicle suddenly comes in front of you.

•

Your vehicle abruptly crosses over in front of an oncoming vehicle.

Honda Accord (2022 year). Manual in english - page 29
