uu

When Driving

u

Tire Pressure Monitoring System (TPMS)

446

Driving

You must start TPMS calibration every time you:

•

Adjust the pressure in one or more tires.

•

Rotate the tires.

•

Replace one or more tires.

Before calibrating the TPMS:

•

Set the cold tire pressure in all four tires.

2

Checking Tires

 P. 575

Make sure:

•

The vehicle is at a complete stop.

•

The transmission is in

(

P

.

•

The power mode is in ON.

■

TPMS Calibration

1

TPMS Calibration

TPMS cannot be calibrated if a compact spare tire is
installed.
The calibration process requires approximately 30
minutes of cumulative driving at speeds between 30-
60 mph (48-97 km/h).
During this period, if the power mode is set to ON and
the vehicle is not moved within 45 seconds, you may
notice the low tire pressure/TPMS indicator comes on
briefly. This is normal and indicates that the calibration
process is not yet complete.

447

uu

When Driving

u

Tire Pressure Monitoring System (TPMS)

Driving

You can calibrate the system from the
customized feature on the audio/information
screen.

1.

Set the power mode to ON.

2.

Press the

 button.

3.

Select

Settings

.

4.

Select

Vehicle

.

5.

Select

TPMS Calibration

.

6.

Select

Calibrate

.

•

If the

Calibration Failed To Start.



message appears, repeat steps 5-6.

•

The calibration process finishes
automatically.

1

TPMS Calibration

If the tire chains

*

 are installed, remove them before

calibrating the TPMS.

If the low tire pressure/TPMS indicator comes on even
when the properly inflated specified regular tires are
installed, have your vehicle checked by a dealer.

We recommend that the tires be replaced with the
same brand, model, and size as the originals. Ask a
dealer for details.

* Not available on all models

448

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) - Required Federal Explanation

Driving

Tire Pressure Monitoring System (TPMS) - Required
Federal Explanation

Each tire, including the spare (if provided), should be checked
monthly when cold and inflated to the inflation pressure
recommended by the vehicle manufacturer on the vehicle placard
or tire inflation pressure label.

(If your vehicle has tires of a different size than the size indicated
on the vehicle placard or tire inflation pressure label, you should
determine the proper tire inflation pressure for those tires.)

As an added safety feature, your vehicle has been equipped with
a tire pressure monitoring system (TPMS) that illuminates a low
tire pressure telltale

when one or more of your tires is significantly under-inflated.

Accordingly, when the low tire pressure telltale illuminates, you
should stop and check your tires as soon as possible, and inflate
them to the proper pressure.

Driving on a significantly under-inflated tire causes the tire to
overheat and can lead to tire failure. Under-inflation also reduces
fuel efficiency and tire tread life, and may affect the vehicle's
handling and stopping ability.

U.S. models

449

uu

When Driving

u

Tire Pressure Monitoring System (TPMS) - Required Federal Explanation

Driving

Please note that the TPMS is not a substitute for proper tire
maintenance, and it is the driver's responsibility to maintain
correct tire pressure, even if under-inflation has not reached the
level to trigger illumination of the TPMS low tire pressure telltale.

Your vehicle has also been equipped with a TPMS malfunction
indicator to indicate when the system is not operating properly.
The TPMS malfunction indicator is combined with the low tire
pressure telltale. When the system detects a malfunction, the
telltale will flash for approximately one minute and then remain
continuously illuminated. This sequence will continue upon
subsequent vehicle start-ups as long as the malfunction exists.

When the malfunction indicator is illuminated, the system may
not be able to detect or signal low tire pressure as intended.

TPMS malfunctions may occur for a variety of reasons, including
the installation of replacement or alternate tires or wheels on the
vehicle that prevent the TPMS from functioning properly.

Always check the TPMS malfunction telltale after replacing one or
more tires or wheels on your vehicle to ensure that the
replacement or alternate tires and wheels allow the TPMS to
continue to function properly.

450

uu

When Driving

u

Blind spot information System

*

Driving

Blind spot information System

*

Is designed to detect vehicles in specified alert zones adjacent to your vehicle,
particularly in harder to see areas commonly known as “blind spots.”

When the system detects vehicles approaching from behind in adjacent lanes, the
appropriate indicator comes on for a few seconds, providing assistance when you
change lanes.

■

How the system works

1

Blind spot information System

*

Important Safety Reminder

Like all assistance systems, the blind spot information
system has limitations. Overreliance on the blind spot
information system may result in a collision.

The blind spot information system alert indicator may
not come on under the following conditions:

•

A vehicle does not stay in the alert zone for more
than two seconds.

•

A vehicle is parked in a side lane.

•

The speed difference between your vehicle and the
vehicle you are passing is greater than 6 mph (10
km/h).

•

An object not detected by the radar sensors
approaches or passes your vehicle.

•

A vehicle running in the adjacent lane is a
motorcycle or other small vehicle.

3

WARNING

Failure to visually confirm that it is safe to
change lanes before doing so may result in
a crash and serious injury or death.
Do not rely only on the blind spot
information system when changing lanes.

Always look in your mirrors, to either side
of your vehicle, and behind you for other
vehicles before changing lanes.

Alert zone range

A: Approx. 1.6 ft. (0.5 m)
B: Approx. 10 ft. (3 m)
C: Approx. 10 ft. (3 m)

Radar Sensors:
underneath the
rear bumper
corners

Alert Zone

A

B

C

●

Your vehicle speed is
between 20 mph (32 km/h)
and 100 mph (160 km/h).

●

The transmission is in

(

D

.

* Not available on all models

Continued

451

uu

When Driving

u

Blind spot information System

*

Driving

■

When the system detects a vehicle

Blind spot information System Alert Indicator:
Located on the outside rearview mirror on
both sides.

Comes on when:

•

A vehicle enters the alert zone from behind
to overtake you with a speed difference of
no more than 31 mph (50 km/h) from your
vehicle.

•

You pass a vehicle with a speed difference
of no more than 12 mph (20 km/h).

Blinks and a beeper sounds when:
You move the turn signal lever in the direction
of the detected vehicle. The beeper sounds
three times.

1

Blind spot information System

*

The system is for your convenience only. Even if an
object is within the alert zone, the following
situations may occur.

•

The blind spot information system alert indicator
may not come on due to obstruction (splashes,
etc.) even without the

Blind Spot Information

System Not Available

 driver information

interface appearing.

•

The blind spot information system alert indicator
may come on even with the message appearing.

You can change the setting for the blind spot
information system.

2

Customized Features

 P. 351

The system does not operate when in

(

R

.

Turn the system off when towing a trailer.
The system may not work properly for the following
reasons:

•

The added mass tilts the vehicle and changes the
radar coverage.

•

The trailer itself can be detected by the radar
sensors, causing the blind spot information system
alert indicators to come on.

2.0 L engine models

Comes On

Blinks

* Not available on all models

uu

When Driving

u

Blind spot information System

*

452

Driving

■

Blind spot information System On and Off

When you turn the blind spot information
system on and off, do the following.

1.

Press the safety support switch.

2.

Roll the left selector wheel to the



symbol and push it.

The blind spot information system is in the
previously selected

ON

 or

OFF

 setting each

time you start the engine.

1

Blind spot information System

*

The blind spot information system may be adversely
affected when:

•

Objects (guard rails, poles, trees, etc.) are detected.

•

An object that does not reflect radio waves well,
such as a motorcycle, is in the alert zone.

•

Driving on a curved road.

•

A vehicle is moving from a far lane to the adjacent
lane.

•

The system picks up external electrical interference.

•

The rear bumper or the sensors have been
improperly repaired or the rear bumper has been
deformed.

•

The orientation of the sensors has been changed.

•

In bad weather (Heavy rain, snow, and fog).

•

Making a turn at an intersection.

•

Driving on a bumpy road.

•

Making a short turn that slightly tilts the vehicle.

For a proper blind spot information system operation:

•

Always keep the rear bumper corner area clean.

•

Do not cover the rear bumper corner area with
labels or stickers of any kind.

•

Take your vehicle to a dealer if you need the rear
bumper corner area or the radar sensors to be
repaired, or the rear bumper corner area is strongly
impacted.

Left Selector Wheel

Safety Support Switch

* Not available on all models

453

Continued

Driving

Honda Sensing

®

Honda Sensing

®

 is a driver support system which employs the use of three distinctly

different kinds of sensors: a radar sensor located at the lower part of the front
bumper, a front sensor camera mounted to the interior side of the windshield,
behind the rearview mirror, and the sonar sensors located in the front and rear
bumpers.

Honda Sensing

®

 is a driver support system which employs the use of two distinctly

different kinds of sensors: a radar sensor located at the lower part of the front
bumper and a front sensor camera mounted to the interior side of the windshield,
behind the rearview mirror.

Honda Sensing

®

 has following functions.

■

The functions which do not require switch operations to activate

•

Collision Mitigation Braking System

TM

 (CMBS

TM

)

2

 P. 456

•

Low Speed Braking Control

*



2

 P. 465

•

Road Departure Mitigation (RDM) System

2

 P. 494

•

Traffic Sign Recognition System

2

 P. 498

■

The functions which require switch operations to activate

•

Adaptive Cruise Control (ACC) with Low Speed Follow

2

 P. 470

•

Lane Keeping Assist System (LKAS)

2

 P. 486

Models with Low Speed Braking Control

Models without Low Speed Braking Control

* Not available on all models

454

uu

Honda Sensing

®

u

Driving

■

 Button

Press to activate standby mode for ACC with
Low Speed Follow. Or press to cancel the
system.

■

LKAS Button

Press to activate standby mode for LKAS. Or
press to cancel the system.

■

RES/+ and SET/- Buttons

Press

RES/+

 button to resume the ACC with

Low Speed Follow or increase the vehicle
speed.
Press

SET/−

 button to set the ACC with Low

Speed Follow or decrease the vehicle speed.

■

Interval Button

Press to change the ACC with Low Speed
Follow following-interval.

■

CANCEL Button

Press to cancel ACC with Low Speed Follow.

■

Operation Switches for the ACC with Low Speed Follow/

LKAS

 button

Interval
Button

CANCEL



Button

LKAS Button

RES/+

 Button

SET/-

 Button

455

uu

Honda Sensing

®

u

Driving

You can see the current state of ACC with
Low Speed Follow and LKAS.

a

Indicates that ACC with Low Speed Follow
is ready to be activated.

•

White: The system is standby.

•

Green: The system is on.

•

Amber: There is a problem with the system.

b

Indicates that LKAS is ready to be activated.

•

White: The system is standby.

•

Green: The system is on.

•

Amber: There is a problem with the system.

c

Indicates that LKAS is activated and
whether or not traffic lane lines are
detected.

•

Solid lane outlines: The system is on.

•

Lane outlines: The system is in standby.

d

Indicates whether or not ACC with Low
Speed Follow detects the vehicle ahead.

e

Shows vehicle set speed in ACC with Low
Speed Follow.

f

Shows set vehicle interval in ACC with Low
Speed Follow.

■

Driver Information Interface Content

1

Driver Information Interface Content

You can have the head-up display show you the
current state of each function.

2

Head-Up Display

*

 P. 159

Models with head-up display

6

* Not available on all models

456

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

Collision Mitigation Braking System

TM

 (CMBS

TM

)

The system can assist you when it determines there is a possibility of your vehicle
colliding with a vehicle or a pedestrian detected in front of your vehicle. The CMBS

TM



is designed to alert you when the potential for a collision is determined, as well as to
reduce your vehicle speed to help minimize collision severity when a collision is
deemed unavoidable.

■

How the system works

1

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Important Safety Reminder

The CMBS

TM

 is designed to reduce the severity of an

unavoidable collision. It does not prevent collisions
nor stop the vehicle automatically. It is still your
responsibility to operate the brake pedal and steering
wheel appropriately according to the driving
conditions.

The CMBS

TM

 may not activate or may not detect a

vehicle in front of your vehicle under certain
conditions:

2

CMBS

TM

 Conditions and Limitations

 P. 460

For directions on the proper handling of the radar
sensor, refer to the following page.

2

Radar Sensor

 P. 506

You can read about handling information for the
camera equipped with this system.

2

Front Sensor Camera

 P. 504

When the CMBS

TM

 activates, it may automatically

apply the brake. It will be canceled when your vehicle
stops or a potential collision is not determined.

The radar sensor is at the
lower part of the front
bumper.

The camera is located
behind the rearview
mirror.

The system starts monitoring the roadway ahead when your vehicle speed is about
3 mph (5 km/h) or above and will search for a vehicle in front of you.

When to use

The CMBS

TM

 activates when:

●

The speed difference between your vehicle and a vehicle or pedestrian detected in
front of you becomes about 3 mph (5 km/h) and over with a chance of a collision.

●

Your vehicle speed is about 62 mph (100 km/h) or less and the system determines
there is a chance of a collision with:

- Vehicles detected in front of you that are stationary, oncoming, or traveling in your
same direction.
- A pedestrian who is detected in front of you.

●

Your vehicle speed is above 62 mph (100 km/h), and the system determines there
is a chance of a collision with a vehicle detected in front of you traveling in your
same direction.

Continued

457

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

■

When the system activates

You can change the distance (

Long

/

Normal

/

Short

) between vehicles at which the

system's earliest collision alert will come on through audio/information screen
setting options.

2

Customized Features

 P. 351

1

When the system activates

The camera in the CMBS

TM

 is also designed to detect

pedestrians.
However, this pedestrian detection feature may not
activate or may not detect a pedestrian in front of
your vehicle under certain conditions.
Refer to the ones indicating the pedestrian detection
limitations from the list.

2

CMBS

TM

 Conditions and Limitations

 P. 460

The head-up warning uses a lens located at the front
end of the dashboard.
Do not cover the lens or spill any liquid on it.

Models with head-up display

Lens

The system provides visual and audible alerts of a possible collision, and stops if the
collision is avoided.

u

Take appropriate action to prevent a collision (apply the brakes, change
lanes, etc.).

Beep

Head-up
Warning
Lights

*

Visual Alerts

Audible Alert

* Not available on all models

458

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

The system has three alert stages for a possible collision. However, depending on circumstances, the CMBS

TM

 may not go through all of

the stages before initiating the last stage.

■

Collision Alert Stages

Distance between vehicles

CMBS

TM

The radar sensor detects a vehicle

Audible & Visual WARNINGS

Braking

Stage

one

There is a risk of a collision with the
vehicle ahead of you.

When in

Long

, visual and audible alerts come

on at a longer distance from a vehicle ahead
than in

Normal

 setting, and in

Short

, at a

shorter distance than in

Normal

.

—

Stage

two

The risk of a collision has increased,
time to respond is reduced.

Visual and audible alerts.

Lightly

applied

Stage

three

The CMBS

TM

 determines that a

collision is unavoidable.

Forcefully

applied

Your Vehicle

Vehicle Ahead

Normal

Short

Long

Your Vehicle

Vehicle Ahead

Your

Vehicle

Vehicle

Ahead

Continued

459

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Driving

When you turn the CMBS

TM

 on and off, do the

following.

1.

Press the safety support switch.

2.

Roll the left selector wheel to the



symbol and push it.

u

A message appears on the driver
information interface when the system
turns on or off.

The CMBS

TM

 is turned on every time you start

the engine, even if you turned it off the last
time you drove the vehicle.

■

CMBS

TM

 On and Off

1

CMBS

TM

 On and Off

The CMBS

TM

 may automatically shut off, and the

safety support indicator (amber) will come and stay
on under certain conditions:

2

CMBS

TM

 Conditions and Limitations

 P. 460

When the CMBS

TM

 is activated, it will continue to

operate even if the accelerator pedal is partially
depressed. However, it will be canceled if the
accelerator pedal is fully depressed.

The Vehicle Stability Assist

TM

 (VSA

®

) system, Vehicle

Stability Assist

TM

 (VSA

®

)

OFF

, adaptive cruise control

(ACC) with Low Speed Follow, safety support and
low tire pressure/TPMS indicators may come on in
amber along with a message in the driver information
interface when you set the power mode to ON after
reconnecting the battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

Left Selector Wheel

Safety Support Switch

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

460

Driving

The system may automatically shut off and the safety support indicator (amber) will
come on under certain conditions. Some examples of these conditions are listed
below. Other conditions may reduce some of the CMBS

TM

 functions.

2

Front Sensor Camera

 P. 504

2

Radar Sensor

 P. 506

■

Environmental conditions

•

Driving in bad weather (rain, fog, snow, etc.).

•

Sudden changes between light and dark, such as an entrance or exit of a tunnel.

•

There is little contrast between objects and the background.

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Driving in the shadows of trees, buildings, etc.

•

Roadway objects or structures are misinterpreted as vehicles and pedestrians.

•

Reflections on the interior of the windshield.

•

Driving at night or in a dark place such as a tunnel (due to low-light conditions,
pedestrians or other vehicles may not be detected).

■

Roadway conditions

•

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

•

Driving on curvy, winding, or undulating roads.

•

The road is hilly or the vehicle is approaching the crest of a hill.

■

CMBS

TM

 Conditions and Limitations

1

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Have your vehicle checked by a dealer if you find any
unusual behavior of the system (e.g., the warning
message appears too frequently).

461

uu

Honda Sensing

®

u

Collision Mitigation Braking System

TM

 (CMBS

TM

)

Continued

Driving

■

Vehicle conditions

•

Headlight lenses are dirty or the headlights are not properly adjusted.

•

The outside of the windshield is blocked by dirt, mud, leaves, wet snow, etc.

•

The inside of the windshield is fogged.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

•

When tire chains

*

 are installed.

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

The camera temperature gets too high.

•

Driving with the parking brake applied.

•

When the radar sensor at the lower part of the front bumper gets dirty.

•

The vehicle is towing a trailer

*

.

•

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

■

Detection limitations

•

A vehicle or pedestrian suddenly crosses in front of you.

•

The distance between your vehicle and the vehicle or pedestrian ahead of you is
too short.

•

A vehicle cuts in front of you at a slow speed, and it brakes suddenly.

•

When you accelerate rapidly and approach the vehicle or pedestrian ahead of you
at high speed.

•

The vehicle ahead of you is a motorcycle, bicycle, mobility scooter or other small
vehicle.

•

When there are animals in front of your vehicle.

•

When you drive on a curved, winding or undulating road that makes it difficult for
the sensor to properly detect a vehicle in front of you.

•

The speed difference between your vehicle and a vehicle or pedestrian in front of
you is significantly large.

•

An oncoming vehicle suddenly comes in front of you.

•

Another vehicle suddenly comes in front of you at an intersection, etc.

•

Your vehicle abruptly crosses over in front of an oncoming vehicle.

•

When driving through a narrow iron bridge.

•

When the lead vehicle suddenly slows down.

* Not available on all models
