Honda Odyssey (2023 year). Manual in english - page 27

430

Customized Features

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Sound

Bass / Treble

Adjusts the settings of the audio speakers’ sound.

Adjusting the Sound

P. 291

Center /
Subwoofer
Volume

(

Subwoofer

Volume

)

Balance /
Fader

Audio Zones

Speed Volume
Compensation

DTS Neural
Surround

Notifications

Changes the notification settings for apps.

—

* Not available on all models

431

Customized Features

Defaulting All the Settings

Features

Defaulting All the Settings

Reset all the menu and customized settings as the factory defaults.

Select .

Select

Settings

Select

System

Select

Factory Data Reset

A confirmation message appears on the
screen.

Select

Continue

to reset the settings.

Select

Continue

again to reset the settings.

The system will reboot.

Defaulting All the Settings

When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.

If you perform

Factory Data Reset

, it will reset the

preinstalled apps to their factory default.

If you perform

Factory Data Reset

, you cannot use

the HondaLink

because it becomes off line.

HondaLink

P. 324

432

Features

HomeLink

Universal Transceiver

The HomeLink

Universal Transceiver can be programmed to operate up to three

remote controlled devices around your home, such as garage doors, lighting, or
home security systems.

Refer to the safety information that came with your garage door opener to test that
the safety features are functioning properly. If you do not have the safety
information, contact the manufacturer.

Before programming HomeLink, make sure that people and objects are out of the
way of the garage or gate to prevent potential injury or damage.

When programming a garage door opener, park just outside the garage door’s path.

■

Important Safety Precautions

HomeLink

Universal Transceiver

Before programming HomeLink to operate a garage
door opener, confirm that the opener has an external
entrapment protection system, such as an “electronic
eye,” or other safety and reverse stop features. If it
does not, HomeLink may not be able to operate it.

* Not available on all models

433

HomeLink

Universal Transceiver

Training HomeLink

Continued

Features

Training HomeLink

If it is necessary to erase a previously entered
learned code:

•

Press and hold the I and III HomeLink
buttons for about 10 seconds, until the
green indicator blinks. Release the buttons,
and proceed to step 1.

•

If you are training the second or third
button, go directly to step 1.

The instructions on the next page should work for most gate or garage openers, but
may not work for all. For detailed instructions about your specific remote opener,
visit

http://www.homelink.com

or call (800) 355-3515.

Training HomeLink

NOTE:
Some LED lightbulbs installed in the garage door
opener can interfere with the training and consistent
operation of your HomeLink device. Please consider
use of Low RF interference bulbs in your garage door
opener.

Indicator

I HomeLink
Button

III HomeLink
Button

HomeLink

Universal Transceiver

Training HomeLink

434

Features

■

Programming a Button

Training HomeLink

Reprogramming a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

Press and hold the desired HomeLink button until
the HomeLink indicator begins to

slowly flash

orange

. This should take about 20 seconds.

Release the HomeLink button and position the
remote transmitter you wish to link 1 - 3 inches
(3 - 8 cm) from the HomeLink button you want to
program, then follow steps 3 - 6 under
“programming a button.”

Erasing Button Memory
To erase programming from the buttons, press and hold
the two outside HomeLink buttons until the HomeLink
indicator changes from

orange to rapidly flashing green

This should take about 10 seconds. You should erase all
programming before selling the vehicle.

Operating
To operate, simple press and release the
programmed HomeLink button. Activation will now
occur for the trained device.

Questions
For questions or comments, visit

www.HomeLink.com

www.youtube.com/

HomeLinkGentex

, or by calling the HomeLink Hotline

(North America only) at (800) 355-3515.

HomeLink

is a registered trademark of Gentex

Corporation.

Training
Complete

HomeLink LED is

continuously on green

YES

Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the
HomeLink

button you want to program.

3b.

Canadian Garage Door Opener

A. Press and release the HomeLink
button. Press, hold and release the
button on the remote every 2 secs.
Does the HomeLink indicator (LED)
change from

slowly flashing orange to

rapidly flashing or continuously on
green

? The process should take less

than 60 seconds.

Press and release the desired HomeLink button. Is the HomeLink indicator (LED)

slowly

flashing orange

3a.

Hold the button on the remote
transmitter. Does HomeLink indicator
(LED) change from

slowly flashing

orange to rapidly flashing green or
continuously on green

? The process

should take less than 60 seconds.

Press and hold the HomeLink button again.

HomeLink indicator

rapidly flashes

green

5a.

The remote has a rolling code. Press the
“learn” button on the remote-controlled
device (e.g. garage door opener).

Press and hold the HomeLink button
again.
The remote-controlled device should
operate.

Training Complete

5b.

Within 30 secs, press and hold the
programmed HomeLink button for 2
secs.

Press and hold the programmed HomeLink
button for about a second. Does the device
(garage door opener) work?

435

Continued

Features

Bluetooth

HandsFreeLink

Bluetooth

HandsFreeLink

(HFL) allows you to place and receive phone calls using

your vehicle’s audio system, without handling your cell phone.

Using HFL

■

HFL Buttons

Bluetooth

HandsFreeLink

Place your phone where you can get good reception.

To use HFL, you need a

Bluetooth

-compatible cell

phone. For a list of compatible phones, pairing
procedures, and special feature capabilities, ask a
dealer or your Honda dealer.

To use the system, the

Bluetooth

setting must be

Phone Setup

P. 440

Voice control tips

•

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphones.

•

Press the

button when you want to call a

number using a phonebook name or a number.
Speak clearly and naturally after a beep.

•

If the microphones pick up voices other than yours,
the command may be misinterpreted.

•

To change the volume level, the volume level is able
to change by the audio system’s volume.

If there is no speed dial entry in the system, the pop-
up notification appears on the screen.

Favorite Contacts

P. 445

If there is no call history, the call history is disabled.

(Talk) Button

Volume up

(Hang-up) Button

(Pick-up) Button

Volume down

ENTER

Button

(Back) Button

Buttons

3 4

(Home) Button

Bluetooth

HandsFreeLink

Using HFL

436

Features

(Pick-up) button:

Press to go directly to the phone screen of the driver

information interface, or to answer an incoming call.

(Hang-up) button:

Press to end a call.

(Back) button:

Press to go back to the previous screen, or cancel a command.

(Talk) button:

Press to access Voice Portal.

buttons:

Press to select an item displayed on the phone screen

of the driver information interface.

ENTER button:

Press to call a number listed in the selected item on the phone

screen of the driver information interface.

(Home) button:

Press to go back to the home screen of the driver information

interface.

To go to the phone screen of the driver information interface:

Press the

(home) button on the steering wheel.

Select

Phone

You can select

Favorite Contacts

Recent Calls

Bluetooth

HandsFreeLink

Bluetooth

Wireless Technology

The

Bluetooth

word mark and logos are registered

trademarks owned by

Bluetooth

SIG, Inc., and any

use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

3 4

437

Bluetooth

HandsFreeLink

Using HFL

Features

The audio/information screen notifies you when there is an incoming call.

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

Only previously stored phonebook names or numbers can be called using voice
commands while the vehicle is in motion.

Favorite Contacts

P. 445

■

HFL Status Display

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

■

Limitations for Manual Operation

Bluetooth

Indicator

Appears when your phone is
connected to HFL.

Signal Strength

HFL Mode

Battery Level Status

Caller’s Name
Caller’s Number

* Not available on all models

438

Bluetooth

HandsFreeLink

HFL Menus

Features

HFL Menus

The power mode must be in ACCESSORY or ON to use the system.

■

Phone settings screen

Select .

Select

Phone

Select

Settings

HFL Menus

To use HFL, you must first pair your

Bluetooth

compatible cell phone to the system while the vehicle
is parked.

Some functions are limited while driving.

Change Connected Phone

(Existing entry list)

+ Connect New Device

Pair a new phone to the system.

Connect, disconnect, or delete a paired device.

Ringtone

Select the ring tone.

Auto Sync Phone

Set phonebook and call history data to be automatically imported when a phone is paired to HFL.

Turn HondaLink

Assist on and off.

HondaLink Assist

Auto Phone Call Transfer

Set calls to automatically transfer from your phone to HFL when you enter the vehicle.

439

Bluetooth

HandsFreeLink

HFL Menus

Continued

Features

■

Phone menu screen

Select .

Select

Phone

Display the last outgoing, incoming and missed calls.

Recent Calls

Favorite Contacts

All

Dialed

Received

Display the last outgoing calls.

Display the last incoming calls.

Missed

Display the last missed calls.

Keypad

Enter a phone number to dial.

(Existing entry list)

Dial the selected number in the speed dial list.

Contacts

Display the paired phone’s phonebook.

440

Bluetooth

HandsFreeLink

HFL Menus

Features

■

Bluetooth

setup

You can turn

Bluetooth

function on and off.

Select .

Select

Settings

Select

Connections

Select

Bluetooth

Select

Options

Select

Bluetooth

, then

■

Phone Setup

Continued

441

Bluetooth

HandsFreeLink

HFL Menus

Features

■

To pair a cell phone (when there is no
phone paired to the system)

Select .

Select

Phone

Select

Connect Phone

Make sure your phone is in search or
discoverable mode, then select

+ Connect

New Device

HFL automatically searches for a

Bluetooth

device.

Select your phone when it appears on the
list.

If your phone still does not appear,
search for

Bluetooth

devices using your

phone.
From your phone, search for

HandsFree

Link

The system gives you a pairing code on the
audio/information screen.

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

Select desired functions and then select

Connect

A confirmation message appears on the
screen. Select

Continue

Connect

without Internet

Phone Setup

Your

Bluetooth

-compatible phone must be paired to

the system before you can make and receive hands-
free calls.

Phone Pairing Tips:

•

You cannot pair your phone while the vehicle is
moving.

•

Up to six phones can be paired.

•

Your phone’s battery may drain faster when it is
paired to the system.

Once you have paired a phone, you can see it
displayed on the screen with one or more icons on
the right side.
These icons indicate the following:

: The phone is compatible with

Bluetooth

Audio.

: The phone can be used with HFL.

: The phone can be used with the internet

tethering.

If there is an active connection to Apple CarPlay or
Android Auto, pairing of additional

Bluetooth

compatible devices is unavailable and

+ Connect

New Device

is grayed out from the

Bluetooth

screen.

Bluetooth

HandsFreeLink

HFL Menus

442

Features

■

To change the currently paired phone

Go to the phone settings screen.

Phone settings screen

P. 438

Select

Change Connected Phone

Select a phone to connect.

HFL disconnects the connected phone
and starts searching for another paired
phone.

Select ,

or .

Select

Apply

■

To delete a paired phone

Go to the phone settings screen.

Phone settings screen

P. 438

Select

Change Connected Phone

Select a phone you want to delete.

Select

Delete Device

A confirmation message appears on the
screen. Select

Delete

To change the currently paired phone

If no other phones are found or paired when trying to
switch to another phone, HFL will inform you that the
original phone is connected again.

To pair other phones, select

+ Connect New Device

from the

Bluetooth

screen.

Continued

443

Bluetooth

HandsFreeLink

HFL Menus

Features

You can change the ring tone setting.

Go to the phone settings screen.

Phone settings screen

P. 438

Select

Ringtone

Select

Vehicle

Phone

If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFL.

Go to the phone settings screen.

Phone settings screen

P. 438

Select

Auto Phone Call Transfer

Select

OFF

■

Ring Tone

Ring Tone

Vehicle

: The fixed ring tone sounds from the

speakers.

Phone

: Depending on the make and model of the

mobile phone, the ring tone stored in the phone will
sound if the phone is connected.

■

Automatic Transferring

Phone

Auto Phone Call Transfer

OFF

12:34

Navigation

When vehicle is turned on, automatically transfer an

active call from device to vehicle speakers.

Bluetooth

HandsFreeLink

HFL Menus

444

Features

■

When Automatic Phone Sync is set to
On:

When your phone is paired, the contents of its
phonebook and call history are automatically
imported to the system.

■

Changing the Automatic Phone Sync
setting

Go to the phone settings screen.

Phone settings screen

P. 438

Select

Auto Sync Phone

Select

OFF

■

Automatic Import of Cellular Phonebook and Call History

Automatic Import of Cellular Phonebook and Call History

When you select a name from the list in the cellular
phonebook, you can see a category icon. The icons
indicate what types of numbers are stored for that
name.

On some phones, it may not be possible to import the
category icons to the system.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Home

Mobile

Work

Other

445

Bluetooth

HandsFreeLink

HFL Menus

Continued

Features

To store a speed dial number:

Go to the phone menu screen.

Phone menu screen

P. 439

Select the

Recent Calls

Contacts

, or

Keypad

screen.

Select the star icon.

A notification appears on the screen if
the speed dial is successfully stored.

To remove the speed dial, select the star
icon again.

■

Favorite Contacts

Recent Calls

Screen

Contacts

Screen

Keypad

Screen

Star Icon

Content .. 25 26 27 28 ..
