Honda Odyssey (2023 year). Manual in english

142

Gauges and Driver Information Interface

Driver Information Interface

strum

nt Pa

nel

■

Show Tachometer

You can show or hide the tachometer.

Press the

button to select

Show

Tachometer

, then press

ENTER

The tachometer appears when the check
box is checked.

3 4

144

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time manually in the audio/information screen, with the power
mode in ON.

Select

, then select

Settings

Select

System

Select

Date & Time

Select

Set Date & Time

Select

Automatic Date & Time

, then

select

OFF

To adjust time:
6.

Select

Set Time

Selecting /

AM/PM icon can be switched to each
other either by selecting

, or by

directly touching the icon.

When you customize the clock display to
24 hour clock, AM/PM icon is not
displayed.

Customized Features

P. 413

Select

Save

to set the time.

■

Adjusting the Time

Clock

The clock is automatically updated through the
navigation system, so the time does not need to be
adjusted.

You can also adjust the clock by touching the clock
displayed on the upper right corner of the display or
the

Clock

icon on the home screen.

1. Touch the clock on the display.

The clock screen of the select face-type appears.

2. Select

Settings

3. Select

Date & Time Settings

4. Select

Set Date & Time

5. Select

Automatic Date & Time

, then select

OFF

6. Select

Set Date

Set Time

7. Adjusting the dates, hours and minutes by

selecting /

8. Select

Save

to set the time.

Models with navigation system

3 4

Set Time

Save

Hours

Minutes

Cancel

Phone

Navigati..

3 4

145

Clock

Adjusting the Clock

Co
ntrols

To adjust date:
6.

Select

Set Date

Selecting /

Select

Save

to set the date.

Clock

You can customize the clock display to show the 12
hour clock or 24 hour clock.

Customized Features

P. 413

3 4

146

Co
ntrols

Locking and Unlocking the Doors

Key

This vehicle comes with the following keys:

Use the keys to start and stop the engine, and lock and unlock all the doors, tailgate,
and fuel fill door.

Key

All of the keys have an immobilizer system. The
immobilizer system helps protect against vehicle
theft.

Immobilizer System

P. 181

Follow the advice below to prevent damage to the
keys:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids, dust or sand.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the remote
engine start.

Remote Engine Start with Vehicle
Feedback

P. 478

Models with keyless access system,
power sliding door, and power tailgate

Models with keyless access
system and power sliding door

147

Locking and Unlocking the Doors

Key

Co
ntrols

The built-in key can be used to lock/unlock the
doors and tailgate when the keyless remote
battery becomes weak and the power door
lock/unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
keyless remote until it clicks.

Contains a number that you will need if you
purchase a replacement key.

■

Built-in Key

Release Knob

Built-in Key

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

148

Locking and Unlocking the Doors

Low Keyless Remote Signal Strength

Co
ntrols

Low Keyless Remote Signal Strength

The vehicle transmits radio waves to locate the keyless remote to start the engine,
lock and unlock the all the doors and fuel fill door, tailgate, opening the power
sliding door, and the power tailgate

In the following cases, starting the engine, locking/unlocking the doors/fuel fill door,
or opening the tailgate, power sliding door, and the power tailgate

may be

inhibited or operation may be unstable:

•

Strong radio waves are being transmitted by nearby equipment.

•

You are carrying the keyless remote together with telecommunications
equipment, laptop computers, cell phones, or wireless devices.

•

A metallic object is touching or covering the keyless remote.

Low Keyless Remote Signal Strength

Communication between the keyless remote and the
vehicle consumes the keyless remote’s battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the keyless
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

* Not available on all models

149

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the keyless remote, you can
lock/unlock the doors and fuel fill door, and
open the tailgate.
You can lock/unlock the doors, fuel fill door,
and tailgate within a radius of about 32 inches
(80 cm) of the outside door handle or tailgate
outer handle.

■

Locking the doors and tailgate

Press the door lock button on the front door
or the tailgate.

Some exterior lights flash; the beeper
sounds; all the doors and tailgate lock;
and the security system sets.

■

Using the Keyless Access System

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior lights come on when you unlock
the doors and tailgate.
No doors opened: The lights fade out after 30 seconds.
Doors and tailgate relocked: The lights go off immediately.

Interior Lights

P. 229

Using the Keyless Access System

You can lock or unlock doors using the keyless access
system only when the power mode in VEHICLE OFF.

•

Do not leave the keyless remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the keyless remote, you
can lock/unlock the doors and the tailgate while
someone else with the remote is within range.

•

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the keyless remote is within range.

•

If you grip a door handle wearing gloves, the door
sensor may be slow to respond or may not respond
by unlocking the doors.

•

After locking the door, you have up to 2 seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least 2 seconds before gripping the handle,
otherwise the door will not unlock.

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors and the
tailgate with the keyless remote if it is above or
below the outside handle.

•

The keyless remote may not operate if it is too close
to the door and door glass.

Door Lock
Button

Lock Button

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

150

Co
ntrols

■

Unlocking the doors and tailgate

Grab the driver’s door handle:

The driver’s door and fuel fill door
unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door or rear door
handle:

All doors and the tailgate unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Press the tailgate outer handle:

The tailgate unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Opening/Closing the Tailgate

P. 162

Using the Keyless Access System

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the keyless
access system, the doors and tailgate will
automatically relock.

The light flash, beep and unlock settings can be
customized.

Customized Features

P. 413

You can also unlock and open with the power
tailgate.

Using the Tailgate Outer Handle

P. 168

The keyless access system will not lock the vehicle
when a door is open.

Models with power tailgate

Tailgate Outer
Handle

Continued

151

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors and tailgate (Walk
away auto lock

)

When you walk away from the vehicle with all
doors and tailgate closed while carrying the
keyless remote, the doors and tailgate will
automatically lock.
The auto lock function activates when all
doors and tailgate are closed, and the keyless
remote is within about 5 feet (1.5 m) radius of
the outside door handle or tailgate outer
handle.
Exit vehicle while carrying the keyless remote
and close door(s) and tailgate.

While within about 5 feet (1.5 m) radius of
the vehicle.

The beeper sounds; the auto lock
function will be activated.

Carry the keyless remote beyond about 5
feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

Some exterior lights flash; the beeper
sounds; all doors and tailgate will then
lock.

Locking the doors and tailgate (Walk away auto lock

)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the audio/information screen.
If you set the auto lock function to ON using the
audio/information screen, only the remote
transmitter that was used to unlock the driver’s door
prior to the setting change can activate auto lock.

Customized Features

P. 413

After the auto lock function has been activated,
when you stay within the locking/unlocking
operation range, the indicator on the keyless remote
will continue to flash until the doors and tailgate are
locked.

When you stay beside the vehicle within the
operation range, the doors and tailgate will
automatically lock approximately 30 seconds after
the auto lock function activating beeper sounds.

When you open a door or tailgate after the auto lock
function activating beeper sounds, the auto lock
function will be canceled.

Under the following circumstances, the auto lock
function will not activate:

•

The keyless remote is inside the vehicle.

The beeper will not sound.

•

The keyless remote is taken out of its operational
range before all doors and tailgate are closed.

The beeper will sound.

The activation range of
the auto lock function is
about 5 feet (1.5 m)

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

152

Co
ntrols

To temporarily deactivate the function:

Set the power mode to OFF.

Open the driver’s door.

Using the master door lock switch, operate
the lock as follows:
Lock



Unlock



Lock



Unlock.

The beeper sounds and the function is
deactivated.

To restore the function:

•

Set the power mode to ON.

•

Lock the vehicle without using the auto lock
function.

•

With the keyless remote on you, move out
of the auto lock function operation range.

•

Open any door.

Locking the doors and tailgate (Walk away auto lock

)

The auto lock function does not operate when any of
the following conditions are met.

•

The keyless remote is inside the vehicle.

•

A door, tailgate or the hood is not closed.

•

The power mode is set to any mode other than
OFF.

•

The keyless remote is not located within a radius of
about 5 feet (1.5 m) from the vehicle when you get
out of the vehicle and close the doors and tailgate.

Auto lock function operation stop beeper

After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

•

The keyless remote is put inside the vehicle through
a window.

•

You are located too close to the vehicle.

•

The keyless remote is put inside the tailgate.

If the warning beeper sounds, check that you are
carrying the keyless remote. Then, open/close a door
and confirm the auto lock activation beeper sounds
once.

If equipped, the user must wait until the power
tailgate fully closes before the auto lock function will
be activated.

Models with power tailgate

Continued

153

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors and tailgate

Press the lock button.

Once:

Some exterior lights flash, all the doors,
tailgate, and fuel fill door lock, and the
security system sets.

Twice (within five seconds after the first
push):

A beeper sounds and verifies the security
system is set.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the remote
transmitter, the doors and tailgate will automatically
relock.
You can change the relock timer setting.

Customized Features

P. 413

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

You can lock or unlock doors using the remote
transmitter only when the power mode is in VEHICLE
OFF.

The remote will not lock the vehicle when a door is
open.

Unlock
Button

Lock
Button

LED

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

154

Co
ntrols

■

Unlocking the doors and tailgate

Press the unlock button.

Once:

Some exterior lights flash twice, and the driver’s door and fuel fill door unlocks.

Twice:

The remaining doors and the tailgate unlock.

If the lock or unlock button of the keyless remote does not work, use the key
instead.

Fully insert the key and turn it.

■

Locking/Unlocking the Doors Using a Key

Using the Remote Transmitter

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

Replacing the Remote Battery

P. 632

You can customize the door unlock mode setting.

Customized Features

P. 413

Locking/Unlocking the Doors Using a Key

When you lock the driver’s door with a key, all of the
other doors, tailgate, and fuel fill door lock at the
same time. When unlocking, the driver’s door
unlocks first. Turn the key a second time within a few
seconds to unlock the remaining doors and the
tailgate.

You can customize the door unlock mode setting.

Customized Features

P. 413

Lock

Unlock

155

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

If you do not have the key on you, or if for some reason you cannot lock a door using
the key, you can lock the door without it.

■

Locking the front doors

Push the lock tab forward

or push the

master door lock switch in the lock direction

, and close the door.

■

Locking the rear doors

Slide the lock tab downward and close the
door.

■

Lockout prevention system

The doors and tailgate cannot be locked when the keyless remote is inside the
vehicle.

■

Locking a Door Without Using a Key

Locking a Door Without Using a Key

When you lock the driver’s door, all the other doors,
tailgate, and fuel fill door lock at the same time.
When you lock the front passenger’s door with the
master door lock switch, all the other doors and the
tailgate lock at the same time.
Before locking a door, make sure that the key is not
inside the vehicle.

156

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Inside

Co
ntrols

Locking/Unlocking the Doors from the Inside

■

Locking a door

Push the lock tab forward.

■

Unlocking a door

Pull the lock tab rearward.

■

Locking a door

Slide the lock tab downward.

■

Unlocking a door

Slide the lock tab upward.

■

Using the Lock Tab

Using the Lock Tab

When you lock the door using the lock tab on the
driver’s door, all of the other doors, tailgate, and fuel
fill door lock at the same time.
When you unlock the door using the lock tab on the
driver’s door, only the driver’s door will unlock.

To unlock

Lock Tab

To lock

Front

To unlock

Lock Tab

To lock

Rear

Continued

157

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Inside

Co
ntrols

Pull the front door inner handle.

The door unlocks and opens in one
motion.

Unlocking and opening the front door from the inner handle unlocks all the other
doors.

To avoid all the doors unlocking, use the lock tab on the driver’s door to unlock,
then lock again before opening the door.

This setting works for one time only. If you do not want all the doors to be
unlock all the time, customize the

Auto Door Unlock

setting to

OFF

using the

audio/information screen.

Customized Features

P. 413

■

Unlocking Using the Front Door Inner Handle

Unlocking Using the Front Door Inner Handle

The front door inner handles are designed to allow
front seat occupants to open the door in one motion.
However this feature requires that front seat
occupants never pull a front door inner handle while
the vehicle is in motion.

Children should always ride in a rear seat where
childproof door locks are provided.

Childproof Door Locks

P. 159

Inner Handle

Honda Odyssey (2023 year). Manual in english - page 9
