516

uu

Honda Sensing

®

u

Road Departure Mitigation System

Driving

■

Roadway conditions

•

Driving on a road with temporary lane markings.

•

Faint, multiple, or varied lane markings are visible on the roadway due to road
repairs or old lane markings.

•

The roadway has merging, split, or crossing lines, such as at an intersection or
crosswalk.

•

The lane markings are extremely narrow, wide, or changing.

•

Part of the lane markings are hidden by an object, such as a vehicle.

•

The road is hilly or the vehicle is approaching the crest of a hill.

•

Your vehicle is strongly shaken on uneven road surfaces.

•

When objects on the road (curb, guard rail, pylons, etc.) are recognized as white
(or yellow) lines.

•

Driving on rough or unpaved roads, or over bumpy surfaces.

•

Driving on roads with double lane lines.

•

Driving on snowy or slippery roads.

•

Passing through an exit or an interchange.

•

The pavement is only partially visible due to snow or puddles on the road.

•

Driving on unpaved or rutted roads.

•

White (or yellow) lines are not recognized correctly due to road conditions such as
curves, twists, or hills.

517

uu

Honda Sensing

®

u

Road Departure Mitigation System

Continued

Driving

■

Vehicle conditions

•

When lighting is weak due to dirt covering the headlight lenses, or there is poor
visibility in a dark place due to the headlights being improperly adjusted.

•

The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals,
accessories, stickers, or film on the windshield.

•

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

•

When the driver operates the brake pedal and steering wheel.

•

There is residue on the windshield from the windshield wipers.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

•

The vehicle is tilted due to heavy load in the cargo area or rear seats.

•

Tire chains are installed.

•

The suspension has been modified.

■

Examples of limitations on detection due to the condition of oncoming
vehicles

•

The oncoming vehicle or vehicle ahead of you is sideways.

•

The oncoming vehicle jumps out in front of you.

•

When the oncoming vehicle blends in with the background, preventing the
system from recognizing it.

•

The headlights of an oncoming vehicle are lit on one side or not lit on either side
in a dark place.

•

The distance between your vehicle and the oncoming vehicle is too short.

•

Part of the oncoming vehicle is not visible due to the vehicle ahead of you.

•

There are multiple oncoming lanes or turning lanes.

•

The vehicle in the adjacent lane is parked or moving at an extremely slow speed.

518

uu

Honda Sensing

®

u

Road Departure Mitigation System

Driving

■

Examples of other limitations on detection or system operation

•

When the oncoming vehicle is specially-shaped.

•

When the camera cannot correctly identify the shape of the oncoming vehicle.

■

With Little Chance of a Collision

The Road Departure Mitigation system may activate in the below conditions.

•

When driving through curves, your vehicle comes to a point where an oncoming
vehicle is right in front of you.

519

uu

Honda Sensing

®

u

Traffic Sign Recognition System

Continued

Driving

Traffic Sign Recognition System

Reminds you of road sign information, such as the current speed limit your vehicle
has just passed through, showing it on the gauge.

When the camera located behind the rearview mirror captures traffic signs while
driving, the system displays the ones that are recognized as designated for your
vehicle. The sign icon will be displayed until the vehicle reaches a predetermined
time and distance.
If the system does not detect any traffic signs while you are driving, the sign icon will
not be displayed.

The sign icon also may switch to another one, or disappear when:

•

The end of speed limit or other designated limit is detected.

•

You make a turn with a turn signal at an intersection.

■

How the System Works

1

Traffic Sign Recognition System

Not all signs may be displayed, but any signs posted
on roadsides should not be ignored. The system does
not work on the designated traffic signs of all the
countries you travel, nor in all situations.
Do not rely too much on the system. Always drive at
speeds appropriate for the road conditions.

Never apply a film or attach any objects to the
windshield that could obstruct the camera’s field of
vision and cause the system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making even
minor repairs within the camera’s field of vision or
installing an aftermarket replacement windshield may
also cause the system to operate abnormally. After
replacing the windshield, have a dealer recalibrate the
camera. Proper calibration of the camera is necessary
for the system to operate properly.

The traffic sign recognition system is not activated for
about 15 seconds after the engine starts.

You can read about handling information for the
camera equipped with this system.

2

Front Wide View Camera

 P. 525

You can turn the traffic sign recognition system on
and off.

2

Settings

*

 P. 123

2

Customized Features

 P. 345

* Not available on all models

uu

Honda Sensing

®

u

Traffic Sign Recognition System

520

Driving

1

Traffic Sign Recognition System

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing system
to shut off, when parking, find a shady area or face
the front of the vehicle away from the sun. If you use
a reflective sun shade, do not allow it to cover the
camera housing.
Covering the camera can concentrate heat on it.

If your vehicle exceeds the detected speed limit, an
icon representing the speed limit sign for the current
area will blink in the display.

2

Settings

*

 P. 123

2

Customized Features

 P. 345

The system’s ability to accurately notify the driver of
the speed limit is dependent on certain conditions
such as the units displayed on the traffic sign as well
as the speed and direction of travel of the vehicle. In
some cases, the system may display false warnings or
other inaccurate information.

2

Traffic Sign Recognition System Conditions
and Limitations

 P. 521

The unit for speed limits (mph or km/h) varies from
country to country. Just after entering a country
whose unit differs to the one of the country from
which you came, Traffic Sign Recognition System
may not work correctly.

2

Settings

*

 P. 123

2

Speed/Distance Units

 P. 122

2

Customized Features

 P. 345

* Not available on all models

Continued

521

uu

Honda Sensing

®

u

Traffic Sign Recognition System

Driving

The traffic sign recognition system may not be able to recognize a traffic sign in the
following cases.

■

Environmental conditions

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Driving at night, in dark areas such as long tunnels.

•

Driving in bad weather (rain, fog, snow, etc.).

•

Sudden changes between light and dark, such as the entrance or exit of a tunnel
or the shadows of trees, buildings, etc.

•

Water is sprayed by or snow blown from a vehicle ahead.

■

Roadway conditions

•

Your vehicle is strongly shaken on uneven road surfaces.

■

Vehicle conditions

•

When lighting is weak due to dirt covering the headlight lenses, or there is poor
visibility in a dark place due to the headlights being improperly adjusted.

•

The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals,
accessories, stickers, or film on the windshield.

•

There is residue on the windshield from the windshield wipers.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

•

The vehicle is tilted due to heavy load in the cargo area or rear seats.

•

The suspension has been modified.

•

Tire chains are installed.

•

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

■

Traffic Sign Recognition System Conditions and Limitations

1

Traffic Sign Recognition System Conditions and Limitations

When the traffic sign recognition system
malfunctions,

 appears on the gauge. If this

message does not disappear, have your vehicle
checked by a dealer.

522

uu

Honda Sensing

®

u

Traffic Sign Recognition System

Driving

■

The position or the condition of the traffic sign

•

The sign is in a place that makes it hard to find.

•

The sign is located far away from your vehicle.

•

The sign is located where it is hard for headlight beams to reach.

•

The sign is on a corner or bend in the road.

•

The sign is faded or bent.

•

The sign is rotated or damaged signs.

•

The sign is covered with mud, snow, or frost.

•

Part of the sign is hidden by the trees, or is in the shadow of a vehicle or other
object.

•

Light (such as a streetlight) is reflected on the surface of the sign, or it is hidden
in shadow.

•

The sign is too bright or too dark (electric signs).

•

Small signs (auxiliary signs, etc.).

■

Other conditions

•

When you are driving at a high speed.

523

uu

Honda Sensing

®

u

Traffic Sign Recognition System

Continued

Driving

The traffic sign recognition system may not operate correctly, such as displaying
signs that do not adhere to the actual regulations for the roadway or do not exist at
all in the following cases.

u

A speed limit sign may display at a higher or lower speed than the actual speed
limit.

•

There is a supplementary sign with further information such as weather, time,
vehicle type, school zone, etc.

•

Figures on the sign are hard to read (electric signs, numbers on the sign are
blurred, etc.).

•

The sign is in the vicinity of the lane you are driving in, even though it is not for
the lane, such as a speed limit sign situated at an exit or an intersection between
the side road and the main road.

•

There are things that look similar in color or shape to recognized objects (similar
sign, electric sign, signboard, structure, etc.).

524

uu

Honda Sensing

®

u

Traffic Sign Recognition System

Driving

The speed limit sign icon is displayed on the screen.

■

Signs Displayed on the Gauge

Speed Limit Sign

525

uu

Honda Sensing

®

u

Front Wide View Camera

Continued

Driving

Front Wide View Camera

The camera, used in systems such as Lane Keeping Assist System (LKAS), Road
Departure Mitigation system, Adaptive Cruise Control (ACC) with Low Speed
Follow, Traffic Sign Recognition system, CMBS

TM

, and Traffic Jam Assist

*

, is designed

to detect an object that triggers any of the systems to operate their functions.

This camera is located behind the rearview
mirror.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing
system to shut off, when parking, find a shady
area or face the front of the vehicle away from
the sun. If you use a reflective sun shade, do
not allow it to cover the camera housing.
Covering the camera can concentrate heat on
it.

■

Camera Location and Handling Tips

1

Front Wide View Camera

Never apply a film or attach any objects to the
windshield, the hood, or the front grille that could
obstruct the camera’s field of vision and cause the
system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making
even minor repairs within the camera’s field of vision
or installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Do not place an object on the top of the instrument
panel. It may reflect onto the windshield and prevent
the system from detecting lane lines properly.

Front Wide
View Camera

* Not available on all models

uu

Honda Sensing

®

u

Front Wide View Camera

526

Driving

1

Front Wide View Camera

If the



Some driver assist systems cannot

operate: Camera temperature too high

 message

appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed towards the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the



Some driver assist systems cannot

operate: Clean front windshield or poor viewing
condition.

 message appears:

•

Park your vehicle in a safe place, and make sure the
windshield is clean.
Clean the windshield if it is dirty. If the message
does not disappear after driven for a while, have
your vehicle checked by a dealer.

527

uu

Honda Sensing

®

u

Sonar Sensors

*

Driving

Sonar Sensors

*

■

Location and range of sensors

The sonar sensors are situated in the front and rear bumpers, and the front grille.

1

Sonar Sensors

*

For the sonar sensors to work properly, do not:

•

Place stickers or other objects on or around the
sensors.

•

Hit the area around the sensors.

•

Attempt to take apart any sensor.

•

Put any accessories on or around the sensors.

Consult with a dealer if:

•

A sensor has been subjected to shock.

•

Work needs to be done to the area around a
sensor.

In the following cases, the sonar sensors may not
work properly. Have your vehicle checked by a dealer.

•

The front or rear bumper has made contact with a
hill, parking block, curb, embankment, etc.

•

The vehicle has been involved in frontal or rear
collision.

•

The vehicle has been driven through a deep
puddle.

Sonar Sensors

Sonar Sensors

Sensor Range

* Not available on all models

528

Driving

Braking

Brake System

Use the parking brake to keep the vehicle stationary when parked. When the
parking brake is applied, you can manually or automatically release it.

■

To apply

The electric parking brake can be applied any
time the vehicle has battery, no matter which
position the power mode is in.

Pull the electric parking brake switch up gently
and securely.

u

The indicator in the switch comes on.

u

The parking brake and brake system
indicator (red) comes on.

■

To release

The power mode must be in ON in order to
release the electric parking brake.

1.

Depress the brake pedal.

2.

Press the electric parking brake switch.

u

The indicator in the switch goes off.

u

The parking brake and brake system
indicator (red) goes off.

Manually releasing the parking brake using
the switch helps your vehicle start slowly and
smoothly when facing downhill on steep hills.

■

Parking Brake

1

Brake System

When you depress the brake pedal, you may hear a
whirring sound from the engine compartment. This is
because the brake system is in operation, and it is
normal.

Electric Parking
Brake Switch

Electric Parking
Brake Switch

1

Parking Brake

You may hear the electric parking brake system
operating from the rear wheel area when you apply
or release the parking brake. This is normal.

The brake pedal may slightly move due to the electric
parking brake system operation when you apply or
release the parking brake. This is normal.

You cannot apply or release the parking brake if the
battery goes dead.

2

If the Battery Is Dead

 P. 617

If you pull up and hold the electric parking brake
switch while driving, the brakes on all four
wheels are applied by the VSA

®

 system until the

vehicle comes to a stop. The electric parking
brake then applies, and the switch should be
released.

Continued

529

uu

Braking

u

Brake System

Driving

■

Automatic parking brake feature operation

If the automatic parking brake feature has been activated:

•

The parking brake is applied automatically when you set the power mode to
VEHICLE OFF.

•

To confirm that the parking brake is applied, check if the parking brake and brake
system indicator (red) is on.

2

Activating and deactivating the automatic parking brake feature

 P. 530

■

To release automatically

Depressing the accelerator pedal releases the parking brake.
Use the accelerator pedal to release the brake when you are starting the vehicle
facing uphill, or in a traffic jam.

Gently depress the accelerator pedal.
When on a hill, it may require more
accelerator input to release.

u

The parking brake and brake system
indicator (red) goes off.

You can release the parking brake
automatically when:

•

You are wearing the driver’s seat belt.

•

The engine is running.

•

The transmission is not in

(

P

 or

(

N

.

1

Parking Brake

In the following situations, the parking brake
automatically operates.

•

When the vehicle stops more than 10 minutes
while ACC with Low Speed Follow is activated.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped automatically by ACC with
Low Speed Follow.

•

When the power system is turned off while ACC
with Low Speed Follow is activated.

•

When the vehicle stops with the automatic brake
hold system activated for more than 10 minutes.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped and the brake hold system
is applied.

•

When the engine is turned off while the brake hold
is applied.

•

When there is a problem with the Brake Hold
System while brake hold is applied.

If the parking brake cannot be released
automatically, release it manually.

When the vehicle is traveling uphill, the accelerator
pedal may need to be pressed farther to
automatically release the electric parking brake.

The parking brake cannot be released automatically
while the following indicators are on:

•

Malfunction indicator lamp

•

Transmission system indicator

Accelerator Pedal

uu

Braking

u

Brake System

530

Driving

■

Activating and deactivating the automatic parking brake feature

With the power mode is in ON, carry out the following steps to either activate or
deactivate the automatic parking brake feature.

1.

Put the transmission into

(

P

.

2.

Without depressing the brake pedal, pull up and release the electric parking brake
switch.

u

Check that the parking brake and brake system indicator (red) has come on.

3.

Pull up and hold the electric parking brake switch. When you hear a beeping
sound, release the switch and within 3 seconds pull up and hold the switch again.

4.

When you hear a sound indicating that the procedure is completed, release the
switch.

u

Two beeps indicates that the feature has been activated.

u

One beep indicates that the feature has been deactivated.

u

When you have completed activating the feature, the parking brake will
remain applied after you turn off the engine.

u

To confirm that the parking brake is applied, check if the parking brake and
brake system indicator (red) is on.

If you need to temporarily deactivate the feature while putting your vehicle through
a conveyor type car wash, you can follow the procedure explained below.

1.

Depress the brake pedal and bring the vehicle to a stop.

2.

Set the power mode to VEHICLE OFF and then within 2 seconds push down the
electric parking brake switch.

u

Activation and deactivation settings for the feature will not be affected.

u

Before temporarily deactivating the feature, make sure to first turn off both
Adaptive Cruise Control (ACC) with Low Speed Follow and the automatic
brake hold system.

u

To confirm that the parking brake is applied, check if the parking brake and
brake system indicator (red) is on.

1

Parking Brake

The parking brake may not be released automatically
while the following indicators are on:

•

Parking brake and brake system indicator

•

VSA

®

 system indicator

•

ABS

 indicator

•

Supplemental restraint system indicator

The parking brake is applied while the vehicle is
moving with the electric parking brake switch being
pulled.

In cold climates, the parking brake may freeze in
place if applied.
When parking the vehicle, chock the wheels and
make sure the automatic parking brake feature is
deactivated.
Also, when putting your vehicle through a conveyor-
type car wash or when having your vehicle towed,
deactivate the automatic parking brake feature and
leave the parking brake released.

Continued

531

uu

Braking

u

Brake System

Driving

Your vehicle is equipped with disc brakes at all four wheels. The brake assist system
increases the stopping force when you depress the brake pedal hard in an
emergency situation. The anti-lock brake system (ABS) helps you retain steering
control when braking very hard.

2

Brake Assist System

 P. 536

2

Anti-lock Brake System (ABS)

 P. 535

■

Foot Brake

1

Foot Brake

Check the brakes after driving through deep water,
or if there is a buildup of road surface water. If
necessary, dry the brakes by lightly depressing the
pedal several times.

If you hear a continuous metallic friction sound when
applying the brakes, this is caused by the brake wear
indicator rubbing on the brake rotor and indicates
that the brake pads need to be replaced. Have the
vehicle checked by a dealer. If you hear only an
occasional squeak or squeal when you initially apply
the brake pedal, this may be normal and caused by
high frequency vibration of the brake pads against
the rotating brake disc.

Constantly using the brake pedal while going down a
long hill builds up heat, which reduces the brake
effectiveness. Apply engine braking by taking your
foot off the accelerator pedal and downshifting to a
lower speed position.

Do not rest your foot on the brake pedal while
driving, as it will lightly apply the brakes and cause
them to lose effectiveness over time and reduce pad
life. It will also confuse drivers behind you.

Whenever the brakes are activated by CMBS

TM

 or

another system that automatically controls braking,
the brake pedal is depressed and released in
accordance with braking function.
