Honda HR-V (2023 year). Manual in english - page 29

484

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

Press the Interval button to change the ACC
with Low Speed Follow following-interval.
Each time you press the button, the following-
interval (the interval behind a vehicle detected
ahead of you) setting cycles through furthest,
far, mid, and nearest following-intervals.

Determine the most appropriate following-
interval setting based on your specific driving
conditions. Be sure to adhere to any
following-interval requirements set by local
regulation.

■

To Set or Change Following-interval

Interval Button

485

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

The higher your vehicle’s following-speed is, the longer the nearest, mid, far or
furthest following-interval becomes. See the following examples for your reference.

When your vehicle stops automatically because a vehicle detected ahead of you has
stopped, the interval between the two vehicles will vary based on the ACC with Low
Speed Follow interval setting.

Following-interval

When the Set Speed is:

50 mph (80 km/h)

65 mph (104 km/h)

Nearest

82.7 feet

25.2 meters

1.1 sec

107.1 feet

32.6 meters

1.1 sec

Mid

113.4 feet

34.6 meters

1.6 sec

147.2 feet

44.9 meters

1.6 sec

Far

144.2 feet

44.0 meters

2.0 sec

187.3 feet

57.1 meters

2.0 sec

Furthest

175.9 feet

53.6 meters

2.4 sec

229.6 feet

70.0 meters

2.4 sec

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

486

Driving

To cancel ACC with Low Speed Follow, do any
of the following:

•

Press the

CANCEL

button.

The

indicator (green) on the gauge

changes to the

indicator (white).

•

Press the

button.

indicator (green) goes off.

•

Depress the brake pedal while the vehicle is
moving forward.

The

indicator (green) on the gauge

changes to the

indicator (white).

■

To Cancel

To Cancel

Resuming the prior set speed: After you have
canceled ACC with Low Speed Follow, you can
activate the ACC with Low Speed Follow with the
prior set speed displayed on the gauge (in gray) by
pressing the

RES/+

SET/−

switch up even if the

vehicle is stopped.
When you turn the ACC with Low Speed Follow off
by pressing the

CANCEL

button or depressing the

brake pedal, the prior set speed is displayed on the
gauge in gray.
When pressing the

RES/+

SET/−

switch up, the ACC

with Low Speed Follow is activated with displayed
speed.
If the

indicator (white) is displayed and you press

the

RES/+

SET/−

switch up, but no prior set speed (in

gray) is displayed, the speed will be set to your
vehicle's current speed.

CANCEL

Button

Continued

487

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

Automatic cancellation

The beeper sounds and a message appears on the driver information interface when
ACC with Low Speed Follow is automatically canceled. Any of these conditions may
cause the ACC with Low Speed Follow to automatically cancel:

•

Bad weather (rain, fog, snow, etc.)

•

The vehicle ahead of you cannot be detected.

•

An abnormal tire condition is detected, or the tires are skidding.

•

Driving on a mountainous road, or driving off road for extended periods.

•

Abrupt steering wheel movement.

•

When the ABS, VSA

, CMBS

, or Low Speed Braking Control

is activated.

•

When the VSA

system indicator comes on.

•

When the vehicle is stopped on a very steep slope.

•

When you manually apply the parking brake.

•

Water is sprayed by or snow blown from a vehicle ahead.

•

Driving into low sunlight (e.g., at dawn or dusk).

•

When the detected vehicle within the ACC with Low Speed Follow range is too
close to your vehicle.

•

When accelerating rapidly.

•

The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals,
accessories, stickers, or film on the windshield.

•

The vehicle is loaded heavy load in the cargo area or rear seats.

•

When passing through a dark place, such as tunnel.

•

When the parking brake and brake system indicator (amber) comes on.

•

The vehicle has repeatedly applied the brakes to maintain the set speed (for
example, you are descending a long slope).

•

When the system doesn't detect any driving actions from the driver for a certain
amount of time while the LKAS is also activated.

The ACC with Low Speed Follow automatic cancellation can be also triggered by the
following causes. In these cases, the parking brake will be automatically applied.

•

The driver’s seat belt is unfastened when the vehicle is stationary.

•

The vehicle stops for more than 10 minutes.

•

The engine is turned off.

To Cancel

The set speed cannot be set or resumed when ACC
with Low Speed Follow has been turned off using the

button. Press the

button to activate the

system, then set the desired speed.

(white)

Prior Set Speed (gray)

* Not available on all models

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

488

Driving

Press and hold the Interval button for one
second.

Cruise mode selected

appears on

the driver information interface for two
seconds, and then the mode switches to
Cruise.
The

indicator comes on.

•

Green: The system is on.

•

White: The system is standby.

To switch back to ACC with Low Speed
Follow, press and hold the Interval button
again for one second.

■

When to use

Desired speed in a range above roughly 25 mph (40 km/h).

Take your foot off the pedal and press the

RES/+

SET/−

switch up or down when

you reach the desired speed.
The moment you release the

RES/+

SET/−

switch, the set speed is fixed, and cruise

control begins. The color of

indicator changes from white to green.

When you use cruise control, Straight Driving Assist (a feature of the Electric Power
Steering system) is activated.
By enabling the steering system to automatically compensate for natural steering
pull, Straight Driving Assist makes it easier for you to keep your vehicle in a straight
line.

■

To Switch ACC with Low Speed Follow to Cruise Control

To Switch ACC with Low Speed Follow to Cruise Control

Always be aware which mode you are in. When you
are driving in Cruise mode, the system will not assist
you to maintain a following-interval from a vehicle
ahead of you.

You cannot switch ACC with Low Speed Follow to
Cruise Control in the following situations:

•

When the vehicle speed is set.

•

When ACC with Low Speed Follow is not activated.

You can switch the displayed set speed
measurements on the driver information interface or
audio/information screen

between mph and km/h.

Settings

P. 123

Speed/Distance Units

P. 122

Customized Features

P. 345

ACC with
Low Speed
Follow ON

Cruise
Control ON

Interval
Button

(white)

■

To Set the Vehicle Speed

* Not available on all models

Continued

489

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

•

Each time you press the

RES/+

SET/−

switch up or down, the vehicle speed is

increased or decreased by about 1 mph or 1 km/h accordingly.

•

If you keep the

RES/+

SET/−

switch pressed up or down, the vehicle speed

increases or decreases by about 5 mph or 5 km/h accordingly.

To cancel cruise control, do any of the following:

•

Press the

CANCEL

button.

The

indicator (green) on the gauge changes to the

indicator (white).

•

Press the

button.

The

indicator (green) goes off.

•

Depress the brake pedal.

The

indicator (green) on the gauge changes to the

indicator (white).

■

To Adjust the Vehicle Speed

■

To Cancel

To Cancel

Resuming the prior set speed: After you have canceled
cruise control, you can activate the cruise control with
the prior set speed displayed on the gauge (in gray) by
pressing the

RES/+

SET/−

switch up while driving at a

speed of at least 25 mph (40 km/h) or more.
When you turn the cruise control off by pressing the

CANCEL

button or depressing the brake pedal, the

prior set speed is displayed on the gauge in gray.
When pressing the

RES/+

SET/−

switch up, the

cruise control is activated with displayed speed.
If the

indicator (white) is displayed and you press

the

RES/+

SET/−

switch up, but no prior set speed (in

gray) is displayed, the speed will be set to your
vehicle's current speed.

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

490

Driving

To Cancel

You cannot set or resume in the following situations:

•

When vehicle speed is less than 25 mph (40 km/h)

•

When cruise control is canceled by pressing the

button.

At vehicle speeds of 22 mph (35 km/h) or less, cruise
control is canceled automatically.

Prior Set Speed (gray)

(white)

491

Honda Sensing

Lane Keeping Assist System (LKAS)

Continued

Driving

Lane Keeping Assist System (LKAS)

Provides steering input to help keep the vehicle in the middle of a detected lane and
provides tactile and visual alerts if the vehicle is detected drifting out of its lane.

■

Steering input assist

The system applies torque to the steering to keep the vehicle between the left and
right lane lines. The applied torque becomes stronger as the vehicle gets closer to
either of the lane lines.

■

Tactile and visual alerts

Rapid vibrations on the steering wheel and a warning display alert you that the
vehicle is drifting out of a detected lane.

Lane Keeping Assist System (LKAS)

Important Safety Reminders

The LKAS is for your convenience only. It is not an
autonomous driving system and always requires
driver attention and control. The system does not
work if you take your hands off the steering wheel or
fail to steer the vehicle.

The LKAS is convenient when it is used on
expressways or freeways.

Do not place objects on the instrument panel.
Objects may reflect on the windshield and prevent
correct detection of the traffic lanes.

The LKAS only alerts you when lane drift is detected
without a turn signal in use. The LKAS may not detect
all lane markings or lane departures; accuracy will
vary based on weather, speed, and lane marker
condition.
It is always your responsibility to safely operate the
vehicle and avoid collisions.

The LKAS may not work properly or may work
improperly under the certain conditions:

LKAS Conditions and Limitations

P. 498

You can read about handling information for the
camera equipped with this system.

Front Wide View Camera

P. 525

■

Front Wide View Camera

Monitors the lane lines

Honda Sensing

Lane Keeping Assist System (LKAS)

492

Driving

When you operate the turn signals to change lanes, the system is suspended, and
resumes after the signals are off.
If you make a lane change without operating the turn signals, the LKAS alerts
activate, and torque is applied to the steering.

Provides assistance to keep the vehicle in the center of the lane. When the vehicle
nears a white or yellow line, steering force of the electric power steering will become
stronger.

■

Lane Keep Support Function

Lane Keeping Assist System (LKAS)

When it fails to detect lanes, the system will
temporarily be canceled. When a lane is detected, the
system will recover automatically.

The LKAS may not function as designed while driving
in frequent stop and go traffic, or on roads with
sharp curves.

493

Honda Sensing

Lane Keeping Assist System (LKAS)

Continued

Driving

When the vehicle enters the warning area, the LKAS alerts you with slight steering
wheel vibration as well as a warning display.

■

Lane Departure Warning Function

LKAS indicator (green)

Amber line

Warning Area

Honda Sensing

Lane Keeping Assist System (LKAS)

494

Driving

The system can be used when the following conditions are met.

•

The lane in which you are driving has detectable lane markers on both sides, and
your vehicle is in the center of the lane.

•

The vehicle is traveling between about 45 and 90 mph (72 and 145 km/h).

•

You are driving on a straight or slightly curved road.

•

The turn signals are off.

•

The brake pedal is not depressed.

■

How to activate the system

Press the LKAS button.

LKAS indicator (white) appears on the
gauge.
The system is standby.

If traffic lane lines are detected, white
lines appear on the gauge.

■

When the System can be Used

When the System can be Used

If the vehicle drifts toward either left or right lane line
due to the system applying torque, turn off the LKAS
and have your vehicle checked by a dealer.

Be sure to keep the following below to activate the
system properly;

•

Always keep the windshield around the camera
clean.

•

When cleaning the windshield, be careful not to
apply windshield cleanser to the camera lens.

•

Do not touch the camera lens.

•

Do not attach a sticker to the area around the
camera.

If LKAS button is pressed when the system can be
used, LKAS is on without standby.

White lines

LKAS indicator
(white)

LKAS
Button

495

Honda Sensing

Lane Keeping Assist System (LKAS)

Continued

Driving

Keep your vehicle near the center of the
lane while driving.

The LKAS indicator changes from white
to green, and white lines change to
green once the system starts operating
after detecting the left and right lane
markings.

Press the LKAS button.

The LKAS is turned off every time you stop the
engine, even if you turned it on the last time
you drove the vehicle.

LKAS indicator (green)

Green lines

■

To Cancel

LKAS Button

Honda Sensing

Lane Keeping Assist System (LKAS)

496

Driving

■

The system operation is suspended if
you:

•

Decrease the vehicle speed to about 40 mph
(64 km/h) or less.

Increasing the vehicle speed to about
45 mph (72 km/h) or more resumes the
LKAS.

•

Depress the brake pedal.

The LKAS resumes and starts detecting
the lane lines again once you release the
brake pedal.

•

Your vehicle is driving to the right or the left
of the lane.

To Cancel

You can change the setting for the LKAS.
LKAS suspended beep on and off can be selected.

Settings

P. 123

Customized Features

P. 345

When the LKAS is suspended,
green lines on the gauge change
to white lines or disappear, and
the beeper sounds (if activated).

LKAS indicator (white)

White lines

* Not available on all models

497

Honda Sensing

Lane Keeping Assist System (LKAS)

Continued

Driving

■

The LKAS may be automatically suspended when:

•

The system fails to detect lane lines.

•

The steering wheel is turned quickly.

•

You fail to steer the vehicle.

•

Driving through a sharp curve.

•

Driving at a speed in excess of approximately 94 mph (150 km/h).

Once these conditions no longer exist, the LKAS automatically resumes.

■

The LKAS may be automatically canceled when:

In the following cases, traffic lane lines may disappear on the gauge, the beeper may
sound, and the LKAS may automatically be canceled:

•

The camera temperature gets extremely high.

•

The camera behind the rearview mirror, or the area around the camera, including
the windshield, gets dirty.

•

The ABS or VSA

system engages.

498

Honda Sensing

Lane Keeping Assist System (LKAS)

Driving

The system may not detect lane markings and therefore may not keep the vehicle in
the middle of the lane under certain conditions, including the following:

■

Environmental conditions

•

There is little contrast between lane lines and the roadway surface.

•

Driving in bad weather (rain, fog, snow, etc.).

•

Driving on a snowy or wet roadway.

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Shadows of adjacent objects (trees, buildings, guard rails, vehicles, etc.) are
parallel to white (or yellow) lines.

•

Sudden changes between light and dark, such as the entrance or exit of a tunnel
or the shadows of trees, buildings, etc.

•

Driving at night or in a dark place such as a tunnel (due to low-light conditions,
lane lines or the road surface may not be illuminated).

•

The distance between your vehicle and the vehicle ahead of you is too short, and
lane lines and the road surface are not visible.

•

Strong light is reflected onto the roadway.

■

LKAS Conditions and Limitations

499

Honda Sensing

Lane Keeping Assist System (LKAS)

Continued

Driving

■

Roadway conditions

•

Driving on a road with temporary lane markings.

•

Faint, multiple, or varied lane markings are visible on the roadway due to road
repairs or old lane markings.

•

The roadway has merging, split, or crossing lines, such as at an intersection or
crosswalk.

•

The lane markings are extremely narrow, wide, or changing.

•

Part of the lane markings are hidden by an object, such as a vehicle.

•

The road is hilly or the vehicle is approaching the crest of a hill.

•

Your vehicle is strongly shaken on uneven road surfaces.

Faded lines

Duplicate lines

Tire tracks

Very wide or narrow traffic lane

Content .. 27 28 29 30 ..
