Honda Sensing

®

u

Low Speed Braking Control

*

468

Driving

You can turn the system on and off using the driver information interface.

2

Switching the Display

 P. 107

2

Safety Support

 P. 118

The system is turned on every time you start the engine, even if you turned it off the
last time you drove the vehicle.

■

System On and Off

1

System On and Off

The system may temporarily turn off after
reconnecting the battery.
The system will automatically turn ON after the
vehicle has been moving at over 12 mph (20 km/h)
for some time.
If the system does not turn on, have your vehicle
checked by a dealer.

Continued

469

uu

Honda Sensing

®

u

Low Speed Braking Control

*

Driving

Conditions for assistive driving power suppression.

•

When the accelerator is no longer depressed.

•

When the accelerator is depressed for approximately four seconds.

•

When the brake pedal is depressed.

Conditions for assistive braking cancellation.

•

A certain amount of time has passed since activation.

The system may not operate correctly in the following conditions:

■

Examples of obstacles the sonar sensor cannot detect

•

Obstacles that do not reflect sound waves well, such as people, snow, cloth,
sponges, etc.

•

Thin obstacles such as fences, bicycles, sign posts, etc.

•

Short or small obstacles.

•

Obstacles immediately in front of the bumper.

•

Moving objects or obstacles that suddenly enter the road.

•

Obstacles that are not perpendicular to the ground.

■

Conditions for Cancellation

■

Low Speed Braking Control System Conditions and Limitations

1

Conditions for Cancellation

After Low Speed Braking Control has activated once,
it will not activate again for the same obstacle.
They can be activated again after driving for a certain
distance after last activation.

Low Speed Braking Control activates separately when
moving forward and reversing. (For example, if it
activates when moving forward, it can be activated
again immediately if reversing.)
However, if assistive braking has been activated, in
order to activate assistive driving power suppression
again, it is necessary to drive for a certain distance to
reset the system.

470

uu

Honda Sensing

®

u

Low Speed Braking Control

*

Driving

■

Examples of situations where the sonar sensor cannot detect obstacles

•

The sonar sensor is dirty (covered by snow, water, mud, etc.).

•

The vehicle is too hot or cold.

•

The steering wheel is turned sharply when approaching the obstacle at an angle.

■

Examples of other cases where the system may not work correctly

•

The vehicle is tilted due to heavy load or suspension modifications.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

•

Bad weather conditions such as heavy rain, fog, snow, sandstorms, etc.

•

The ambient temperature/humidity is too high or low.

•

When going down a very steep slope.

•

When close to other vehicles with sonar sensors or other objects that emit
ultrasonic waves.

■

Situations where the system may activate even without risk of a collision

•

When passing through short or narrow gates.

•

When driving on uneven surfaces, grassy areas, or places with steps.

•

When a sloped pillar or wall is protruding from a high position.

•

When there are obstacles next to the road.

•

When driving toward flags, curtains, tree branches, railroad crossing bars, etc.

•

When driving on flooded roads.

471

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

Adaptive Cruise Control (ACC) with Low Speed Follow

Helps maintain a constant vehicle speed and a set following-interval behind a vehicle
detected ahead of yours and, if the detected vehicle comes to a stop, can decelerate
and stop your vehicle, without you having to keep your foot on the brake or the
accelerator.
When ACC with Low Speed Follow slows your vehicle by applying the brakes, your
vehicle’s brake lights will illuminate.

•

Vehicle speed for ACC with Low Speed Follow:

A vehicle is detected ahead

within ACC with Low Speed Follow range

 – ACC with Low Speed Follow

operates at speeds up to 90 mph (145 km/h).

No vehicle is detected within ACC with Low Speed Follow range

 – ACC

with Low Speed Follow operates at the speed of 25 mph (40 km/h) or above.

•

Shift position for ACC with Low Speed Follow: In

(

D

 or

(

S

.

1

Adaptive Cruise Control (ACC) with Low Speed Follow

3

WARNING

Improper use of ACC with Low Speed
Follow can lead to a crash.

Use ACC with Low Speed Follow only
when driving on expressways or freeways
and in good road and weather conditions.

3

WARNING

ACC with Low Speed Follow has limited
braking capability and may not stop your
vehicle in time to avoid a collision with a
vehicle that quickly stops in front of you.

Always be prepared to apply the brake
pedal if the conditions require.

When to use

A front wide view camera is
located behind the rearview
mirror.

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

472

Driving

■

How to activate the system

1

Adaptive Cruise Control (ACC) with Low Speed Follow

Important Reminder

As with any system, there are limits to ACC with Low
Speed Follow. Use the brake pedal whenever
necessary, and always keep a safe interval between
your vehicle and other vehicles.

You can read about handling information for the
camera equipped with this system.

2

Front Wide View Camera

 P. 525

ACC with Low Speed Follow may not work properly
under certain conditions.

2

ACC with Low Speed Follow Conditions
and Limitations

 P. 479

When not using ACC with Low Speed Follow: Turn
off adaptive cruise by pressing the

 button.

3

WARNING

Exiting a vehicle that has been stopped
while the ACC with Low Speed Follow
system is operating can result in the
vehicle moving without operator control.

A vehicle that moves without operator
control can cause a crash, resulting in
serious injury or death.

Never exit a vehicle when the vehicle is
stopped by ACC with Low Speed Follow.

How to use

■

Press the

 button on the

steering wheel.

 (white) is on in the gauge

ACC with Low Speed Follow is ready to use.

Continued

473

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

When driving at about 25 mph (40 km/h) or above:

Take your foot off the

pedal and press the

RES/+

/

SET/−

 switch up or down when you reach the desired

speed. The moment you release the switch, the set speed is fixed, and ACC with Low
Speed Follow begins.

When driving slower than about 25 mph (40 km/h):

If the vehicle is moving

and the brake pedal is not depressed, pressing the switch fixes the set speed to
about 25 mph (40 km/h) regardless of current vehicle speed. If your vehicle is
stationary, you can set the vehicle speed even with the brake pedal depressed.

■

To Set the Vehicle Speed

1

Adaptive Cruise Control (ACC) with Low Speed Follow

Do not use ACC with Low Speed Follow under the
following conditions:

•

On roads with frequent lane change or continuous
stop and go traffic, ACC with Low Speed Follow
cannot keep an appropriate distance between your
vehicle and the vehicle ahead of you.

•

On roads with sharp turns.

•

On roads with toll collection facilities or other
objects between lanes of traffic, or in parking
areas, or facilities with drive through access.

•

On roads with bad weather (rain, fog, snow, etc.),
ACC with Low Speed Follow may not detect the
distance between your vehicle and the vehicle
ahead of you properly.

•

On roads with slippery or icy surfaces. The wheels
may spin out and your vehicle may lose the control
on the condition.

•

On roads with steep uphill or steep downhill slopes.

•

On roads with undulating slopes.

On when ACC with Low
Speed Follow begins

Up or down

RES/+

/

SET/−

 Switch

 (green)

1

To Set the Vehicle Speed

The Vehicle Stability Assist

TM

 (VSA

®

) system, Vehicle

Stability Assist

TM

 (VSA

®

)

OFF

, Adaptive Cruise Control

(ACC) with Low Speed Follow, low tire pressure/
TPMS

*

, parking brake and brake system and safety

support indicators may come on in amber along with a
message in the gauge when you set the power mode
to ON after reconnecting the battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

* Not available on all models

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

474

Driving

When ACC with Low Speed Follow starts
operating, the vehicle icon, interval bars and
set speed appear on the gauge.

When you use ACC with Low Speed Follow,
Straight Driving Assist (a feature of the Electric
Power Steering system) is activated.
By enabling the steering system to
automatically compensate for natural steering
pull, Straight Driving Assist makes it easier for
you to keep your vehicle in a straight line.

1

To Set the Vehicle Speed

You can switch the displayed set speed
measurements on the driver information interface or
audio/information screen

*

 between mph and km/h.

2

Settings

*

 P. 123

2

Speed/Distance Units

 P. 122

2

Customized Features

 P. 345

Set Vehicle Speed

Set Vehicle Interval

 (green)

* Not available on all models

Continued

475

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

There is a vehicle ahead

ACC with Low Speed Follow monitors if a vehicle ahead of you enters the ACC with
Low Speed Follow range. If a vehicle is detected doing so, the ACC with Low Speed
Follow system maintains or decelerates your vehicle’s set speed in order to keep the
vehicle’s set following-interval from the vehicle ahead.

2

To Set or Change Following-interval

 P. 484

■

When in Operation

1

When in Operation

If the vehicle ahead of you slows down abruptly, or if
another vehicle cuts in front of you, a beeper sounds,
a message appears on the driver information
interface.

Depress the brake pedal, and keep an appropriate
interval from the vehicle ahead.

Beep

ACC with Low Speed Follow Range: 394 ft. (120 m)

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

476

Driving

When a vehicle whose speed is slower than
your set speed is detected in front of you, your
vehicle starts to slow down.

1

When in Operation

Even if the interval between your vehicle and the
vehicle detected ahead is short, ACC with Low Speed
Follow may start accelerating your vehicle under the
following circumstances:

•

The vehicle ahead of you is going at almost the
same speed as, or faster than, your vehicle.

•

A vehicle that cuts in front of you is going faster
than your vehicle, gradually increasing the interval
between the vehicles.

You can also set the system to beep when a vehicle in
front of you comes in and goes out of the ACC with
Low Speed Follow detecting range. A vehicle detect
beep on and off can be selected.

2

Settings

*

 P. 123

2

Customized Features

 P. 345

Limitations

You may need to use the brake to maintain a safe
interval when using ACC with Low Speed Follow.
Additionally, ACC with Low Speed Follow may not
work properly under certain conditions.

2

ACC with Low Speed Follow Conditions
and Limitations

 P. 479

* Not available on all models

Continued

477

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

There is no vehicle ahead

Your vehicle maintains the set speed without
having to keep your foot on the brake or
accelerator pedal.
If there previously was a vehicle detected
ahead that kept your vehicle from traveling at
the set speed, ACC with Low Speed Follow
accelerates your vehicle to the set speed, and
then maintains it.

On steep downhill during ACC with Low
Speed Follow, it brakes to inhibit excessive
acceleration for maintaining the set speed.
However, the vehicle speed may become
faster than the set speed.

■

When you depress the accelerator pedal

You can temporarily increase the vehicle speed. In this case, there is no audible or
visual alert even if a vehicle is in the ACC with Low Speed Follow range.
ACC with Low Speed Follow stays on unless you cancel it. Once you release the
accelerator pedal, the system resumes an appropriate speed for keeping the
following-interval while a vehicle ahead is within the ACC with Low Speed Follow
range.

1

When in Operation

•

ACC with Low Speed Follow may temporarily
control the interval between your vehicle and the
vehicle in adjacent lane or surroundings of your
vehicle depending on the road conditions (e.g.
curves) or vehicle conditions (e.g. operating the
steering wheel or the vehicle location in the lane).

•

When the vehicle ahead of you moves away, such
as when entering an interchange or rest area, ACC
with Low Speed Follow may continue to maintain
the set following-interval for a short time.

A vehicle icon with line contour
appears on the gauge.

478

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

A vehicle detected ahead is within ACC with Low Speed Follow range and
slows to a stop

Your vehicle also stops, automatically. The

Stopped

 message appears on the gauge.

When the vehicle ahead of you starts again,
the vehicle icon on the gauge blinks. If you
press the

RES/+

/

SET/−

 switch up or down, or

depress the accelerator pedal, ACC with Low
Speed Follow operates again within the prior
set speed.

If no vehicle is ahead of you before you
resume driving, depress the accelerator pedal
and ACC with Low Speed Follow will operate
again within the prior set speed.

 (green)

 (green)

479

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

The system may automatically shut off under certain conditions. Some examples of
these conditions are listed below. Other conditions may reduce some of the ACC
with Low Speed Follow functions.

2

Front Wide View Camera

 P. 525

■

Environmental conditions

•

Driving in bad weather (rain, fog, snow, etc.).

•

Sudden changes between light and dark, such as the entrance or exit of a tunnel
or the shadows of trees, buildings, etc.

•

Strong light is reflected onto vehicles or road surfaces.

•

Water is sprayed by or snow blown from a vehicle ahead.

•

Driving at night or in a dark place such as a tunnel (due to low-light conditions,
the whole vehicle may not be illuminated).

•

Driving into low sunlight (e.g., at dawn or dusk).

■

ACC with Low Speed Follow Conditions and Limitations

480

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

Roadway conditions

•

Driving on curvy, winding, undulating, or sloping roads.

•

Driving on rutted roads (snowy or unpaved roads, etc.).

•

Puddles or a film of water is on the road surface.

•

Your vehicle is strongly shaken on uneven road surfaces.

■

Vehicle conditions

•

The vehicle is tilted due to heavy load in the cargo area or rear seats.

•

Tire chains are installed.

•

The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals,
accessories, stickers, or film of the windshield.

•

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

•

There is residue on the windshield from the windshield wipers.

•

When lighting is weak due to dirt covering the headlight lenses, or there is poor
visibility in a dark place due to the headlights being improperly adjusted.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

•

The suspension has been modified.

481

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

■

Examples of conditions under which the camera may not correctly detect
the vehicle ahead of you

•

A vehicle suddenly crosses in front of you.

•

The interval between your vehicle and the vehicle ahead of you is too short.

•

When the vehicle ahead of you blends in with the background, preventing the
system from recognizing it.

•

The headlights of the vehicle ahead of you are lit on one side or not lit on either
side in a dark place.

482

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

Examples of conditions under which the system may not work properly

•

A vehicle ahead of you stops and the speed difference between your vehicle and
the vehicle ahead of you is significantly large.

•

When the vehicle ahead of you slows suddenly.

•

When the vehicle ahead of you is a specially-shaped vehicle.

•

When a vehicle is lower in the rear than the front such as trucks that are not
carrying a load, or a narrow vehicle.

•

When your vehicle or the vehicle ahead of you is driving on the edge of the lane.

•

When the vehicle ahead of you is a narrow vehicle such as a motorcycle.

•

When the minimum ground clearance of a vehicle ahead of you is extremely high.

•

When the camera cannot correctly identify the shape of the vehicle ahead of you.

Camera detects upper section of an empty carrier truck.

Continued

483

uu

Honda Sensing

®

u

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

Increase or decrease the vehicle speed using the

RES/+

/

SET/−

switch on the steering

wheel.

•

Each time you press the

RES/+

/

SET/−

switch up or down, the vehicle speed is

increased or decreased by about 1 mph or 1 km/h accordingly.

•

If you keep the

RES/+

/

SET/−

switch pressed up or down, the vehicle speed

increases or decreases by about 5 mph or 5 km/h accordingly.

■

To Adjust the Vehicle Speed

1

To Adjust the Vehicle Speed

If a vehicle detected ahead is going at a speed slower
than your increased set speed, ACC with Low Speed
Follow may not accelerate your vehicle. This is to
maintain the set interval between your vehicle and
the vehicle ahead.

When you depress the accelerator pedal and then
press down and release the

RES/+

/

SET/−

switch, the

current speed of the vehicle is set.

To increase speed

To decrease speed
