131

Gauges and Driver Information Interface

Driver Information Interface

Continued

strum

nt Pa

nel

Roll the left selector wheel until

Meter

setup

appears on the display.

Press the left selector wheel.

Language selection

appears first in the

display.

Roll the left selector wheel until

“Trip A”

reset timing

appears on the display, then

press the left selector wheel.

The display switches to the
customization setup screen, where you
can select

When fully refueled

IGN

OFF

Manually reset

, or

Back

Roll the left selector wheel and select

When fully refueled

, then press the left

selector wheel.

The

Selected

appears, then the display

returns to the customization menu
screen.

134

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time in the clock display with the power mode in ON.

Press the

MENU

button.

Select

Clock Settings

Select

Automatic Time

, then select

OFF

Select

Set Time

Select

12H

24H

to change 12 or 24 hour

clock.

Select

or .

Select

Set

to set the time.

■

Adjusting the Time

Adjusting the Clock

The clock is automatically updated through the audio
system.

You can also select and enter with the selector knob
instead of the touch panel.

Models with 7-in. Color Touchscreen

MENU

Button

Models with 7-in. Color Touchscreen

135

Clock

Adjusting the Clock

Co
ntrols

Press the

button.

Select

General Settings

Select

System

Select

Date & Time

Select

Set Date & Time

Select

Automatic Date & Time

, then

select

OFF

To adjust date:
7.

Select

Set Date

Select

or .

Select

Save

to set the date.

To adjust time:
7.

Select

Set Time

Select

or .

Select

Save

to set the time.

Adjusting the Clock

You can also adjust the clock by touching the clock
displayed on the header area of the audio/
information screen,

Clock

displayed on the home

screen, or

All Apps

1. Touch the clock on the screen.

The clock screen of the face-type appears.

2. Select

Settings

3. Select

Date & Time

4. Select

Set Date & Time

5. Select

Automatic Date & Time

, then select

OFF

6. Select

Set Date

Set Time

7. Adjusting the dates, hours and minutes by

selecting

or .

8. Select

Save

to set the time.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

How to Customize the General Settings

P. 345

You can customize the date display to

MM/DD/

YYYY

DD/MM/YYYY

YYYY/MM/DD

How to Customize the General Settings

P. 345

Models with 9-in. Color Touchscreen

136

Co
ntrols

Locking and Unlocking the Doors

Key

This vehicle comes with the following keys:

Use the keys to start and stop the engine, and
lock and unlock all the doors, tailgate, and
fuel fill door.

Key

All the keys have an immobilizer system. The
immobilizer system helps protect against vehicle
theft.

Immobilizer System

P. 156

Follow the advice below to prevent damage to the
keys:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids, dust and sand.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the remote
engine start.

Remote Engine Start

P. 420

Models with

button

Models without

button

Models with

button

* Not available on all models

137

Locking and Unlocking the Doors

Key

Co
ntrols

The built-in key can be used to unlock the
doors when the keyless remote battery
becomes weak and the power door unlock
operation is disabled.

To remove the built-in key, push the release
button and then pull out the key. To reinstall
the built-in key, push the built-in key into the
keyless remote until it clicks.

Contains a number that you will need if you
purchase a replacement key.

■

Built-in Key

Release Button

Built-in Key

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

138

Locking and Unlocking the Doors

Low Keyless Remote Signal Strength

Co
ntrols

Low Keyless Remote Signal Strength

The vehicle transmits radio waves to locate the keyless remote to start the engine,
lock and unlock

all the doors and the fuel fill door, and open the tailgate.

In the following cases, starting the engine, locking/unlocking

the doors/fuel fill

door, or opening the tailgate may be inhibited or operation may be unstable:

•

Strong radio waves are being transmitted by nearby equipment.

•

You are carrying the keyless remote together with telecommunications
equipment, laptop computers, cell phones, or wireless devices.

•

A metallic object is touching or covering the keyless remote.

Low Keyless Remote Signal Strength

Communication between the keyless remote and the
vehicle consumes the keyless remote’s battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the keyless
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

* Not available on all models

139

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the keyless remote, you can
lock/unlock the doors and fuel fill door, and
open the tailgate.
You can lock/unlock the doors, fuel fill door,
and tailgate within a radius of about 32 inches
(80 cm) of the outside door handle or tailgate
outer handle.

■

Using the Keyless Access System

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior light comes on when you unlock
the doors and tailgate.
No doors opened: The light fades out after 30
seconds.
Doors and tailgate relocked: The light goes off
immediately.

Interior Lights

P. 189

Using the Keyless Access System

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the keyless
access system, the doors and tailgate will
automatically relock.

You can lock or unlock doors using the keyless access
system only when the power mode is in VEHICLE OFF.

•

Do not leave the keyless remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the keyless remote, you
can lock/unlock the doors and tailgate while
someone else with the remote is within range.

•

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the keyless remote is within range.

* Not available on all models

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

140

Co
ntrols

■

Locking the doors and tailgate

Touch the door lock sensor on the front door
or press the lock button on the tailgate.

All the doors, fuel fill door, and tailgate
lock and the security system sets.

Some exterior lights flash once and the
beeper sounds once.

Using the Keyless Access System

•

If you grip a front door handle or touch the front
door lock sensor wearing gloves, the door sensor
may be slow to respond or may not respond by
locking/unlocking the doors.

•

After locking the door, you have up to 2 seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least 2 seconds before gripping the handle,
otherwise the door will not unlock.

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors and tailgate
with the keyless remote if it is above or below the
outside handle.

•

The keyless remote may not operate if it is too close
to the door, door glass and tailgate.

The light flash, beep, and door unlock mode settings
can be customized using the driver information
interface or audio/information screen.

Settings

P. 123

How to Customize the Vehicle Settings

P. 357

The keyless access system will not lock the vehicle
when a door is open.

Models with 7-in. Color Touchscreen

Models with 9-in. Color Touchscreen

Door Lock
Sensor

Lock Button

* Not available on all models

141

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

■

Unlocking the doors and tailgate

Grab the driver’s door handle:

The driver’s door and fuel fill door
unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

All the doors and the tailgate unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Press the tailgate outer handle:

The tailgate unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Opening/Closing the Tailgate

P. 154

Outer Handle

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

142

Co
ntrols

■

Locking the doors and tailgate (Walk
away auto lock

)

When you walk away from the vehicle with all
doors and tailgate closed while carrying the
keyless remote, the doors and tailgate will
automatically lock.
The auto lock function activates when all
doors and tailgate are closed, and the keyless
remote is within about 5 feet (1.5 m) radius of
the outside door handle or tailgate outer
handle.
Exit vehicle while carrying keyless remote and
close door(s) and tailgate.

While within about 5 feet (1.5 m) radius of
the vehicle.

The beeper sounds; the auto lock
function will be activated.

Carry the keyless remote beyond about 5
feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

Some exterior lights flash; the beeper
sounds; all doors and tailgate will then
lock.

Locking the doors and tailgate (Walk away auto lock

)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the driver information interface or audio/
information screen.
If you set the auto lock function to ON using the
driver information interface or audio/information
screen, only the remote transmitter that was used to
unlock the driver’s door prior to the setting change
can activate auto lock.

Settings

P. 123

How to Customize the Vehicle Settings

P. 357

After the auto lock function has been activated,
when you stay within the locking/unlocking
operation range, the indicator on the keyless remote
will continue to flash until the doors and tailgate are
locked.

When you stay beside the vehicle within the
operation range, the doors and tailgate will
automatically lock approximately 30 seconds after
the auto lock function activating beeper sounds.

When you open a door or tailgate after the auto lock
function activating beeper sounds, the auto lock
function will be canceled.

Models with 7-in. Color Touchscreen

Models with 9-in. Color Touchscreen

The activation range of
the auto lock function is
about 5 feet (1.5 m)

* Not available on all models

Continued

143

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

To temporarily deactivate the function:

Set the power mode to OFF.

Open the driver’s door.

Using the master door lock switch, operate
the lock as follows:
Lock



Unlock



Lock



Unlock.

The beeper sounds and the function is
deactivated.

To restore the function:

•

Set the power mode to ON.

•

Lock the vehicle without using the auto lock
function

•

With the keyless remote on you, move out
of the auto lock function operation range.

•

Open any door.

Locking the doors and tailgate (Walk away auto lock

)

Under the following circumstances, the auto-lock
function will not activate:

•

The keyless remote is inside the vehicle.

The beeper will not sound.

•

The keyless remote is taken out of its operational
range before all the doors are closed.

The beeper will sound.

The auto lock function does not operate when any of
the following conditions are met.

•

The keyless remote is inside the vehicle.

•

A door, tailgate or the hood is not closed.

•

The power mode is set to any mode other than
OFF.

•

The keyless remote is not located within a radius of
about 5 feet (1.5 m) from the vehicle when you get
out of the vehicle and close the doors and tailgate.

Auto lock function operation stop beeper

After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

•

The keyless remote is put inside the vehicle through
a window.

•

You are located too close to the vehicle.

•

The keyless remote is put inside the tailgate.

If the warning beeper sounds, check that you are
carrying the keyless remote. Then, open/close a door
and confirm the auto lock activation beeper sounds
once.

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

144

Co
ntrols

The vehicle will automatically lock after you
lock the doors in advance then close the doors
and tailgate.

Activate lock presetting after closing the
driver’s door.

Touch the door lock sensor on the driver’s
door

or press the lock button on the

remote transmitter.

Alert sounds and lock presetting is
activated.

Close all doors and the tailgate.

Some exterior lights flash and a beeper
sounds when vehicle locks.

Make sure the doors and tailgate are locked
before moving away from the vehicle.

■

Locking the doors and tailgate (lock presetting)

Locking the doors and tailgate (lock presetting)

Lock presetting will be reset if a door or the tailgate is
opened before the vehicle has locked completely.

Before locking a door, make sure that the key is not
inside the vehicle.

You can turn this function on and off.

Settings

P. 123

How to Customize the Vehicle Settings

P. 357

Models with 7-in. Color Touchscreen

Models with 9-in. Color Touchscreen

Door Lock
Sensor

* Not available on all models

Continued

145

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors and tailgate

Press the lock button.

Once:

Some exterior lights flash, all the doors,
fuel fill door, and tailgate lock, and the
security system sets.

Twice (within five seconds after the first
push):

A beeper sounds and verifies the security
system is set.

■

Unlocking the doors and tailgate

Press the unlock button.

Once:

Some exterior lights flash twice, and the
driver’s door and fuel fill door unlock.

Twice:

The remaining doors and the tailgate
unlock.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the remote
transmitter, the doors and tailgate will automatically
relock.

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

The remote transmitter will not lock the vehicle when
a door is open.

You can lock or unlock doors using the remote
transmitter only when the power mode is in VEHICLE
OFF.

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

Replacing the Remote Battery

P. 594

LED

Unlock
Button

Lock
Button
