Honda Ridgeline (2023 year). Manual in english - page 13





uu

Audio System

u

USB Ports

206

Features

On the back of the console
compartment

*

The USB ports (2.5A) are only for charging
devices.

1

USB Ports

These ports are for battery charge only. You cannot
play music even if you have connected music players
to them.

On the back of the console compartment

*

On the back of the console
compartment

* Not available on all models

207

uu

Audio System

u

Auxiliary Input Jack

Features

Auxiliary Input Jack

Use the jack to connect a standard audio device.

1.

Open the

AUX

 cover.

2.

Connect a standard audio device to the
input jack using a 1/8 inch (3.5 mm) stereo
miniplug.

u

The audio system automatically switches
to the AUX mode.

1

Auxiliary Input Jack

To switch to another mode or return to the AUX
mode, select the audio source icon.

You cannot use the auxiliary input jack if you replace
the audio system.

208

uu

Audio System

u

Audio System Theft Protection

Features

Audio System Theft Protection

The audio system is disabled when it is disconnected from the power source, such as
when the battery is disconnected or goes dead. In certain conditions, the system
may display a code entry screen. If this occurs, reactivate the audio system.

Reactivating the audio system

1.

Set the power mode to ON.

2.

Turn on the audio system.

3.

Press and hold the audio system power button for more than two seconds.

u

The audio system is reactivated when the audio control unit establishes a
connection with the vehicle control unit. If the control unit fails to recognize
the audio unit, you must go to a dealer and have the audio unit checked.

209

uu

Audio System

u

Audio Remote Controls

Continued

Features

Audio Remote Controls

Allow you to operate the audio system while driving.

SOURCE Button

Cycles through the audio modes as follows:
FM

AM

SiriusXM

®

*

USB

iPod

Pandora

®

*

Apps/Apple CarPlay/Android Auto

Bluetooth

®

 Audio

AUX

(

+



(

-

 (Volume) Buttons

Press

(

+

To increase the volume.

Press

(

-

To decrease the volume.



Buttons

When listening to the radio

Press :

To select the next preset radio station.

Press :

To select the previous preset radio station.

Press and hold

To select the next strong station.

Press and hold

To select the previous strong station.

When listening to an iPod, USB flash drive, or

Bluetooth

®

 Audio

Press :

To skip to the next song.

Press :

To go back to the beginning of the current or previous song.

When listening to a USB flash drive, or

Bluetooth

®

 Audio

Press and hold

To skip to the next folder.

Press and hold

To go back to the previous folder.

When listening to Pandora

®

*

Press :

To skip to the next song.

Press and hold

To select the next station.

Press and hold

To select the previous station.

1

Audio Remote Controls

Some modes appear only when an appropriate
device or medium is used.

Depending on the

Bluetooth

®

 device you connect,

some functions may not be available.

 Button

SOURCE

 Button

 Button

(

+

 Button

(

-

 Button

 (Menu)

Button

(

-

 Button

* Not available on all models

uu

Audio System

u

Audio Remote Controls

210

Features

Steering Wheel

 (Menu) Button

When listening to the radio

Press :

To display the menu items. You can select

Scan

Save Preset

, or

Seek

.

When listening to the SiriusXM

®

*

Press :

To display the menu items. You can select

Scan

Save Preset

Channel

, or

Category

.

When listening to a USB flash drive

Press :

To display the menu items. You can select

Scan

Repeat

, or

Random

.

When listening to an iPod

Press :

To display the menu items. You can select

Repeat

 or

Shuffle

.

When listening to a

Bluetooth

®

 Audio

Press :

To display the menu items. You can select

Pause

 or

Play

.

When listening to Pandora

®

*

Press :

To display the menu items. You can select

Bookmark

 or

Play/Pause

.

1

Audio Remote Controls

The

 button is available only when the audio

mode is FM, AM, SiriusXM

®

*

, USB, iPod, Pandora

®

*

or

Bluetooth

®

 Audio.

* Not available on all models

211

Features

Audio System Basic Operation

To use the audio system function, the power mode must be in ACCESSORY or ON.

: Select to go to the home screen.

2

Using the audio/information screen



P. 213

: Select to display any mode.

The available modes include

Sound

View

Radio Text

Music Search

, and various play

modes.

: Select to go back to the previous display.

: Select to change the audio/information

screen brightness.
Select

 once and select

(

-

 or

(

+

 to make

an adjustment.

u

Each time you select

, the mode

switches among the daytime mode,
nighttime mode, and off mode.

1

Audio System Basic Operation

Audio Menu Items

2

Station List

 P. 237, 238

2

Music Search List

 P. 248, 257

2

Scan

 P. 237, 246, 258

2

Play Mode

 P. 249, 258

 (Day/Night) Icon

 (Home) Icon

 (Menu) Icon

 (Back) Icon

212

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

Audio/Information Screen

Displays the audio status and wallpaper. From this display, you can go to various
setup options.

Using the

 button

Press the

 (display) button to change the display.

Switching the Display

Audio/Information Screen

 (Display) Button

Continued

213

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

Using the audio/information screen

Select

 to go to the home screen.

Select the following icons on the home screen.

Phone

Displays the HFL information.

2

Bluetooth

®

 HandsFreeLink

®

 P. 330

1

Using the audio/information screen

Touchscreen Operation

Use simple gestures - including touching, swiping,
and scrolling - to operate certain audio functions.

Some items may be grayed out during driving to
reduce the potential for distraction.

You can select them when the vehicle is stopped or
use voice commands.

Wearing gloves may limit or prevent touchscreen
response.

You can use the microfiber cleaning cloth included
in your owner’s kit to remove dust or fingerprints
from the touchscreen.

You can change the touchscreen sensitivity setting.

2

Customized Features

 P. 299

Home Screen

 (Home) Icon

uu

Audio System Basic Operation

u

Audio/Information Screen

214

Features

Info

Displays

Trip Computer

Voice Info

Clock/Wallpaper

 and

System/Device

Information

.

Trip Computer

:

Current Drive

 tab: Displays the current trip information.

History of Trip A

 tab: Displays information for the three previous drives. The

information is stored every time you reset Trip A.
To delete the history manually, select

Delete History

 on the

History of Trip A



tab. The confirmation message appears on the screen, then select

Yes

.

Voice Info

: Displays the all commands list.

Clock/Wallpaper

: Displays the clock and wallpaper.

System/Device Information

:

System Info

: Displays the software version of the audio system.

USB Info

: Displays the memory usage of the USB device.

Audio

Displays the current audio information.

Settings

Enters the customizing menu screen.

2

Customized Features

 P. 299

Navigation

*

Displays the navigation screen.

2

Refer to the Navigation System Manual

1

Info

When you select

Info Top

 from the customize

settings, displays

Trip Computer

 or

Clock/

Wallpaper

.

2

Customized Features

 P. 299

* Not available on all models

215

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

HondaLink

Displays the HondaLink

®

 screen.

2

HondaLink

®

 P. 261

Apple CarPlay/Android Auto

Displays the

Apple CarPlay

 or

Android Auto

 screen.

2

Apple CarPlay

 P. 269

2

Android Auto

TM

 P. 273

Truck Bed Audio

*

Displays the Truck Bed Audio System screen.

2

Truck Bed Audio System

*

 P. 277

* Not available on all models

uu

Audio System Basic Operation

u

Audio/Information Screen

216

Features

1.

Select .

2.

Select and hold an icon.

u

The screen switches to the customization
screen.

3.

Drag and drop the icon to where you want
it to be.

4.

Select

OK

.

u

The screen will return to the home
screen.

Changing the Home Screen Icon Layout

1

Changing the Home Screen Icon Layout

It is not possible to change the position of the



icon.

Continued

217

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

You can change, store, and delete the wallpaper on the audio/information screen.

Import wallpaper

You can import up to five images for wallpaper from a USB flash drive.

1.

Connect the USB flash drive to the USB
port.

2

USB Ports

 P. 205

2.

Select

Settings

.

3.

Select

Clock/Info

.

4.

Select

Clock/Wallpaper Type

, then open

the

Wallpaper

 tab.

5.

Select

Add New

.

u

The picture name is displayed on the list.

6.

Select a desired picture.

u

The preview is displayed on the left side
on the screen.

7.

Select

Start Import

 to save the data.

u

The display will return to the wallpaper
list.

Wallpaper Setup

1

Wallpaper Setup

The wallpaper you set up on

Clock/Wallpaper Type



cannot be displayed on the multi-information display.

When importing wallpaper files, the image must be
in the USB flash drive’s root directory.
Images in a folder cannot be imported.

The file name must be fewer than 255 characters.

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

The individual file size limit is 5 MB.

The maximum image size is 4,096 × 4,096 pixels. If
the image size is less than 800 × 480 pixels, the
image is displayed in the middle of the screen with
the extra area appearing in black.

If the USB flash drive does not have any pictures,
the

No files detected

 message appears.

uu

Audio System Basic Operation

u

Audio/Information Screen

218

Features

Select wallpaper

1.

Select

Settings

.

2.

Select

Clock/Info

.

3.

Select

Clock/Wallpaper Type

, then open the

Wallpaper

 tab.

u

The screen changes to the wallpaper list.

4.

Select a desired wallpaper.

u

The preview is displayed on the left side on the screen.

u

The pop-up menu appears on the screen.

5.

Select

Set

.

u

The display will return to the wallpaper list.

To view wallpaper once it is set

1.

Select .

2.

Select

Info

.

3.

Select .

4.

Select

Clock/Wallpaper

.

Delete wallpaper

1.

Select

Settings

.

2.

Select

Clock/Info

.

3.

Select

Clock/Wallpaper Type

, then open the

Wallpaper

 tab.

u

The screen changes to the wallpaper list.

4.

Select a wallpaper that you want to delete.

u

The preview is displayed on the left side on the screen.

u

The pop-up menu appears on the screen.

5.

Select

Delete

.

u

A confirmation message appears on the screen.

6.

Select

Yes

 to delete completely.

u

The display will return to the wallpaper list.

1

Wallpaper Setup

From the pop-up menu, select

Preview

 to see a

preview at full-size screen.

To go back to the previous screen, select

OK

, or

select .

When the file size is large, it takes a while to be
previewed.

To delete all wallpapers you add, select

Delete All

then

Yes

.

Continued

219

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

To move to the next screen

Selecting   or  , or swiping the screen left or right changes to the next screen.

Home Screen

1

Home Screen

The home screen has 5 pages (fixed). You cannot add
any more pages.

Swipe

 Icon

 Icon

Current page position

uu

Audio System Basic Operation

u

Audio/Information Screen

220

Features

To use apps or widgets

1.

Select .

2.

Select .

u

The

Apps

 screen appears.

3.

Select the app or widget you want to use.

Preinstalled app list:

Browser

: Displays the web browser utilized

by smartphone and Wi-Fi connection.

Calculator

: Displays Calculator.

Downloads

: Displays the data downloaded

from the web browser and so on.

Install USB

: Check with a Honda dealer for

apps that are available for installation.

Search

: Displays various retrieval screens.

Settings

: Displays the Android setting

screen.

1

To use apps or widgets

Select and hold a selected app or widget to add that
app’s or widget’s shortcut on the home screen.

Pre-installed apps may not start up normally. If this
occurs, you need to reset the system.

2

Defaulting All the Settings

 P. 323

If you perform

Factory Data Reset

, it may reset all

the settings to their factory default.

2

Defaulting All the Settings

 P. 323

In case those apps still do not startup normally even
after

Factory Data Reset

, contact an authorized

Honda dealer.

There is a possibility that a browser is shut down in
the situation of the use. In that situation, the screen
will return to before the browser startup.

Do not install apps other than those confirmed by a
Honda dealer. Installation of unauthorized apps may
introduce data corruption risks to your vehicle’s
information and your privacy.

You can delete user installed apps by the following
procedure.
1. Select .
2. Select

Settings

.

3. Select

System

.

4. Select the

Others

 tab.

5. Select

Detail Information

.

6. Select an app that you want to delete.
7. Select

Delete

.

Pre-installed apps cannot be deleted.

 (APPS)

Icon

221

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

To add app or widget icons on the home screen

App or widget icons can be added on the home screen.

1.

Select .

2.

Select .

3.

Select and hold empty space on the home
screen.

u

The pop-up menu appears on the screen.

4.

Select

Add App

 or

Add Widget

.

u

The

Apps

/

Widgets

 screen appears.

Select and hold.















Content      ..     11      12      13      14     ..
