Interior/Exterior Convenience Items

Other Interior Convenience Items

190

Co
ntrols

The seat heaters can be used when the power
mode is in ON.

There is no heater in the rear center seating
position.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

■

Rear Seat Heaters

Rear Seat Heaters

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

191

Interior/Exterior Convenience Items

In-Bed Convenience Items

Continued

Co
ntrols

In-Bed Convenience Items

Turn the knobs to the left to open the lid.

To use the AC power outlet, the power mode must be in ACCESSORY or ON.

Turn the knobs to the left to open the lid.

In-Bed Box

P. 191

Open the cover and plug in the appliance
slightly. Turn the plug 90° clockwise, then
push it in all the way.

■

In-Bed Box

Knobs

■

AC Power Outlet

AC Power Outlet

Do not use the AC power outlet for electrical
appliances that require high initial peak wattage,
such as cathode-ray tube type televisions,
refrigerators, electric pumps, etc. It is not suitable for
devices that process precise data, such as medical
equipment, and that require an extremely stable
power supply, such as microcomputer-controlled
electric blankets, touch sensor lamps, etc.

The AC power outlet is designed to supply power for
up to 115 volt appliances that are rated 400 watts or
less.

Continued use of any electrical appliance/device
exceeding these ratings may result in damage to the
appliance/device.

When the AC power outlet is not in use, close the
cover to prevent any small foreign objects from
getting into the AC power outlet.

* Not available on all models

Interior/Exterior Convenience Items

In-Bed Convenience Items

192

Co
ntrols

■

ON and OFF

Press the AC power outlet button to turn the
system on and off.

The indicator in the button comes on
when the system is on.

400W

(Amber) mode is:

•

When the engine running and the
transmission in

(

150W

(Green) mode is:

•

When the power mode is in ACCESSORY or
ON.

•

When the engine running and the
transmission out of

(

•

When the truck bed audio system is
activated.

AC Power Outlet

The protection circuit may be activated to cut the
power supply if any of the following conditions apply:

•

The engine is started when the power outlet switch
on.

•

An electrical appliance exceeding the maximum
capacity is used.

•

The total power consumed by the electrical
features (head lights, air conditioning, etc.),
including the truck bed audio, has exceeded the
maximum vehicle wattage capacity for a prolonged
period of time.

Indicator

* Not available on all models

Continued

193

Interior/Exterior Convenience Items

In-Bed Convenience Items

Co
ntrols

The bed lights can be turned on or off by
pressing the button when the transmission is
in

(

The indicator in the instrument panel
comes on when the lights are on.

The tie-down anchors on the pickup bed can
be used to install a net for securing items.

■

Bed Lights

Bed Lights

The bed lights come on when you swing open the
tailgate or open the trunk.

If you set the power mode to ACCESSORY or
VEHICLE OFF and leave the bed lights on, they will
shut off after 30 minutes.

■

Tie-down Anchors

Anchors

194

Interior/Exterior Convenience Items

In-Bed Convenience Items

Co
ntrols

There are three hooks for plastic grocery bags
at the back of the trunk. They are designed to
hold light items. Heavy objects may damage
the hooks.

■

Cargo Hooks

Hooks

195

Continued

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the engine is running.

Press the

AUTO

button.

Adjust the interior temperature using the driver’s side or passenger’s side
temperature control switch.

Press the

(

ON/OFF

) button to cancel.

Using Automatic Climate Control

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.
The

AUTO

indicator will go off, but functions

unrelated to the button that was pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may operate at low speed for a while after the

AUTO

button has been pressed.

During idle-stops, the climate control system may
have reduced cooling performance.
To return it back to the original condition, press the
Auto Idle Stop system

OFF

button to cancel idle-stop.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit,

is displayed.

Pressing the

(

ON/OFF

) button switches the

climate control system between on and off. When
turned on, the system returns to your last selection.

While ECON mode is active, the climate control
system may have reduced cooling performance.

Floor and
windshield
defroster vents

Floor vents

Dashboard and floor,
and back of the
center console vents

Dashboard and
back of the center
console vents

AUTO

Button

Driver’s Side
Temperature
Control Switch

(Recirculation) Button

Fan Control Button

A/C

(Air Conditioning)

Button

Passenger’s Side
Temperature Control
Switch

(Windshield Defroster)

Button

SYNC

(Synchronized) Button

(

ON/OFF

) Button

MODE

Button

Climate Control System

Using Automatic Climate Control

196

Co
ntrols

■

Switching between the recirculation and fresh air modes

Press the

button and switch the mode depending on environmental conditions.

Recirculation Mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh Air Mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Pressing the

button turns the air

conditioner system on and automatically
switches the system to fresh air mode.

Press the

button again to turn off, the

system returns to the previous settings.

■

Defrosting the Windshield and Windows

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If you press the

button during Auto Idle Stop, the

engine restarts automatically.

Continued

197

Climate Control System

Using Automatic Climate Control

Co
ntrols

■

To rapidly defrost the windows

Press the

button.

Press the

button.

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode. If you keep the system in recirculation mode,
the windows may fog up from humidity. This
impedes visibility.

Climate Control System

Using Automatic Climate Control

198

Co
ntrols

You can set the temperature synchronously for the driver side, front passenger side
and rear seats in synchronized mode.

Press the

SYNC

button.

The system will switch to synchronized mode.

Adjust the temperature using driver’s side temperature control switch.

Press the

SYNC

button or adjust the interior temperature using the passenger’s side

temperature control switch to return to synchronized mode off.

■

Synchronized Mode

Synchronized Mode

When you press the

button, the system changes

to synchronized mode.

When the system is in synchronized mode off, the
temperature for the driver, front passenger, and rear
seats can be set separately.

199

Climate Control System

Rear Climate Control System

Continued

Co
ntrols

Rear Climate Control System

Use the system when the engine is running and the climate control system is
operating.

Press the

REAR

(

Rear ON/OFF

) button.

Press the

RR SETTINGS

button.

The system adjusts the rear climate control system.

To turn off the rear climate control system, press the

REAR

(

Rear ON/OFF

)

button.

■

Using the Rear Climate Control System From the Front Panel

Rear Climate Control System

LOCK

appears on the rear control panel while the

rear lock is on.

If the rear lock is on while in SYNC mode, the rear
control panel is disabled.

LOCK SYNC

appears on the

rear control panel.

Models with REAR LOCK button

Using the Rear Climate Control System From the Front Panel

Press the

REAR LOCK

button to turn the rear lock

mode on and off.
While the rear lock mode is on, the rear control panel
is disabled.

REAR LOCK

appears on the display.

Models with REAR LOCK button

REAR LOCK

Button

(

Rear ON/OFF

) Button

RR SETTINGS

Button

Climate Control System

Rear Climate Control System

200

Co
ntrols

Use the system when the engine is running and the climate control system is
operating.

Press the

(Rear

ON/OFF

) button.

Press the Rear

AUTO

button.

Adjust the interior temperature using the rear temperature control button.

To turn off the rear climate control system, press the

(Rear

ON/OFF

) button.

■

Using the Rear Climate Control System From the Rear Panel

Using the Rear Climate Control System From the Rear Panel

When the

REAR LOCK

button on the front control

panel is off, the temperature of the rear passenger
compartment can be controlled independently.

Rear floor
vents

Center console
vents and floor
vents

Center console
vents

(Rear Fan
Control) Buttons

(Rear

ON/OFF

) Button

Rear Temperature
Control Buttons

Rear

AUTO

Button

* Not available on all models

201

Climate Control System

Automatic Climate Control Sensors

Co
ntrols

Automatic Climate Control Sensors

The automatic climate control system is
equipped with sensors. Do not cover or spill
any liquid on them.

Sensor

202

This page intentionally left blank.

203

Features

This chapter describes how to operate technology features.

Audio System

About Your Audio System................ 204
USB Ports ......................................... 205
Auxiliary Input Jack .......................... 207
Audio System Theft Protection ......... 208
Audio Remote Controls.................... 209

Audio System Basic Operation

........ 211

Audio/Information Screen ................ 212
Adjusting the Sound ........................ 229
Display Setup ................................... 230
Voice Control Operation .................. 232
Playing AM/FM Radio ....................... 236
Playing SiriusXM

Radio

................. 239

Playing an iPod ................................ 247

Song By Voice

(SBV)...................... 250

Playing Pandora

............................ 254

Playing a USB Flash Drive ................. 256
Playing

Bluetooth

Audio................. 259

HondaLink

..................................... 261

Wi-Fi Connection ............................. 266
Siri Eyes Free .................................... 268
Apple CarPlay .................................. 269
Android Auto

................................ 273

Truck Bed Audio System

................ 277

Models with navigation system

Audio Error Messages

...................... 278

General Information on the Audio

System

............................................. 281

Customized Features

........................ 299

HomeLink

Universal Transceiver

* Not available on all models

204

Features

Audio System

About Your Audio System

The audio system features AM/FM radio and SiriusXM

Radio

service. It can also

play WMA/MP3/AAC files, USB flash drives, iPod, iPhone, and

Bluetooth

devices.

You can operate the audio system from the icons and knob on the panel, the remote
controls on the steering wheel, or the icons on the touchscreen interface.

About Your Audio System

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

SiriusXM

Radio

is available on a subscription basis

only. For more information on SiriusXM

Radio

contact a dealer.

General Information on the Audio System

P. 281

SiriusXM

Radio

is available in the United States and

Canada, except Hawaii, Alaska, and Puerto Rico.

SiriusXM

is a registered trademark of SiriusXM

Radio, Inc.

Remote Controls

iPod

USB Flash

Drive

* Not available on all models

205

Audio System

USB Ports

Continued

Features

USB Ports

■

On the front console compartment

The USB port (1.5A) is for charging devices,
playing audio files and connecting compatible
phones with Apple CarPlay or Android Auto.

To prevent any potential issues, be sure
to use an Apple MFi Certified Lightning
Connector for Apple CarPlay, and for
Android Auto, the USB cables should be
certified by USB-IF to be compliant with
USB 2.0 Standard.

■

In the console compartment

The USB port (1.0A) is for playing audio files
on a USB flash drive, connecting a cellular
phone, and charging devices.

USB Ports

•

Do not leave the iPod or USB flash drive in the
vehicle. Direct sunlight and high temperatures may
damage it.

•

We recommend that you use a USB cable if you are
attaching a USB flash drive to the USB port.

•

Do not connect the iPod or USB flash drive using a
hub.

•

Do not use a device such as a card reader or hard disk
drive, as the device or your files may be damaged.

•

We recommend backing up your data before using
the device in your vehicle.

•

Displayed messages may vary depending on the
device model and software version.

The USB port can supply up to 1.5A/2.5A of power. It
does not output 1.5A/2.5A unless the device
requests.
For amperage details, read the operating manual of
the device that needs to be charged.

Under certain conditions, a device connected to the
port may generate noise to the radio station you are
listening to.

USB charge

On the front console compartment

In the console compartment

Content .. 10 11 12 13 ..
