Continued

205

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Cargo area

Open the cover to use it.

The AC power outlet can be used when the engine is running.

Open the cover to use it. Plug in the appliance
slightly, turn it 90° clockwise, then push it all
the way.

■

AC Power Outlet

*

1

AC Power Outlet

*

NOTICE

Do not use the AC power outlet for electric
appliances that require high initial peak wattage,
such as cathode-ray tube type televisions,
refrigerators, electric pumps, etc. It is not suitable for
devices that process precise data, such as medical
equipment, and that require an extremely stable
power supply, such as microcomputer-controlled
electric blankets, touch sensor lamps, etc.

The AC power outlet is designed to supply power for
up to 115 volt appliances that are rated 150 watts or
less.

Continued use of any electric appliance/device
exceeding these ratings may result in damage to the
appliance/device.

When the AC power outlet is not in use, close the
cover to prevent any small foreign objects from
getting into the AC power outlet.

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

206

Co
ntrols

To use the wireless charger, the power mode must be in ACCESSORY or ON.
Charge a compatible device on the area indicated by the

 mark as follows:

1.

Place the device you want to charge on the
charging area.

u

The system will automatically start
charging the device, and the green
indicator light will come on.

u

Make sure that the device is compatible
with the system and placed with the
chargeable side in the center of the
charging area.

2.

When charging is completed, the green
indicator light will go off.

u

If the device is not located on the charge
area correctly, the green indicator light
will blink.

■

Wireless Charger

*

1

Wireless Charger

*

FCC statement

This product complies with the appropriate
requirements or the required standards of FCC
(Federal Communication Commission), described
below:
This device complies with Part 18 of the FCC rules.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used
per the instructions, may cause harmful interference
to radio communications.

In order to use safely:

•

Remove any metal objects from the charge pad
before charging a device.

•

Do not open the charger case.

•

Do not use the charger if it malfunctions.

Contact your dealer.

Green
Indicator

Charging Area

* Not available on all models

Continued

207

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

When charging does not start

Perform one of the solutions in the following table.

Indicator

Cause

Solution

Slow Blink

There is an obstacle(s) between
the charging area and the
device.

Remove the
obstacle(s).

The device is not within the
charging area.

Move the device to the
center of the charging
area where

 is

located.

Fast Blink

The wireless charger is faulty.

Turn the vehicle off
and back on. If the
indicator still blinks,
contact a dealer.

1

Wireless Charger

*

Using the audio/information screen, you can disable
the wireless charger function.

2

Customized Features

 P. 385

3

CAUTION

Metal objects between the charge pad
and the device to be charged will get
hot and can burn you.

•

Always remove foreign objects from
the charge pad before charging the
device.

•

Be sure the surface is clear of dust and
other debris before charging.

•

Do not spill liquids (i. e. water, drinks,
etc.) on the charger and the device.

•

Do not use oil, grease, alcohol,
benzine or thinner for cleaning the
charge pad.

•

Do not cover the system with towels,
clothing, or other objects while
charging etc.

•

Avoid spraying aerosols which may
come in contact with the charge pad
surface.

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

208

Co
ntrols

1

Wireless Charger

*

This system consumes a lot of power. Do not use the
system for a long time when the engine is not
running. This may weaken the battery, making it
difficult to start the engine.

When using the wireless charger, check the user’s
manual that came with the compatible device you
want to charge.

NOTICE

Do not place any magnetic recording media or
precision machines within the charging area while
charging.
The data on your cards such as credit cards can be
lost because of the magnetic effect. Also precision
machines such as watches can be affected.

“Qi” and

 marks are the registered trademarks

owned by Wireless Power Consortium (WPC).

In the following cases, charging may stop or not start:

•

The device is already fully charged.

•

The temperature of the device is extremely high
while charging.

•

You are at a place that emits strong
electromagnetic waves or noises, such as a TV
station, electric power plant, or gas station.

A device may not charge if the size or shape of its
chargeable side is not appropriate for use with the
charging area.

* Not available on all models

Continued

209

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

There is a coat hook on the rear grab handle
of both sides. Pull it down to use it.

1

Wireless Charger

*

Not all devices are compatible with the system.

During the charging phase, it is normal for the
charging area and device to heat up.

Charging may be briefly interrupted when:

•

All the doors and the tailgate are closed
- to avoid interference with the proper functioning
of the keyless access system.

•

The position of the device is altered.

Do not charge more than one device at a time on a
charging area.

■

Coat Hooks

1

Coat Hooks

The coat hooks are not designed for large or heavy
items.

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

210

Co
ntrols

To open the sunglasses holder, push and
release the indent. To close, push it again until
it latches.

You can store eyeglasses and other small
items in this holder.

■

Conversation mirror

The sunglasses holder comes with a mirror.
Open the sunglasses holder fully, then push it
back to the first detent.

You can use the mirror to view the rear seats.

■

Sunglasses Holder

1

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Push

Continued

211

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Pull the tab and roll up the sunshade all the
way. Use the hooks to hang it.

■

Integrated Sunshades

*

1

Integrated Sunshades

*

Use the sunshades only when the windows are fully
closed. Using the shade while a window is open can
unhook and blow off the shade, hitting and hurting
anyone sitting near the window.

Tab

Hook

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

212

Co
ntrols

The seat heaters can be used when the power
mode is in ON.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

When the power mode is turned on after it is
turned off, the previous setting is maintained.

■

Front Seat Heaters

*

1

Front Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

After a certain period of time, the strength setting for
the seat heaters will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

Continued

213

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The seat heaters or ventilators can be used
when the power mode is in ON.
The seat heaters: Use them to warm up the
seat.
The seat ventilators: Use them when you want
to ventilate the surface of the seats. When
used with the air conditioning, the surface of
the seats will become easier to cool.

Press the seat heater or the seat ventilator
button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator
on)
Four times - The OFF setting (no indicators on)

When the power mode is turned on after it is
turned off, the previous setting is maintained.

■

Front Seat Heaters/Ventilators

*

1

Front Seat Heaters/Ventilators

*

Do not use the seat heaters and the seat ventilation
even in LO when the engine is off. Under such
conditions, the battery may be weakened, making
the engine difficult to start.

After a certain period of time, the strength setting for
the seat heaters will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

214

Co
ntrols

The power mode must be in ON to use the
seat heaters.

There is no heater in the rear center seating
position.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

■

Second Row Outer Seat Heaters

*

1

Second Row Outer Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

After a certain period of time, the strength setting for
the rear seat heaters will automatically be reduced by
one level at a time until the rear seat heater shuts off.
The elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

Continued

215

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
heated steering wheel.

Press the button on the right side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you start the engine, even if you turned it
on the last time you drove the vehicle.

■

Heated Steering Wheel

*

1

Heated Steering Wheel

*

Do not use the heated steering wheel continuously
when the engine is off. Under such conditions, the
battery may be weakened, making the engine
difficult to start.

Indicator

Heated Steering Wheel Button

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

216

Co
ntrols

The tie-down anchors on the cargo area floor
can be used to install a net for securing items.

The cargo hooks on both sides of the cargo
area can be used to hang a light items.

■

Tie-down Anchors

Anchor

Anchor

■

Cargo Hooks

1

Cargo Hooks

Heavy objects may damage the hook. Make sure any
items put on this hook weigh less than 6.6 lbs (3 kg).

Distribute cargo evenly on the floor of the cargo area,
placing the heaviest items on the bottom and as far
forward as possible.

217

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Pull the handle to open the cargo floor lid.

■

Storing items on the lid at the bottom

This is convenient when storing a tall item.

1.

Pull the handle and open the lid.

2.

Pull the lid towards you until it disengages
from the support rods.

3.

Push the far end of the lid down to the
bottom of the under-floor storage area,
then lower the other end.

■

Under-floor Storage Area

1

Storing items on the lid at the bottom

The lid can be flipped over and placed in either upper
or lower position. This allows for storage of dirty
items, or items that may damage the carpet lining of
the lid.

218

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that will as quickly as
possible, raise or lower the interior temperature to your preference.

Use the system when the engine is running.

1.

Press the

AUTO

 button.

2.

Adjust the interior temperature using the driver’s side or passenger’s side
temperature control switch.

3.

Press the



ON/OFF

 button to cancel.

1

Using Automatic Climate Control

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.
The

AUTO

 indicator will go off, but functions

unrelated to the button that was pressed will be
controlled automatically.

During idle-stops, air-conditioning is suspended, and
only the blower remains active.
If you do not want air-conditioning suspended, press
the Auto Idle Stop

OFF

 button to cancel idle-stop.

To prevent cold air from blowing in from outside, the
fan may operate at low speed for a while after the

AUTO

 button has been pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit,

Lo

 or

Hi

 is displayed.

Floor and
defroster
vents

Floor vents

Dashboard and floor,
and back of the
center console vents

Dashboard and
back of the center
console vents

AUTO

 Button

Driver’s Side
Temperature
Control Switch

 (Recirculation) Button

Fan Control Button

A/C

 (Air Conditioning)

Button

Passenger’s Side
Temperature Control
Switch

 (On/Off) Button

 (Windshield Defroster)

Button

SYNC

 (Synchronization) Button

Continued

219

uu

Climate Control System

u

Using Automatic Climate Control

Co
ntrols

■

Switching between the recirculation and fresh air modes

Press the

 button and switch the mode depending on environmental conditions.

Recirculation Mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh Air Mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Pressing the

 button turns the air

conditioner system on and automatically
switches the system to fresh air mode.

Press the

 button again to turn off, the

system returns to the previous settings.

■

Defrosting the Windshield and Windows

1

Using Automatic Climate Control

Pressing the



ON/OFF

 button switches the

climate control system between on and off. When
turned on, the system returns to your last selection.

1

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If you press the

 button during Auto Idle Stop, the

engine restarts automatically.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

uu

Climate Control System

u

Using Automatic Climate Control

220

Co
ntrols

■

To rapidly defrost the windows

1.

Press the

 button.

2.

Press the

 button.

1

To rapidly defrost the windows

After defrosting or defogging the windows, switch
over to fresh air mode. If you keep the system in
recirculation mode, the windows may fog up from
humidity. This impedes visibility.
