189

uu

Adjusting the Seats

u

Head Restraints

Co
ntrols

To reinstall a head restraint:

Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button(s). Pull up on the restraint to make sure it is locked
in position.

A passenger in the third row seating position
should put the head restraint in the upright
position before the vehicle begins moving.

To fold down the head restraint:

Pull the strap.

To put the head restraint back in the
upright position:

Pull up the head restraint and push rearward
until it latches.

■

Folding Down the Third Row Outer Head Restraint

Strap

190

uu

Adjusting the Seats

u

Maintain a Proper Sitting Position

Co
ntrols

Maintain a Proper Sitting Position

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor until the vehicle is safely parked and the engine is
off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.

In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

1

Maintain a Proper Sitting Position

3

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

191

uu

Adjusting the Seats

u

Rear Seats

Continued

Co
ntrols

Rear Seats

Pressing the button on the seat-back, or seat
cushion tilts the second row outer seat's seat-
back forward.

u

The whole seat slides forward.

Pulling the lever on the seat side, and the
second row outer seat’s seat-back forward.

u

The whole seat slides forward.

Pulling up on the strap also tilts the seat-back
forward.

■

Third Row Seat Access

1

Third Row Seat Access

The button is disabled when the vehicle is moving.

When you enter the third row seat, be careful not to
trip over the second row seat belt.

Models with button type

Models with lever type

Strap

All models

uu

Adjusting the Seats

u

Rear Seats

192

Co
ntrols

Separately fold down the left and right halves of the second row seat to make room
for cargo.

1.

Store the center seat belt first. Insert the
latch plate into the slot on the side of the
anchor buckle.

2.

Retract the seat belt into the holder on the
ceiling.

2

Seat Belt with Detachable Anchor

 P. 42

3.

Lower the center head restraint to its lowest
position. Put the armrest back into the seat-
back.

4.

Pull up on the seat-back angle adjustment
lever.

To return the seat to the original position, pull
up the seat-back in the upright position.

■

Folding Down the Second Row Seat

1

Folding Down the Second Row Seat

Make sure that the folded seat-back does not press
against the front passenger seat, as this can cause the
weight sensors in the front passenger seat to work
improperly.

2

Passenger Airbag Off Indicator

 P. 57

The front seats must be far enough forward so they
do not interfere with the second row seats as they
fold down.

To lock the seat-back upright, push it backwards until
it locks.

Make sure the seat-back, head restraints and seat
cushion are securely latched back into place before
driving.

Make sure the center shoulder belt is re-positioned in
the holding slot.

Models with bench seat

Models with bench seat

Lever

All models

193

uu

Adjusting the Seats

u

Rear Seats

Co
ntrols

Separately fold down the left and right halves of the third row seat to make room
for cargo.

■

To fold down the seat

1.

Pull the strap on the seat-back fully.

u

The head restraint tilts downward.

2.

Push the seat-back forward while pulling
the strap.

■

To return the seat to the original position

1.

Pull the seat-back up with the strap pulled.

2.

Pull the head restraint up to its original position.

■

Folding Down the Third Row Seat

1

Folding Down the Third Row Seat

Make sure all items in the cargo area or items
extending to the third row seats are properly
secured. Loose items can fly forward if you have
to brake hard.

Strap

1

To return the seat to the original position

Make sure the seat-back and head restraints are
securely latched back into place before driving.

194

uu

Adjusting the Seats

u

Armrest

Co
ntrols

Armrest

Pull down the armrest.

Pull the armrest all the way down, then pull it
up to the desired angle.

■

Using the Front Seat Armrest

Models with adjustable armrest

195

uu

Adjusting the Seats

u

Armrest

Co
ntrols

Pull down the armrest.

Pull down the armrest of the center backrest.

■

Using the Second Row Seat Armrest

Models with captain seat

Models with bench seat

196

Co
ntrols

Interior Lights/Interior Convenience Items

Interior Lights

■

ON

The interior lights come on regardless of
whether the tailgate and doors are open or
closed.

■

Door activated

The interior lights come on in the following
situations:

•

When the tailgate or any doors are opened.

•

You unlock the driver’s door.

•

When the power mode is set to VEHICLE
OFF.

■

OFF

The interior lights remain off regardless of
whether the tailgate or the doors are open or
closed.

■

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.

The lights go off after about 30 seconds in the
following situations:

•

When you unlock the driver’s door but do not open
it.

•

When you set the power mode to VEHICLE OFF but
do not open a door.

You can change the interior lights dimming time.

2

Customized Features

 P. 385

The interior lights go off immediately in the following
situations:

•

When you lock the driver’s door.

•

When you close the driver’s door in ACCESSORY
mode.

•

When you set the power mode to ON.

If you leave any of the tailgate or doors open in
VEHICLE OFF mode, the interior lights go off after
about 15 minutes.

To avoid draining the battery, do not leave the
interior light on for an extended length of time when
the engine or power system is off.

Models without panoramic roof

Door Activated Position

Off

On

Models with panoramic roof

Door Activated Position

Off

On

Continued

197

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

Co
ntrols

■

Front

The map lights can be turned on and off by
pressing the lenses or buttons.

■

Map Lights

1

Map Lights

When the front interior light switch is in the door
activated position and any door is open, the map
light will not go off when you press the lens.

Models without panoramic roof

Models with panoramic roof

Models without panoramic roof

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

198

Co
ntrols

■

Second and third row

The map lights can be turned on and off by
pressing the lenses when the front interior
light switch is in the door activated position.

1

Map Lights

When the front interior light switch is in the door
activated position and any door is open, the rear map
light will not go off when you press the lens.

Models without panoramic roof

Models with panoramic roof

199

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

Co
ntrols

■

ON

The light comes on regardless of whether the
tailgate is open or closed.

■

Tailgate activated

The light comes on when you open the
tailgate, and goes off when closed.

■

OFF

The light stays off with or without opening the
tailgate.

■

Cargo Area Light

Off

On

Tailgate Activated Position

200

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Interior Convenience Items

Pull the lever to open the glove box. You can
lock the glove box with the built-in key.

To open the console compartment, press the
button to unlock the lid, and then slide it
rearward.

■

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Glove Box

To Lock

■

Console Compartment

Button

201

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Co
ntrols

■

Console Tray

Slide the tray when you use the console
compartment.

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

202

Co
ntrols

■

Front seat beverage holders

Are located in the console between the front
seats.

■

Door side beverage holders

Are located on the both of front and rear door
side pockets.

■

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids damage the upholstery, carpeting, and
electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

Front

Rear

203

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Co
ntrols

■

Second row bench seat beverage
holders

*

Fold the armrest down to use the rear seat
beverage holders.

■

Second row captain seat beverage
holders

*

■

Third row seat beverage holders

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

204

Co
ntrols

The accessory power sockets can be used when the power mode is in ACCESSORY
or ON.

■

Console panel

Open the lid and the cover to use it.

■

Console compartment

Pull the handle and open the cover to use it.

■

Accessory Power Sockets

1

Accessory Power Sockets

Do not insert an automotive type cigarette lighter
element.
This can overheat the power socket.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent battery drain, only use the power socket
with the engine running.

When the accessory power socket is not in use, close
the cover to prevent any small foreign objects from
getting into the power socket.
