Honda Pilot (2022 year). Manual in english - page 10

157

Co
ntrols

Panoramic Roof

Opening/Closing the Sunshade

You can operate the sunshade when the power mode is in ON. Use the switch in the
front of the ceiling to open and close the sunshade.

■

Automatic operation

To open:

Pull the switch back firmly.

To close:

Push the switch forward firmly.

The sunshade automatically opens or closes all
the way. To stop the sunshade midway, touch
the switch briefly.

■

Manual operation

To open:

Pull the switch back lightly, and

hold it until the desired position is reached.

To close:

Push the switch forward lightly, and

hold it until the desired position is reached.

■

Using the Sunshade Switch

Opening/Closing the Sunshade

The sunshade can be operated for up to 10 minutes
after you set the power mode to OFF.
Opening either front door cancels this function.

When resistance is detected, the auto reverse
function causes the sunshade to change directions,
then stop. Auto reverse stops sensing when the
sunshade is almost closed to ensure that it fully
closes.

The sunshade can be opened or closed to adjust the
amount of light that enters the cabin.

WARNING

Opening or closing the sunshade on
someone’s hands or fingers can cause
serious injury.

Make sure all hands and fingers are clear of
the sunshade before opening or closing it.

Open

* Not available on all models

158

Co
ntrols

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

*1: Canadian models

■

Changing the Power Mode

ENGINE START/STOP Button

ENGINE START/STOP

Button Operating Range

You can start the engine when the keyless remote is
inside the vehicle.

If the battery of the keyless remote is getting low, the
engine may not start when you push the

ENGINE

START/STOP

button. If the engine does not start,

refer to the following link.

If the Keyless Remote Battery is Weak

P. 622

The engine may also run if the keyless remote is close
to the door or window, even if it is outside the
vehicle.

ON mode:
The

ENGINE START/STOP

button is on (in red), if the

engine is running.

If the power mode does not change from VEHICLE
OFF to ACCESSORY, press the

ENGINE START/STOP

button while moving the steering wheel left and
right. The steering wheel will unlock, allowing the
mode to change.

Operating Range

Canadian models

VEHICLE OFF (LOCK)

The button is off.
The steering wheel is locked

The power to all electrical
components is turned off.

Press the button.

Without pressing
the brake pedal

ACCESSORY

The button blinks (in red).
Operate the audio system and
other accessories in this position.

The button blinks (in red).
All electrical components can be
used.

Continued

159

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

Co
ntrols

If you leave the vehicle for 30 to 60 minutes with the transmission in

(

and the

power mode in ACCESSORY, the vehicle automatically goes into the mode similar to
VEHICLE OFF (LOCK) to avoid draining the battery.

When in this mode:
The steering wheel does not lock.
You cannot lock or unlock doors with the remote transmitter or the keyless access
system.

Press the

ENGINE START/STOP

button to switch the mode to VEHICLE OFF (LOCK).

If you open the driver’s door when the power mode is set to ACCESSORY, a warning
beeper sounds.

■

Automatic Power Off

■

Power Mode Reminder

ENGINE START/STOP Button

Do not leave the power mode in ACCESSORY or ON
when you get out.

Canadian models

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

160

Co
ntrols

When the power mode is set to any mode
other than OFF and you remove the keyless
remote from the vehicle and shut the door, an
alarm will sound. If the alarm continues to
sound, place the keyless remote in another
location.

■

When the power mode is in
ACCESSORY

The alarm will sound from outside the vehicle.

■

When the power mode is in ON

An alarm will sound both inside and outside
the vehicle. In addition, a warning indicator
will appear on the instrument panel.

■

Keyless Remote Reminder

Keyless Remote Reminder

When the keyless remote is within the system’s
operational range, and the driver’s door is closed, the
warning function cancels.

If the keyless remote is taken out of the vehicle after
the engine has been started, you can no longer
change the

ENGINE START/STOP

button mode or

restart the engine. Always make sure if the remote is
in your vehicle when you operate the

ENGINE

START/STOP

button.

Removing the keyless remote from the vehicle
through a window does not activate the warning
buzzer.

Do not put the keyless remote on the dashboard or in
the glove box. It may cause the warning buzzer to go
off. Under some other conditions that can prevent
the vehicle from locating the remote, the warning
buzzer may also go off even if the remote is within
the system’s operational range.

161

Operating the Switches Around the Steering Wheel

Turn Signals

Co
ntrols

Turn Signals

The turn signals can be used when the power
mode is in ON.

■

One-touch turn signal

When you lightly push up or down and release
the turn signal lever, the exterior turn signals
and turn signal indicator blink three times.
This feature can be used when signaling for a
lane change.

Right Turn

Left Turn

162

Operating the Switches Around the Steering Wheel

Light Switches

Co
ntrols

Light Switches

Rotating the light switch turns the lights on
and off, regardless of the power mode
setting.

■

High beams

Push the lever forward until you hear a click.

■

Low beams

When in high beams, pull the lever back to
return to low beams.

■

Flashing the high beams

Pull the lever back, and release it.

■

Lights off

Turn the lever to OFF either when:

•

The transmission is in

(

•

The parking brake is applied.

To turn the lights on again, turn the lever to

OFF

to cancel the lights off mode. Even if you

do not cancel the lights off mode, the lights
come on automatically when:

•

The transmission is taken out of

(

and the

parking brake is released.

•

The vehicle starts to move.

■

Manual Operation

Light Switches

If you leave the power mode in VEHICLE OFF while
the lights are on, a chime sounds when the driver’s
door is opened.

When the lights are on, the lights on indicator in the
instrument panel will be on.

Lights On Indicator

P. 86

Do not leave the lights on when the engine is off
because it will cause the battery to discharge.

If you sense that the level of the headlights is
abnormal, have your vehicle inspected by a dealer.

Your vehicle is equipped with the automatic
headlight adjusting system that automatically adjusts
the vertical angle of the high/low beam headlights. If
you find a significant change in the vertical angle of
the headlights, there may be a problem with the
system. Have your vehicle checked by a dealer.

Models without automatic headlight adjusting system

Models with automatic headlight adjusting system

High Beams

Flashing the high beams

Low Beams

Turns on parking, side marker,
tail, and rear license plate lights

Turns on headlights, parking,
side marker, tail, and rear
license plate lights

U.S. models

Canadian models

High Beams

Flashing the high beams

Low Beams

Canadian models

Continued

163

Operating the Switches Around the Steering Wheel

Light Switches

Co
ntrols

Automatic lighting control can be used when
the power mode is in ON.

When the light switch is in

AUTO

, the

headlights and other exterior lights will switch
on and off automatically depending on the
ambient brightness.

The headlights come on when you unlock a
door in dark areas with the headlight switch in

AUTO

Once you lock the door, the headlights
will go off.

■

Automatic Operation (automatic lighting control)

Automatic Operation (automatic lighting control)

We recommend that you turn on the lights manually
when driving at night, in a dense fog, or in dark areas
such as long tunnels or parking facilities.

The light sensor is in the location shown below.
Do not cover this light sensor with anything;
otherwise, the automatic lighting system may not
work properly.

Light Sensor

Models with automatic
intermittent wipers

Models without automatic
intermittent wipers

Light Sensor

Canadian models

U.S. models

Operating the Switches Around the Steering Wheel

Light Switches

164

Co
ntrols

The headlights automatically come on when the wipers are used several times within
a certain number of intervals with the headlight switch in

AUTO

The headlights automatically go off a few minutes later if the wipers are stopped.

The headlights, all other exterior lights, and the instrument panel lights turn off 15
seconds after you set the power mode to VEHICLE OFF, take the remote with you,
and close the driver’s door.

If you set the power mode to VEHICLE OFF with the headlight switch on, but do not
open the door, the lights turn off after 10 minutes (three minutes, if the switch is in
the

AUTO

position).

The lights turn on again when you unlock or open the driver’s door. If you unlock
the door, but do not open it within 15 seconds, the lights go off. If you open the
driver’s door, you will hear a reminder chime alerting you that the lights are on.

■

Headlight Integration with Wipers

■

Automatic Lighting Off Feature

Automatic Operation (automatic lighting control)

You can adjust the auto light sensitivity as follows:

Customized Features

P. 385

Setting

The exterior lights come on

when the ambient light is at

Max

High

Mid

Low

Min

U.S. models

Bright

Dark

Headlight Integration with Wipers

This feature activates during the headlights are off in

AUTO

The instrument panel brightness does not change
when the headlights come on.

At dark ambient light levels, the automatic lighting
control feature turns on the headlights, regardless of
the number of wiper sweeps.

Automatic Lighting Off Feature

You can change the headlight auto off timer setting.

Customized Features

P. 385

165

Operating the Switches Around the Steering Wheel

Fog Lights

Co
ntrols

Fog Lights

When the parking lights or the headlights are
on, turn the fog light switch on to use the fog
lights.

Fog Light Switch

166

Operating the Switches Around the Steering Wheel

Auto High-Beam

Co
ntrols

Auto High-Beam

The front sensor camera detects the light sources ahead of the vehicle such as the
lights of a preceding or oncoming vehicle, or street lights. When you are driving at
night, the system automatically switches the headlights between low beam and high
beam depending on the situation.

When all of the following conditions have been met, the auto high-beam indicator
comes on and the auto high-beam is activated.

•

The power mode is in ON.

•

The light switch is in

AUTO

•

The lever is in the low beam position.

•

The headlights have been automatically
activated.

•

It is dark outside the vehicle.

If the auto high-beam indicator does not come on even when all the conditions have
been met, carry out the following procedure and the indicator will come on.

•

Pull the lever toward you for flashing the high beams then release it while driving.

Auto High-Beam

The auto high-beam system does not always operate
in every situation. This system is just for assisting the
driver. Always observe your surroundings and switch
the headlights between high beam and low beam
manually if necessary.

If you find the timing of beam changes inconvenient
for driving, change the headlight beams manually.

The range and the distance at which the camera can
recognize varies depending on conditions
surrounding your vehicle.

Regarding the handling of the camera mounted to
the inside of the windshield, refer to the following.

Front Sensor Camera

P. 533

For the auto high-beam to work properly:

•

Do not place an object that reflects light on the
dashboard.

•

Keep the windshield around the camera clean.

•

When cleaning the windshield, be careful not to
apply the windshield cleanser to the camera lens.

•

Do not attach an object, sticker or film to the area
around the camera.

•

Do not touch the camera lens.

If the camera receives a strong impact, or repairing of
the area near the camera is required, consult a dealer.

■

How to Use the Auto High-Beam

Front Sensor Camera

Auto High-Beam
Indicator

Light Switch

Continued

167

Operating the Switches Around the Steering Wheel

Auto High-Beam

Co
ntrols

■

Automatic switching between high-beam and low-beam

When auto high-beam is active, the headlights switch between high beam and low
beam based on the following conditions.

■

Manual switching between high-beam and low-beam

If you want to manually switch the headlights between high beam and low beam,
follow either of the procedures below. Note that when you do this, the auto high-
beam indicator will turn off and the auto high-beam will be deactivated.

Using the lever:

Pull the lever toward you for flashing the high beams then release it within about
one second while driving.

To reactivate the auto high-beam, pull the lever toward you for flashing the
high beams then release it while driving. The auto high-beam indicator will
come on.

Using the light switch:

Turn the light switch to

To reactivate the auto high-beam, turn the light switch to

AUTO

when the

lever is in the low beam position, the auto high-beam indicator will come on.

Switching to high beam:

Switching to low beam:

All of the following conditions must
be met before the high beams turn
on.

●

Your vehicle speed is 45mph
(72 km/h) or more.

●

There are no preceding or
oncoming vehicle with headlights
or taillights turned on.

●

There are few street lights on the
road ahead.

One of the following conditions
must be met before the low beams
turn on.

●

Your vehicle speed is 30 mph
(48 km/h) or less.

●

There is a preceding or oncoming
vehicle with headlights or
taillights turned on.

●

There are many street lights on
the road ahead.

How to Use the Auto High-Beam

In the following cases, the auto high-beam system
may not switch the headlights properly or the
switching timing may be changed. In case of the
automatic switching operation does not fit for your
driving habits, please switch the headlights manually.

•

The brightness of the lights from the preceding or
oncoming vehicle is intense or poor.

•

Visibility is poor due to the weather (rain, snow,
fog, windshield frost, etc.).

•

Surrounding light sources, such as street lights,
electric billboards and traffic lights are illuminating
the road ahead.

•

The brightness level of the road ahead constantly
changes.

•

The road is bumpy or has many curves.

•

A vehicle suddenly appears in front of you, or a
vehicle in front of you is not in the preceding or
oncoming direction.

•

Your vehicle is tilted with a heavy load in the rear.

•

A traffic sign, mirror, or other reflective object
ahead is reflecting strong light toward the vehicle.

•

The oncoming vehicle frequently disappears under
roadside trees or behind median barriers.

•

The preceding or oncoming vehicle is a motorcycle,
bicycle, mobility scooter, or other small vehicle.

The auto high-beam system keeps the headlight low
beam when:

•

Windshield wipers are operating.

•

The camera has detected a dense fog.

Operating the Switches Around the Steering Wheel

Auto High-Beam

168

Co
ntrols

You can turn the auto high-beam system off. If you want to turn the system off or
on, set the power mode to ON, then carry out the following procedures while the
vehicle is stationary.

To turn the system off:

With the light switch is in

AUTO

, pull the lever

toward you and hold it for at least 40 seconds.
After the auto high-beam indicator light blinks
twice, release the lever.

To turn the system on:

With the light switch is in

AUTO

, pull the lever

toward you and hold it for at least 30 seconds.
After the auto high-beam indicator light blinks
once, release the lever.

■

How to Turn Off the Auto High-Beam

How to Use the Auto High-Beam

If the

Some Driver Assist Systems Cannot

Operate: Camera Temperature Too High

message

appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed toward the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the

Some Driver Assist Systems Cannot

Operate: Clean Front Windshield

Auto High-

Beam Cannot Operate: Clean Windshield

message appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

How to Turn Off the Auto High-Beam

If you turn the auto high-beam system off, the system
does not operate until you turn the system on.

Park in a safe place before turning the system off or
on.

AUTO

Position

169

Operating the Switches Around the Steering Wheel

Daytime Running Lights

Co
ntrols

Daytime Running Lights

The parking/daytime running lights come on when the following conditions have
been met:

•

The power mode is in ON.

•

The headlight switch is

AUTO

OFF

•

The parking brake is released.

•

The power mode is in ON.

•

The headlight switch is

AUTO

•

The parking brake is released.

The lights remain on even if you set the parking brake. Setting the power mode to
VEHICLE OFF will turn off the daytime running lights.

The daytime running lights are off once the headlight switch is turned on, or when
the head light switch is in

AUTO

and it is getting darker outside.

U.S. models

Canadian models

170

Operating the Switches Around the Steering Wheel

Wipers and Washers

Co
ntrols

Wipers and Washers

The windshield wipers and washers can be
used when the power mode is in ON.

■

MIST

The wipers run at high speed until you release
the lever.

■

Wiper switch (OFF, INT

/AUTO

, LO,

HI)

Move the lever up or down to change the
wiper settings.

■

Adjusting wiper operation

Turn the adjustment ring to adjust wiper
operation.

■

Washer

Sprays while you pull the lever toward you.
When you release the lever for more than one
second, the spray stops, the wipers sweep two
or three more times to clear the windshield,
then stop.

*1: Models with manual intermittent operation
*2: Models with automatic intermittent operation

■

Windshield Wipers/Washers

Wipers and Washers

NOTICE

Do not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.

Turn the washers off if no washer fluid comes out.
The pump may get damaged.

The wiper motor may stop motor operation
temporarily to prevent an overload. Wiper operation
will return to normal within a few minutes, once the
circuit has returned to normal.

If the vehicle speeds up while the wipers are
operating intermittently, the length of the wipe
interval shortens.
When the vehicle speeds up, the wiper operation’s
shortest delay setting (+) and the

setting become

the same.

NOTICE

In cold weather, the blades may freeze to the
windshield.
Operating the wipers in this condition may damage
the wipers. Use the defogger or heated windshield

to warm the windshield, then turn the wipers on.

Models with intermittent time adjustment ring

Intermittent Time
Adjustment Ring

MIST

INT

AUTO

OFF

: Low speed wipe

: High speed wipe

Pull to
use
washer.

Lower speed, fewer sweeps

Higher speed, more sweeps

* Not available on all models

Continued

171

Operating the Switches Around the Steering Wheel

Wipers and Washers

Co
ntrols

When you push the lever down to

AUTO

, the

windshield wipers sweep once, and go into
the automatic mode.

The wipers operate intermittently, at low
speed, or at high speed and stop in
accordance with the amount of rainfall the
rainfall sensor detects.

■

Auto sensitivity adjustment

When the wiper function is set to

AUTO

, you

can adjust the sensitivity of the rainfall sensor
(using the adjustment ring) so that wipers will
operate in accordance with your preference.

Sensor sensitivity

■

Automatic Intermittent Wipers

Wipers and Washers

If the wipers stop operating due to an obstacle such
as the buildup of snow, park the vehicle in a safe
place.
Rotate the wiper switch to

OFF

, and set the power

mode to ACCESSORY or VEHICLE OFF, then remove
the obstacle.

Automatic Intermittent Wipers

The rainfall sensor is in the location shown below.

NOTICE

AUTO

should always be turned

OFF

before the

following situations in order to prevent severe
damage to the wiper system:

•

Cleaning the windshield

•

Driving through a car wash

•

No rain present

Rainfall Sensor

Adjustment Ring

Low sensitivity

High sensitivity

* Not available on all models

172

Operating the Switches Around the Steering Wheel

Wipers and Washers

Co
ntrols

The rear wiper and washer can be used when
the power mode is in ON.

■

Wiper switch (OFF, INT, ON)

Change the wiper switch setting according to
the amount of rain.

■

Washer (

)

Sprays while you rotate the switch to this
position.
Hold it to activate the wiper and to spray the
washer. Once released, it stops operating
after a few more sweeps.

■

Operating in reverse

When you change the transmission to

(

with the windshield wiper activated, the

rear wiper operates automatically as follows even if its switch is off.

■

Rear Wiper/Washer

INT

: Intermittent

OFF

Washer

Front Wiper Operation

Rear Wiper Operation

INT

(Intermittent)

Intermittent

(Low speed wipe)

(High speed wipe)

Continuous

Content .. 8 9 10 11 ..
