Continued

141

uu

Opening and Closing the Tailgate

u

Precautions for Opening/Closing the Tailgate

Co
ntrols

The power tailgate can be operated by pressing the power tailgate button on the
remote transmitter, pressing the power tailgate button in the driver side control
panel, pressing the button on the tailgate, or by raising and lowering your foot
under the center of the rear bumper for hands free access

*

.

The power tailgate can be opened/closed when the transmission is in

(

P

.

1

Precautions for Opening/Closing the Tailgate

NOTICE

Do not push or pull on the power tailgate when it is
being automatically opened or closed.
Forcibly opening or closing the power tailgate while
in operation can deform the tailgate frame.

When operating the power tailgate, make sure there
is enough space around your vehicle. People near the
tailgate may be seriously hurt if the tailgate hits or
closes on their heads. Be especially cautious if
children are around.

The power tailgate may not open or close under the
following conditions:

•

You start the engine while the tailgate is
automatically opening or closing.

•

The vehicle is parked on a steep hill.

•

The vehicle is swayed in a strong wind.

•

The tailgate or the roof is covered with snow or ice.

3

WARNING

Closing a power tailgate while anyone is in
the path of the tailgate can cause serious
injury.

Make sure everyone is clear before closing
the power tailgate.

Models with power tailgate

Models with power tailgate

* Not available on all models

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

*

142

Co
ntrols

Opening/Closing the Power Tailgate

*

Use a forward and back kicking motion for
about 1 second under the center of the rear
bumper to open or close the power tailgate
while carrying the keyless remote.

u

Some exterior lights flash twice and a
beeper sounds once, then the tailgate
begins to move.

■

Using the Hands Free Access

*

1

Precautions for Opening/Closing the Tailgate

If you close the power tailgate with all the doors
locked, the power tailgate locks automatically.

1

Using the Hands Free Access

*

During rain or in other instances when the vehicle
becomes wet, the sensor may not properly detect
your foot motion.

When performing work on or around the rear section
of the vehicle, you may inadvertently open or close
the tailgate.
To prevent this from happening, select Customized
Features on the audio/information screen and then
select OFF for the feature.

2

Customized Features

 P. 385

If you hold your foot under the bumper for too long
or sweep your foot from side to side, the power
tailgate does not open or close.

This function will not operate if you don't have the
keyless remote on you. Please make sure you have
the keyless remote on you.

1 sec.

* Not available on all models

Continued

143

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

*

Co
ntrols

Press the power tailgate button for more than
one second to operate when the power mode
is in VEHICLE OFF.

u

Some exterior lights flash and the beeper
sounds.

If you press the button again while the power
tailgate is moving, it will reverse direction.

■

Customizing when to open the tailgate

Anytime:

The power tailgate unlocks and opens at the same time. This is the

default setting.

When Unlocked:

The tailgate opens when all doors are unlocked.

2

Customized Features

 P. 385

■

Using the Remote Transmitter

1

Opening/Closing the Power Tailgate

*

If you close the power tailgate when all the doors are
locked, the power tailgate locks automatically.

If you replace the battery or the power tailgate fuse
while the tailgate is open, the power tailgate may be
disabled. The power tailgate resumes once you
manually close the tailgate.

Installing aftermarket components other than
genuine Honda accessories on the power tailgate
may prevent it from fully opening or closing.

Make sure the power tailgate is fully open before you
get your cargo in and out.

Make sure the power tailgate is fully closed before
you start the vehicle.

The beeper sounds when you start driving while the
power tailgate is still open, or closing.

Power
Tailgate
Button

* Not available on all models

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

*

144

Co
ntrols

To open or close the power tailgate, press the
power tailgate button for about one second.

u

Some exterior lights flash and the beeper
sounds.

If you press the button again while the power
tailgate is moving, it will reverse direction.

■

Using the Power Tailgate Button

1

Opening/Closing the Power Tailgate

*

If the power tailgate meets resistance while opening
or closing, the auto reverse feature reverses the
direction. The beeper sounds three times.

The auto reverse function stops sensing when the
tailgate is almost closed to make sure that it fully
closes.

Do not touch the sensors located on both sides of the
tailgate. The power tailgate does not close if you
touch either sensor when you are trying to close the
tailgate.

Be careful not to scratch the sensors with a sharp
object. If scratched, they can be damaged, and the
power tailgate closing feature malfunctions.

Power Tailgate Button

* Not available on all models

Continued

145

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

*

Co
ntrols

If you press the outer handle of the tailgate for
no longer than one second, the tailgate opens
automatically.

u

The beeper sounds.

u

If you want to open the tailgate
manually, press the button for more than
one second.

2

Opening and Closing the Tailgate



P. 140

If you are carrying the keyless remote, you do
not have to unlock the tailgate before
opening it.

If you press the outer handle again while the
power tailgate is moving, it will reverse
direction.

■

Using the Tailgate Outer Handle

1

Opening/Closing the Power Tailgate

*

Do not leave the key, remote transmitter, or keyless
remote in the cargo area before closing the tailgate.

Even if you are not carrying the keyless remote, you
can lock/unlock the tailgate while someone else with
the remote is within range.

You can change the power tailgate operation setting
on and off.

2

Customized Features

 P. 385

Outer
Handle

* Not available on all models

146

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

*

Co
ntrols

Press the button on the tailgate to close the
power tailgate.

u

The beeper sounds.

If you press the button again while the power
tailgate is moving, it will reverse direction.

■

Using the Tailgate Inner Button

147

uu

Opening and Closing the Tailgate

u

Opening/Closing the Power Tailgate

*

Co
ntrols

If you manually close the power tailgate, it latches automatically.

Automatically lowers the power tailgate when there is a possibility that the fully
opened power tailgate can fall down by its own weight (for example, by snow on
the tailgate). The beeper sounds while the power tailgate lowers.

■

Auto-Closer

■

Power Tailgate Fall Detection

1

Auto-Closer

The auto-closer feature does not activate if you press
the tailgate outer handle while the power tailgate is
closing.

Do not put any force on the tailgate while the power
tailgate is latching.

Keep your hands away from the tailgate when you
manually close the tailgate and let it latch
automatically. It is dangerous to put your hands
around the tailgate as it starts to latch itself.

1

Power Tailgate Fall Detection

If you try to manually close the power tailgate
immediately after it fully opens, the power tailgate
fall detection may be activated.

Once the power tailgate fall detection activates, wait
until the power tailgate fully closes. Keep away from
the power tailgate when it is in motion.

If the power tailgate fall detection constantly
activates, consult at a dealer.

148

uu

Opening and Closing the Tailgate

u

Opening/Closing the Tailgate

Co
ntrols

Opening/Closing the Tailgate

When all the doors are unlocked or press the
tailgate unlock button on the remote
transmitter, the tailgate is unlocked.
Press the tailgate outer handle and lift open
the tailgate.

If you are carrying the keyless remote, you do
not have to unlock the tailgate before
opening it.

To close the tailgate, grab the inner handle,
pull the tailgate down, and push it closed
from outside.

■

Using the Tailgate Outer Handle

1

Using the Tailgate Outer Handle

Do not leave the key, remote transmitter, or keyless
remote in the cargo area before closing the tailgate.

Even if you are not carrying the keyless remote, you
can lock/unlock the tailgate while someone else with
the remote is within range.

Outer
Handle

Inner Handle

149

uu

Opening and Closing the Tailgate

u

Opening/Closing the Tailgate

Co
ntrols

Press the tailgate unlock button to unlock the
tailgate.

■

Using the Remote Transmitter

1

Using the Remote Transmitter

If you have unlocked and opened the tailgate using
the remote transmitter or keyless remote, when
closing, the tailgate locks automatically.

Tailgate
Unlock
Button

150

Co
ntrols

Security System

Immobilizer System

The immobilizer system prevents a key that has not been pre-registered from
starting the engine. Each key contains electronic transmitters that use electronic
signals to verify the key.

Pay attention to the following when pressing the

ENGINE START/STOP

 button:

•

Do not allow objects that emit strong radio waves near the

ENGINE START/

STOP

 button.

•

Make sure the key is not covered by or touching a metal object.

•

Do not bring a key from another vehicle’s immobilizer system near the

ENGINE

START/STOP

 button.

•

Do not put the key near magnetic items. Electronic device, such as televisions and
audio systems emit strong magnetic fields. Note that even a key chain can
become magnetic.

Security System Alarm

The security system alarm activates when the tailgate, hood or doors are forcibly
opened. The alarm does not activate if the tailgate or doors are opened with the key,
remote transmitter or keyless access system.

However, the alarm activates if a door is opened with the key and then the hood is
opened before the power mode is set to ON.

1

Immobilizer System

NOTICE

Leaving the key in the vehicle can result in theft or
accidental movement of the vehicle.
Always take the key with you whenever you leave the
vehicle unattended.

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

1

Security System Alarm

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

The security alarm continues for a maximum of two
minutes until the security system alarm deactivates.

Continued

151

uu

Security System

u

Security System Alarm

Co
ntrols

■

When the security system alarm activates

The horn sounds intermittently, and some exterior lights flash.

■

To deactivate the security system alarm

Unlock the vehicle using the key, remote transmitter or keyless access system. The
system, along with the horn and flashing lights, is deactivated.

■

Setting the security system alarm

The security system alarm automatically sets when the following conditions have
been met:

•

The power mode is set to VEHICLE OFF.

•

The hood is closed.

•

All doors and the tailgate are locked from outside with the key, remote
transmitter, or keyless access system.

■

When the security system alarm sets

The security system alarm indicator in the instrument panel blinks. When the
blinking interval changes after about 15 seconds, the security system alarm is set.

■

To cancel the security system alarm

The security system alarm is canceled when the vehicle is unlocked using the remote
transmitter or keyless access system, or the power mode is set to ON. The security
system alarm indicator goes off at the same time.

1

Security System Alarm

Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:

•

Unlocking the door with the lock tab.

•

Opening the hood with the hood release.

If the battery goes dead after you have set the
security system alarm, the security alarm may go off
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the key, remote transmitter or
keyless access system.

152

uu

Security System

u

Security System Alarm

Co
ntrols

■

The panic button on the remote
transmitter

If you press the panic button for
approximately one second, the following will
occur for about 30 seconds:

•

The horn sounds.

•

Some exterior lights flash.

■

Canceling panic mode

Press any button on the remote transmitter, or
set the power mode to ON.

■

Panic Mode

Panic
Button

153

Continued

Co
ntrols

Opening and Closing the Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the power mode is in ON,
using the switches on the doors.

The driver’s side switches can be used to open and close all the windows. The power
window lock button on the driver’s side must be switched off (not pushed in,
indicator off) to open and close the windows from anywhere other than the driver’s
seat.

When the power window lock button is pushed in, the indicator comes on and you
can only operate the driver’s window. Turn the power window lock button on if a
child is in the vehicle.

■

Manual operation

To open:

Push the switch down lightly, and

hold it until the desired position is reached.

To close:

Pull the switch up lightly, and hold it

until the desired position is reached.

■

Automatic operation

To open:

 Push the switch down firmly.

To close:

 Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

■

Opening/Closing Windows with Auto-Open/Close Function

1

Opening/Closing the Power Windows

The power windows can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF.
Opening either front door cancels this function.

Auto Reverse

If a power window senses resistance when closing
automatically, it stops closing and reverse direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

3

WARNING

Closing a power window on someone’s
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

ON
OFF

Power Window
Lock Button

Front Passenger’s
Window Switch

Driver’s Window
Switch

Indicator

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

154

Co
ntrols

To open:

Push the switch down.

To close:

Pull the switch up.

Release the switch when the window reaches
the desired position.

To open:

Press the unlock button, and then

within 10 seconds, press it again and hold it.

If the windows stop midway, repeat the
procedure.

■

Opening/Closing Windows without Auto-Open/Close Function

1

Opening/Closing the Power Windows

While driving with any of the windows open, you
may hear a booming, throbbing, or helicopter-type
noise or pressure. This is called wind buffeting. This is
a normal occurrence that can be minimized.

If you hear a wind buffeting noise with any of the
windows open, lower all of the other windows
slightly or open the moonroof

*

.

Close

Open

■

Opening the Windows with the Remote

1

Opening the Windows with the Remote

If you open the windows with the remote, the
moonroof will open automatically along with them.

Models with moonroof

Unlock
Button

* Not available on all models

155

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

Co
ntrols

To open:

 Unlock the driver’s door with the

key. Within 10 seconds of returning the key to
the central position, turn the key in the unlock
direction and hold it there.

To close:

 Lock the driver’s door with the key.

Within 10 seconds of returning the key to the
central position, turn the key in the lock
direction and hold it there.

Release the key to stop the windows at the
desired position. If you want further
adjustment, repeat the same operation.

■

Opening/Closing the Window with the key

1

Opening/Closing the Window with the key

If you open/close the windows with the key, the
moonroof will open/close automatically along with
them.

Models with moonroof

Close

Open

156

Co
ntrols

Moonroof

*

Opening and Closing the Moonroof

You can operate the moonroof when the power mode is in ON. Use the switch in
the front of the ceiling to open and close the moonroof.

■

Automatic operation

To open:

 Pull the switch back firmly.

To close:

 Push the switch forward firmly.

The moonroof will automatically open or close
all the way. To stop the moonroof midway,
push the switch briefly.

■

Manual operation

To open:

 Pull the switch back lightly, and

hold it until the desired position is reached.

To close:

 Push the switch forward lightly, and

hold it until the desired position is reached.

■

Tilting the moonroof up

To tilt:

 Push on the center of the moonroof

switch.

To close:

 Push the switch forward firmly, then

release.

■

Using the Moonroof Switch

1

Opening and Closing the Moonroof

NOTICE

Opening the moonroof in below freezing
temperature or when it is covered with snow or ice
can damage the moonroof panel or motor.

The power moonroof can be operated for up to 10
minutes after you set the power mode to OFF.
Opening either front door cancels this function.

When resistance is detected, the auto reverse function
causes the moonroof to change directions, then stop.
Auto reverse stops sensing when the moonroof is
almost closed to ensure that it fully closes.

You can use the remote transmitter or the key to
operate the moonroof.

2

Opening the Windows with the Remote



P. 154

2

Opening/Closing the Window with the key



P. 155

3

WARNING

Opening or closing the moonroof on
someone’s hands or fingers can cause
serious injury.

Make sure all hands and fingers are clear of
the moonroof before opening or closing it.

Open

Close

Tilt

Models without panoramic roof

Models with panoramic roof

Open

Close

Tilt

* Not available on all models
