uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

204

Co
ntrols

There is a coat hook on the rear grab handle
of both sides. Pull it down to use it.

1

Wireless Charger

*

Not all devices are compatible with the system.

During the charging phase, it is normal for the
charging area and device to heat up.

Charging may be briefly interrupted when:

•

All the doors and the tailgate are closed
- to avoid interference with the proper functioning
of the keyless access system.

•

The position of the device is altered.

Do not charge more than one device at a time on a
charging area.

■

Coat Hooks

1

Coat Hooks

The coat hooks are not designed for large or heavy
items.

* Not available on all models

Continued

205

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

To open the sunglasses holder, push and
release the indent. To close, push it again until
it latches.

You can store eyeglasses and other small
items in this holder.

■

Conversation mirror

*

The sunglasses holder comes with a mirror.
Open the sunglasses holder fully, then push it
back to the first detent.

You can use the mirror to view the rear seats.

■

Sunglasses Holder

1

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Push

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

206

Co
ntrols

Pull the tab and roll up the sunshade all the
way. Use the hooks to hang it.

■

Integrated Sunshades

*

1

Integrated Sunshades

*

Use the sunshades only when the windows are fully
closed. Using the shade while a window is open can
unhook and blow off the shade, hitting and hurting
anyone sitting near the window.

Tab

Hook

* Not available on all models

Continued

207

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The seat heaters can be used when the power
mode is in ON.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator
on)
Four times - The OFF setting (no indicators on)

When the power mode is turned on after it is
turned off, the previous setting is maintained.

■

Front Seat Heaters

*

1

Front Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

After a certain period of time, the strength setting for
the seat heaters will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

208

Co
ntrols

The seat heaters or ventilators can be used
when the power mode is in ON.
The seat heaters: Use them to warm up the
seat.
The seat ventilators: Use them when you
want to ventilate the surface of the seats.
The lower you set the air conditioning
temperature, the more you will feel the effect
of the seat ventilation.
Press the seat heater or the seat ventilator
button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator
on)
Four times - The OFF setting (no indicators on)

When the power mode is turned on after it is
turned off, the previous setting is maintained.

■

Front Seat Heaters/Ventilators

*

1

Front Seat Heaters/Ventilators

*

Do not use the seat heaters and the seat ventilation
even in LO when the engine is off. Under such
conditions, the battery may be weakened, making
the engine difficult to start.

After a certain period of time, the strength setting for
the seat heaters will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

Continued

209

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
seat heaters.

There is no heater in the rear center seating
position.
Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator
on)
Four times - The OFF setting (no indicators on)

When the power mode is turned on after it is
turned off, the previous setting is maintained.

■

Rear Outer Seat Heaters

*

1

Rear Outer Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

After a certain period of time, the strength setting for
the rear seat heaters will automatically be reduced by
one level at a time until the rear seat heater shuts off.
The elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

210

Co
ntrols

The power mode must be in ON to use the
heated steering wheel.

Press the button on the right side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you start the engine, even if you turned it
on the last time you drove the vehicle.

■

Heated Steering Wheel

*

1

Heated Steering Wheel

*

Do not use the heated steering wheel continuously
when the engine is off. Under such conditions, the
battery may be weakened, making the engine
difficult to start.

Indicator

Heated Steering
Wheel Button

* Not available on all models

Continued

211

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The tie-down anchors on the cargo area floor
can be used to install a net for securing items.

The cargo hooks on both sides of the cargo
area can be used to hang a light items.

■

Tie-down Anchors

Anchor

Anchor

■

Cargo Hooks

1

Cargo Hooks

Heavy objects may damage the hook. Make sure any
items put on this hook weigh less than 6.6 lbs (3 kg).

Distribute cargo evenly on the floor of the cargo area,
placing the heaviest items on the bottom and as far
forward as possible.

212

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Pull the handle to open the cargo floor lid.

■

Under-floor Storage Area

213

Continued

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that will as quickly as
possible, raise or lower the interior temperature to your preference.

Use the system when the engine is running.

1.

Press the

AUTO

 button.

2.

Adjust the interior temperature using the driver’s side or passenger’s side
temperature control switch.

3.

Press the



ON/OFF

 button to cancel.

1

Using Automatic Climate Control

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.
The

AUTO

 indicator will go off, but functions

unrelated to the button that was pressed will be
controlled automatically.

During Auto Idle Stop, air-conditioning is suspended,
and only the blower remains active.
If you do not want air-conditioning suspended, press
the Auto Idle Stop

OFF

 button to cancel Auto Idle

Stop.

To prevent cold air from blowing in from outside, the
fan may operate at low speed for a while after the

AUTO

 button has been pressed.

While ECON mode is active, the climate control
system may have reduced cooling performance.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit,

Lo

 or

Hi

 is displayed.

Floor and
defroster
vents

Floor vents

Dashboard and floor,
and back of the
center console vents

Dashboard and
back of the center
console vents

AUTO

 Button

Driver’s Side
Temperature
Control Switch

 (Recirculation) Button

Fan Control Button

A/C (Air Conditioning)
Button

Passenger’s Side
Temperature Control
Switch

 (On/Off) Button

 (Windshield Defroster)

Button

SYNC

 (Synchronization) Button

uu

Climate Control System

u

Using Automatic Climate Control

214

Co
ntrols

■

Switching between the recirculation and fresh air modes

Press the

 button and switch the mode depending on environmental conditions.

Recirculation Mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh Air Mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Pressing the

 button turns the air

conditioner system on and automatically
switches the system to fresh air mode.

Press the

 button again to turn off, the

system returns to the previous settings.

■

Defrosting the Windshield and Windows

1

Using Automatic Climate Control

Pressing the



ON/OFF

 button switches the

climate control system between on and off. When
turned on, the system returns to your last selection.

1

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If you press the

 button during Auto Idle Stop, the

engine restarts automatically.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

215

uu

Climate Control System

u

Using Automatic Climate Control

Co
ntrols

■

To rapidly defrost the windows

1.

Press the

 button.

2.

Press the

 button.

1

To rapidly defrost the windows

After defrosting or defogging the windows, switch
over to fresh air mode. If you keep the system in
recirculation mode, the windows may fog up from
humidity. This impedes visibility.

216

uu

Climate Control System

u

Synchronization Mode

Co
ntrols

Synchronization Mode

You can set the temperature synchronously for the driver side, front passenger side
and rear seats in synchronization mode.

1.

Press the

SYNC

 button.

u

The system will switch to synchronization mode.

2.

Adjust the temperature using driver’s side temperature control switch.

Press the

SYNC

 button to return to synchronization mode off.

1

Synchronization Mode

When you press the

 button, the system changes

to synchronization mode.

When the system is in synchronization mode off, the
temperature for the driver, front passenger, and rear
seats can be set separately.

217

uu

Climate Control System

u

Rear Climate Control System

Continued

Co
ntrols

Rear Climate Control System

Use the system when the engine is running and the climate control system is
operating.

1.

Press the

REAR



 (Rear On/Off) button.

2.

Press the

RR SETTINGS

 button.

u

The system switches to the rear control mode for 10 seconds. The

REAR



indicator appears on the display.

■

Using the Rear Climate Control System From the Front Panel

1

Rear Climate Control System

LOCK

 appears on the rear control panel while the

rear lock is on.

If the rear lock is on while in SYNC mode, the rear
control panel is disabled.

LOCK SYNC

 appears on the

rear control panel.

Models with rear lock button

1

Using the Rear Climate Control System From the Front Panel

Press the

REAR LOCK

 button to turn the rear lock

mode on and off.
While the rear lock mode is on, the rear control panel
is disabled.

u

REAR LOCK

appears on the display.

When the rear fan is set to maximum speed, Auto
Idle Stop does not activate.

u

Auto Idle Stop may not activate under other

conditions when the rear climate control system is
in use.

Models with rear lock button

REAR LOCK

 Button

(Rear On/Off) Button

RR SETTINGS

 Button

uu

Climate Control System

u

Rear Climate Control System

218

Co
ntrols

3.

Press the

AUTO

 button.

u

The rear system changes to AUTO mode.

u

The system automatically adjusts the fan speed and airflow levels to maintain
the set rear temperature. Change the temperature if necessary.

4.

To turn off the rear climate control system, press the

 (Rear On/Off) button.

Use the system when the engine is running and the climate control system is
operating.

1.

Press the

 (Rear On/Off) button.

2.

Press the Rear

AUTO

 button.

3.

Adjust the interior temperature using the rear temperature control button.

4.

To turn off the rear climate control system, press the

 button.

■

Using the Rear Climate Control System From the Rear Panel

*

1

Using the Rear Climate Control System From the Rear Panel

*

When the

REAR LOCK

 button on the front control

panel is off, the temperature of the rear passenger
compartment can be controlled independently.

Rear floor
vents

Rear console
vents and
floor vents

Rear console
vents

 /



(Rear Fan
Control) Buttons

 (Rear On/Off) Button

Rear Temperature
Control Buttons

Rear

AUTO

 Button

* Not available on all models

219

uu

Climate Control System

u

Automatic Climate Control Sensors

Co
ntrols

Automatic Climate Control Sensors

The automatic climate control system is
equipped with sensors. Do not cover or spill
any liquid on them.

Sensor

Sensor
