Honda Passport (2022 year). Manual in english

172

Operating the Switches Around the Steering Wheel

Wipers and Washers

Co
ntrols

The rear wiper and washer can be used when
the power mode is in ON.

■

Wiper switch (OFF, INT, ON)

Change the wiper switch setting according to
the amount of rain.

■

Washer (

)

Sprays on the rear window while you rotate
the switch to this position.
Hold it to activate the rear wiper and to spray
the washer. Once released, the washer spray
will stop and the rear wiper will return to its
selected switch setting after a few more
sweeps.

■

Operating in reverse

When you shift the transmission to

(

with the windshield wiper activated, the rear

wiper operates automatically as follows even if its switch is off.

■

Rear Wiper/Washer

INT

: Intermittent

OFF

Washer

Front Wiper Operation

Rear Wiper Operation

INT

(Intermittent)

Intermittent

(Low speed wipe)

(High speed wipe)

Continuous

173

Operating the Switches Around the Steering Wheel

Rear Defogger/Heated Door Mirror

Button

Co
ntrols

Rear Defogger/Heated Door Mirror

Button

Press the rear defogger and heated door
mirror button to defog the rear window and
mirrors when the power mode is in ON.

The rear defogger and heated door mirrors
automatically switch off after 10-30 minutes
depending on the outside temperature.

The rear defogger automatically switches off
after 10-30 minutes depending on the outside
temperature.

Rear Defogger/Heated Door Mirror

Button

This system consumes a lot of power, so turn it off
when the window has been defogged.
Also, do not use the system for a long time while the
engine is idling. This may weaken the battery, making
it difficult to start the engine.

When the power mode is set to ON and the outside
temperature is below 41°F (5°C), the heated door
mirror may automatically activate for 10 minutes.

Models with heated door mirror

Models without heated door mirror

* Not available on all models

174

Operating the Switches Around the Steering Wheel

Heated Windshield Button

Co
ntrols

Heated Windshield Button

Press the heated windshield button to deice
the windshield when the power mode is in
ON.

Canadian models

Heated Windshield Button

This system consumes a lot of power, so turn it off
when the window has been deiced. Also, do not use
the system for a long period when the engine is
idling. This may weaken the battery, making it
difficult to start the engine.

When the outside temperature is below 39°F (4°C),
the heated windshield may automatically activate.
The system deactivates itself once the outside
temperature reaches 43°F (6°C).

175

Operating the Switches Around the Steering Wheel

Brightness Control

Co
ntrols

Brightness Control

When the power mode is in ON, you can use
the

(

button to adjust instrument

panel brightness.

Brighten:

Press the

(

button.

Dim:

Press the

(

button.

You will hear a beeper when the brightness
reaches minimum or maximum. Several
seconds after you have adjusted the
brightness, you will be returned to the
previous screen.

■

Brightness level indicator

The brightness level is shown on the display
while you are adjusting it.

Brightness Control

Instrument panel brightness varies, depending on
whether the exterior lights are on or off. The
instrument panel dims to reduce glare when they are
on.

When it is bright outside and the headlight
integration with the wiper is activated, the
instrument panel brightness does not change.

To cancel the reduced instrument panel brightness
when the exterior lights are on, press the

(

button

until the brightness display is up to max, the beeper
sounds.

The brightness can be set differently for when the
exterior lights are on, and when they are off.

(

Button

(

Button

176

Operating the Switches Around the Steering Wheel

Driving Position Memory System

Co
ntrols

Driving Position Memory System

You can store two driver's seat (except for power lumbar) and outside mirror
positions with the driving position memory system.
When you unlock and open the driver’s door with a remote transmitter or keyless
access system, door mirrors adjust to one of the two preset positions and the seat
adjusts to the retracted position of one of the two preset positions automatically.

The seat will move to the stored position when you set the power mode to
ACCESSORY.

When you enter the vehicle, the driver information interface briefly shows you which
remote transmitter you used to unlock the vehicle.

•

DRIVER 1

transmitter is linked to memory button 1.

•

DRIVER 2

transmitter is linked to memory button 2.

The driver’s seat moves rearward depending
on the set seating position once you

•

Stop the vehicle.

•

Put the transmission in

(

•

Turn the engine off.

•

Open the driver’s door.

Once the power mode is in the ACCESSORY
position, the driver’s seat moves to the

DRIVER 1

preset position.

Driving Position Memory System

Using the audio/information screen, you can disable
the automatic seat and door mirrors adjustment
function.

Customized Features

P. 327

The driver’s seat easy exit feature can be turned ON/
OFF.

Customized Features

P. 327

System Operation

The system will not operate if:

•

The vehicle speed is above 3 mph (5 km/h).

•

Either memory position button is pressed while the
seat is in motion.

•

The seat position is adjusted while in operation.

•

The memory 1 or 2 position is set fully to the rear.

The system may not recognize a key if:

•

The key is in close proximity to a cell phone or other
wireless device.

•

Both keys are in the vehicle at the same time.

•

The driving position memory system is disabled in
customized features.

•

Opening driver's door without fully grabbing door
handle.

DRIVER 1

DRIVER 2

* Not available on all models

177

Operating the Switches Around the Steering Wheel

Driving Position Memory System

Co
ntrols

Set the power mode to ON. Adjust the
driver’s seat and the door mirrors to the
desired position.

Press the

SET

button.

You will hear a beep, and the memory
button indicator light will blink.

Press and hold memory button

(

within five seconds of pressing the

SET

button.

You will hear two beeps, and the
indicator light on the button you pressed
stays on once the seat and the outside
mirror positions have been memorized.

Put the transmission into

(

Apply the parking brake.

Press a memory button (

(

You will hear a beep, and the indicator
light will blink.

The seat and the door mirrors will
automatically move to the memorized
positions. When it has finished moving, you
will hear the beep, and the indicator light
stays on.

■

Storing a Position in Memory

Storing a Position in Memory

After you press the

SET

button, the storing operation

will be canceled when:

•

You do not press the memory button within five
seconds.

•

You readjust the seat position and door mirror
before the double-beep.

•

You set the power mode to any position except
ON.

Memory Button 1

Memory Button 2

SET

Button

■

Recalling the Stored Position

Recalling the Stored Position

The seat and the door mirrors will stop moving if you:

•

Press the

SET

button or memory button

(

•

Adjust the seat position or door mirrors.

•

Put the transmission into a position other than

(

Memory Buttons

178

Operating the Switches Around the Steering Wheel

Adjusting the Steering Wheel

Co
ntrols

Adjusting the Steering Wheel

The steering wheel height and distance from your body can be adjusted so that you
can comfortably grip the steering wheel in an appropriate driving posture.

Push the steering wheel adjustment lever
down.

The steering wheel adjustment lever is
under the steering column.

Move the steering wheel up or down, and
in or out.

Make sure you can see the instrument
panel gauges and indicators.

Pull the steering wheel adjustment lever up
to lock the steering wheel in position.

After adjusting the position, make sure
you have securely locked the steering
wheel in place by trying to move it up,
down, in, and out.

Adjusting the Steering Wheel

WARNING

Adjusting the steering wheel position while
driving may cause you to lose control of the
vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the
vehicle is stopped.

Lever

To lock

To adjust

179

Co
ntrols

Adjusting the Mirrors

Interior Rearview Mirror

Adjust the angle of the rearview mirror when you are sitting in the correct driving
position.

Flip the tab to switch the position.
The night position will help to reduce the glare
from headlights behind you when driving
after dark.

When you are driving after dark, the
automatic dimming rearview mirror and
power door mirror reduce the glare from
headlights behind you. Press the AUTO button
to turn this function on and off. When
activated, the AUTO indicator comes on.

■

Rearview Mirror with Day and Night Positions

Adjusting the Mirrors

Keep the inside and outside mirrors clean and
adjusted for best visibility.

Adjust the mirrors before you start driving.

Front Seats

P. 181

Tab

Daytime
Position

Night Position

Down

■

Automatic Dimming Rearview Mirror

and Power Door

Mirrors

Automatic Dimming Rearview Mirror

and Power Door Mirrors

The auto dimming function cancels when the
transmission is in

(

Sensor

Auto Button

Down

* Not available on all models

180

Adjusting the Mirrors

Power Door Mirrors

Co
ntrols

Power Door Mirrors

You can adjust the door mirrors when the
power mode is in ON.

■

Mirror position adjustment

L/R selector switch:

Select the left or right

mirror. After adjusting the mirror, return the
switch to the center position.

Mirror position adjustment switch:

Press

the switch left, right, up, or down to move the
mirror.

■

Folding door mirrors

Press the folding button to fold in and out the
door mirrors.

If activated, either side door mirror
automatically tilts downward when you put
the transmission into

(

; this improves close-

in visibility on the selected side of the vehicle
when backing up. The mirror automatically
returns to its original position when you take
the transmission out of

(

To activate this feature, set the power mode
to ON, and slide the selector switch to the left
or right side.

Selector
Switch

Adjustment Switch

Folding
Button

■

Reverse Tilt Door Mirror

Selector
Switch

* Not available on all models

181

Continued

Co
ntrols

Adjusting the Seats

Front Seats

Adjust the driver’s seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately press the pedals without leaning
forward, and grip the steering wheel
comfortably. The passenger’s seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

■

Adjusting the front power seats

Adjusting the Seats

The National Highway Traffic Safety Administration
and Transport Canada recommend that drivers allow
at least 10 inches (25 cm) between the center of the
steering wheel and the chest.

Always make seat adjustments before driving.

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back.

Allow sufficient
space.

■

Adjusting the Seat Positions

Horizontal Position
Adjustment

Height Adjustment

Seat-back Angle
Adjustment

* Not available on all models

Continued

183

Adjusting the Seats

Front Seats

Co
ntrols

■

Adjusting the front manual seats

Adjusting the front manual seats

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

Horizontal Position
Adjustment

Pull up on the bar to move the
seat, then release the bar.

Height Adjustment

(Driver side only)
Pull up or push down the lever
to raise or lower the seat.

Seat-back Angle
Adjustment

Pull up the lever to
change the angle.

* Not available on all models

Adjusting the Seats

Front Seats

184

Co
ntrols

Adjust the driver’s seat-back to a comfortable,
upright position, leaving ample space
between your chest and the airbag cover in
the center of the steering wheel.

The front seat passenger should also adjust
their seat-back to a comfortable, upright
position.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the
occupant’s chest reduces the protective capability of the belt. It also increases the
chance of sliding under the belt in a crash and being seriously injured. The farther a
seat-back is reclined, the greater the risk of injury.

■

Adjusting the Seat-Backs

Adjusting the Seat-Backs

Do not put a cushion, or other object, between the
seat-back and your back.

Doing so may interfere with proper seat belt or airbag
operation.

If you cannot get far enough away from the steering
wheel and still reach the controls, we recommend
that you investigate whether some type of adaptive
equipment may help.

WARNING

Reclining the seat-back too far can result in
serious injury or death in a crash.

Adjust the seat-back to an upright position,
and sit well back in the seat.

185

Adjusting the Seats

Rear Seats

Continued

Co
ntrols

Rear Seats

■

Adjusting the Seat Positions

Adjusting the Seat Positions

WARNING

An unsecured seat or seat-back can move
out of position or collapse without warning
if there is sudden acceleration or stop or in
a crash.

A seat or seat-back that suddenly moves or
collapses can result in severe injury or
death.

Always make sure all seats and seat-backs
are securely locked into position before
driving.

Seat-back Angle
Adjustment

Pull up the lever to change
the angle.

Horizontal Position
Adjustment

Pull up the bar to move the
seat, then release the bar.

Adjusting the Seats

Rear Seats

186

Co
ntrols

Separately fold down the left and right halves of the rear seat to make room for
cargo.

Store the center seat belt first. Insert the latch plate into the slot on the side of the
anchor buckle.

Retract the seat belt into the holder on the ceiling.

Seat Belt with Detachable Anchor

P. 44

Lower the center head restraint to its lowest position. Put the armrest back into
the seat-back.

Pull up on the seat-back angle adjustment
lever.

To return the seat to the original position, pull
up the seat-back in the upright position.

■

Folding Down the Rear Seat

Folding Down the Rear Seat

Make sure that the folded seat-back does not press
against the front passenger seat, as this can cause the
weight sensors in the front passenger seat to work
improperly.

Passenger Airbag Off Indicator

P. 59

The front seats must be far enough forward so they
do not interfere with the rear seats as they fold
down.

To lock the seat-back upright, push it backwards until
it locks.

Make sure the seat-back, head restraints and seat
cushion are securely latched back into place before
driving. Before center occupant use, make sure the
center shoulder belt is reinserted into the anchor
buckle.

Lever

187

Adjusting the Seats

Rear Seats

Co
ntrols

This feature alerts you to the possible presence of passengers or items in the rear
seats before you exit the vehicle. It activates when the vehicle is set to VEHICLE OFF
if the rear doors were opened shortly before or after the vehicle was set to ON.

A reminder appears on the driver information
interface and an alert will sound when the
power mode is set to VEHICLE OFF.

■

Rear Seat Reminder

Rear Seat Reminder

When the power mode is set to VEHICLE OFF, the
reminder comes on briefly, then the function is
deactivated.

The reminder will not work if the power mode has
not been set to ON within 10 minutes of operating
the rear doors.

The system does not detect passengers in the rear
seats. Instead, it can detect when a rear door is
opened and closed, indicating that there may be
something in the rear seats.

You can turn off the notification setting.

Customized Features

P. 327

Honda Passport (2022 year). Manual in english - page 11
