Honda HR-V eHEV (2022 year). Manual in english - page 30

481

Continued

Driving

Parking Your Vehicle

When Stopped

1.

Depress the brake pedal firmly.

2.

With the brake pedal depressed, pull up the electric parking brake switch slowly,
but fully.

3.

Change the shift position to

(

P

.

4.

Turn off the power system.

u

The parking brake and brake system indicator (red) goes off in about 30
seconds.

Always set the parking brake, in particular if you are parked on an incline.

1

Parking Your Vehicle

Do not park your vehicle near flammable objects,
such as dry grass, oil, or timber.
Heat from the exhaust can cause a fire.

3

WARNING

The vehicle can roll away if left unattended
without confirming that Park is engaged.

A vehicle that rolls away could cause a crash
resulting in serious injury or death.

Always keep your foot on the brake pedal
until you have confirmed that

(

P

 is shown

on the shift position indicator.

uu

Parking Your Vehicle

u

When Stopped

482

Driving

1

When Stopped

NOTICE

The following can damage the driveline:

•

Depressing the accelerator and brake pedals
simultaneously.

•

Changing to

(

P

 before the vehicle stops

completely.

When facing uphill, do not hold the vehicle by
depressing the accelerator pedal.
Doing so may cause the power system to overheat
and fail.

In extremely cold temperatures, the parking brake
may freeze up if applied. If such temperatures are
expected, do not apply the parking brake but, if
parking on a slope, either turn the front wheels so
they will contact the curb if the vehicle rolls down the
slope or block the wheels to keep the vehicle from
moving. If you do not take either precaution, the
vehicle may roll unexpectedly, leading to a crash.

483

uu

Parking Your Vehicle

u

Parking Sensor System

Continued

Driving

Parking Sensor System

The corner and centre sensors monitor obstacles around your vehicle, and the
beeper, driver information interface and audio/information screen let you know the
approximate distance between your vehicle and the obstacle.

■

The sensor location and range

1

Parking Sensor System

Even when the system is on, always confirm if there is
no obstacle near your vehicle before parking.

The system may not work properly when:

•

The sensors are covered with snow, ice, mud, or
dirt.

•

The vehicle is on uneven surface, such as grass,
bumps, or a hill.

•

The vehicle has been out in hot or cold weather.

•

The system is affected by devices that emit
ultrasonic waves.

•

Driving in bad weather.

The system may not sense:

•

Thin or low objects.

•

Sonic-absorptive materials, such as snow, cotton,
or sponge.

•

Objects directly under the bumper.

Do not put any accessories on or around the sensors.

When you set the power mode to ON, the system will
be in the previously selected condition.

a

Front Corner Sensors

b

Rear Corner Sensors

c

Front Centre Sensors

d

Rear Centre Sensors

484

uu

Parking Your Vehicle

u

Parking Sensor System

Driving

■

Parking sensor system on and off

With the power mode in ON, press the
parking sensor system button to turn on or off
the system. The indicator in the button comes
on when the system is on.

The front corner, rear centre and rear corner
sensors start to detect an obstacle when the
transmission is in

(

R

, and the vehicle speed is

less than 8 km/h (5 mph).

The front corner and front centre sensors start
to detect an obstacle when the transmission is
in any position other than

(

P

 or

(

R

, and the

vehicle speed is less than 8 km/h (5 mph).

485

uu

Parking Your Vehicle

u

Parking Sensor System

Continued

Driving

■

Screen Operation

The split screen tab disappears, and the split
view returns to the last camera view mode
under the following conditions:

•

If the parking sensor system is turned off.

•

If there is a malfunction in the system.

a

Split View Off

b

Split Screen Tab

c

Split View On

486

uu

Parking Your Vehicle

u

Parking Sensor System

Driving

■

When the distance between your vehicle and obstacles becomes shorter

*1:At this stage, only the centre sensors detect obstacles.

Interval between

beeps

Distance between the Bumper and Obstacle

Indicator

Driver information interface/

Audio/information screen

Corner Sensors

Centre Sensors

Moderate

—

Front: About 100-60 cm

Rear: About 110-60 cm

Yellow

*1

 Comes on

Short

About 60-45 cm

About 60-45 cm

Amber Comes on

Very short

About 45-35 cm

About 45-35 cm

Continuous

About 35 cm or less

About 35 cm or less

Red Comes on

a

Indicators light up where the sensor detects an obstacle.

Audio/information screen

Driver information interface

487

uu

Parking Your Vehicle

u

Parking Sensor System

Driving

1.

Make sure that the parking sensor system is not activated. Set the power mode to
VEHICLE OFF (LOCK).

2.

Press and hold the parking sensor system button, and set the power mode to ON.

3.

Keep pressing the button for 10 seconds. Release the button when the indicator
in the button flashes.

4.

Press the button again. The indicator in the button goes off.

u

The beeper sounds twice. The rear sensors are now turned off.

To turn the rear sensors on again, follow the above procedure. The beeper sounds
three times when the rear sensors come back on.

■

Turning off All Rear Sensors

1

Turning off All Rear Sensors

When you set the shift position to

(

R

, the indicator in

the parking sensor system button blinks as a
reminder that the rear sensors have been turned off.

488

uu

Parking Your Vehicle

u

Cross Traffic Monitor

*

Driving

Cross Traffic Monitor

*

Monitors the rear corner areas using the radar sensors when reversing, and alerts
you if a vehicle approaching from a rear corner is detected.

The system is convenient especially when you are getting out of a parking space
backwards.

1

Cross Traffic Monitor

*

The parking sensor system’s alerting buzzer overrides
the cross traffic monitor buzzer when the sensors are
detecting obstacles at the closest range.

3

WARNING

Cross traffic monitor cannot detect all
approaching vehicles and may not detect
an approaching vehicle at all.

Failure to visually confirm that it is safe to
back up the vehicle before doing so may
result in a collision.

Do not solely rely on the system when
reversing; always also use your mirrors, and
look behind and to the sides of your vehicle
before reversing.

* Not available on all models

Continued

489

uu

Parking Your Vehicle

u

Cross Traffic Monitor

*

Driving

The system activates when:

•

The power mode is in ON.

•

The Cross Traffic Monitor is turned on.

2

Cross Traffic Monitor On and Off

 P. 492

2

Customized Features

 P. 305

•

The transmission is in

(

R

.

•

Your vehicle is moving at 5 km/h (3 mph) or
lower.

When a vehicle is detected approaching from a rear corner, Cross Traffic Monitor
alerts you with a buzzer and a displayed warning.

■

How the System Works

1

Cross Traffic Monitor

*

Cross traffic monitor may not detect or may delay
detecting an approaching vehicle, or may alert
detection without an approaching vehicle under the
following conditions:

•

An obstacle, such as another vehicle and a wall,
near your vehicle’s rear bumper, is blocking the
radar sensor’s scope.

•

Your vehicle is moving at the speed of about 5
km/h (3 mph) or higher.

•

A vehicle is approaching at the speed other than
between about 10 km/h (6 mph) and 25 km/h (16
mph).

•

The system picks up external interference such as
other radar sensors from another vehicle or strong
radio wave transmitted from a facility nearby.

•

Either corner of the rear bumper is covered with
snow, ice, mud or dirt.

•

When there is bad weather.

•

Your vehicle is on an incline.

•

Your vehicle is tilted due to a heavy load in the rear.

•

Your vehicle is reversing towards a wall, a pole, a
vehicle, and so on.

The rear bumper or the sensors have been improperly
repaired or the rear bumper has been deformed.
Have your vehicle checked by a dealer.

a

Radar sensors:
Underneath the rear bumper
corners.

* Not available on all models

uu

Parking Your Vehicle

u

Cross Traffic Monitor

*

490

Driving

The system will not detect a vehicle that approaches from directly behind your
vehicle, nor will it provide alerts about a detected vehicle when it moves directly
behind your vehicle.

The system does not provide alerts for a vehicle that is moving away from your
vehicle, and it may alert for pedestrians, bicycles, or stationary objects.

1

Cross Traffic Monitor

*

For proper operation, always keep the rear bumper
corner area clean.
Do not cover the rear bumper corner area with labels
or stickers of any kind.

* Not available on all models

Continued

491

uu

Parking Your Vehicle

u

Cross Traffic Monitor

*

Driving

An arrow icon appears on the side a vehicle is approaching on the audio/information
screen.

■

When the System Detects a Vehicle

1

When the System Detects a Vehicle

If the

 on the lower right changes to

 in amber

when the transmission is in

(

R

, mud, snow, ice and

other debris may have accumulated in the vicinity of
the sensor. The system is temporarily cancelled.
Check the bumper corners for any obstructions, and
thoroughly clean the area if necessary.

If the

 comes on when the transmission is in

(

R

,

there may be a problem with the Cross Traffic
Monitor system. Do not use the system and have your
vehicle checked by a dealer.

If the display remains the same with the transmission
in

(

R

, there may be a problem with the rear camera

system and the Cross Traffic Monitor system.
Do not use the system and have your vehicle checked
by a dealer.

a

Arrow Icon

b

Normal View

c

Wide View

d

Top Down View

492

uu

Parking Your Vehicle

u

Cross Traffic Monitor

*

Driving

Tap to turn the system on and off. The
indicator comes on with the system on.
You can also switch the system on and off
from the customized feature on the audio/
information screen.

2

Customized Features

 P. 305

■

Cross Traffic Monitor On and Off

a

 Icon

493

Continued

Driving

Multi-View Rear Camera

About Your Multi-View Rear Camera

The audio/information screen can display your vehicle’s rear view. The display
automatically changes to the rear view when the transmission is put into

(

R

.

■

Multi-View Rear Camera Display Area

1

About Your Multi-View Rear Camera

The rear camera view is restricted. You cannot see
the corner ends of the bumper or what is underneath
the bumper. Its unique lens also makes objects
appear closer or farther than they actually are.

Visually confirm that it is safe to drive before backing
up. Certain conditions (such as weather, lighting, and
high temperatures) may also restrict the rear view. Do
not rely on the rearview display which does not give
you all information about conditions at the back of
your vehicle.

If the camera lens is covered with dirt or moisture,
use a soft, moist cloth to keep the lens clean and free
of debris.

a

Camera

b

Approx. 1 m (39 inches)

c

Tailgate open range

uu

Multi-View Rear Camera

u

About Your Multi-View Rear Camera

494

Driving

You can view three different camera modes on the audio/information screen.
Touch the appropriate icon to switch the mode.

•

If you were last using Wide view mode or Normal view mode, the same view
mode will be activated the next time you put the transmission into

(

R

.

•

If you were using Top down view mode before you turned off the power system,
Wide view mode will be activated the next time you set the power mode to ON
and put the transmission into

(

R

.

•

If you were using Top down view mode and 10 seconds elapsed after you took
the transmission out of

(

R

, Wide view mode will be activated the next time you

put the transmission into

(

R

.

1

About Your Multi-View Rear Camera

You can change the

Fixed Guideline

 and

Dynamic

Guideline

 settings.

2

Customized Features

 P. 305

Fixed Guideline
ON:

Guidelines appear when you put the

transmission into

(

R

.

OFF:

Guidelines do not appear.

Dynamic Guideline
ON:

Guidelines move according to the steering

wheel direction.

OFF:

Guidelines do not move.

a

 Wide View Mode

b

 Normal View Mode

c

 Top Down View Mode

d

Bumper

495

Driving

Refueling

Fuel Information

■

Fuel recommendation

Your vehicle is designed to operate on premium unleaded petrol with a research
octane of 95 or higher.
If this octane grade is unavailable, regular unleaded petrol with a research octane of
91 or higher may be used temporarily.
The use of regular unleaded petrol can cause metallic knocking noises in the engine
and will result in decreased engine performance. The long-term use of regular-grade
petrol can lead to engine damage.

■

Fuel tank capacity: 40 L (8.8 Imp gal)

EN 228 standards petrol/gasohol fuel

Unleaded premium petrol/gasohol up to E10 (90% petrol and 10%
ethanol), research octane number 95 or higher

1

Fuel Information

NOTICE

Use of petrol that contains lead presents the
following risks:

•

Damage to the exhaust system including the
catalytic converter

•

Damage to the engine and fuel system

•

Detrimental effects on the engine and other
systems

Oxygenated Fuels

Oxygenated fuels are blended with petrol and
ethanol or other compounds. Your vehicle is also
designed to operate on oxygenated fuels containing
up to 10% ethanol by volume and up to 22% ETBE
by volume, based on the EN 228 standards. For more
information, ask your dealer.

496

uu

Refueling

u

How to Refuel

Driving

How to Refuel

1.

Stop your vehicle with the service station
pump on the left side of the vehicle in the
rear.

2.

Turn off the power system.

3.

Pull on the fuel fill door release handle
under the driver’s side lower outside corner
of the dashboard.

u

The fuel fill door opens.

4.

Remove the fuel fill cap slowly. If you hear a
release of air, wait until this stops, then turn
the knob slowly to open the fuel fill cap.

1

How to Refuel

The filler nozzle automatically stops to leave space in
the fuel tank so that fuel does not overflow as a result
of changes in air temperature.

Do not continue to add fuel after the filler nozzle has
automatically stopped. Additional fuel can exceed
the full tank capacity.

3

WARNING

Petrol is highly flammable and explosive.
You can be burned or seriously injured
when handling fuel.

•

Turn the power system off, and keep
heat, sparks, and flames away.

•

Handle fuel only outdoors.

•

Wipe up spills immediately.

a

Fuel Fill Door Release Handle

b

Pull

a

Cap
