465

uu

Honda Sensing

u

Traffic Sign Recognition System

Continued

Driving

■

The position or the condition of the traffic sign

•

The sign is in a place that makes it hard to find.

•

The sign is located far away from your vehicle.

•

The sign is located where it is hard for headlight beams to reach.

•

The sign is on a corner or bend in the road.

•

The sign is faded or bent.

•

The sign is rotated or damaged signs.

•

The sign is covered with mud, snow, or frost.

•

Part of the sign is hidden by the trees, or is in the shadow of a vehicle or other
object.

•

Light (such as a streetlight) is reflected on the surface of the sign, or it is hidden
in shadow.

•

The sign is too bright or too dark (electric signs).

•

Small signs (auxiliary signs, etc.).

■

Other conditions

•

When you are driving at a high speed.

466

uu

Honda Sensing

u

Traffic Sign Recognition System

Driving

The Traffic Sign Recognition System may not operate correctly, such as displaying
signs that do not adhere to the actual regulations for the roadway or do not exist at
all in the following cases:

u

A speed limit sign may display at a higher or lower speed than the actual speed
limit.

•

There is a supplementary sign with further information such as weather, time,
vehicle type, etc.

•

Figures on the sign are hard to read (electric sign, numbers on the signs are
blurred, etc.).

•

The sign is in the vicinity of the lane you are driving in, even though it is not for
the lane, such as a speed limit sign situated at the junction between the side road
and the main road.

•

There are things that look similar in colour or shape to recognised objects (similar
sign, electric sign, signboard, structure, etc.).

467

uu

Honda Sensing

u

Traffic Sign Recognition System

Driving

Two traffic signs can be simultaneously displayed next to each other when detected.
The speed limit sign icon is displayed on the right half of the screen. The overtaking
prohibition sign icon appears on the left. Any additional sign that indicates speed
limit based on weather (snow, etc.) or specific period of time can appear on either
side.

Depending on situation,

*1

 can be replaced with

*2

, or

*2

 can appear on the right side.

■

Signs Displayed on the Gauge

a

Overtaking Prohibition Sign

*1

b

Speed Limit Sign

c

Additional Speed Limit Sign Based on Conditions

*2

d

Speed Limit Sign

468

uu

Honda Sensing

u

Front Wide View Camera

Driving

Front Wide View Camera

The front wide view camera, used in systems such as Lane Keeping Assist System
(LKAS), Road Departure Mitigation System, Adaptive Cruise Control (ACC) with Low
Speed Follow, Traffic Sign Recognition System, and Collision Mitigation Braking
System (CMBS), is designed to detect an object that triggers any of the systems to
operate its functions.

This front wide view camera is located behind
the rearview mirror.

To help to reduce the likelihood that high
interior temperatures will cause the front wide
view camera’s sensing system to shut off,
when parking, find a shady area or face the
front of the vehicle away from the sun. If you
use a reflective sun shade, do not allow it to
cover the front wide view camera housing.
Covering the front wide view camera can
concentrate heat on it.

■

Front Wide View Camera Location and Handling Tips

1

Front Wide View Camera

Never apply a film or attach any objects to the
windscreen, the bonnet, or the front grille that could
obstruct the front wide view camera’s field of vision
and cause the system to operate abnormally.
Scratches, nicks, and other damage to the
windscreen within the front wide view camera’s field
of vision can cause the system to operate abnormally.
If this occurs, we recommend that you replace the
windscreen with a genuine Honda replacement
windscreen. Making even minor repairs within the
front wide view camera’s field of vision or installing
an aftermarket replacement windscreen may also
cause the system to operate abnormally.
After replacing the windscreen, have a dealer
recalibrate the front wide view camera. Proper
calibration of the front wide view camera is necessary
for the system to operate properly.

Do not place an object on the top of the instrument
panel. It may reflect onto the windscreen and prevent
the system from detecting lane lines properly.

a

Front Wide View Camera

469

uu

Honda Sensing

u

Front Wide View Camera

Driving

1

Front Wide View Camera

If the

 message appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use demister mode
with the air flow directed towards the front wide
view camera.

•

Start driving the vehicle to lower the windscreen
temperature, which cools down the area around
the front wide view camera.

If the



Some Driver Assist System Cannot

Operate: Clean Front Windscreen Or Poor
Viewing Condition.

 message appears:

•

 Park your vehicle in a safe place, and make sure
the windscreen is clean.
Clean the windscreen if it is dirty. If the message
does not disappear after driven for a while, have
your vehicle checked by a dealer.

470

uu

Honda Sensing

u

Sonar Sensors

Driving

Sonar Sensors

■

Location and range of sensors

The sonar sensors are situated in the front and rear bumpers.

1

Sonar Sensors

For the sonar sensors to work properly, do not:

•

Place stickers or other objects on or around the
sensors.

•

Hit the area around the sensors.

•

Attempt to take apart any sensor.

•

Put any accessories on or around the sensors.

Consult with a dealer if:

•

A sensor has been subjected to shock.

•

Work needs to be done to the area around a
sensor.

In the following cases, the sonar sensors may not
work properly. Have your vehicle checked by a dealer.

•

The front or rear bumper has made contact with a
hill, parking block, curb, embankment, etc.

•

The vehicle has been involved in frontal or rear
collision.

•

The vehicle has been driven through a deep
puddle.

a

Sonar Sensors

a

Sonar Range

471

Continued

Driving

Braking

Brake System

Use the parking brake to keep the vehicle stationary when parked. When the
parking brake is applied, you can manually or automatically release it.

■

To apply

The electric parking brake can be applied any
time the vehicle has 12-volt battery, no matter
which position the power mode is in.

Pull the electric parking brake switch up gently
and securely.

u

The indicator in the switch comes on.

u

The parking brake and brake system
indicator (red) comes on.

■

To release

The power mode must be in ON in order to
release the electric parking brake.

1.

Depress the brake pedal.

2.

Press the electric parking brake switch.

u

The indicator in the switch goes off.

u

The parking brake and brake system
indicator (red) goes off.

Manually releasing the parking brake using
the switch helps your vehicle start slowly and
smoothly when facing downhill on steep hills.

■

Parking Brake

1

Brake System

When you depress the brake pedal, you may hear a
whirring sound from the engine compartment. This is
because the brake system is in operation, and it is
normal.

1

Parking Brake

You may hear the electric parking brake system
motor operating from the rear wheel area when you
apply or release the parking brake. This is normal.

The brake pedal may slightly move due to the electric
parking brake system operation when you apply or
release the parking brake. This is normal.

You cannot apply or release the parking brake if the
12-volt battery goes dead.

2

If the 12-Volt Battery Is Dead

 P. 587

If you pull up and hold the electric parking brake
switch while driving, the brakes on all four
wheels are applied by the electric servo brake
system until the vehicle comes to a stop. The
electric parking brake then applies, and the
switch should be released.

a

Electric Parking Brake Switch

a

Electric Parking Brake Switch

uu

Braking

u

Brake System

472

Driving

■

Automatic parking brake feature operation

If the automatic parking brake feature has been activated:

•

The parking brake is applied automatically when you set the power mode to OFF.

•

To confirm that the parking brake is applied, check if the parking brake and brake
system indicator is (red) on.

2

Activating and deactivating the automatic parking brake feature

 P. 473

■

To release automatically

Depressing the accelerator pedal releases the parking brake.
Use the accelerator pedal to release the parking brake when you are starting the
vehicle facing uphill, or in a traffic jam.

Gently depress the accelerator pedal.
When on a hill, it may require more
accelerator input to release.

u

The parking brake and brake system
indicator (red) goes off.

You can release the parking brake automatically when:

•

You are wearing the driver’s seat belt.

•

The power system is on.

•

The transmission is not in

(

P

 or

(

N

.

1

Parking Brake

In the following situations, the parking brake
automatically operates.

•

When the vehicle stops more than 10 minutes
while ACC with Low Speed Follow is activated.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped automatically by ACC with
Low Speed Follow.

•

When the power system is turned off while ACC
with Low Speed Follow is activated.

•

When the vehicle stops with the automatic brake
hold system activated for more than 10 minutes.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped and brake hold is applied.

•

When the power system is turned off while brake
hold is applied.

•

When there is a problem with the Brake Hold
System while brake hold is applied.

If the parking brake cannot be released
automatically, release it manually.

When the vehicle is travelling uphill, the accelerator
pedal may need to be pressed farther to
automatically release the electric parking brake.

a

Accelerator Pedal

Continued

473

uu

Braking

u

Brake System

Driving

■

Activating and deactivating the automatic parking brake feature

With the power mode in ON, carry out the following steps to either activate or
deactivate the automatic parking brake feature.

1.

Put the transmission into

(

P

.

2.

Without depressing the brake pedal, pull up the electric parking brake switch.

u

Check that the parking brake and brake system indicator has come on.

3.

Pull up and hold the parking brake switch. When you hear a beeping sound,
release the switch and within 3 seconds pull up and hold the switch again.

4.

When you hear a sound indicating that the procedure is completed, release the
switch.

u

Two beeps indicates that the feature has been activated.

u

One beep indicates that the feature has been deactivated.

u

When you have completed activating the feature, the parking brake will
remain applied after you turn off the power system.

u

To confirm that the parking brake is applied, check if the parking brake and
brake system indicator (red) is on.

If you need to temporarily deactivate the feature while having your vehicle towed,
you can follow the procedure explained below.

1.

Depress the brake pedal and bring the vehicle to a stop.

2.

Set the power mode to OFF and then within 2 seconds push down the electric
parking brake switch.

u

Activation and deactivation settings for the feature will not be affected.

u

Before temporarily deactivating the feature, make sure to first turn off the
automatic brake hold system.

u

To confirm that the parking brake is applied, check if the parking brake and
brake system indicator (red) is on.

1

Parking Brake

The parking brake cannot be released automatically
while the following indicators are on:

•

Malfunction indicator lamp

•

Transmission system indicator

The parking brake may not be released automatically
while the following indicators are on:

•

Power system indicator

•

Parking brake and brake system indicator (amber)

•

VSA system indicator

•

ABS

 indicator

•

Supplemental restraint system indicator

1

Activating and deactivating the automatic parking brake feature

In cold climates, the parking brake may freeze in
place if applied.

When parking the vehicle, chock the wheels and
make sure the automatic parking brake feature is
deactivated.

Also, when putting your vehicle through a conveyor-
type car wash or when having your vehicle towed,
deactivate the automatic parking brake feature and
leave the parking brake released.

uu

Braking

u

Brake System

474

Driving

Your vehicle is equipped with disc brakes at all four wheels. The brake assist system
increases the stopping force when you depress the brake pedal hard in an
emergency situation. The anti-lock brake system (ABS) helps you to retain steering
control when braking very hard.

2

Brake Assist System

 P. 479

2

Anti-lock Brake System (ABS)

 P. 478

■

Foot Brake

1

Foot Brake

Check the brakes after driving through deep water,
or if there is a buildup of road surface water. If
necessary, dry the brakes by lightly depressing the
pedal several times.

If you hear a continuous metallic friction sound when
applying the brakes, the brake pads need to be
replaced. Have your vehicle checked by a dealer.

Constantly using the brake pedal while going down a
long hill builds up heat, which reduces the brake
effectiveness. Apply regenerative braking by taking
your foot off the accelerator pedal and shifting to
position .

Do not rest your foot on the brake pedal while
driving, as it will lightly apply the brakes and cause
them to lose effectiveness over time and reduce pad
life. It will also confuse drivers behind you.

B

Continued

475

uu

Braking

u

Brake System

Driving

Keeps the brake applied after releasing the brake pedal until the accelerator pedal is
pressed. You can use this system while the vehicle is temporarily stopped, like at
traffic lights and in heavy traffic.

■

Turning on the system

Fasten your seat belt properly, then start the
power system. Press the automatic brake hold
button.

u

The automatic brake hold system
indicator comes on. The system is turned
on.

The system is in the previously selected on or
off setting each time you fasten the driver’s
seat belt and start the power system.

■

Automatic Brake Hold

1

Automatic Brake Hold

3

WARNING

Activating the automatic brake hold system
on steep hills or slippery roads may still
allow the vehicle to move if you remove
your foot from the brake pedal.

If a vehicle unexpectedly moves, it may
cause a crash resulting in serious injury or
death.

Never activate the automatic brake hold
system or rely on it to keep a vehicle from
moving when stopped on a steep hill or
slippery roads.

3

WARNING

Using the automatic brake hold system to
park the vehicle may result in the vehicle
unexpectedly moving.

If a vehicle moves unexpectedly, it may
cause a crash, resulting in serious injury or
death.

Never leave the vehicle when braking is
temporarily kept by automatic brake hold
and always park the vehicle by putting the
transmission in

(

P

 and applying the parking

brake.

a

Automatic Brake Hold Button

b

Comes On

uu

Braking

u

Brake System

476

Driving

■

Activating the system

Depress the brake pedal to come to a
complete stop. The shift lever must not be in

(

P

 or

(

R

.

u

The automatic brake hold indicator
comes on. Braking is kept for up to 10
minutes.

u

Release the brake pedal after the
automatic brake hold indicator comes
on.

■

Cancelling the system

Depress the accelerator pedal while the shift
lever is in a position other than

(

P

 or

(

N

. The

system is cancelled and the vehicle starts to
move.

u

The automatic brake hold indicator goes
off. The system continues to be on.

1

Automatic Brake Hold

3

WARNING

When using the automatic brake hold,
keep your foot on the brake pedal until the
automatic brake hold indicator comes on.

If the vehicle unexpectedly moves, it may
cause a crash resulting in serious injury or
death.

Release your foot from the brake pedal
after the automatic brake hold indicator
comes on.

a

Brake Pedal

b

On

c

Comes On

a

Accelerator Pedal

b

On

c

Goes Off

477

uu

Braking

u

Brake System

Driving

■

The system automatically cancels when:

•

You engage the parking brake.

•

You depress the brake pedal and put the transmission into

(

P

 or

(

R

.

■

The system automatically cancels and the parking brake is applied when:

•

Braking is kept for more than 10 minutes.

•

The driver’s seat belt is unfastened.

•

The power system is turned off.

•

There is a problem with automatic brake hold system.

■

Turning off the automatic brake hold system

While the system is on, press the automatic
brake hold button again.

u

The automatic brake hold system
indicator goes off.

If you want to turn off automatic brake hold
while the system is in operation, press the
automatic brake hold button with the brake
pedal depressed.

1

Automatic Brake Hold

While the system is activated, you can turn off the
power system or park the vehicle through the same
procedure as you normally do.

2

When Stopped

 P. 481

You may hear an operating noise if the vehicle moves
while the automatic brake hold system is in
operation.

1

Turning off the automatic brake hold system

Make sure to turn off the automatic brake hold
system before using an automated car wash.

If you turn off the power system or unfasten the
driver’s seat belt while the automatic brake hold
system is on, the automatic brake hold system will
automatically turn off.
In this case, when the driver’s seat belt is fastened
and the power system is turned back on, the
automatic brake hold system will turn on without
needing to press the automatic brake hold button.

a

Automatic Brake Hold Button

b

Goes Off

478

uu

Braking

u

Anti-lock Brake System (ABS)

Driving

Anti-lock Brake System (ABS)

Helps to prevent the wheels from locking up, and helps you to retain steering
control by pumping the brakes rapidly, much faster than you can.

The electronic brake distribution (EBD) system, which is part of the ABS, also
balances the front-to-rear braking distribution according to vehicle loading.

You should never pump the brake pedal. Let the ABS work for you by always
keeping firm, steady pressure on the brake pedal. This is sometimes referred to as
“stomp and steer.”

■

ABS operation

The brake pedal may pulsate slightly when the ABS is working. Depress the brake
pedal and keep holding the pedal firmly down. On dry pavement, you will need to
press on the brake pedal very hard before the ABS activates. However, you may feel
the ABS activate immediately if you are trying to stop on snow or ice.

ABS may activate when you depress the brake pedal when driving on:

•

Wet or snow covered roads.

•

Roads paved with stone.

•

Roads with uneven surfaces, such as potholes, cracks, manholes, etc.

When the vehicle speed goes under 10 km/h (6 mph), the ABS stops.

■

ABS

1

Anti-lock Brake System (ABS)

NOTICE

The ABS may not function correctly if you use a tyre
of the incorrect size or type.

If the

ABS

 indicator comes on while driving, there

may be a problem with the system.
While normal braking will not be affected, there is a
possibility that the ABS will not be operating. Have
your vehicle checked by a dealer immediately.

The ABS is not designed for the purpose of reducing
the time or distance it takes for a vehicle to stop: It is
designed to limit brake lockup which can lead to
skidding and loss of steering control.

In the following cases, your vehicle may need more
distance to stop than a vehicle without the ABS:

•

You are driving on rough or uneven road surfaces,
such as gravel or snow.

•

The tyres are equipped with tyre chains.

The following may be observed with the ABS system:

•

Motor sounds coming from the engine
compartment when the brakes are applied, or
when system checks are being performed after the
power system has been started and while the
vehicle accelerates.

•

Brake pedal and/or the vehicle body vibration when
ABS activates.

These vibrations and sounds are normal to ABS
systems and are no cause for concern.

479

uu

Braking

u

Brake Assist System

Driving

Brake Assist System

Is designed to assist the driver by generating greater braking force when you depress
the brake pedal hard during emergency braking.

■

Brake assist system operation

Press the brake pedal firmly for more powerful braking.

When brake assist operates, the pedal may wiggle slightly and an operating noise
may be heard. This is normal. Keep holding the brake pedal firmly down.

480

uu

Braking

u

Emergency Stop Signal

Driving

Emergency Stop Signal

Activates when you brake hard while driving at 60 km/h (37 mph) or above to alert
drivers behind you about sudden braking by rapidly flashing hazard warning lights.
This may help to alert drivers behind you to take appropriate means to avoid a
possible collision with your vehicle.

■

When the system activates:

The hazard warning lights stop flashing when:

•

You release the brake pedal.

•

The ABS is deactivated.

•

Your vehicle’s decelerating speed becomes moderate.

•

You press the hazard warning button.

1

Emergency Stop Signal

The emergency stop signal is not a system that can
prevent a possible rear-end collision caused by your
hard braking. It flashes the hazard warning lights at
the time you are braking hard. It is always
recommended to avoid hard braking unless it is
absolutely necessary.

The emergency stop signal does not activate with the
hazard warning button pressed in.

If the ABS stops working for a certain period during
braking, the emergency stop signal may not activate
at all.

a

Hard Braking

b

Brake Lights Come On

c

Hazard Warning Lights Flash

d

Hazard Warning Indicators Blink
