207

Continued

Co
ntrols

Seats

Front Seats

Adjust the driver’s seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately press the pedals without leaning
forward, and grip the steering wheel
comfortably. The passenger’s seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

1

Seats

Always make seat adjustments before driving.

1

Front Seats

In addition to the seat adjustment, you can adjust the
steering wheel up and down, in and out. Allow at
least 25 cm (10 inches) between the centre of the
steering wheel and the chest.

3

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back to allow sufficient
space.

uu

Seats

u

Front Seats

208

Co
ntrols

■

Adjusting the front manual seat

■

Adjusting the Seat Positions

1

Adjusting the front manual seat

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

a

Horizontal Position Adjustment

Pull up on the bar to move the seat, then release the bar.

b

Seat-back Angle Adjustment

Pull up the lever to change the angle.

c

Height Adjustment (Driver’s side only)

Pull up or push down the lever to raise or lower the seat.

209

uu

Seats

u

Front Seats

Co
ntrols

Adjust the driver’s seat-back to a comfortable,
upright position, leaving ample space
between your chest and the airbag cover in
the centre of the steering wheel.

The front seat passenger should also adjust
their seat-back to a comfortable, upright
position.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the
occupant’s chest reduces the protective capability of the belt. It also increases the
chance of sliding under the belt in a crash and being seriously injured. The farther a
seat-back is reclined, the greater the risk of injury.

■

Adjusting the Seat-Backs

1

Adjusting the Seat-Backs

Do not put a cushion, or other object, between the
seat-back and your back.

Doing so may interfere with proper seat belt or airbag
operation.

If you cannot get far enough away from the steering
wheel and still reach the controls, we recommend
that you investigate whether some type of adaptive
equipment may help.

3

WARNING

Reclining the seat-back too far can result in
serious injury or death in a crash.

Adjust the seat-back to an upright position,
and sit well back in the seat.

210

uu

Seats

u

Rear Seats

Co
ntrols

Rear Seats

1.

Store the centre seat belt first. Insert the
latch plate into the slot on the side of the
anchorage buckle.

2.

Retract the seat belt into the holder on the
ceiling.

2

Seat Belt with Detachable Anchorage



P. 53

3.

Lower the rear seat head restraint to its
lowest position.

4.

Pull the release lever and fold down the
seat.

■

Folding Down the Rear Seats

1

Folding Down the Rear Seats

The rear seat-backs can be folded down to
accommodate bulkier items in the luggage area.

When returning the seat-back to its original position,
push it firmly back. Also, make sure all rear shoulder
belts are positioned in front of the seat-back.

Make sure all items in the luggage area or items
extending through the opening into the rear
seats are properly secured. Loose items can fly
forward if you have to brake hard.

3

WARNING

Make sure the seat-backs are latched
securely before driving.

a

Latch Plate

b

Anchorage Buckle

a

Release Lever

Continued

211

uu

Seats

u

Rear Seats

Co
ntrols

Separately lift up the left and right rear seat
cushions to make room for luggage area.

■

Lifting up the seat cushion

1.

Make sure the seat belt buckles are in their
loops on the seat.

2.

Pull up the rear seat cushion.

3.

Fold the seat leg down while pushing the
seat cushion firmly against the seat-back to
lock it.

■

Folding Up the Rear Seat

1

Folding Up the Rear Seat

After you fold the seat up, or put it back in the
original position, make sure the seat is firmly secured
by rocking it forward and back.

Check if there are any items on the seat before you
pull the seat cushion up. Check if there are any
obstacles around the floor guide before you put the
seat-back in the original position.

a

Loop

a

Seat Leg

212

uu

Seats

u

Rear Seats

Co
ntrols

■

Putting the seat in the original position

1.

Hold the seat cushion in place with one
hand, then unlock it by pulling up the seat
leg fully with your other hand.

u

Hold the seat cushion firmly, as it may
abruptly fall when you unlock it.

2.

Slowly lower the seat cushion, and set the
seat leg in the floor guide until it latches in
place.

a

Seat Leg

b

Floor Guide

c

Latch

213

uu

Seats

u

Rear Seat Reminder

Co
ntrols

Rear Seat Reminder

This feature alerts you to the possible presence of passengers or items in the rear
seats before you exit the vehicle. It activates when the vehicle is set to VEHICLE OFF
if the rear doors were opened shortly before or after the vehicle was set to ON.

A reminder appears on the driver information
interface and an alert will sound when the
power mode is set to VEHICLE OFF.

1

Rear Seat Reminder

When the power mode is set to VEHICLE OFF, the
reminder comes on briefly, then the function is
deactivated.

The reminder will not work if the power mode has
not been set to ON within 10 minutes of operating
the rear doors.

The system does not detect passengers in the rear
seats. Instead, it can detect when a rear door is
opened and closed, indicating that there may be
something in the rear seats.

You can turn off the notification setting.

2

How to Customize the Vehicle Settings



P. 312

214

uu

Seats

u

Maintain a Proper Sitting Position

Co
ntrols

Maintain a Proper Sitting Position

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor, until the vehicle is safely parked and the power
mode is off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.

In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

1

Maintain a Proper Sitting Position

3

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

215

uu

Seats

u

Head Restraints

Continued

Co
ntrols

Head Restraints

Your vehicle is equipped with head restraints in all seating positions.

Head restraints are most effective for
protection against whiplash and other rear-
impact crash injuries when the centre of the
back of the occupant’s head rests against the
centre of the restraint. The tops of the
occupant’s ears should be level with the
centre height of the restraint.

To raise the head restraint:

Pull it upward.

To lower the head restraint:

Push it down while pressing the release
button.

■

Adjusting the Front Head Restraints

1

Adjusting the Front Head Restraints

In order for the head restraint system to work
properly:

•

Do not hang any items on the head restraints, or
from the restraint legs.

•

Do not place any objects between an occupant and
the seat-back.

•

Install each restraint in its proper location.

3

WARNING

Improperly positioning head restraints
reduces their effectiveness and increases
the likelihood of serious injury in a crash.

Make sure head restraints are in place and
positioned properly before driving.

Position head in the centre of the
head restraint.

uu

Seats

u

Head Restraints

216

Co
ntrols

A passenger sitting in the rear seat seating
position should adjust the height of their head
restraint to an appropriate position before the
vehicle begins moving.

To raise the head restraint:

Pull it upward.

To lower the head restraint:

Push it down while pressing the release
button.

■

Changing the Rear Seat Head Restraint Position

1

Changing the Rear Seat Head Restraint Position

When you use the head restraint in the rear seating
position, pull up the head restraint to its highest
position. Do not use it in any lower position.

217

uu

Seats

u

Head Restraints

Co
ntrols

Head restraints can be removed for cleaning or repair.

To remove a head restraint:

Pull the restraint up as far as it will go. Then, push the release button and pull the
restraint up and out.

To reinstall a head restraint:

Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

■

Removing and Reinstalling the Head Restraints

1

Removing and Reinstalling the Head Restraints

3

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

218

uu

Seats

u

Armrest

Co
ntrols

Armrest

Pull down the armrest in the centre seat-back.

■

Using the Rear Seat Armrest

219

Continued

Co
ntrols

Interior Convenience Items

Interior Lights

■

ON

The interior lights come on regardless of
whether the doors are open or closed.

■

Door activated

The interior lights come on in the following
situations:

•

When any doors are opened.

•

You unlock the driver’s door.

•

When the power mode is set to VEHICLE
OFF.

■

OFF

The interior lights remain off regardless of
whether the doors are open or closed.

■

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after about 30 seconds in the
following situations:

•

When you unlock the driver’s door but do not open
it.

•

When you set the power mode to VEHICLE OFF but
do not open a door.

You can change the interior lights dimming time.

2

How to Customize the Vehicle Settings



P. 312

The interior lights go off immediately in the following
situations:

•

When you lock the driver’s door.

•

When you close the driver’s door in ACCESSORY
mode.

•

When you set the power mode to ON.

If you leave any of the doors open in VEHICLE OFF
mode, the interior lights go off after about 15
minutes.

To avoid draining the 12-volt battery, do not leave
the interior light on for an extended length of time
when the power system is off.

a

Door Activated Position

b

On

c

Off

uu

Interior Convenience Items

u

Interior Lights

220

Co
ntrols

■

Front seat

The map lights can be turned on and off by
pressing the buttons.

■

Rear seat

The map lights can be turned on and off by
touching the map lights.

■

Map Light Switches

1

Map Light Switches

When the front interior light switch is in the door
activated position and any door is open, the map
light will not go off when you press the buttons or
touch the map lights.

a

Touch

221

uu

Interior Convenience Items

u

Interior Lights

Co
ntrols

The luggage area lights come on when you
open the tailgate.

■

Luggage Area Lights

222

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

Storage Items

Pull the handle to open the glove box.

Pull the knob to open the console box.

■

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

■

Console Box

a

Knob
