Continued

223

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

■

Front seat beverage holders

Are located in the console between the front
seats.

■

Front door side beverage holders

Are located on the both of front door side
pockets.

■

Rear door side beverage holders

Are located on the both of rear door.

■

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

uu

Interior Convenience Items

u

Storage Items

224

Co
ntrols

■

Rear seat beverage holders

Fold the armrest down to use the rear seat
beverage holders.

There are coat hooks on the rear left and right
grab handles.

■

Coat Hooks

1

Coat Hooks

The coat hooks are not designed for large or heavy
items.

Continued

225

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

The tie-down anchorages on the luggage area
floor can be used to install a net for securing
items.

The luggage hook in the luggage area can be
used to hang a light items.

■

Tie-down Anchorages

1

Tie-down Anchorages

Do not let anyone access items in the luggage area
while driving. Loose items can cause injury if you have
to brake hard.

a

Anchorages

b

Anchorages

*

■

Luggage Hook

1

Luggage Hook

NOTICE

Do not hang a large object or an object that weighs
more than 3 kg (6 lbs) on the side luggage hook.
Hanging heavy or large objects may damage the
hook.

* Not available on all models

uu

Interior Convenience Items

u

Storage Items

226

Co
ntrols

Pull the strap to open the luggage floor lid.

There is a rubber band on the back of the
luggage floor lid. You can hang the string
attached to the lid on the luggage hook and
let it stand while carrying parcels in or out.

■

Under-floor Storage Area

1

Under-floor Storage Area

Do not drive with the lid upright.

This may cause unforeseeable accident or injury at
sudden braking.

3

WARNING

Do not pull out or push in parcels while
driving.

This may cause unforeseeable accident or
injury at sudden braking.

a

Strap

b

Luggage Floor Lid

c

Luggage Floor Box

a

Luggage Floor Lid

b

Rubber Band

c

Luggage Hook

Models with Rubber Band

Continued

227

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

The luggage area cover can be removed to give you more luggage room.

■

To remove the luggage area cover

1.

Open the tailgate.

2.

Remove the luggage area cover from hooks
on both sides.

3.

Remove the cover from the guide while
keeping the tab depressed.

Reverse this procedure to install the
luggage area cover.

After reinstalling the luggage area cover,
make sure it is latched securely.

■

To store the luggage area cover

1.

Hold the corner near the tag on the cover.

■

Luggage Area Cover

1

Luggage Area Cover

Do not place items on the luggage area cover, or
stack objects higher than the top of the back seat.
They could block your view and be thrown around
the vehicle during a crush or sudden stop.

When removing the luggage area cover, hold it firmly
with your hands as it may open vigorously. Carefully
check the surrounds and slowly open the cover while
holding it firmly with both hands.

a

Hooks

b

Tab

c

Guide

a

Tag

228

uu

Interior Convenience Items

u

Storage Items

Co
ntrols

2.

Hold both corners of the luggage area
cover with your arms crossed one on the
other and fold the cover.

3.

Bring both circular halves together in
perfect alignment.

4.

Store the luggage area cover in the back
pocket of the front seat while keeping it
firmly pushed by hand.

229

uu

Interior Convenience Items

u

Other Interior Convenience Items

Continued

Co
ntrols

Other Interior Convenience Items

The sun visor can be extended horizontally.

■

Sun Visor

uu

Interior Convenience Items

u

Other Interior Convenience Items

230

Co
ntrols

The accessory power socket can be used when the power mode must be in
ACCESSORY or ON.

■

Console panel

Open the cover to use it.

■

Accessory Power Socket

1

Accessory Power Socket

NOTICE

Do not insert an automotive type cigarette lighter
element. This can overheat the accessory power
socket.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent 12-volt battery drain, only use the
accessory power socket with the power system on.

When the accessory power socket is not in use, close
the cover to prevent any small foreign objects from
getting into the accessory power socket.

Continued

231

uu

Interior Convenience Items

u

Other Interior Convenience Items

Co
ntrols

To use the wireless charger, the power mode must be in ACCESSORY or ON.
Charge any devices compatible with Qi wireless charging on the area indicated by
the

 mark as follows:

1.

To turn the system on and off, press and
hold the

 (power) button.

u

When the system is activated, the green
indicator light comes on.

2.

Place the device you want to charge on the
charging area.

u

The system will automatically start
charging the device, and the amber
indicator light will come on.

u

Make sure that the device is compatible
with the system, and placed with the
chargeable side in the centre of the
charging area.

3.

When charging is completed, the green
indicator light will come on.

u

Depending on the device, the amber
indicator light will stay on.

■

Wireless Charger

*

1

Wireless Charger

*

This system consumes a lot of power. Do not use the
system for a long time when the power system is off.
This may weaken the 12-volt battery, making it
difficult to turn the power system on.

When using the wireless charger, check the user’s
manual that came with the compatible device you
want to charge.

 appears on the audio/information screen when

the device is being charged by the wireless charger.

3

WARNING

Metal objects between the charge pad and
the device to be charged will get hot and
can burn you.

•

Always remove foreign objects from the
charge pad before charging the device.

•

Be sure the surface is clear of dust and
other debris before charging.

•

Do not spill liquids (i. e. water, drinks,
etc.) on the charger and the device.

•

Do not use oil, grease, alcohol, benzine or
thinner for cleaning the charge pad.

•

Do not cover the system with towels,
clothing, or other objects while charging
etc.

•

Avoid spraying aerosols which may come
in contact with the charge pad surface.

a

 (Power) Button

b

Green Indicator

c

Amber Indicator

d

Charging Area

* Not available on all models

uu

Interior Convenience Items

u

Other Interior Convenience Items

232

Co
ntrols

■

When charging does not start

Perform one of the solutions in the following table.

Indicator

Cause

Solution

Green

&

Amber

Blinking
simulta-

neously

There is an obstacle(s) between
the charging area and the
device.

Remove the obstacle(s).

The device is not within the
charging area.

Pick up and reset the
device to the centre of
the charging area
where

 is located.

The temperature of the wireless
charger pad increases.

Temporarily suspend
charging the device.
Wait for the
temperature to drop
and attempt to charge
the device again.

Amber

Blinking

The wireless charger is faulty.

Contact a dealer for
repairs.

1

Wireless Charger

*

The wireless charger can support up to 15W, but the
charging rate varies based on the device and other
conditions.

NOTICE

Do not place any magnetic recording media or
precision machines within the charge area while
charging.
The data on your cards such as credit cards can be
lost because of the magnetic effect. Also, precision
machines such as watches can be affected.

“Qi” and

 marks are the registered trademarks

owned by Wireless Power Consortium (WPC).

In the following cases, charging may stop or not start:

•

The device is already fully charged.

•

The temperature of the device is extremely high
while charging.

•

You are at a place that emits strong
electromagnetic waves or noises, such as TV
station, electric power plant, or petrol station.

•

The device has a cover, case or accessories which
are not compatible with wireless charging.

A device may not charge if the size or shape of its
chargeable side is not appropriate for use with the
charging area.

Not all devices are compatible with the system.

During the charging phase, it is normal for the
charging area and the device to heat up.

* Not available on all models

Continued

233

uu

Interior Convenience Items

u

Other Interior Convenience Items

Co
ntrols

1

Wireless Charger

*

Charging may be briefly interrupted when:

•

All doors or the tailgate are closed

- to avoid interference with the proper functioning
of the keyless access system.

•

The position of the device is altered.

Do not charge more than one device at a time on a
charging area.

Burn risk:
Any metal objects placed between pad and device
may become hot.

If the device becomes too hot and its battery
protection function activates, it may charge
extremely slowly or no longer charge. The
temperature at which the battery protection function
activates depends on the device.

* Not available on all models

uu

Interior Convenience Items

u

Other Interior Convenience Items

234

Co
ntrols

The heated steering wheel can be used when
the power mode is in ON.

Press the button on the right side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you turn the power system on, even if
you turned it on the last time you drove the
vehicle.

■

Heated Steering Wheel

*

1

Heated Steering Wheel

*

Do not use the heated steering wheel continuously
when the power system is off. Under such conditions,
the 12-volt battery may be weakened, making it
difficult to turn the power system on.

* Not available on all models

235

uu

Interior Convenience Items

u

Other Interior Convenience Items

Co
ntrols

The seat heaters can be used when the power
mode is in ON.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

When the power mode is turned on after it is
turned off, the previous setting is maintained.

■

Front Seat Heaters

1

Front Seat Heaters

Do not use the seat heaters even in LO when the
power system is off. Under such conditions, the 12-
volt battery may be weakened, making the power
system difficult to start.

After a certain period of time, the strength setting for
the seat heater will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lowerlimb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

236

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the power system is on.

1.

Press the

AUTO

 button.

2.

Adjust the interior temperature using the temperature control dial.

3.

Press the

 (on/off) button to cancel.

*1:Left-hand drive types shown. For the right-hand drive types, these buttons are

located at the symmetrically opposite to the left-hand drive type.

1

Using Automatic Climate Control

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.

The

AUTO

 indicator will go off, but functions

unrelated to the button that were pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the

AUTO



button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit,

Lo

 or

Hi

 is displayed.

Pressing the

 button switches the climate control

system between on and off. When turned on, the
system returns to your last selection.

While ECON mode is active, the climate control
system may have reduced cooling performance.

The High Voltage battery level being low may reduce
the climate control system performance.

Models without SYNC button

a

AUTO

 Button

*1

h

MODE Control Dial

•

 Air flows from dashboard vents

•

 Air flows from dashboard and

floor vents

•

 Air flows from floor vents

•

 Air flows from floor and

windscreen demister vents

b

Temperature Control Dial

*1

c

Fan Control Dial

*1

d

ON/OFF

 Button

*1

e

A/C

 (Air Conditioning) Button

*1

f

 (Recirculation) Button

*1

g

 (Windscreen Demister) Button

*1

237

uu

Climate Control System

u

Using Automatic Climate Control

Continued

Co
ntrols

*1:Left-hand drive types shown. For the right-hand drive types, these buttons are

located at the symmetrically opposite to the left-hand drive type.

Models with SYNC button

a

AUTO

 Button

*1

j

MODE

 Control Button

*1

•

 Air flows from dashboard vents

•

 Air flows from dashboard and

floor vents

•

 Air flows from floor vents

•

 Air flows from floor and

windscreen demister vents

b

Driver’s Side Temperature Control
Dial

*1

c

Passenger’s Side Temperature Control
Dial

*1

d

Fan Control Dial

*1

e

ON/OFF

 Button

f

A/C

 (Air Conditioning) Button

*1

g

 (Recirculation) Button

*1

h

 (Windscreen Demister) Button

*1

i

SYNC

 (Synchronization) Button

*1

238

uu

Climate Control System

u

Using Automatic Climate Control

Co
ntrols

■

Switching between the recirculation and fresh air modes

Press the

 (recirculation) button and switch the mode depending on

environmental conditions.
Recirculation mode (indicator on): Recirculates air from the vehicle’s interior
through the system.
Fresh air mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.
