175

uu

Security System

u

Security System Alarm

Co
ntrols

Security System Alarm

The security system alarm activates when the tailgate, bonnet, or doors are forcibly
opened. The alarm does not activate if the tailgate or doors are opened with the
remote transmitter or keyless access system.

■

When the security system alarm activates

The horn sounds intermittently and all the exterior lights flash.

■

To deactivate the security system alarm

Unlock the vehicle using the remote transmitter or keyless access system, or turn the
power mode to ON. The system, along with the horn and flashing lights, is
deactivated.

■

Setting the security system alarm

The security system alarm automatically sets when the following conditions have
been met:

•

The power mode is set to VEHICLE OFF.

•

The bonnet is closed.

•

All doors and the tailgate are locked from outside with the key, remote
transmitter, or keyless access system.

■

When the security system alarm sets

The security system alarm indicator in the instrument panel blinks and the blinking
interval changes after about 15 seconds.

■

To cancel the security system alarm

The security system alarm is cancelled when the vehicle is unlocked using the remote
transmitter or keyless access system, or when the power mode is set to ON. The
security system alarm indicator goes off at the same time.

1

Security System Alarm

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

The security system alarm will continue for
approximately 5 minutes before the security system
deactivates.
The system will go through ten 30-second cycles,
during which the horn will sound and the security
system alarm indicator will flash.
Depending on circumstances, the security system
may continue operating for more than 5 minutes.

Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:

•

Unlocking the door with the lock tab.

•

Opening the bonnet with the bonnet release
handle.

•

Opening the tailgate with the power tailgate
button on the dashboard.

If the 12-volt battery goes dead after you have set the
security system alarm, the security alarm may go off
once the 12-volt battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the remote transmitter or
keyless access system.

If you unlock a door with the built-in key while the
security system is activated, the alarm will go off.

Models with power tailgate

176

uu

Security System

u

Super Locking

*

Co
ntrols

Super Locking

*

The super locking function disables the lock tabs on all doors.

■

To activate the super locking function

•

Turn the key in the driver’s door towards the vehicle front twice within five
seconds.

•

Press the lock button on the remote transmitter twice within five seconds.

•

Touch the door lock sensor on the door handle or press the lock button on the
tailgate twice within five seconds.

■

To cancel the super locking function

Unlock the driver’s door with the remote transmitter or keyless access system.

1

Super Locking

*

If you unlock a door with the built-in key while the
security system is activated, the alarm will go off.

3

WARNING

No one must be inside the vehicle with the
super locking set. Persons locked in can get
seriously sick or die from the heat built
inside the vehicle if left in the sun.

Make sure there is no one inside the vehicle
before setting the super locking.

* Not available on all models

177

Continued

Co
ntrols

Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the power mode is in ON,
using the switches on the doors.

The driver’s side switches can be used to open and close all the windows. The power
window lock button on the driver’s side must be switched off (not pushed in,
indicator off) to open and close the windows from anywhere other than the driver’s
seat.

When the power window lock button is pushed in, the indicator comes on and you
can only operate the driver’s window. Turn the power window lock button on if a
child is in the vehicle.

1

Opening/Closing the Power Windows

WARNING:

Always take the ignition key with you

whenever you leave the vehicle alone or with other
occupants.

The power windows can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF.
Closing driver’s door cancels this function.

Auto Reverse

If a power window senses resistance when closing
automatically, it will stop closing and reverse
direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

3

WARNING

Closing a power window on someone’s
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

178

uu

Windows

u

Opening/Closing the Power Windows

Co
ntrols

■

Manual operation

To open:

Push the switch down lightly, and

hold it until the desired position is reached.

To close:

Pull the switch up lightly, and hold it

until the desired position is reached.

■

Automatic operation

To open:

Push the switch down firmly.

To close:

Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

■

Opening/Closing the Windows with Auto-Open/Close Function

a

Power Window Lock Button

b

Driver’s Window Switch

c

Front Passenger’s Window
Switch

d

Rear Passenger’s Window
Switch

179

uu

Windows

u

Opening/Closing the Power Windows

Co
ntrols

To open:

Press the unlock button, and then

within 10 seconds, press it again and hold it.

To close:

Press the lock button, and then

within 10 seconds, press it again and hold it.

If the windows stop midway, repeat the
procedure.

To close:

Lock the driver’s door with the key.

Within 10 seconds of returning the key to the
central position, turn the key in the lock
direction and hold it there.

Release the key to stop the windows at the
desired position. If you want further
adjustment, repeat the same operation.

■

Opening/Closing the Windows with the Remote

1

Opening/Closing the Windows with the Remote

You can turn the remote window control function on
and off.

2

How to Customize the Vehicle Settings



P. 312

a

Unlock Button

b

Lock Button

■

Closing the Windows with the Key

a

Close

180

Co
ntrols

Operating the Switches Around the Steering Wheel

POWER Button

If you carry the keyless remote and press

POWER

 button without depressing the brake

pedal, the power mode will change in this
order: VEHICLE OFF



ACCESSORY



ON



VEHICLE OFF.

VEHICLE OFF:

Vehicle power is turned OFF.

ACCESSORY:

The audio system and some accessories can be
used.

ON:

All accessories can be used.

■

Changing the Power Mode

1

POWER Button

If the keyless remote is set in a storage box or another
place where its signal can be interrupted, the power
mode may not change.

When the power mode is set to ON, the power mode
will change to ACCESSORY if the

POWER

 button is

pressed while the transmission is in a position other
than

(

P

.

181

uu

Operating the Switches Around the Steering Wheel

u

POWER Button

Continued

Co
ntrols

If you leave the vehicle for 30 to 60 minutes with the transmission in

(

P

 and the

power mode in ACCESSORY, the vehicle automatically goes into the mode similar to
VEHICLE OFF (LOCK) to avoid draining the 12-volt battery.

When in this mode: The steering wheel does not lock. You cannot lock or unlock
doors with the remote transmitter or the keyless access system. Press the

POWER



button twice to switch the mode to VEHICLE OFF (LOCK).

If you open the driver’s door when the power mode is in ACCESSORY, a warning
beep sounds.

■

Automatic Power Off

■

Power Mode Reminder

uu

Operating the Switches Around the Steering Wheel

u

POWER Button

182

Co
ntrols

When the power mode is set to any mode
other than OFF and you remove the keyless
remote from the vehicle and shut the door, an
alarm will sound. If the alarm continues to
sound, place the keyless remote in another
location.

■

When the power mode is in
ACCESSORY

The alarm will sound from outside the vehicle.

■

When the power mode is in ON

An alarm will sound both inside and outside
the vehicle. In addition, a warning indicator
will appear on the instrument panel.

■

Keyless Remote Reminder

1

Keyless Remote Reminder

When the keyless remote is within the system’s
operational range, and all the doors are closed, the
warning function cancels.

If the keyless remote is taken out of the vehicle after
the power system has been turned on, you can no
longer change the

POWER

 button mode or restart

the power system. Always make sure if the keyless
remote is in your vehicle when you operate the

POWER

 button.

Removing the keyless remote from the vehicle
through a window does not activate the warning
buzzer.

Do not put the keyless remote on the dashboard or in
the glove box. It may cause the warning buzzer to go
off. Under some other conditions that can prevent
the vehicle from locating the keyless remote, the
warning buzzer may also go off even if the keyless
remote is within the system’s operational range.

183

uu

Operating the Switches Around the Steering Wheel

u

Lights

Continued

Co
ntrols

Lights

The lights will turn on automatically depending on the ambient brightness. They can
also be switched on and off manually.

The exterior lights will switch on automatically
when the light switch is set to

AUTO

 while

the power mode is in ON.

■

Manual operation

Headlights/position lights:

Turn the light switch to

.

Position lights:

Turn the light switch to

.

Headlight/position lights off:

Turn the light switch to

OFF

 and release it while the transmission is in

(

P

 and the

parking brake is applied.

u

The lights will come back on automatically when:

•

The light switch is turned to

OFF

 again and released.

•

The transmission is changed out of

(

P

 and the parking brake is released.

■

Headlights/Position Lights

1

Lights

When the lights are on, the lights on indicator in the
instrument panel will be on.

2

Lights On Indicator

 P. 111

1

Headlights/Position Lights

When the position lights are on, the tail and rear
licence plate lights will also switch on.

When the light switch is turned to

 or

 and

the power is turned to OFF, a beeper sounds when
the driver’s door is opened.

When the light switch is turned to

AUTO

 and the

ambient light levels are low, the headlights and
position lights will switch on if you unlock a door.
They will switch off when the door is locked.

The light sensor is in the location shown below. Do
not cover the light sensor.

uu

Operating the Switches Around the Steering Wheel

u

Lights

184

Co
ntrols

When the headlights are on, push the lever forward. Pull the lever back to return to
low beams.

■

Flashing the high beams

Pull the lever back to switch on the high
beams.

u

Release the lever to return to low beams.

■

High Beams

1

Headlights/Position Lights

Do not leave the lights on when the power system is
off because it will cause the 12-volt battery to
discharge.

Continued

185

uu

Operating the Switches Around the Steering Wheel

u

Lights

Co
ntrols

The turn signals can be used when the power
mode is in ON.

■

: Turn signal

Push the lever up or down based on the
direction you want to turn, and the turn signal
will blink.

■

: One-touch turn signal

When you lightly push the lever up or down
and release it, the turn signal will blink 3
times.

u

If you lightly push the lever in the
opposite direction while it is blinking, the
blinking will stop.

■

Turn Signals

1

Turn Signals

The turn signal indicator on the instrument panel will
blink when the external turn signal blinks.

2

Indicators

 P. 102

uu

Operating the Switches Around the Steering Wheel

u

Lights

186

Co
ntrols

The headlights automatically come on when the wipers are used several times within
a certain number of intervals with the headlight switch in

AUTO

.

The headlights automatically go off a few minutes later if the wipers are stopped.

The headlights, all other exterior lights, and the instrument panel lights turn off 15
seconds after you set the power mode to VEHICLE OFF, take the keyless remote with
you, and close the driver’s door.

However, when the switch is in

, the position lights remain on.

If you set the power mode to VEHICLE OFF with the headlight switch on, but do not
open the door, the lights turn off after 10 minutes (3 minutes, if the switch is in the

AUTO

 position).

The lights turn on again when you unlock or open the driver’s door. If you unlock
the door, but do not open it within 15 seconds, the lights go off. If you open the
driver’s door, you will hear a reminder chime alerting you that the lights are on.

■

Headlight Integration with Wipers

■

Automatic Lighting Off Feature

1

Headlight Integration with Wipers

This feature activates while the headlights are off in

AUTO

. The instrument panel brightness does not

change when the headlights come on.

At dark ambient light levels, the automatic lighting
control feature turns on the headlights, regardless of
the number of wiper sweeps.

You can turn the headlight integration with wipers
function on and off.

2

How to Customize the Vehicle Settings



P. 312

1

Automatic Lighting Off Feature

You can change the headlight auto off timer setting.

2

How to Customize the Vehicle Settings



P. 312

187

uu

Operating the Switches Around the Steering Wheel

u

Lights

Continued

Co
ntrols

The fog lights can be used when the power mode is in ON.

■

Front fog lights

*

Can be used when the position lights or the headlights are on.

■

Rear fog light

Can be used when the headlights or the front fog lights

*

 are on.

■

Front and rear fog light switch

*

To turn the front fog lights on:

Rotate the switch up from the

OFF

 position to

the

 position. The

 indicator comes on.

To turn the front and rear fog lights on:

Rotate the switch one position up from the



position. The

 and

 indicators come on.

To turn the rear fog lights on:

Rotate the switch one position up from the



position and then rotate the switch one
position down from the

 position. The



indicator stays on.
To turn the rear fog light off, turn the
headlight switch to the

OFF

 position.

■

Fog Lights

* Not available on all models

188

uu

Operating the Switches Around the Steering Wheel

u

Lights

Co
ntrols

■

Rear fog light switch

*

To turn the rear fog lights on:

Rotate the switch to

. The

 indicator

comes on.

* Not available on all models

189

uu

Operating the Switches Around the Steering Wheel

u

Lights

Co
ntrols

The daytime running lights come on when the following conditions have been met:

•

The power mode is in ON.

•

The headlight switch is

AUTO

.

•

The ambient light is bright.

While the vehicle is stopped, if you turn the light switch to

OFF

 and release it, the

daytime running lights will turn off. When the transmission is changed out of

(

P



and the parking brake is released, the lights will come on again. Otherwise, if the
light switch is once more turned to

OFF

, the lights will come on again.

■

Daytime Running Lights

1

Daytime Running Lights

Daytime running lights and the position lights share
the same light source.

Daytime running lights are brighter than the position
lights.

The daytime running lights will not switch on if the
position lights have been turned on manually.

190

uu

Operating the Switches Around the Steering Wheel

u

Active Cornering Lights

*

Co
ntrols

Active Cornering Lights

*

Enhance the visibility of the corner(s) when making a turn. With the power mode in
ON, the headlights on, and the vehicle speed at less than 40 km/h (25 mph), the
cornering light(s) comes on either when operating the turn signals or the steering
wheel, or put the transmission into

(

R

.

■

The corner you are making a turn towards is illuminated when:

1

Active Cornering Lights

*

The active cornering lights go off automatically after
five minutes. To resume the lights on, recreate the
same condition; putting the turn signal lever or
steering wheel in the centre position, then operate it
again, or if the transmission has been in

(

R

, move it

to another position momentarily.

a

 Active Cornering Lights

a

You operate the turn signal lever.

b

You turn the steering wheel around 70 degrees or more.

c

Headlight beam coverage

d

Cornering light beam coverage

* Not available on all models
