Honda HR-V eHEV (2022 year). Manual in english - page 10

159

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

If you do not have the key on you, or if for some reason you cannot lock a door using
the key, you can lock the door without it.

■

Locking the driver’s door

Push the lock tab forward

 or push the

master door lock switch in the lock direction

, then pull and hold the outside door

handle

. Close the door, then release the

handle.

■

Locking the passenger’s doors

Push the lock tab forward and close the door.

■

Lockout prevention system

The doors and tailgate cannot be locked when the keyless remote is inside the
vehicle.

■

Locking a Door Without Using a Key

1

Locking a Door Without Using a Key

When you lock the driver’s door, all the other doors
and tailgate lock at the same time.

Before locking a door, make sure that the key is not
inside the vehicle.

160

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

Co
ntrols

Locking/Unlocking the Doors from the Inside

■

Locking a door

Push the lock tab forward.

■

Unlocking a door

Pull the lock tab rearward.

■

Using the Lock Tab

1

Using the Lock Tab

When you lock/unlock the door using the lock tab on
the driver’s door, all the other doors and the tailgate
lock/unlock at the same time.

a

To lock

b

To unlock

161

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

Co
ntrols

Pull the front door inner handle.

u

The door unlocks and opens in one
motion.

Press the master door lock switch in as shown
to lock or unlock all the doors and the tailgate.

■

Unlocking Using the Front Door Inner Handle

1

Unlocking Using the Front Door Inner Handle

The front door inner handles are designed to allow
front seat occupants to open the door in one motion.
However, this feature requires that front seat
occupants never pull a front door inner handle while
the vehicle is in motion.

Children should always ride in a rear seat where
childproof door locks are provided.

2

Childproof Door Locks

 P. 162

a

Inner Handle

■

Using the Master Door Lock Switch

1

Using the Master Door Lock Switch

When you lock/unlock the driver’s door using the
master door lock switch, all the other doors and the
tailgate lock/unlock at the same time.

a

To lock

b

To unlock

162

uu

Locking and Unlocking the Doors

u

Childproof Door Locks

Co
ntrols

Childproof Door Locks

The childproof door locks prevent the rear doors from being opened from the inside
regardless of the position of the lock tab.

Slide the lever in the rear door to the lock
position, and close the door.

■

When opening the door

Open the door using the outside door handle.

■

Setting the Childproof Door Locks

1

Childproof Door Locks

To open the door from the inside when the
childproof door lock is on, put the lock tab in the
unlock position, lower the rear window, put your
hand out of the window, and pull the outside door
handle.

a

Unlock

b

Lock

163

Co
ntrols

Tailgate

Precautions for Opening/Closing the Tailgate

Always make sure individuals and objects are clear of the tailgate before opening or
closing it.

•

Open the tailgate all the way.

u

If it is not fully opened, the tailgate may begin to close under its own weight.

•

Be careful when it is windy. The wind may cause the tailgate to close.

Keep the tailgate closed while driving to:

u

Avoid possible damage.

u

Prevent exhaust gas from leaking into the vehicle.

2

Carbon Monoxide Gas

 P. 98

1

Precautions for Opening/Closing the Tailgate

Be careful not to hit your head on the tailgate or to
put your hands between the tailgate and the luggage
area when closing the tailgate.

When you are storing or picking up luggage from the
luggage area or by using a forward and back kicking
motion under the centre of the rear bumper for
hands free access

*

, while the engine is idling, do not

stand in front of the exhaust pipe. You may get
burned.

Do not allow any passenger in the luggage space.
They may get hurt during hard braking, a sudden
acceleration, or a crash.

3

WARNING

Anyone caught in the path of a tailgate
that is being opened or closed can be
seriously injured.

Make sure that all people are clear of the
tailgate before opening or closing it.

Models without power tailgate

All models

* Not available on all models

164

uu

Tailgate

u

Opening/Closing the Tailgate

Co
ntrols

Opening/Closing the Tailgate

When all the doors are unlocked or you press
the tailgate unlock button

*

 on the remote

transmitter, the tailgate is unlocked. Press the
tailgate outer handle and lift open the
tailgate.
If you are carrying the keyless remote, you do
not have to unlock the tailgate before
opening it.

To close the tailgate, grab the inner handle,
pull the tailgate down, and push it closed
from outside.

1

Precautions for Opening/Closing the Tailgate

Make sure luggage or other items do not touch the
tailgate support struts.

a

 Tailgate Support Struts

1

Opening/Closing the Tailgate

•

Do not leave the keyless remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the keyless remote, you
can unlock the tailgate while someone else with
the keyless remote is within range.

a

Outer Handle

a

Inner Handle

* Not available on all models

165

uu

Tailgate

u

Opening/Closing the Power Tailgate

*

Continued

Co
ntrols

Opening/Closing the Power Tailgate

*

The power tailgate can be operated by pressing the power tailgate button on the
remote transmitter, pressing the power tailgate button in the driver’s side control
panel, pressing the outer handle or button on the tailgate, or by raising and
lowering your foot under the centre of the rear bumper for hands free access.

The power tailgate can be opened/closed when the transmission is in

(

P

.

1

Opening/Closing the Power Tailgate

*

WARNING:

Always take the ignition key with you

whenever you leave the vehicle alone or with other
occupants.

NOTICE

Do not push or pull on the power tailgate when it is
being automatically opened or closed.
Forcibly opening or closing the power tailgate while
in operation can deform the tailgate frame.

When operating the power tailgate, make sure there
is enough space around your vehicle. People near the
tailgate may be seriously hurt if the tailgate hits or
closes on their heads. Be especially cautious if
children are around.

3

WARNING

Opening or closing a power tailgate while
any part of a passenger is in the tailgate’s
operating path can cause serious injury.

Make sure all passengers or objects are
clear of the tailgate operating range
before opening or closing the tailgate.

* Not available on all models

uu

Tailgate

u

Opening/Closing the Power Tailgate

*

166

Co
ntrols

Use a forward and back kicking motion for
about 1 second under the centre of the rear
bumper to open or close the power tailgate
while carrying the keyless remote.

u

Some exterior lights will flash, then the
tailgate begins to move.

■

Using the Hands Free Access

1

Using the Hands Free Access

During rain or in other instances when the vehicle
becomes wet, the sensor may not properly detect
your foot motion.

When performing work on or around the rear section
of the vehicle, you may inadvertently open or close
the tailgate.
To prevent this from happening, select Customized
Features on the audio/information screen and then
select OFF for the feature.

2

How to Customize the Vehicle Settings



P. 312

If you hold your foot under the bumper for too long
or sweep your foot from side to side, the power
tailgate does not open or close.
This function will not operate if you don’t have the
keyless remote on you. Please make sure you have
the keyless remote on you.

a

About 1 second

167

uu

Tailgate

u

Opening/Closing the Power Tailgate

*

Continued

Co
ntrols

When you walk away from the vehicle while carrying the keyless remote, the power
tailgate will automatically close.

1.

Carry the keyless remote and press the walk
away close button.

u

The indicator on the walk away close
button will turn green when the walk
away close is activated.

2.

Walk at least 1.0 m (3 feet) away from the
vehicle within 30 seconds of pressing the
walk away close button.

u

Some exterior lights will flash then the
power tailgate begins to close.

■

Power Tailgate Walk Away Close

a

Walk Away Close Button

Walk at least 1.0 m (3 feet) away

uu

Tailgate

u

Opening/Closing the Power Tailgate

*

168

Co
ntrols

Press the power tailgate button for more than
one second to operate when the power mode
is in VEHICLE OFF.

u

Some exterior lights will flash.

If you press the button again while the power
tailgate is moving, it will stop.
Press the button for more than one second,
and the power tailgate will reverse direction.

■

Customizing when to open the tailgate

Anytime:

The power tailgate unlocks and opens at the same time. This is the

default setting.

When unlocked:

The tailgate opens when all doors are unlocked.

2

How to Customize the Vehicle Settings

 P. 312

■

Using the Remote Transmitter

1

Opening/Closing the Power Tailgate

*

The power tailgate may not open or close under the
following conditions:

•

You activate the power system while the tailgate is
automatically opening or closing.

•

The vehicle is parked on a steep hill.

•

The vehicle is swayed in a strong wind.

•

The tailgate or the roof is covered with snow or ice.

If you replace the 12-volt battery or the power
tailgate fuse while the tailgate is open, the power
tailgate may be disabled. The power tailgate resumes
once you manually close the tailgate.

Installing aftermarket components other than Honda
genuine accessories on the power tailgate may
prevent it from fully opening or closing.

Make sure the power tailgate is fully open before you
get your luggage in and out.

The beeper sounds when you start driving while the
power tailgate is still open, or closing.

a

Power Tailgate Button

* Not available on all models

Continued

169

uu

Tailgate

u

Opening/Closing the Power Tailgate

*

Co
ntrols

To open or close the power tailgate, press the
power tailgate button for about one second.

u

Some exterior lights will flash.

If you press the button again while the power
tailgate is moving, it will stop.
Press the button for about one second, and
the power tailgate will reverse direction.

■

Using the Power Tailgate Button

1

Opening/Closing the Power Tailgate

*

If the power tailgate meets resistance while opening
or closing, the auto reverse feature reverses the
direction. The beeper sounds three times.

The auto reverse function stops sensing when the
tailgate is almost closed to make sure that it fully
closes.

Do not touch the sensors located on both sides of the
tailgate. The power tailgate does not close if you
touch either sensor when you are trying to close the
tailgate.

Be careful not to scratch the sensors with a sharp
object. If scratched, they can be damaged, and the
power tailgate closing feature malfunctions.

* Not available on all models

uu

Tailgate

u

Opening/Closing the Power Tailgate

*

170

Co
ntrols

If you press the outer handle of the tailgate for
no longer than one second, the tailgate opens
automatically.

u

If you want to open the tailgate
manually, press the outer handle for
more than one second.

2

Opening/Closing the Tailgate

 P. 164

If you are carrying the keyless remote, you do
not have to unlock the tailgate before
opening it.

If you press the outer handle again while the
power tailgate is moving, it will stop.
Press the outer handle, and the power tailgate
will reverse direction.

■

Using the Tailgate Outer Handle

1

Using the Tailgate Outer Handle

•

Do not leave the keyless remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the keyless remote, you
can unlock the tailgate while someone else with
the keyless remote is within range.

You can change the power tailgate operation setting
on and off.

2

How to Customize the Vehicle Settings



P. 312

a

Outer Handle

171

uu

Tailgate

u

Opening/Closing the Power Tailgate

*

Continued

Co
ntrols

Press the tailgate inner button on the tailgate
to close the power tailgate.

If you press the tailgate inner button again
while the power tailgate is moving, it will stop.
Press and release the tailgate inner button
again, and the power tailgate will reverse
direction.

■

Using the Tailgate Inner Button

a

Tailgate Inner Button

uu

Tailgate

u

Opening/Closing the Power Tailgate

*

172

Co
ntrols

The extent to which the power tailgate
automatically opens can be programmed.

To program:

1.

Open the tailgate to the desired position.

2.

Press and hold the tailgate inner button.
You will hear one long beep, followed by
two short beeps.

■

Programming Tailgate Position

1

Programming Tailgate Position

If the tailgate is only slightly opened, the position
cannot be programmed, even if you push the tailgate
inner button.

If you want to reprogram the power tailgate to open
all the way, manually raise the tailgate to its upper
most position and follow the directions step 2.

a

Tailgate Inner Button

173

uu

Tailgate

u

Opening/Closing the Power Tailgate

*

Co
ntrols

If you manually close the power tailgate, it latches automatically.

Automatically lowers the power tailgate when there is a possibility that the fully
opened power tailgate can fall down by its own weight (for example, by snow on
the tailgate). The beeper sounds while the power tailgate lowers.

■

Auto-Closer

■

Power Tailgate Fall Detection

1

Auto-Closer

The auto-closer feature does not activate if you push
the tailgate outer handle while the power tailgate is
closing.

NOTICE

Do not put any force on the tailgate while the power
tailgate is latching.

Keep your hands away from the tailgate when you
manually close the tailgate and let it latch
automatically. It is dangerous to put your hands
around the tailgate as it starts to latch itself.

1

Power Tailgate Fall Detection

If you try to manually close the power tailgate
immediately after it fully opens, the power tailgate
fall detection may activate.

Once the power tailgate fall detection activates, wait
until the power tailgate fully closes. Keep away from
the power tailgate when it is in motion.

If the power tailgate fall detection constantly
activates, consult at a dealer.

174

Co
ntrols

Security System

Immobilizer System

This system prevents a key that has not been pre-registered from starting the power
system.

Pay attention to the following when pressing the

POWER

 button:

•

Do not allow objects that emit strong radio waves near the

POWER

 button.

•

Make sure the key is not covered by or touching a metal object.

•

Do not bring a key from another vehicle’s immobilizer system near the

POWER



button.

Do not put the key near magnetic items. Electronic device, such as televisions and
audio systems emit strong magnetic fields. Note that even a key chain can become
magnetic.

1

Immobilizer System

NOTICE

Leaving the key in the vehicle can result in theft or
accidental movement of the vehicle.
Always take the key with you whenever you leave the
vehicle unattended.

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

If the system repeatedly does not recognise the
coding of your key, contact a dealer. If you have lost
your key and cannot start your vehicle, contact a
dealer.

Apply and hold the brake pedal before set the power
mode to ON the first time after the 12-volt battery
has been disconnected.

Right-hand drive type
