Honda CR-V Hybrid (2022 year). Manual in english - page 35

558

Braking

Brake Assist System

Driving

Brake Assist System

Designed to assist the driver by generating greater braking force when you depress
the brake pedal hard during emergency braking.

■

Brake assist system operation

Press the brake pedal firmly for more powerful braking.

When brake assist operates, the pedal may wiggle slightly and an operating noise
may be heard. This is normal. Keep holding the brake pedal firmly down.

559

Continued

Driving

Parking Your Vehicle

When Stopped

Depress the brake pedal firmly.

With the brake pedal depressed, pull up the electric parking brake switch slowly,
but fully.

Change the shift position to

(

Turn off the power system.

The parking brake and brake system indicator (red) goes off in about 15
seconds.

Always set the parking brake, in particular if you are parked on an incline.

Parking Your Vehicle

Do not park your vehicle near flammable objects,
such as dry grass, oil, or timber.
Heat from the exhaust can cause a fire.

WARNING

The vehicle can roll away if left unattended
without confirming that Park is engaged.

A vehicle that rolls away could cause a crash
resulting in serious injury or death.

Always keep your foot on the brake pedal
until you have confirmed that

(

is shown

on the shift position indicator.

Parking Your Vehicle

When Stopped

560

Driving

When Stopped

NOTICE

The following can damage the driveline:

•

Depressing the accelerator and brake pedals
simultaneously.

•

Changing to

(

before the vehicle stops

completely.

When facing uphill, do not hold the vehicle by
depressing the accelerator pedal.
Doing so may cause the power system to overheat
and fail.

In extremely cold temperatures, the parking brake
may freeze up if applied. If such temperatures are
expected, do not apply the parking brake but, if
parking on a slope, either turn the front wheels so
they will contact the curb if the vehicle rolls down the
slope or block the wheels to keep the vehicle from
moving. If you do not take either precaution, the
vehicle may roll unexpectedly, leading to a crash.

561

Parking Your Vehicle

Parking Sensor System

Continued

Driving

Parking Sensor System

The corner and center sensors monitor obstacles around your vehicle, and the
beeper, driver information interface and audio/information screen let you know the
approximate distance between your vehicle and the obstacle.

■

The sensor location and range

Parking Sensor System

Even when the system is on, always confirm if there is
no obstacle near your vehicle before parking.

The system may not work properly when:

•

The sensors are covered with snow, ice, mud, or
dirt.

•

The vehicle is on uneven surface, such as grass,
bumps, or a hill.

•

The vehicle has been out in hot or cold weather.

•

The system is affected by devices that emit
ultrasonic waves.

•

Driving in bad weather.

The system may not sense:

•

Thin or low objects.

•

Sonic-absorptive materials, such as snow, cotton,
or sponge.

•

Objects directly under the bumper.

Do not put any accessories on or around the sensors.

Front: Within about 24 in (60 cm)

or less
Rear: Within about 28 in (70 cm)

or less

Front: Within about 39 in (100 cm)

or less
Rear: Within about 43 in (110 cm)

or less

Front Corner Sensors

Rear Corner Sensors

Front Center Sensors

Rear Center Sensors

* Not available on all models

Parking Your Vehicle

Parking Sensor System

562

Driving

■

Parking sensor system on and off

With the power mode in ON, press the
parking sensor system button to turn on or off
the system. The indicator in the button comes
on when the system is on.
The front corner and front center sensors start
to detect an obstacle when the transmission is
in any position other than

(

, and the

vehicle speed is less than 5 mph (8 km/h).

The front corner, rear corner and rear center
sensors start to detect an obstacle when the
transmission is in

(

, and the vehicle speed is

less than 5 mph (8 km/h).

Parking sensor system on and off

When you set the power mode to ON, the system will
be in the previously selected condition.

Continued

563

Parking Your Vehicle

Parking Sensor System

Driving

■

Screen Operation

You can switch the display to normal display
or split display by touching the tab vicinity or
on the camera display.

Screen Operation

If the parking sensor system is off or there is a
malfunction in the system, the tab disappears, and
the split display returns to the normal display.

You can also switch the display to normal display or
split display using the audio/information screen.

Customized Features

P. 369

Touch

Camera

display

Tab

Normal display

Split display

564

Parking Your Vehicle

Parking Sensor System

Driving

■

When the distance between your vehicle and obstacles behind becomes shorter

*1: At this stage, only the center sensors detect obstacles.

Interval between

beeps

Distance between the Bumper and Obstacle

Indicator

Driver Information Interface/

Audio/Information Screen

Corner Sensors

Center Sensors

Moderate

—

Front: About 41-26 in
(105-65 cm)
Rear: About 45-26 in
(115-65 cm)

Blinks in Yellow

Short

Front: About 26-19 in
(65-50 cm)
Rear: About 30-19 in
(75-50 cm)

About 26-19 in (65-50 cm)

Blinks in Amber

Very short

About 19-16 in (50-40 cm) About 19-16 in (50-40 cm)

Continuous

About 16 in (40 cm) or less About 16 in (40 cm) or less

Blinks in Red

Indicators light up where the

sensor detects an obstacle

Indicators light up where the

sensor detects an obstacle

Audio/information screen

Driver information interface

565

Parking Your Vehicle

Parking Sensor System

Driving

Make sure that the parking sensor system is not activated. Set the power mode to
VEHICLE OFF (LOCK).

Press and hold the parking sensor system button, and set the power mode to ON.

Keep pressing the button for 10 seconds. Release the button when the indicator
in the button flashes.

Press the button again. The indicator in the button goes off.

The beeper sounds twice. The rear sensors are now turned off.

To turn the rear sensors on again, follow the above procedure. The beeper sounds
three times when the rear sensors come back on.

■

Turning off All Rear Sensors

Turning off All Rear Sensors

When you shift to

(

, the indicator in the parking

sensor system button blinks as a reminder that the
rear sensors have been turned off.

566

Parking Your Vehicle

Cross Traffic Monitor

Driving

Cross Traffic Monitor

Monitors the rear corner areas using the radar sensors when reversing, and alerts
you if a vehicle approaching from a rear corner is detected.

The system is convenient when you are backing out of a parking space.

Cross Traffic Monitor

CAUTION

Cross Traffic Monitor cannot detect all
approaching vehicles and may not detect
an approaching vehicle at all.

Failure to visually confirm that it is safe to
back up the vehicle before doing so may
result in a collision.

Do not solely rely on the system when
reversing; always also use your mirrors, and
look behind and to the sides of your vehicle
before reversing.

* Not available on all models

Continued

567

Parking Your Vehicle

Cross Traffic Monitor

Driving

The system activates when:

•

The power mode is in ON.

•

The Cross Traffic Monitor system is turned
on.

Cross Traffic Monitor On and Off

P. 569

•

The transmission is in

(

•

Your vehicle is moving at 3 mph (5 km/h) or
lower.

When a vehicle is detected approaching from a rear corner, Cross Traffic Monitor
alerts you with a buzzer and a displayed warning.

The system will not detect a vehicle that approaches from directly behind your
vehicle, nor will it provide alerts about a detected vehicle when it moves directly
behind your vehicle.

The system does not detect or provide alerts for a vehicle that is moving away from
your vehicle, and it may alert for pedestrians, bicycles, or stationary objects.

■

How the System Works

Cross Traffic Monitor

Cross Traffic Monitor may not detect or may delay
alerting an approaching vehicle, or may alert without
an approaching vehicle under the following
conditions:

•

An obstacle, such as another vehicle and a wall,
near your vehicle’s rear bumper, is blocking the
radar sensor’s scope.

•

Your vehicle is moving at the speed of about 3 mph
(5 km/h) or higher.

•

A vehicle is approaching at the speed other than
between about 6 mph (10 km/h) and 16 mph (25
km/h).

•

The system picks up external interference such as
other radar sensors from another vehicle or strong
radio wave transmitted from a facility nearby.

•

Either corner of the rear bumper is covered with
snow, ice, mud or dirt.

•

When there is bad weather.

•

Your vehicle is on an incline.

•

Your vehicle is tilted due to a heavy load in the rear.

•

Your vehicle is reversing towards a wall, a pole, a
vehicle, and so on.

The rear bumper or the sensors have been improperly
repaired or the rear bumper has been deformed.
Have your vehicle checked by a dealer.

For proper operation, always keep the rear bumper
corner area clean.
Do not cover the rear bumper corner area with labels
or stickers of any kind.

Radar sensors:
Underneath the rear bumper

corners

* Not available on all models

Parking Your Vehicle

Cross Traffic Monitor

568

Driving

An arrow icon appears on the side a vehicle is approaching on the audio/information
screen.

■

When the System Detects a Vehicle

When the System Detects a Vehicle

If the

on the lower right changes to

when the

transmission is in

(

, mud snow or ice may have

accumulated in the vicinity of the sensor. Check the
bumper corners for any obstructions, and thoroughly
clean the area if necessary.

If the

comes on when the transmission is in

(

there may be a problem with the Cross Traffic
Monitor system. Do not use the system and have your
vehicle checked by a dealer.

If the display remains the same with the transmission
in

(

, there may be a problem with the rear camera

system and the Cross Traffic Monitor system.
Do not use the system and have your vehicle checked
by a dealer.

Wide View

Normal View

Arrow Icon

Top Down View

569

Parking Your Vehicle

Cross Traffic Monitor

Driving

You can switch on and off the system using the audio/information screen.

Select .

Select

Settings

Select

Camera

Select

Cross Traffic Monitor

Select

Off

, then select

The system can also be turned on and off on
the audio/information screen by pressing the
CTM icon.

■

Cross Traffic Monitor On and Off

Icon

570

Driving

Multi-View Rear Camera

About Your Multi-View Rear Camera

The audio/information screen can display your vehicle’s rear view.
The display automatically changes to a rear view when the transmission is put into

(

■

Multi-View Rear Camera Display Area

About Your Multi-View Rear Camera

The rear camera view is restricted. You cannot see
the corner ends of the bumper or what is underneath
the bumper. Its unique lens also makes objects
appear closer or farther than they actually are.

Visually confirm that it is safe to drive before backing
up. Certain conditions (such as weather, lighting, and
high temperatures) may also restrict the rear view. Do
not rely on the rearview display which does not give
you all information about conditions at the back of
your vehicle.

If the camera lens is covered with dirt or moisture,
use a soft, moist cloth to keep the lens clean and free
of debris.

You can change the

Fixed Guideline

and

Dynamic

Guideline

settings.

Customized Features

P. 369

Fixed Guideline
On:

Guidelines appear when you put the

transmission into

(

Off:

Guidelines do not appear.

Dynamic Guideline
On:

Guidelines move according to the steering wheel

direction.

Off:

Guidelines do not move.

Models with Display Audio

Guidelines

Bumper

Wide View Mode

Normal View Mode

Top Down View Mode

Approx.

39 inches

(1 m)
Approx.

20 inches

(50 cm)
Tailgate

Open

Range

Camera

571

Multi-View Rear Camera

About Your Multi-View Rear Camera

Driving

You can view three different camera angles on the rearview display.

Press the selector knob to switch the angle.

Touch the appropriate icon to switch the angle.

: Wide view mode
: Normal view mode
: Top down view mode

•

If you were last using Wide view mode or Normal view mode, the same view
mode will be activated the next time you put the transmission into

(

•

If you were using Top down view mode before you turned off the power system,
Wide view mode will be activated the next time you set the power mode to ON
and put the transmission into

(

•

If you were using Top down view mode and 10 seconds elapsed after you took
the transmission out of

(

, Wide view mode will be activated the next time you

put the transmission into

(

About Your Multi-View Rear Camera

You can change the

Camera Guideline

Off

settings.

Customized Features

P. 362

Camera Guideline
On:

Guidelines appear when you put the

transmission into

(

Off:

Guidelines do not appear.

Models with color audio system

Models with Display Audio

All models

572

Driving

Refueling

Fuel Information

■

Fuel recommendation

Use of lower octane gasoline can cause a persistent, heavy metallic knocking noise
that can lead to engine damage.

■

Top tier detergent gasoline

Because the level of detergency and additives in gasoline vary in the market, Honda
endorses the use of “TOP TIER Detergent Gasoline” where available to help
maintain the performance and reliability of your vehicle. TOP TIER Detergent
Gasoline meets a new gasoline standard jointly established by leading automotive
manufacturers to meet the needs of today’s advanced engines.

Qualifying gasoline retailers will, in most cases, identify their gasoline as having met
“TOP TIER Detergent Gasoline” standards at the retail location. This fuel is
guaranteed to contain the proper level of detergent additives and be free of metallic
additives. The proper level of detergent additives, and absence of harmful metallic
additives in gasoline, help avoid buildup of deposits in your engine and emission
control system.

For further important fuel-related information for your vehicle, or on information on
gasoline that does not contain MMT, visit

www.hondacars.com.

for additional

information on gasoline. For more information on top tier gasoline, visit

www.toptiergas.com

■

Fuel tank capacity: 14 US gal (53 L)

Unleaded gasoline, pump octane number 87 or higher

Fuel Information

NOTICE

We recommend quality gasoline containing
detergent additives that help prevent fuel system and
engine deposits. In addition, in order to maintain
good performance, fuel economy, and emissions
control, we strongly recommend the use of gasoline
that does NOT contain harmful manganese-based
fuel additives such as MMT, if such gasoline is
available.

Use of gasoline with these additives may adversely
affect performance, and cause the malfunction
indicator lamp on your instrument panel to come on.
If this happens, contact a dealer for service.

Some gasoline today is blended with oxygenates such
as ethanol. Your vehicle is designed to operate on
oxygenated gasoline containing up to 15% ethanol
by volume. Do not use gasoline containing methanol.
If you notice any undesirable operating symptoms, try
another service station or switch to another brand of
gasoline.

573

Refueling

How to Refuel

Continued

Driving

How to Refuel

Your fuel tank is not equipped with a fuel filler cap. You can insert the filler nozzle
directly into the filler neck. The tank seals itself again when you pull out the filler
nozzle.

Stop your vehicle with the service station
pump on the left side of the vehicle in the
rear.

Turn off the power system.

Pull on the fuel fill door release handle
under the lower left corner of the
dashboard.

The fuel fill door opens.

How to Refuel

The fuel filler opening is designed to accept only
service station filler nozzles for refueling. Use of
smaller diameter tubes (e.g., those used to siphon
fuel for other uses) or other non-service station
devices can damage the area in and around the filler
opening.

WARNING

Gasoline is highly flammable and explosive.
You can be burned or seriously injured
when handling fuel.

•

Stop the engine, and keep heat, sparks,
and flames away.

•

Handle fuel only outdoors.

•

Wipe up spills immediately.

Pull

Content .. 33 34 35 36 ..
