Honda CR-V (2022 year). Manual in english - page 46

uu

If a Tyre Goes Flat

u

Changing a Flat Tyre

736

Han

d

lin
g the U

n

expected

11.

Loosen each wheel nut about one turn

using the wheel nut wrench.

1.

Place the jack under the jacking point
closest to the tyre to be changed.

■

How to Set Up the Jack

1

How to Set Up the Jack

WARNING:

The jack shall be placed on a flat and

stable surface on the same level as the vehicle is
parked.

The jack that came with your vehicle has the
following label.

1. See Owner’s Manual.
2. Never get under vehicle when supported by jack.
3. Place jack underneath reinforced area.

3

WARNING

The vehicle can easily roll off the jack,
seriously injuring anyone underneath.

Follow the directions for changing a tyre
exactly, and no person should place any
portion of their body under a vehicle that is
supported by a jack.

Jacking Points

Continued

737

uu

If a Tyre Goes Flat

u

Changing a Flat Tyre

Han

d

lin
g the U

n

expected

2.

Turn the end bracket clockwise as shown in
the image until the top of the jack contacts
the jacking point.

u

Make sure that the jacking point tab is
resting in the jack notch.

3.

Raise the vehicle, using the jack handle bar
and the jack handle, until the tyre is off the
ground.

1

How to Set Up the Jack

Do not use the jack with people or luggage in the
vehicle.

Use the jack provided in your vehicle.
Other jacks may not support the weight (“load”) or
may not fit the jacking point.

The following instructions must be followed to use
the jack safely:

•

Do not use while the engine is running.

•

Use only where the ground is firm and level.

•

Use only at the jacking points.

•

Do not get in the vehicle while using the jack.

•

Do not put anything on top of or underneath the
jack.

Jacking Point

Jack
Handle
Bar

Wheel Nut

 Wrench as Jack Handle

uu

If a Tyre Goes Flat

u

Changing a Flat Tyre

738

Han

d

lin
g the U

n

expected

1.

Remove the wheel nuts and flat tyre.

2.

Wipe the mounting surfaces of the wheel
with a clean cloth.

3.

Mount the compact spare tyre.

4.

Screw the wheel nuts until they touch the
lips around the mounting holes, then stop
rotating.

5.

Lower the vehicle and remove the jack.
Tighten the wheel nuts in the order
indicated in the image. Go around,
tightening the nuts, two to three times in
this order.

Wheel nut torque:

108 N∙m (11 kgf∙m, 80 lbf∙ft)

■

Replacing the Flat Tyre

1

Replacing the Flat Tyre

Do not over tighten the wheel nuts by applying extra
torque using your foot or a pipe.

Continued

739

uu

If a Tyre Goes Flat

u

Changing a Flat Tyre

Han

d

lin
g the U

n

expected

1.

Remove the centre cap.

2.

Place the flat tyre face down in the spare
tyre well.

3.

Remove the spacer cone from the wing
bolt, flip it over, and insert it back on the
bolt. Secure the flat tyre with the wing bolt.

4.

Securely store the wheel nut wrench and
jack handle bar back in the tool bag

*

 or tool

case

*

. Store the bag in the luggage area.

5.

Store the jack in its holder. Turn the jack’s
end bracket to lock it in place.

■

Storing the Flat Tyre

1

Storing the Flat Tyre

3

WARNING

Loose items can fly around the interior in a
crash and can seriously injure the
occupants.

Store the wheel, jack, and tools securely
before driving.

Centre Cap

Spacer
Cone

Wing Bolt

For

compact

spare tyre

For

full-size

tyre

* Not available on all models

740

uu

If a Tyre Goes Flat

u

Changing a Flat Tyre

Han

d

lin
g the U

n

expected

If you replace a flat tyre with the spare tyre, the

 indicator comes on while you are

driving. After driving for a few kilometres (miles), the indicator will start blinking for
a short time and then stay on.

 appears on the driver information interface, but

this is normal.

Initialise the deflation warning system when you replace the tyre with a specified
regular tyre.

2

Deflation Warning System Initialisation

 P. 548

■

Deflation Warning System and the Spare Tyre

741

Han

d

lin
g the U

n

expected

Engine Does Not Start

Checking the Engine

If the engine does not start, check the starter.

Starter condition

Checklist

Starter doesn’t turn or turns
over slowly.

The battery may be dead. Check
each of the items on the right and
respond accordingly.

Check for a message on the driver information interface.

•

If

appears.

2

If the Keyless Remote Battery is Weak

 P. 742

u

Make sure the keyless remote is in its operating range.

2

ENGINE START/STOP Button Operating Range

 P. 215

Check the brightness of the interior lights.

Turn on the interior lights and check the brightness.

•

If the interior lights are dim or do not come on at all

2

 Battery

 P. 710

•

If the interior lights come on normally

2

 Fuses

 P. 756

The starter turns over normally,
but the engine doesn’t start.

There may be a problem with a
fuse. Check each of the items on
the right and respond accordingly.

Review the engine start procedure.

Follow its instructions, and try to start the engine again.

2

 Starting the Engine

 P. 510, 513

Check the immobilizer system indicator.

When the immobilizer system indicator is blinking, the engine cannot be started.

2

Immobilizer System

 P. 200

Check the fuel level.

There should be enough fuel in the tank.

2

Fuel Gauge

 P. 146

Check the fuse.

Check all fuses or have the vehicle checked by a dealer.

2

 Inspecting and Changing Fuses

 P. 762

If the problem continues:

2

Emergency Towing

 P. 763

1

Checking the Engine

If you must start the vehicle immediately, use an
assisting vehicle or booster battery to jump start it.

2

If the Battery Is Dead

 P. 744

Models with keyless access system

742

uu

Engine Does Not Start

u

If the Keyless Remote Battery is Weak

Han

d

lin
g the U

n

expected

If the Keyless Remote Battery is Weak

If the beeper sounds,

 appears on the driver information interface, the

ENGINE

START/STOP

 button flashes, and the engine will not start, start the engine as

follows:

1.

Touch the centre of the

ENGINE START/

STOP

 button with the

H

 logo on the keyless

remote while the

ENGINE START/STOP



button is flashing. The buttons on the
keyless remote should be facing you.

u

The

ENGINE START/STOP

 button

flashes for about 30 seconds.

2.

Depress the brake pedal and press the

ENGINE START/STOP

 button within 10

seconds after the beeper sounds and the

ENGINE START/STOP

 button changes

from flashing to on.

u

If you don’t depress the pedal, the mode
will change to ACCESSORY.

Models with keyless access system

743

uu

Engine Does Not Start

u

Emergency Engine Stop

Han

d

lin
g the U

n

expected

Emergency Engine Stop

The

ENGINE START/STOP

 button may be used to stop the engine due to an

emergency situation even while driving. If you must stop the engine, do either of the
following operations:

•

Press and hold the

ENGINE START/STOP

 button for about two seconds.

•

Firmly press the

ENGINE START/STOP

 button three times.

The steering wheel will not lock.

The power mode is in ACCESSORY when the engine is stopped.
To change the mode to VEHICLE OFF, put the transmission into

(

P

 after the vehicle

comes to a complete stop. Then press the

ENGINE START/STOP

 button twice

without depressing the brake pedal.

The power mode changes to VEHICLE OFF.

Models with keyless access system

1

Emergency Engine Stop

Do not press the

ENGINE START/STOP

 button while

driving unless it is absolutely necessary for the engine
to be turned off.
If you press the

ENGINE START/STOP

 button while

driving, the beeper sounds.

Continuously variable transmission models

Manual transmission models

744

Han

d

lin
g the U

n

expected

If the Battery Is Dead

Turn off the power to electric devices, such as audio and lights. Turn off the engine,
then open the bonnet.

1.

Open the terminal cover on your vehicle’s
battery positive

+

 terminal.

2.

Connect the first jumper cable to your
vehicle’s battery

+

 terminal.

3.

Connect the other end of the first jumper
cable to the booster battery

+

 terminal.

u

Use a 12-volt booster battery only.

u

When using an automotive battery
charger to boost your 12-volt battery,
select a lower charging voltage than 15-
volt. Check the charger manual for the
proper setting.

4.

Connect the second jumper cable to the
booster battery

-

 terminal.

■

Jump Starting Procedure

1

If the Battery Is Dead

NOTICE

If a battery sits in extreme cold, the electrolyte inside
can freeze. Attempting to jump start with a frozen
battery can cause it to rupture.

Securely attach the jumper cables clips so that they
do not come off when the engine vibrates. Also be
careful not to tangle the jumper cables or allow the
cable ends to touch each other while attaching or
detaching the jumper cables.

Battery performance degrades in cold conditions and
may prevent the engine from starting.

3

WARNING

A battery can explode if you do not follow
the correct procedure, seriously injuring
anyone nearby.

Keep all sparks, open flames, and smoking
materials away from the battery.

+

 Terminal

Booster Battery

745

uu

If the Battery Is Dead

u

Han

d

lin
g the U

n

expected

5.

Connect the other end of the second
jumper cable to the engine mounting bolt
(as shown). Do not connect this jumper
cable to any other part.

6.

If your vehicle is connected to another
vehicle, start the assisting vehicle’s engine
and increase its rpm slightly.

7.

Attempt to start your vehicle’s engine. If it
turns over slowly, check that the jumper
cables have good metal-to-metal contact.

Once your vehicle’s engine has started, remove the jumper cables in the following
order.

1.

Disconnect the jumper cable from your vehicle’s ground.

2.

Disconnect the other end of the jumper cable from the booster battery

-



terminal.

3.

Disconnect the jumper cable from your vehicle’s battery

+

 terminal.

4.

Disconnect the other end of the jumper cable from the booster battery

+



terminal.

Have your vehicle inspected by a nearby service station or a dealer.

*1: Models with the keyless access system have an

ENGINE START/STOP

 button instead of an

ignition switch.

■

What to Do After the Engine Starts

1

Jump Starting Procedure

The indicators for the Adaptive Cruise Control
(ACC)

*

/Adaptive Cruise Control (ACC) with Low

Speed Follow (LSF)

*

, road departure mitigation

system, Vehicle Stability Assist (VSA) system, VSA
OFF, Collision Mitigation Braking System (CMBS), low
tyre pressure/deflation warning system

*

, and parking

brake and brake system (amber) may come on along
with a message in the driver information interface
when you turn the ignition switch to ON

(

w

*1

 after

reconnecting the battery.
Drive a short distance at more than 20 km/h (12
mph). The indicator should go off. If it does not, have
your vehicle checked by a dealer.

* Not available on all models

746

Han

d

lin
g the U

n

expected

Shift Lever Does Not Move

*

Follow the procedure below if you cannot move the shift lever out of the

(

P



position.

1.

Set the parking brake.

2.

Remove the key from the ignition switch.

2.

Remove the built-in key from the keyless
remote.

3.

Wrap a cloth around the tip of a small flat-
tip screwdriver. Put it into the shift lock
release slot as shown in image, and remove
the cover.

4.

Insert the key into the shift lock release slot.

5.

While pushing the key down, press the shift
lever release button, and place the shift
lever into

(

N

.

u

The lock is now released. Have the shift
lever checked by a dealer as soon as
possible.

■

Releasing the Lock

Slot

Cover

Models without keyless access system

Models with keyless access system

All models

Release Button

Shift Lock Release Slot

* Not available on all models

747

Continued

Han

d

lin
g the U

n

expected

Overheating

How to Handle Overheating

Overheating symptoms are as follows:

•

The temperature gauge needle is at upper level or the engine suddenly loses
power.

•

Steam or spray comes out of the engine compartment.

■

First thing to do

1.

Immediately park the vehicle in a safe place.

2.

Turn off all accessories and turn on the hazard warning lights.

u

No steam or spray present:

Keep the engine running and open the bonnet.

u

Steam or spray is present:

Turn off the engine and wait until it subsides. Then open the bonnet.

1

How to Handle Overheating

NOTICE

Continuing to drive with the temperature gauge
needle at upper level may damage the engine.

3

WARNING

Steam and spray from an overheated
engine can seriously scald you.

Do not open the bonnet if steam is coming
out.

uu

Overheating

u

How to Handle Overheating

748

Han

d

lin
g the U

n

expected

■

Next thing to do

1.

Check that the cooling fan is operating and
stop the engine once the temperature
gauge needle comes down.

u

If the cooling fan is not operating,
immediately stop the engine.

2.

Once the engine has cooled down, inspect
the coolant level and check the cooling
system components for leaks.

u

If the coolant level in the reserve tank is
low, add coolant until it reaches the

MAX

 mark.

u

If there is no coolant in the reserve tank,
check that the radiator is cool. Cover the
reserve tank cap with a heavy cloth and
open the cap. If necessary, add coolant
up to the base of the filler neck, and put
the cap back on.

■

Last thing to do

Once the engine has cooled sufficiently, restart it and check the temperature gauge.
If the temperature gauge needle has gone down, resume driving. If it has not gone
down, contact a dealer for repairs.

1

How to Handle Overheating

If the coolant is leaking, contact a dealer for repairs.

Use water as an emergency/temporary measure only.
Have a dealer flush the system with proper antifreeze
as soon as possible.

3

WARNING

Removing the reserve tank cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.

Always let the engine and radiator cool
down before removing the reserve tank
cap.

MAX

Reserve Tank

MIN

749

Han

d

lin
g the U

n

expected

Indicator, Coming On/Blinking

If the Low Oil Pressure Indicator Comes On

■

Reasons for the indicator to come on

Comes on when the engine oil pressure is low.

■

What to do as soon as the indicator comes on

1.

Immediately park the vehicle on level ground in a safe place.

2.

If necessary, turn the hazard warning lights on.

■

What to do after parking the vehicle

1.

Stop the engine and let it sit for approximately three minutes.

2.

Open the bonnet and check the oil level.

2

Oil Check

 P. 683

3.

Start the engine and check the low oil pressure indicator.

u

The indicator goes off: Start driving again.

u

The indicator does not go off within 10 seconds: Immediately stop
the engine and contact a dealer for repairs.

If the Charging System Indicator Comes On

■

Reasons for the indicator to come on

Comes on when the battery is not being charged.

■

What to do when the indicator comes on

Turn off the climate control system, rear demister, and other electrical
systems, and immediately contact a dealer for repairs.

1

If the Low Oil Pressure Indicator Comes On

NOTICE

Running the engine with low oil pressure can cause
serious mechanical damage almost immediately.

1

If the Charging System Indicator Comes On

If you need to stop temporarily, do not turn off the
engine. Restarting the engine may rapidly discharge
the battery.

750

uu

Indicator, Coming On/Blinking

u

If the Malfunction Indicator Lamp Comes On or Blinks

Han

d

lin
g the U

n

expected

If the Malfunction Indicator Lamp Comes On or
Blinks

■

Reasons for the indicator lamp to come on or blink

•

Comes on if there is a problem with the engine emissions control
system.

•

Blinks when engine misfiring is detected.

■

What to do when the indicator lamp comes on

Avoid high speeds and immediately get your vehicle inspected at a
dealer.

■

What to do when the indicator lamp blinks

Park the vehicle in a safe place with no flammable items and wait at least
10 minutes or more with the engine stopped until it cools.

1

If the Malfunction Indicator Lamp Comes On or Blinks

NOTICE

If you drive with the malfunction indicator lamp on,
the emissions control system and the engine could be
damaged.

If the malfunction indicator lamp blinks again when
restarting the engine, drive to the nearest dealer at
50 km/h (30 mph) or less. Have your vehicle
inspected.

751

uu

Indicator, Coming On/Blinking

u

If the Brake System Indicator (Red) Comes On or Blinks

Han

d

lin
g the U

n

expected

If the Brake System Indicator (Red) Comes On or
Blinks

■

Reasons for the indicator to come on

•

The brake fluid is low.

•

There is a malfunction in the brake system.

■

What to do when the indicator comes on while driving

Depress the brake pedal lightly to check pedal pressure.

•

If normal, check the brake fluid level the next time you stop.

•

If abnormal, take immediate action. If necessary, downshift the
transmission to slow the vehicle using engine braking.

■

Reasons for the indicator to blink

•

There is a problem with the electric parking brake system.

■

What to do when the indicator blinks

•

Avoid using the parking brake and have your vehicle checked by a
dealer immediately.

1

If the Brake System Indicator (Red) Comes On or Blinks

Have your vehicle repaired immediately.
It is dangerous to drive with low brake fluid. If there
is no resistance from the brake pedal, stop
immediately in a safe place. If necessary, downshift
the gears.

If the brake system indicator (red) and

ABS

 indicator

come on simultaneously, the electronic brake
distribution system is not working. This can result in
vehicle instability under sudden braking.
Have your vehicle inspected by a dealer immediately.

If the brake system indicator (red) blinks at the same
time when the brake system indicator (amber) comes
on, the parking brake may not work.
Avoid using the parking brake and have your vehicle
checked by a dealer immediately.

2

If the Brake System Indicator (Red) Comes
On or Blinks at the Same Time When the
Brake System Indicator (Amber) Comes On



P. 752

(Red)
