Honda CR-V (2022 year). Manual in english

671

Maintenance Schedule

Continued

Main

tenan

*1:Only severe schedule is required in some countries: refer to the local warranty booklet.
*2:Regular use of injector cleaner may be required for models designated for the following countries, it will depend on the quality of the

fuel used. Consult your dealer for details: Reunion, Melilla, Ceuta, Canary Islands

*3:Sensory Method

Adjust the valves during service 120,000 km (75,000 miles) if they are noisy.

*4:It is recommended that you replace the fuel filter if the fuel you are using is suspected to be contaminated with dust, etc. because the

filter may be clogged sooner.

*5:Refer to page 691 for replacement information under driving conditions.

Service at the indicated distance or
time - whichever comes first.

km X 1,000

100

120

140

160

180

200

miles X 1,000

12.5

25.0

37.5

50.0

62.5

75.0

87.5 100.0 112.5 125.0

months

108

120

Replace engine oil

When indicator comes on or 1 year

Replace engine oil filter

When indicator comes on or 2 years

Add genuine injector cleaner agent

Every 10,000 km (6,000 miles) or 1 year

Replace air cleaner element

Every 30,000 km (18,500 miles)

Inspect valve clearance

Every 120,000 km (75,000 miles)

Replace fuel filter

Normal

Every 180,000 km (112,500 miles)

Severe

Every 110,000 km (68,500 miles)

Replace spark plugs

Every 100,000 km (62,500 miles)

Inspect drive belts

•

Replace engine coolant

At 200,000 km (125,000 miles) or 10 years,

thereafter every 100,000 km (62,500 miles) or 5 years

Except European and Ukrainian models

672

Maintenance Schedule

Main

tenan

Service at the indicated distance or
time - whichever comes first.

km X 1,000

100

120

140

160

180

200

miles X 1,000

12.5

25.0

37.5

50.0

62.5

75.0

87.5 100.0 112.5 125.0

months

108

120

Replace transmission fluid

Normal

Every 120,000 km (75,000 miles) or 6 years

Severe

•

CVT

•

Replace rear differential fluid

AWD

•

Inspect front and rear brakes

Every 10,000 km (6,000 miles) or 6 months

Replace brake fluid

Every 3 years

Replace dust and pollen filter

•

Rotate tyres (Check tyre inflation and condition at least once
per month)

Every 10,000 km (6,000 miles)

Visually inspect the following items:

Tie rod ends, steering gearbox, and boots

Every 10,000 km (6,000 miles) or 6 months

Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)

•

All fluid levels and condition of fluid
Exhaust system
Fuel lines and connections

673

Maintenance Schedule

Continued

Main

tenan

*1:Sensory method

Adjust the valves during services 120,000 km if they are noisy.

*2:It is recommended that you replace the fuel filter if the fuel you are using is suspected to be contaminated with dust, etc. because the

filter may be clogged sooner.

*3:Refer to page 691 for replacement information under driving conditions.

Service at the indicated distance or time
- whichever comes first.

km X 1,000

105 120 135 150 165 180 195

months

108 120 132 144 156

Replace engine oil

When indicator comes on or 1 year

Replace engine oil filter

When indicator comes on or 2 years

Replace air cleaner element

Every 30,000 km

Inspect valve clearance

Every 120,000 km

Replace fuel filter

Normal

Every 180,000 km

Severe

Every 105,000 km

Replace spark plugs

Every 120,000 km (Inspect: 15,000 km)

Inspect drive belts

•

Replace engine coolant

At 200,000 km or 10 years, thereafter every 100,000 km or 5 years

Ukrainian models

674

Maintenance Schedule

Main

tenan

Service at the indicated distance or time
- whichever comes first.

km X 1,000

105 120 135 150 165 180 195

months

108 120 132 144 156

Replace transmission fluid

•

CVT

•

Replace rear differential fluid

AWD

•

Inspect front and rear brakes

•

Replace brake fluid

Every 3 years

Replace dust and pollen filter

•

Check lights alignment

•

Test drive (noise, stability, dashboard
operation)

•

Rotate tyres (Check tyre inflation and
condition at least once per month)

Every 15,000 km

Visually inspect the following items:

Tie rod ends, steering gearbox, and boots

•

Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluid
Exhaust system
Fuel lines and connections

675

Maintenance Schedule

Main

tenan

If you drive your vehicle under severe conditions, you must have the following items
served to the maintenance schedule indicated as Severe.

Items

Condition

Engine oil and filter

A, B, C, D and E

Transmission fluid

B and D

Maintenance Schedule

The condition is considered as severe when you drive:
A. Less than 8 km (5 miles), or less than 16 km (10
miles) in freezing temperatures per trip.
B. In extremely hot temperature above 35°C.
C. With extensive idling or long periods of stop-and-
go.
D. With a trailer towing, or loaded roof rack, or in
mountains.
E. On muddy, dusty or de-iced roads.

* Not available on all models

676

Maintenance Schedule

Maintenance Record (On Vehicles without Service Book)

Main

tenan

Maintenance Record (On Vehicles without Service Book)

Have your servicing dealer record all required maintenance below. Keep receipts for all work done on your vehicle.

Km or Month

Date

Sign or Stamp

20,000 km

12,500 Mi. (or 12 Mo.)

40,000 km

25,000 Mi. (or 24 Mo.)

60,000 km

37,500 Mi. (or 36 Mo.)

80,000 km

50,000 Mi. (or 48 Mo.)

100,000 km

62,500 Mi. (or 60 Mo.)

120,000 km

75,000 Mi. (or 72 Mo.)

140,000 km

87,500 Mi. (or 84 Mo.)

160,000 km

100,000 Mi. (or 96 Mo.)

180,000 km

112,500 Mi. (or 108 Mo.)

200,000 km

125,000 Mi. (or 120 Mo.)

Except European and Ukrainian models

677

Maintenance Schedule

Maintenance Record (On Vehicles without Service Book)

Main

tenan

Km or Month

Date

Sign or Stamp

15,000 km

(or 12 Mo.)

30,000 km

(or 24 Mo.)

45,000 km

(or 36 Mo.)

60,000 km

(or 48 Mo.)

75,000 km

(or 60 Mo.)

90,000 km

(or 72 Mo.)

105,000 km

(or 84 Mo.)

120,000 km

(or 96 Mo.)

135,000 km

(or 108 Mo.)

150,000 km

(or 120 Mo.)

165,000 km

(or 132 Mo.)

180,000 km

(or 144 Mo.)

195,000 km

(or 156 Mo.)

Ukrainian models

678

Main

tenan

Maintenance Under the Bonnet

Maintenance Items Under the Bonnet

Brake/Clutch

Fluid

(Black Cap)

Left-hand Drive Type

Engine Coolant Reserve Tank

Washer Fluid
(Blue Cap)

Engine Oil Dipstick
(Orange)

Engine Oil Fill Cap

Battery

Reserve Tank Cap

Brake/Clutch

Fluid

(Black Cap)

Right-hand Drive Type

* Not available on all models

679

Maintenance Under the Bonnet

Opening the Bonnet

Continued

Main

tenan

Opening the Bonnet

Park the vehicle on a level surface, and set
the parking brake.

Pull the bonnet release handle under the
driver’s side lower outside corner of the
dashboard.

The bonnet will pop up slightly.

Push the bonnet latch lever (located under
the front edge of the bonnet to the centre)
to the side and raise the bonnet. Once you
have raised the bonnet slightly, you can
release the lever.

Remove the support rod from the clamp
using the grip. Mount the support rod in
the bonnet.

When closing, remove the support rod, and
stow it in the clamp, then gently lower the
bonnet. Remove your hand at a height of
approximately 30 cm and let the bonnet close.

Opening the Bonnet

NOTICE

Do not open the bonnet when the wiper arms are
raised. The bonnet will strike the wipers, resulting in
possible damage to the bonnet and/or the wipers.

When closing the bonnet, check that the bonnet is
securely latched.

If the bonnet latch lever moves stiffly, or if you can
open the bonnet without lifting the lever, the latch
mechanism should be cleaned and lubricated.

Do not open the bonnet while the Auto Idle Stop
function is activated.

WARNING

The bonnet support rod can become very
hot due to heat from the engine.

To ensure against possible burns, do not
handle the metal section of the rod:
Use the foam grip instead.

Models with Auto Idle Stop

Bonnet Release Handle

Pull

Lever

Support Rod

Grip

Clamp

681

Maintenance Under the Bonnet

Recommended Engine Oil

Continued

Main

tenan

Recommended Engine Oil

Use a genuine engine oil or another commercial engine oil of suitable type and
viscosity (for the ambient temperature) as shown in the image that follows.

Oil is a major contributor to your engine’s performance and longevity. If you drive
the vehicle with insufficient or deteriorated oil, the engine may fail or be damaged.

*1:Formulated to improve fuel economy.

Genuine Engine Oil

Commercial Engine Oil

•

Honda Genuine Engine Oil Type 2.0

•

ACEA C2/C3

Recommended Engine Oil

Engine Oil Additives
You cannot use Engine Oil Additives.

European and Ukrainian models

Ambient Temperature

683

Maintenance Under the Bonnet

Oil Check

Main

tenan

Oil Check

We recommend that you check the engine oil level every time you refuel.
Park the vehicle on level ground.
Wait approximately three minutes after turning the engine off before you check the
oil.

Remove the dipstick (orange).

Wipe the dipstick with a clean cloth or
paper towel.

Insert the dipstick back all the way into its
hole.

Remove the dipstick again, and check the
level. It should be between the upper and
lower marks. Add oil if necessary.

Oil Check

If the oil level is near or below the lower mark, slowly
add oil, being careful not to overfill.

The amount of oil consumed depends on how the
vehicle is driven and the climatic and road conditions
encountered. The rate of oil consumption can be up
to 1 litre per 1,000 km/625 miles.
Consumption is likely to be higher when the engine is
new.

Upper Mark

Lower Mark

684

Maintenance Under the Bonnet

Adding Engine Oil

Main

tenan

Adding Engine Oil

Unscrew and remove the engine oil fill cap.

Add oil slowly.

Reinstall the engine oil fill cap, and tighten
it securely.

Wait for three minutes and recheck the
engine oil dipstick.

Adding Engine Oil

NOTICE

Do not fill the engine oil above the upper mark.
Overfilling the engine oil may result in leaks and
engine damage.

If any oil spills, wipe it away immediately. Spilled oil
may damage the engine compartment components.

Engine Oil
Fill Cap

685

Maintenance Under the Bonnet

Engine Coolant

Continued

Main

tenan

Engine Coolant

This coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.

We recommend you check the engine coolant level every time you refuel. Check the
reserve tank. Add the engine coolant accordingly.

1. Make sure the engine and radiator are

cool.

Check the amount of coolant in the reserve
tank.

If the coolant level is below the

MIN

mark, add the specified coolant until it
reaches the

MAX

mark.

Inspect the cooling system for leaks.

Specified coolant: Honda All Season Antifreeze/Coolant Type 2

■

Checking the Coolant

Engine Coolant

NOTICE

If temperatures consistently below -30°C are
expected, the coolant mixture should be changed to
a higher concentration. Consult your Honda dealer
for details about a suitable coolant mixture.

If Honda antifreeze/coolant is not available, you may
use another major brand of non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminium engines.
Continued use of any non-Honda coolant can result
in corrosion, causing the cooling system to
malfunction or fail. Have the cooling system flushed
and refilled with Honda antifreeze/coolant as soon as
possible.

Do not add rust inhibitors or other additives to your
vehicle’s cooling system. They may not be compatible
with the coolant or with the engine components.

WARNING

Removing the reserve tank cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.

Always let the engine and radiator cool
down before removing the reserve tank
cap.

Reserve
Tank

MAX

MIN

Maintenance Under the Bonnet

Engine Coolant

686

Main

tenan

1. Make sure the engine and radiator are

cool.

Turn the reserve tank cap 1/8 turn anti-
clockwise and relieve any pressure in the
cooling system.

Push down and turn the reserve tank cap
anti-clockwise to remove it.

Pour coolant into the reserve tank until it
reaches the

MAX

mark.

Put the reserve tank cap back on, and
tighten it fully.

■

Adding the Coolant

Adding the Coolant

NOTICE

Pour the fluid slowly and carefully so you do not spill
any. Clean up any spills immediately; they can
damage components in the engine compartment.

Reserve Tank Cap

Honda CR-V (2022 year). Manual in english - page 42
