Honda Insight (2019 year). Instruction

287

Audio System Basic Operation

Voice Control Operation

Continued

Features

Voice Control Operation

Your vehicle has a voice control system that allows hands-free operation.
The voice control system uses the

(talk) and

(back) buttons on the steering

wheel and a microphone near the map lights on the ceiling.

To achieve optimum voice recognition when using the voice control system:
• Make sure the correct screen is displayed for the voice command that you are

using.
The system recognizes only certain commands.
Available voice commands.

2 Voice Portal Screen P. 288

• Close the windows and moonroof

• Adjust the dashboard and side vents so air does not blow onto the microphone

on the ceiling.

• Speak clearly in a clear, natural speaking voice without pausing between words.
• Reduce any background noise if possible. The system may misinterpret your

command if more than one person is speaking at the same time.

■

Voice Recognition

Voice Control Operation

When you press the

button, a helpful prompt asks

what you would like to do. Press and release the

button again to bypass this prompt and give a
command.

* Not available on all models

288

Audio System Basic Operation

Voice Control Operation

Features

When the

(talk) button is pressed,

available voice commands appear on the
screen.
For a complete list of commands, say “Voice
Help” after the beep.

The system only recognizes the commands
on the following pages, at certain screens.
Free form voice commands are not
recognized.

■

Voice Portal Screen

This can be only used when the phone is
connected. When the system recognizes the
Phone command, the screen will change
the dedicated screen for the voice
recognition of the phone.

■

Phone Commands

• Phone
• Call <Your Contact Name>
• Call <Phone Number>
The system recognize an only contact name
in the stored phonebook of your phone. If
full name is registered in first name field,
the system will recognize the first name and
last name as one contact name.

Phone commands are not available if using
Apple CarPlay.

When the system recognizes the Audio
command, the screen will change the
dedicated screen for the voice recognition
of the audio.

■

Phone Commands

■

Audio Commands

■

FM Commands

• FM
• Tune to <87.7-107.9> FM

■

AM Commands

• AM
• Tune to <530-1710> AM

■

Sirius XM Commands

• Sirius XM
• Channel <1-999>
• Channel <station name>

■

USB Commands

• USB
• Play genre <Genre name>
• Play Artist <Artist name>
• Play Album <Album name>
• Play Playlist <Playlist name>
• Play Song <Song name>
• Play Music
• List Genre <Genre name>
• List Artist <Artist name>
• List Album <Album name>
• List Playlist <Playlist name>

* Not available on all models

289

Audio System Basic Operation

Voice Control Operation

Features

The system accepts navigation command on
the dedicated screen for the voice
recognition of the navigation.

2 Refer to the Navigation System Manual

• Voice Help
• Cancel
• Back
Voice Help are readout voice guidance for
Help on current screen.

*1: Models with navigation system

■

Navigation Commands

■

Standard Commands

290

Audio System Basic Operation

Playing AM/FM Radio

Features

Playing AM/FM Radio

(Back) Button

Press to go back to the previous
display.

Buttons

Press

to search up and

down the selected band for a
station with a strong signal.

VOL/

AUDIO (Volume/Power) Knob

Push to turn the audio system on and off.
Turn to adjust the volume.

Tune Icon
Select to use the on-screen
keyboard for entering the
radio frequency directly.

Audio/Information Screen

Scan Icon
Select to scan each station
with a strong signal.

Preset Icons
Tune the radio frequency for preset memory.
Select and hold the preset icon to store that
station. Select

to display beyond preset 5.

Settings Icon
Select whether to tune to HD
Radio

TM*

automatically.

Seek Icon
Select

to search the selected band

up or down for a station with a strong signal.

Sound Icon
Select to display the sound
settings.

HD Radio Icon

Select to displays the
subchannel list screen.

Station List Icon
Select to displays the station
list screen.

* Not available on all models

Continued

291

Audio System Basic Operation

Playing AM/FM Radio

Features

To store a station:
1. Tune to the selected station.
2. Select and hold the preset number for the station you want to store.

Lists the strongest stations on the selected band.
1. Select Station List to display a list.
2. Select the station.

■

Manual update

Updates your available station list at any time.
1. Select Station List to display a list.
2. Select Refresh.

■

Preset Memory

■

Station List

Preset Memory

The ST indicator appears on the display indicating
stereo FM broadcasts.
Stereo reproduction in AM is not available.

Switching the Audio Mode
Roll up or down to select Audio on the left selector
wheel or select the audio source icon on the screen.

2 Audio Remote Controls P. 237

You can store 12 AM/FM stations into preset
memory.

HD Radio Technology manufactured under license
from iBiquity Digital Corporation. U.S. and Foreign
Patents. HD Radio

and the HD, HD Radio, and

“Arc” logos are proprietary trademarks of iBiquity
Digital Corp.

Models with HD Radio

feature

Audio System Basic Operation

Playing AM/FM Radio

292

Features

Samples each of the strongest stations on the selected band for 10 seconds. To turn
off scan, select Stop or press the

button.

Provides text data information related to your selected RDS-capable FM station.

■

To find an RDS station from Station List

1. Select Station List to display a list while listening to an FM station.
2. Select the station.

■

Manual update

Updates your available station list at any time.
1. Select Station List to display a list while listening to an FM station.
2. Select Refresh.

■

Scan

Samples each of the strongest stations on the selected band for 10 seconds. To turn
off scan, select Stop or press the

button.

■

Scan

■

Radio Data System (RDS)

Radio Data System (RDS)

When you select an RDS-capable FM station, the RDS
automatically turns on, and the frequency display
changes to the station name. However, when the
signals of that station become weak, the display
changes from the station name to the frequency.

293

Audio System Basic Operation

Playing AM/FM Radio

Features

1. Select Tune.
2. Enter the desired radio frequency using the

on-screen keyboard.

3. Select Enter to tune into the frequency.

Displays the subchannel list when an HD Radio

station is selected while listening to

an FM station.
1. Select HD Radio.
2. Select the channel number.

Change the AM/FM settings.
1. Select Settings.
2. Select an option.

• HD Radio: Automatically choose a digital or an analog channel, or listen to

analog only.

• Artwork: Turns the artwork display on and off.

■

Radio Frequency Manual Tune Screen

Radio Frequency Manual Tune Screen

You can tune the range of FM frequency between
87.7 to 107.9MHz and range of AM frequency
between 530 to 1710kHz.

icons:

Select

to tune the radio frequency.

On-screen Keyboard

■

HD Subchannel

■

AM/FM Settings

Models with HD Radio

feature

294

Audio System Basic Operation

Playing SiriusXM® Radio

Features

Playing SiriusXM® Radio

(Back) Button

Press to go back to the previous
display.

Channel Icons
Select

to the previous or next channel.

Select and hold to rapidly skip 10 channels at a time.

VOL/

AUDIO (Volume/Power) Knob

Push to turn the audio system on and off.
Turn to adjust the volume.

Category Icons
Select

to display

and select a SiriusXM®
Radio category.

Audio/Information Screen

Preset Icons
Tune the radio frequency for
preset memory. Select and hold
the preset icon to store that
channel. Select

to display

beyond preset 5.

Album Art

Settings Icon
Select settings to display and
customize siriusXM settings.

Buttons

Select

to the previous

or next channel.
Select and hold to rapidly skip 10
channels at a time.

Sound Icon
Select to display the sound
settings.

Channel List Icon
Select to display the channel list.
Select Keypad to use the on-
screen keyboard for entering the
channel number directly.

* Not available on all models

Continued

295

Audio System Basic Operation

Playing SiriusXM® Radio

Features

1. Select Settings.
2. Select Tune Mode.
3. Select Channel or Category.

■

To Change the Tune Mode

Playing SiriusXM® Radio

In the channel mode, all available channels are
selectable. In the category mode, you can select a
channel within a category (Jazz, Rock, Classical, etc.).

There may be instances when SiriusXM® Radio does
not broadcast all the data fields (artist name, title).
This does not indicate a problem with your audio
system.

SiriusXM® Radio stations load in ascending order,
which can take about a minute. Once they have
loaded you will be able to scroll up or down to make
your selections.

Switching the Audio Mode
Roll up or down to select Audio on the left selector
wheel or select the audio source icon on the screen.

2 Audio Remote Controls P. 237

Tune Start:
When you change to a preset channel, a song being
played on that channel restarts from the beginning
with this function. This can be turned on or off by the
following procedure.
1. Select Settings.
2. Select Tune Start.
3. Select ON or OFF.

To change a category, select Category icons, or
select More and then select Category List.

* Not available on all models

Audio System Basic Operation

Playing SiriusXM® Radio

296

Features

1. Select Channel List.
2. Select Keypad.
3. Enter the desired channel number using the

on-screen keyboard.

4. Select Enter to tune into the channel.

To store a channel:
1. Tune to the selected channel.
2. Select and hold the preset number for the station you want to store.

■

Multi-channel preset (for music channels only)

You can store up to 10 of your preferred music channels per preset.

1. Tune a station.
2. Select and hold the preset number you

want to add a music channel.

3. Select Add to TuneMix or Create

TuneMix.

A message appears if there are no
available presets.

■

SiriusXM® Channel Manual Tune Screen

SiriusXM® Channel Manual Tune Screen

icons:

Select

to the previous or next channel.

Select and hold to rapidly skip 10 channels at a time.

On-screen Keyboard

■

Preset Memory

Preset Memory

You can store 12 SiriusXM® channels into the preset
memory.

Multi-channel preset (for music channels only)

TuneMix

is registered trademarks of SiriusXM®

Radio, Inc.

TuneMix:
The multi-channel preset function can be turned on
or off by the following procedure.
1. Select Settings.
2. Select TuneMix.
3. Select ON or OFF.

When you want to replace the channel, select
Replace preset.
If you want to delete a channel, select Edit TuneMix,
and then select the channel you want to delete.

Continued

297

Audio System Basic Operation

Playing SiriusXM® Radio

Features

Suggested channel listing received from SiriusXM® can be displayed and selected.
1. Select Category List.
2. Select Featured Favorites.

■

Listening to Featured Channels

Listening to Featured Channels

Up to ten featured channels by SiriusXM® can be
displayed.

Featured channel lists are at the top of the channel
list.

To switch the sorting method, select Number or
Name on the upper right of the screen.

Select Keypad to use the on-screen keyboard for
entering the channel number directly.

Audio System Basic Operation

Playing SiriusXM® Radio

298

Features

The system can record up to the last 60 minutes broadcast of your currently tuned
channel as well as the last 30 minutes broadcast of preset channels, starting from
the moment you turn the vehicle on. If you tuned to preset channel, the system
records up to 60 minutes of a broadcast instead of up to 30 minutes. You can
rewind and replay the last 30 or 60 minutes of a broadcast.

Move the position you want to replay by selecting

To play or pause on playback mode, select the play/pause icon.

■

Returning to real-time broadcast

Select and hold

■

Replay Function

Replay Function

The system starts storing broadcast in memory when
the power mode is turned ON. You can go back to
the program from that point.

You can no longer replay any program once the
power mode is turned off as it erases memory.
You can check how long the program has been
stored in memory from the audio/information screen.

After 30 or 60 minutes of recording the system will
automatically start deleting the oldest data.

(A): Shows how much time the replayed segment is
behind the real-time broadcast
(B): Replayed segment
(C): Length stored in memory
(D): Play/Pause icon

Audio/Information Screen

(C)

(B)

(A)

(D)

Continued

299

Audio System Basic Operation

Playing SiriusXM® Radio

Features

While listening to other channel, you can receive sports alerts such as scores from
your favorite teams.

■

To set up a favorite team

1. Select Settings.
2. Select Sports Notifications Setup.
3. Select Favorite Teams.
4. Select + Add Favorite Team.
5. Select a team.

■

To set up an alert message

1. Select Settings.
2. Select Sports Notifications Setup.
3. Select Notifications.
4. Select Game Notifications or SportsFlash Game Play Notifications.
5. Select Notifications.
6. Select ON.
7. Select a favorite team.

■

Live Sports Alert

Live Sports Alert

The Pop-up appears and notifies you of a sports alert
function.

To set up a favorite team

Sports alerts cut in only when SiriusXM® mode is on.

Audio System Basic Operation

Playing SiriusXM® Radio

300

Features

You can receive traffic and weather information.
1. Select Settings.
2. Select Traffic & Weather Now Setup.
3. Select Selected City.
4. Select the region.

■

Traffic and Weather Information

Traffic and Weather Information

When traffic and weather information is received, a
notification is displayed in the header area.

2 Status Area P. 276

Traffic & Weather Now are registered trademarks of
SiriusXM® Radio, Inc.

Continued

301

Audio System Basic Operation

Playing SiriusXM® Radio

Features

You can view a channel schedule or receive a alert when your favorite program is
about to start.

■

To view a channel schedule

1. Select More.
2. Select Channel Schedule.

■

To set up an alert message

1. Select More.
2. Select Channel Schedule.
3. Select a program.
4. Select Set Program Alert.
5. Select Just Once or Everytime.

■

Channel Schedule

Channel Schedule

Select Keypad to use the on-screen keyboard for
entering the channel number directly.

To set up an alert message

The Pop-up appears and notifies you of an alert
function.

Selecting Just Once disables the alert feature next
time you turn the power mode to ON.

If you want to delete the alert, select Remove Alert.

To enable an alert message, change settings for the
alert function.

2 To enable the alert function P. 302

302

Audio System Basic Operation

Playing SiriusXM® Radio

Features

You can change settings for the alert function.

■

To enable the alert function

1. Select Settings.
2. Select Manage Program Alerts.
3. Select Notifications.
4. Select ON or OFF.

■

To remove an alert

1. Select Settings.
2. Select Manage Program Alerts.
3. Select Alerts Set.
4. Select

on the alert you want to delete.

A confirmation message appears on the
screen. Select Yes.

■

Manage Program Alert

Honda Insight (2019 year). Instruction - part 19
