Honda Insight (2019 year). Instruction - part 18

Continued

271

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

To change to a next screen

Selecting

 or

, or swiping the screen left or right changes to the next screen.

■

Home Screen

1

Home Screen

The home screen has 2 or 3 pages. You can add up
to 7 pages.

Press the

 button to go directly back to the first

page of the home screen from any page.

Swipe

 Icon

>

 Icon

<

Current page position

<

>

uu

Audio System Basic Operation

u

Audio/Information Screen

272

Features

■

To add app icons on the home screen

App icons can be added on the home screen.

1. Press the

 button.

2. Select and hold the home screen.
3. Select Add.
4. Drag and drop the icon to where you want

it to be.

5. Select Done.

u

The screen will return to the home
screen.

1

To add app icons on the home screen

You can add app icons by the following procedure.
1. Press the

 button.

2. Select All Apps.
3. Select Customize.
4. Select Add.
5. Drag and drop the icon to where you want it to

be.

6. Select Done.

u

The screen will return to the home screen.

Pre-installed apps may not start up normally. If this
occurs, you need to reset the system.

2 Defaulting All the Settings P. 385

If you perform Factory Data Reset, it may reset all
the settings to their factory default.

2 Defaulting All the Settings P. 385

In case those apps still do not startup normally even
after Factory Data Reset, contact your dealer.

There is a possibility that a browser is shut down in
the situation of the use. In that situation, the screen
will return to before the browser startup.

Continued

273

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

To move icons on the home screen

You can change location on the home screen.

1. Select and hold an icon.

u

The screen switches to the customization
screen.

2. Drag and drop the icon to where you want

it to be.

3. Select Done.

u

The screen will return to the home
screen.

1

To move icons on the home screen

Select Tips to show tips. To hide them, select it again.

Select and hold.

Drag and drop.

uu

Audio System Basic Operation

u

Audio/Information Screen

274

Features

■

To remove icons on the home screen

You can delete the icons on the home screen.

1. Select and hold an icon.

u

The screen switches to the customization
screen.

2. Drag and drop the icon you want to remove

to the Hide icon.

u

The icon is removed from the home
screen.

3. Select Done.

u

The screen will return to the home
screen.

1

To remove icons on the home screen

Apps will not be deleted by deleting the icon on the
home screen.

Select Tips to show tips. To hide them, select it again.

Select and hold.

Drag and drop to
Hide icon.

Continued

275

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

■

To shortcut icons on the home screen

You can store up to three icons on the upper left of the home screen.

1. Select and hold an icon.

u

The screen switches to the customization
screen.

2. Drag and drop the icon you want to store to

the upper left of the home screen.

u

The icon is shortcut.

3. Select Done.

u

The screen will return to the home
screen.

1

To shortcut icons on the home screen

Select Tips to show tips. To hide them, select it again.

Select and hold.

Drag and
drop to
preset icon.

Shortcut
Icons

276

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

1. Select the system status icon.

u

The status area appears.

2. Select an item to see the details.
3. Press the

 button or the system status

icon to close the area.

■

Status Area

System
Status Icon

Status Area

277

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

You can edit, show, or hide the meter contents on the driver information interface.

1. Press the

 button.

2. Select Settings.
3. Select System.
4. Select Config. of Instrument Panel.
5. Select and hold the content you wish to

show or hide.

u

The checked items are displayed on the
driver information interface.

■

Editing order

To change the order of the contents on the driver information interface, first select:

1. Press the

 button.

2. Select Settings.
3. Select System.
4. Select Config. of Instrument Panel.
5. Select Reorder.
6. Select and hold the contents you want to

move.

7. Drag and drop the contents to where you

want it to be.

8. Select Done.

■

Customizing the Meter

1

Customizing the Meter

You can store up to three customized configurations.
To select or customize a configuration, select Select
configuration.
When you select Select configuration during
customization, the settings you changed will be
saved.

278

uu

Audio System Basic Operation

u

System Updates

Features

System Updates

The audio system’s firmware can be updated with a Wi-Fi connection, or with a USB
device.

■

Wireless connection mode setup

1. Press the

 button.

2. Select System Updates.
3. Select Settings.
4. Select Connection Setup.

5. Select Change Mode.
6. Select Network, then Confirm.

u

The display returns to the network list.

7. Select an access point from the network list,

then Save.

u

If the audio system requires a password,
enter a password.

■

How to Update Wirelessly

1

Wireless connection mode setup

If your vehicle has a telematics control unit (TCU), you
do not need the wireless connection mode setup.

Continued

279

uu

Audio System Basic Operation

u

System Updates

Features

■

How to update

When the audio system update is available, the notification is shown on the audio/
information screen. Use the following procedure to update the system.

1. Press the

 button.

2. Select System Updates.

3. Select via Wireless.

u

If a notification is displayed on the
screen, the screen of step 5 will be
displayed.

4. Select Download Now.

u

A notification appears on the screen.

1

How to update

You can update the system via Wi-Fi, but cannot use
the captive portal that require login or agreement the
terms of use on the browser.

Your download will be canceled if:

•

Your Wi-Fi connection is severed.

•

You turn off the power system when the 12-volt
battery is low on power.

Your download will recommence the next time a Wi-
Fi connection is established.

Notification

uu

Audio System Basic Operation

u

System Updates

280

Features

5. Select Install Now or Install while

Vehicle OFF.

u

A notification appears on the screen if
the update is successful.

1

How to update

For the 12-volt battery protection, Install while
Vehicle OFF cannot be selected when the battery is
low on power. If you want to install the updated
data, recharge the battery or select Install Now.

281

uu

Audio System Basic Operation

u

System Updates

Continued

Features

■

Automatic download settings

Use the following procedure to change to the automatic download setting.

1. Press the

 button.

2. Select System Updates.
3. Select Settings.
4. Select Auto Download.
5. Select the access point, then Yes.

■

View a version and update status

Use the following procedure to confirm the version and update status.
1. Press the

 button.

2. Select System Updates.
3. Select Settings.
4. Select Version Status.

uu

Audio System Basic Operation

u

System Updates

282

Features

■

Download the update files from the server

1. Press the

 button.

2. Select System Updates.
3. Select via USB.

u

A notification appears on the screen.

4. Connect a USB device into the USB port.

u

The inventory data is copied into the USB
device.

2 USB Port(s) P. 235

5. Remove the USB device from the USB port.
6. Connect the USB device into your

computer, and then download the update
files.

u

Follow the link to download the required
software update files. Refer to
https://usb.honda.com for instructions.

■

How to Update with a USB Device

1

How to Update with a USB Device

A USB device with a minimum of 8 GB of free space
or more is recommended.

Be sure to delete any previous inventory or update
files from the USB before starting the USB update
process.

283

uu

Audio System Basic Operation

u

System Updates

Features

■

Update the audio system

1. Press the

 button.

2. Select System Updates.
3. Select via USB.

u

A notification appears on the screen.

4. Connect the USB device with the update

files into the USB port.

u

A notification appears on the screen.

2 USB Port(s) P. 235

5. Select Install Now.

u

A notification appears on the screen if
the update is successful.

284

uu

Audio System Basic Operation

u

Adjusting the Sound

Features

Adjusting the Sound

1. Press the

 button.

2. Select an audio source icon.
3. Select Sound.
4. Select the setting you want.
5. Select Save.

Select an item from the following choices:
• Bass / Treble: Treble, Midrange, Bass
• Balance / Fader: Balance, Fader
• DTS Neural Surround

*

: DTS Neural

Surround

TM

• Speed Volume Compensation: Speed

Volume Compensation (SVC)

1

Adjusting the Sound

The SVC adjusts the volume level based on the
vehicle speed. As you go faster, audio volume
increases. As you slow down, audio volume
decreases.

You can also adjust the sound the following
procedure.
1. Press the

 button.

2. Select Settings.
3. Select Sound.

To reset each setting for Bass / Treble, Balance /
Fader, DTS Neural Surround

*

 and Speed Volume

Compensation select Default.

* Not available on all models

285

uu

Audio System Basic Operation

u

Display Setup

Continued

Features

Display Setup

You can change the brightness of the audio/information screen.

1. Press the

 button.

2. Select Settings.
3. Select Display.
4. Select Day Mode or Night Mode.
5. Select the setting you want.
6. Select Save.

■

Changing the Screen Brightness

1

Changing the Screen Brightness

You can change the Contrast and Black Level
settings in the same manner.

To reset the settings, select Default.

286

uu

Audio System Basic Operation

u

Display Setup

Features

Select the current source icon, then select an icon on the source list.

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

■

Selecting an Audio Source

■

Limitations for Manual Operation

*

Select the source icon

Source Select Screen

Source List Icons

* Not available on all models
