Honda Insight (2019 year). Instruction - part 17

255

Audio System Basic Operation

Playing a USB Flash Drive

Continued

Features

Playing a USB Flash Drive

Your audio system reads and plays sound files on a USB flash drive in either MP3,
WMA, AAC

or WAV format.

Connect your USB flash drive to the USB port, then press the MEDIA button.

2 USB Port(s) P. 235

*1:Only AAC format files recorded with iTunes are playable on this unit.

USB Indicator
Appears when a USB flash drive is connected.

MEDIA Button
Press to select USB flash drive
(if connected).

(Back) Button

Press to go back to the
previous display.

(Seek/Skip) Buttons

Press

to change files.

Press and hold to move rapidly within a file.

VOL/

(Volume/Power) Knob

Press to turn the audio system
on and off.
Turn to adjust the volume.

Selector Knob
Turn to change files.
Press, and then turn to select
an item. After that, press again
to make your selection.

MENU/CLOCK Button
Press to display the menu
items.

Audio/Information Screen

Play Mode Buttons (1-6)
Press to select a play mode.

Audio System Basic Operation

Playing a USB Flash Drive

256

Features

1. Press

to display a folder list.

2. Rotate

to select a folder.

3. Press

to display a list of files in that

folder.

4. Rotate

to select a file, then press

■

How to Select a File from a Folder with the Selector Knob

Playing a USB Flash Drive

Use the recommended USB flash drives.

2 General Information on the Audio System

P. 337

Files in WMA format protected by digital rights
management (DRM) cannot be played.
The audio system displays Unplayable File, and then
skips to the next file.

If there is a problem, you may see an error message
on the audio/information screen.

2 iPod/USB Flash Drive P. 332

Track
Selection

Folder
Selection

257

Audio System Basic Operation

Playing a USB Flash Drive

Features

You can select repeat, random, and scan modes when playing a file.

Available mode icons appear above the play
mode buttons.
Press the button corresponding to the mode
you want to select.

■

To turn off a play mode

Press the selected button.

■

How to Select a Play Mode

How to Select a Play Mode

Play Mode Menu Items
Repeat

Repeat One Folder: Repeats all files in the

current folder.

Repeat One Track: Repeats the current file.

Random

Random in Folder: Plays all files in the

current folder in random order.

Random All: Plays all files in random order.

Scan

Scan Folders: Provides 10-second sampling

of the first file in each of the main folders.

Scan Tracks: Provides 10-second sampling

of all files in the current folder.

You can also select a play mode by pressing the
MENU/CLOCK button.
Rotate

to select Play Mode, then press

Rotate

to select a mode, then press

To turn it off, rotate

to select Normal Play, then

press .

Play Mode Buttons

258

Audio System Basic Operation

Playing Bluetooth® Audio

Features

Playing Bluetooth® Audio

Your audio system allows you to listen to music from your Bluetooth-compatible
phone.
This function is available when the phone is paired and connected to the vehicle’s
Bluetooth® HandsFreeLink® (HFL) system.

2 Phone Setup P. 395

Playing Bluetooth® Audio

Not all Bluetooth-enabled phones with streaming
audio capabilities are compatible with the system.
For a list of compatible phones:

•

U.S.: Visit automobiles.honda.com/handsfreelink/,
or call 1-888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

In some states, it may be illegal to perform some data
device functions while driving.

Only one phone can be used with HFL at a time.
When there are more than two paired phones in the
vehicle, the first paired phone the system finds is
automatically connected.

If more than one phone is paired to the HFL system,
there will be a delay before the system begins to play.

In some cases, the name of the artist, album, or track
may not appear correctly.

Some functions may not be available on some
devices.

MEDIA Button
Press to select
Bluetooth Audio
mode (if
connected)

VOL/

(Volume/

Power) Knob
Press to turn the
audio system on
and off.
Turn to adjust
the volume.

MENU/CLOCK
Button
Press to display
the menu items.

Audio/Information Screen

Bluetooth Indicator
Appears when your phone
is connected to HFL.

(Seek/

Skip) Buttons

Press

to change files.

Play Button (Preset 1)
Press to resume a file.

Pause Button (Preset 2)
Press to pause a file.

Selector Knob
Turn to change groups.
Press, and then turn to select
an item. After that, press again
to make your selection.

(Back) Button

Press to go back to the previous display.

Continued

259

Audio System Basic Operation

Playing Bluetooth® Audio

Features

1. Make sure that your phone is paired and

connected to HFL.

2. Press the MEDIA button until the

Bluetooth® Audio mode is selected.

If the phone is not recognized, another HFL-
compatible phone, which is not compatible
for Bluetooth® Audio, may already be
connected.

■

To pause or resume a file

Press the play button (preset 1) or pause button (preset 2) to select a mode.

■

To Play Bluetooth® Audio Files

To Play Bluetooth® Audio Files

To play the audio files, you may need to operate your
phone. If so, follow the phone maker's operating
instructions.

The pause function may not be available on some
phones.

If any audio device is connected to the USB port, you
may need to press the MEDIA button repeatedly to
select the Bluetooth® Audio system.

Switching to another mode pauses the music playing
from your phone.

Play Button (Preset 1)

Pause Button (Preset 2)

MEDIA Button

Audio System Basic Operation

Playing Bluetooth® Audio

260

Features

1. Press

to display the music search list.

2. Rotate

to select a category.

3. Press

to display a list of items in the

category.

4. Rotate

to select an item, then press

Press

and rotate

repeatedly until a

desired item you want to listen is
displayed.

■

How to Select a Song from the Music Search List with the
Selector Knob

How to Select a Song from the Music Search List with the Selector
Knob

Depending on the Bluetooth® device you connect,
some or all of the categories may not be displayed.

Item
Selection

Category
Selection

261

Audio System Basic Operation

Siri® Eyes Free

Features

Siri® Eyes Free

You can talk to Siri using the

(Talk) button on the steering wheel when your

iPhone is paired to the Bluetooth® HandsFreeLink® (HFL) system.

2 Phone Setup P. 395

■

Using Siri Eyes Free

Siri® Eyes Free

Siri is a trademark of Apple Inc.

Check Apple Inc. website for features available for
Siri.

We recommend against using Siri other than in Siri
Eyes Free while operating a vehicle.

Using Siri Eyes Free

Some commands work only on specific phone
features or apps.

This audio system cannot operate the audio functions
by using Siri Eyes Free.

(Talk) Button

Press and hold until the display changes as shown.

(Hang-up/back) Button

Press to deactivate Siri Eyes Free.

While in Siri Eyes Free:
The display remains the same.
No feedback or commands
appear.

Appears
when Siri is
activated in
Siri Eyes Free

262

Features

Audio System Basic Operation

To use the audio system function, the power mode must be in ACCESSORY or ON.

(Home) Button: Press to go to the home

screen.

2 Switching the Display P. 131

(Back) Button: Press to go back to the

previous display when it is displayed.

(Seek/Skip) Buttons: Press to

change station, channel, song or file.

(Day/Night) Button: Press to change

the audio/information screen brightness.
Press

once and select

to make

an adjustment.

Each time you press

, the mode

switches among the daytime mode,
nighttime mode and off mode.

Models with Display Audio

(Day/Night) Button

(Home) Button

(Back) Button

(Seek/Skip)

Buttons

263

Audio System Basic Operation

Audio/Information Screen

Continued

Features

Audio/Information Screen

Displays the audio status and wallpaper. From this display, you can go to various
setup options.

■

Using the audio/information screen

Press the

button to go to the home screen.

Select the following icons on the home screen or after selecting

All Apps.

■

Phone

Displays the HFL information.

2 Bluetooth® HandsFreeLink® P. 414

■

Switching the Display

Audio/Information Screen

Touchscreen Operation

•

Use simple gestures - including touching, swiping,
and scrolling - to operate certain audio functions.

•

Some items may be grayed out during driving to
reduce the potential for distraction.

•

You can select them when the vehicle is stopped or
use voice commands.

•

Wearing gloves may limit or prevent touchscreen
response.

You can change the touchscreen sensitivity setting.

2 Customized Features P. 366

Home Screen

Models without
navigation system

Models with
navigation system

(Home) Button

All Apps

264

Audio System Basic Operation

Audio/Information Screen

Features

■

Trip Computer

Displays the trip computer information.
• Current Drive tab: Displays the current trip information.
• Trip A/Trip B tab: Displays information for the current and three previous drives.

The information is stored every time you reset Trip A/B.
To reset the Trip A/B, select Settings, then select Delete Trip History.
To change the setting of how to reset Trip A/B, select Trip A Reset Method or
Trip B Reset Method.

■

Clock

Displays the clock.

■

System Updates

Updates the software version of the audio system.

2 System Updates P. 278

■

FM/AM/Sirius XM

/USB1/USB2/Bluetooth Audio/Smartphone Connection

Displays the each audio information.

■

Settings

Enters the customizing menu screen.

2 Customized Features P. 366

■

Navigation

Displays the navigation screen.

2 Refer to the Navigation System Manual

* Not available on all models

265

Audio System Basic Operation

Audio/Information Screen

Continued

Features

■

HondaLink®

Displays the HondaLink® screen.

2 HondaLink® P. 313

■

Apple CarPlay/Android Auto

Displays the Apple CarPlay or Android Auto screen.

2 Apple CarPlay

P. 325

2 Android Auto

P. 328

■

Messages

Displays the text message screen.

2 Bluetooth® HandsFreeLink® P. 414

■

AT&T Hotspot

Displays the AT&T Hotspot screen.

■

Compass

Displays the compass screen.

* Not available on all models

Audio System Basic Operation

Audio/Information Screen

266

Features

■

Power Flow

Displays the motor and engine power flow, average fuel economy, and range.

Audio/Information Screen

The power flow monitor is also displayed on the
driver information interface.

2 Power Flow Monitor P. 152

While the vehicle is stationary with the engine
running, the following may appear on the audio/
information screen.

The auto
engine stop
activates.
(Engine OFF)

The auto
engine stop
does not
activate.
(Engine ON)

Engine ON

Engine OFF

Engine

Average Fuel Economy
(Current Drive)

High Voltage Battery

Power Flow

Driving Range

Continued

267

Audio System Basic Operation

Audio/Information Screen

Features

Displays the power flow, indicating what is supplying power to the vehicle and/or
charging the battery.

The indicator for the power transmission appears in blue, and for the battery
charging operation, in green.

Display

Color of indicators

Vehicle’s Condition

Blue

Power is being supplied by
the High Voltage battery
and the engine-driven
generator.

Blue

Power is being supplied by
the High Voltage battery.

Blue

Power is being supplied by
the engine-driven
generator.

Audio/Information Screen

While the engine provides propulsion directly to the
wheels, the

icon appears in the power flow

monitor on the screen.

268

Audio System Basic Operation

Audio/Information Screen

Features

Display

Color of indicators

Vehicle’s Condition

Blue and Green

Power is being supplied
directly by the engine and
the High Voltage battery is
being charged by the
engine-driven generator.

Green

The High Voltage battery is
being charged through
regenerative braking.

Green

The High Voltage battery is
being charged by the
engine-driven generator.

Continued

269

Audio System Basic Operation

Audio/Information Screen

Features

You can change, store, and delete the wallpaper on the audio/information screen.

■

Import wallpaper

1. Connect the USB flash drive to the USB

port.

2 USB Port(s) P. 235

2. Select Clock.
3. Select Settings.
4. Select Clock Faces.
5. Select Add New Wallpaper.

The Searching... screen is displayed.

6. Import a desired picture.

Multiple pictures can be imported at the
same time.

7. Select Start Import.

The display will return to the Clock Faces
screen.

■

Wallpaper Setup

Wallpaper Setup

The wallpaper you set up on Clock Faces cannot be
displayed on the driver information interface.

•

When importing wallpaper files, the image must be
in the USB flash drive’s root directory.
Images in a folder cannot be imported.

•

The file name must be fewer than 64 characters.

•

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

•

The individual file size limit is less than 2 MB.

•

If the USB flash drive does not have any pictures,
the No files detected message appears.

•

Up to five pictures can be imported.

•

The maximum image size is 1,920 × 936 pixels. If
the image size is less the image is displayed in the
middle of the screen with the extra area appearing
in black.

Audio System Basic Operation

Audio/Information Screen

270

Features

■

Select wallpaper

1. Select Clock.
2. Select Settings.
3. Select Clock Faces.
4. Select a desired wallpaper.
5. Select Set.

The display will return to the Clock Faces screen.

■

To view wallpaper once it is set

1. Press the

button.

2. Select Clock.

■

Delete wallpaper

1. Select Clock.
2. Select Settings.
3. Select Clock Faces.
4. Select a desired wallpaper.
5. Select Delete.
6. Select Yes.

The display will return to the Clock Faces screen.

Wallpaper Setup

You cannot delete the initial imported wallpapers.

Content .. 15 16 17 18 ..
